ThermoFisher Scientific iCAP 7000 Plus Series User manual

iCAP 7000 Plus Series ICP-OES
Operating Manual
BRE0004150 Revision C January 2018

BRE0004150 Revision C January 2018
iCAP 7000 Plus Series ICP-OES
Operating Manual

Legal Notices
© 2018 Thermo Fisher Scientific Inc. All rights reserved.
Original Operating Instructions
Published by:
Thermo Fisher Scientific (Bremen) GmbH, Hanna-Kunath-Str. 11, 28199 Bremen, Germany
Tel: [phone], Fax: [phone]
Microsoft and Windows are registered trademarks of Microsoft Corporation in the United States and
other countries.
The following are registered trademarks in the United States and possibly other countries: Decon is a
registered trademark of Decon Laboratories Limited. Snoop is a registered trademark of Swagelok
Company. Teflon is a registered trademark of E. I. du Pont de Nemours & Co. Tygon is a registered
trademark of Saint-Gobain Performance Plastics Company. Viton is a registered trademark of DuPont
Performance Elastomers LLC.
CETAC is a trademark of Teledyne CETAC Technologies Inc.. Eluo and IsoMist are trademarks of
Glass Expansion, Batman Street, Melbourne, Australia. Nafion is a trademark of E.I. du Pont
Nemours and Co. PEEK polymer is a trademark of Victrex plc. Ultem is a trademark of SABIC
Innovative Plastics IP BV.
All other trademarks are the property of Thermo Fisher Scientific Inc. and its subsidiaries.
Thermo Fisher Scientific Inc. provides this document to its customers with a product purchase to use
in the product operation. This document is copyright protected and any reproduction of the whole or
any part of this document is strictly prohibited, except with the written authorization of Thermo
Fisher Scientific Inc.
Release History: Revision A released in December 2015.
Revision B released in November 2016.
Revision C released in January 2018.

Thermo Scientific iCAP 7000 Plus Series ICP-OES Operating Manual (P/N BRE0004150, Revision C) i
Contents
Chapter 1 Using this Manual .................................................................1-1
About this Manual ......................................................... 1-1
Typographical Conventions ........................................... 1-2
Signal Words............................................................... 1-2
Viewpoint Orientation................................................ 1-2
Data Input .................................................................. 1-2
Topic Headings........................................................... 1-3
Reference Documentation.............................................. 1-4
Contacting Us................................................................ 1-5
Assistance.................................................................... 1-5
Suggestions to the Manual .......................................... 1-5
Chapter 2 System Accessories..............................................................2-1
Required Accessories ...................................................... 2-1
Optional Accessories ...................................................... 2-1
Chapter 3 Functional Description .........................................................3-1
Introduction................................................................... 3-2
Instrument Specification ................................................ 3-4
Optical System............................................................ 3-5
Detector Specifications................................................ 3-6
Detector Mode............................................................ 3-7
Plasma Viewing Specifications..................................... 3-7
Plasma Source Specification ........................................ 3-7
Sample Introduction Specifications ............................. 3-8
Operating Noise Level .............................................. 3-11
Sample Introduction System ........................................ 3-11
Center Tube Options................................................ 3-11
Nebulizer Options .................................................... 3-12
Pump Tubing Options.............................................. 3-12
Internal Standards Kit .................................................. 3-13
Organic Solvent Analysis.............................................. 3-14
Light Organic Samples.............................................. 3-14
Heavy Organic Samples ............................................ 3-14
Volatile Organic Samples .......................................... 3-15
High Dissolved Solid Samples...................................... 3-16
Argon Humidifier Accessory ..................................... 3-16
Aerosalt Nebulizer..................................................... 3-17
Parallel Path Nebulizer.............................................. 3-17
Sheath Gas Adaptor .................................................. 3-17
HF Samples ................................................................. 3-18

