Thermo Scientific TriPlus 300 User manual

Thermo Scientific
TriPlus 300 Headspace
Sampling System
Preinstallation Requirements Guide
P/N 317 09672 Revision C December 2015

© 2015 Thermo Fisher Scientific Inc. All rights reserved.
TriPlus 300 Headspace, TRACE 1300, TRACE 1310, ISQ Series, TSQ 8000 Series, ITQ, and DSQ II are
trademarks of Thermo Fisher Scientific Inc., and its subsidiaries.
Published by Thermo Fisher Scientific S.p.A., Strada Rivoltana 20090 Rodano-Milan, Italy
Tel: [phone]; Fax: [phone]
Thermo Fisher Scientific Inc. provides this document to its customers with a product purchase to use in the
product operation. This document is copyright protected and any reproduction of the whole or any part of this
document is strictly prohibited, except with the written authorization of Thermo Fisher Scientific Inc.
The contents of this document are subject to change without notice. All technical information in this
document is for reference purposes only. System configurations and specifications in this document supersede
all previous information received by the purchaser.
Thermo Fisher Scientific Inc. makes no representations that this document is complete, accurate or error-
free and assumes no responsibility and will not be liable for any errors, omissions, damage or loss that might
result from any use of this document, even if the information in the document is followed properly.
This document is not part of any sales contract between Thermo Fisher Scientific Inc. and a purchaser. This
document shall in no way govern or modify any Terms and Conditions of Sale, which Terms and Conditions of
Sale shall govern all conflicting information between the two documents.
Release history:
First edition Revision A, released April 2013 “Original Instructions”
Second edition Revision B, released March 2015; Third edition Revision C, released December 2015
For Research Use Only. Not for use in diagnostic procedures.

TriPlus 300 Headspace Installation Request Form
Once you read the TriPlus 300 Headspace Preinstallation Requirements Guide, print and complete this form. After all the
requirements on this form are fulfilled, sign and date the form. Then mail or fax this form to your local Thermo Fisher
Scientific sales/service office.
Fill in the information below (please print clearly):
Name __________________________________________________________
Company _______________________________________________________Telephone ____________________
Address _____________________________________________________________________________________
Address _____________________________________________________________________________________
City ________________________________________ State ______________ Country______________________
Signature _______________________________________________________ Date _________________________
Additional Information
Have any special acceptance specifications been agreed to in the contract? Yes No 
If Yes, attach full details of specifications.
Is there any additional equipment that needs to be interfaced to the system? Yes No 
If Yes, attach full details of additional equipment.
Note We reserve the right to invoice you for the Field Service Engineer’s time if the installation requirements are not
met on the date of the installation. To avoid any additional cost, please ensure your site is properly prepared.
Requirements Checklist
All laboratory remodeling has been completed.
Your TriPlus 300 Headspace is on site.
Principal operator will be available during the
installation / certification period.
Doorways, hallways, etc. are a minimum width of 80 cm
(32 in.).
Available floor area is sufficient and flooring will
support the mass of the system.
Available workbench is sufficient for all of the
equipment. List the bench measurements:
Width:
Depth:
Height:
Workbench can support the mass of the system [158 kg
(348 lbs)] and is free from vibration.
Lighting is adequate.
Main power is installed and is in compliance with local
electrical codes.
Power outlets are of the correct configuration. NEMA
type:____________________________
The power outlets are enough for the electrical
connections.
Voltage of power outlet has been measured.
Measured voltage: ________________________
Power is free from fluctuations due to slow changes in
the average voltage or changes due to surges, sags, or
transients.
One or more RJ-45 wall outlet. To connect your system
to your site’s LAN network, you must have an
additional shielded twisted pair network cable.
Air conditioning is adequate for temperature, humidity,
and particulate matter control. The laboratory can be
maintained at a constant temperature, between 15 and
27 °C (59 and 81 °F).
Relative humidity is between 40% and 80% with no
condensation.
Air in your laboratory is free of excessive dust, smoke or
other particulate matter.
Work area is free from magnetic disruption and
electrostatic discharge.
One voice telephone line is installed near the system.
Principal Operator Level of Experience
GC, Injector and Column Knowledge: Experienced Moderate Limited
Gas Chromatography Theory Knowledge: Experienced Moderate Limited
Data System Knowledge: Experienced Moderate Limited
IMPORTANT PREINSTALLATION INFORMATION... PLEASE READ