Contents
ii iCAP 7000 Plus Series ICP-OES Operating Manual (P/N BRE0004150, Revision C) Thermo Scientific
Chapter 4 Safety....................................................................................... 4-1
Safety Symbols and Signal Words in this Manual........... 4-2
Observing this Manual................................................ 4-2
Safety Symbols on the Instrument.................................. 4-2
Rating Plate................................................................. 4-3
Intended Use.................................................................. 4-4
Intended User ............................................................. 4-4
Permitted Materials..................................................... 4-5
Electric Safety Precautions ............................................. 4-6
Impaired Safety Protection.......................................... 4-6
In Case of Emergency .................................................... 4-7
Residual Hazards............................................................ 4-8
Personal Protective Equipment ................................... 4-9
Chapter 5 Installation ............................................................................. 5-1
Safety Guidelines for Installation.................................... 5-2
Spectrometer Dimensions .............................................. 5-3
Installation Requirements .............................................. 5-4
Before Installation....................................................... 5-4
Location Requirements ............................................... 5-4
Environmental Requirements...................................... 5-5
Electrical Requirements............................................... 5-6
Gas Requirements ....................................................... 5-7
Recirculating Chiller ................................................... 5-9
Waste Storage ............................................................. 5-9
Spectrometer Fume Extraction.................................. 5-10
Sample Fume Extraction ........................................... 5-12
Communications Interface........................................... 5-12
Spectrometer Communication Requirements............ 5-12
Data Station Requirements ....................................... 5-13
Installation Checklist ................................................... 5-13
Chapter 6 System Operation.................................................................. 6-1
Safety Guidelines for Operation ..................................... 6-2
Preparing the System for Use ......................................... 6-3
LED Indicators ........................................................... 6-3
Instrument Optimization............................................... 6-4
Method Optimization................................................. 6-4
Setting the Pump Tension........................................... 6-5
Standard Sample Introduction Glassware Assembly ....... 6-5
Duo Torch Assembly .................................................. 6-6
Radial Torch Assembly ............................................. 6-10
Connection of Pump Tubing.................................... 6-14
Radial View Interfaces on a Duo Instrument............. 6-17
Example Standard Operating Procedures ..................... 6-19
Preparing the System................................................. 6-19
Lighting the Plasma .................................................. 6-20
Setting Up Analyses .................................................. 6-23

Contents
Thermo Scientific iCAP 7000 Plus Series ICP-OES Operating Manual (P/N BRE0004150, Revision C) iii
Running the Analysis ................................................ 6-26
Reporting Results......................................................... 6-27
Exporting LabBooks..................................................... 6-28
Auto Peak Adjust ......................................................... 6-30
Shutting Down the System .......................................... 6-32
Chapter 7 Troubleshooting.....................................................................7-1
Safety Guidelines for Troubleshooting ........................... 7-2
Problems with Plasma Ignition....................................... 7-3
Argon Gas................................................................... 7-3
Ignition Spark ............................................................. 7-4
RF Power to the Coil from the RF Generator ............. 7-4
Problems with Plasma Going out Unexpectedly.......... 7-5
Resolving Problems with Analytical Results.................... 7-5
Resolving Specific Analytical Problems........................... 7-7
Poor Precision............................................................. 7-7
Poor Accuracy/Feedback ........................................... 7-11
Poor Detection Limits............................................... 7-11
Suggested Maintenance in Case of Poor Precision
and Detection Limits ................................................... 7-12
Replacing the Pump Tubing ..................................... 7-12
Preventing Blockage of the Nebulizer........................ 7-13
Removing Solids from the Nebulizer......................... 7-14
Chapter 8 Maintenance ..........................................................................8-1
Safety Guidelines for Maintenance................................. 8-2
Cleaning the Instrument ................................................ 8-3
Cleaning and Decontaminating the Sample
Introduction System.................................................... 8-3
Cleaning the Torch ..................................................... 8-3
Cleaning the Spray Chamber ...................................... 8-4
Cleaning the Nebulizer ............................................... 8-5
Cleaning the Purged Optical Path Window ................ 8-5
Cleaning the Radial View Interfaces............................ 8-6
Preventive Maintenance ................................................. 8-8
Water Chiller .............................................................. 8-8
Water Filter................................................................. 8-9
Gas Filters................................................................... 8-9
Torch Alignment ........................................................... 8-9
Thermo Fisher Scientific Service .................................. 8-10
Returning Parts ......................................................... 8-11
Services to be Performed by Thermo Fisher
Scientific Service Only .............................................. 8-11
Appendix A Advanced Hardware ............................................................A-1
Sprint Valve ...................................................................A-2
Supported Autosamplers .............................................A-2

Contents
iv iCAP 7000 Plus Series ICP-OES Operating Manual (P/N BRE0004150, Revision C) Thermo Scientific
Functional Description ...............................................A-2
Operational Settings....................................................A-8
Description of Timings .............................................A-13
Manual Control Features ..........................................A-14
Manual Sampling Using the Sprint Valve .................A-16
Routine Maintenance................................................A-16
Additional Gas Accessory .............................................A-24
Installing the Additional Gas Accessory.....................A-25
Appendix B Optional Accessories.......................................................... B-1
Autosampler...................................................................B-2
Autosampler Setup......................................................B-2
Ultrasonic Nebulizer ......................................................B-3
Hydride Generation.......................................................B-4
On-line Hydride Generation Kit.................................B-4
Integrated Hydride Generation Kit ............................. B-6
Gas Liquid Separator (GLS)........................................B-7
Appendix C Legal Documents...................................................................C-1
Glossary ................................................................................. G-1
Index.........................................................................................I-1

Thermo Scientific iCAP 7000 Plus Series ICP-OES Operating Manual (P/N BRE0004150, Revision C) v
Technical Data for iCAP 7000 Plus Series ICP-OES Systems
The table below summarizes the most important technical specifications of the
iCAP 7000 Plus Series ICP-OES systems, in relation to the installation. See
the respective chapters of the manual for details and additional information.
Parameter Specification Value
Instrument Properties
Spectrometer Depth × width × height 750 × 840 × 590 mm
Weight 85 kg
Power Requirements
Spectrometer Input Nominal voltage 230 V AC, 50/60 Hz
Power 2.88 kVA
Fusea32 A
Cooling Water Requirements
Chiller Supply rate > 5 L/min
Temperature 15 to 30 °C, 5 °C below ambient temperature
Max. temperature fluctuation < 0.2 °C/h
Pressure 0.6 MPa (6 bar, 90 psi)
Cooling capability 750 W minimum
Flow rate > 5 L/min
Water Quality distilled or deionized water
Solid residual < 50 μm particle size
Corrosion inhibitor 2.5% v/v
Gas Requirements
Argon Purity 99.995% or better, < 10 ppm H2O, < 10 ppm O2
Maximum supply rate 25 L/min
Pressure 0.55 MPa (5.5 bar, 80 psi), at maximum 0.6 MPa (6 bar, 90 psi)
Nitrogen
(optional)
Purity 99.995% or better, < 10 ppm H2O, < 10 ppm O2
Maximum supply rate 15 L/min
Pressure 0.55 MPa (5.5 bar, 80 psi)
Compressed Air Requirements
(iCAP 7400 ICP-OES fitted with an additional gas mass flow controller, or the iCAP 7600 ICP-OES)
Purity 99.99% or better, < 100 ppm H2O
Supply rate 100 mL/min
Pressure 0.2 MPa (2 bar, 30 psi)
Operating Environment
Laboratory Temperature 15–35 °C
Max. temperature fluctuation 2 °C/hour
Humidity 20–80% (15–30 °C), 20–60% (30–35 °C); non-condensing and
non-corrosive atmosphere
Max. altitude 3000 m above sea level
Extraction Tube diameter 125 mm
Capability (at the instrument) 10 m/s (Duo), 5 m/s (Radial)
adedicated wall outlet

Technical Data for iCAP 7000 Plus Series ICP-OES Systems
vi iCAP 7000 Plus Series ICP-OES Operating Manual (P/N BRE0004150, Revision C) Thermo Scientific

Thermo Scientific iCAP 7000 Plus Series ICP-OES Operating Manual (P/N BRE0004150, Revision C) 1-1
Chapter 1 Using this Manual
Contents
•About this Manual on page 1-1
•Typographical Conventions on page 1-2
•Reference Documentation on page 1-4
•Contacting Us on page 1-5
About this Manual
This iCAP 7000 Plus Series ICP-OES Operating Manual contains
precautionary statements that can prevent personal injury, instrument
damage, and loss of data if properly followed. It also describes the modes
of operation and principle hardware components of your Thermo
Scientific™ iCAP™ 7000 Series ICP-OES. In addition, this manual
provides step-by-step instructions for cleaning and maintaining your
instrument.
This iCAP 7000 Plus Series ICP-OES Operating Manual is intended for
all personnel that need a thorough understanding of the instrument (to
perform maintenance or troubleshooting, for example). Read this
manual carefully before using the instrument and keep it for future
reference.
Designed, manufactured and tested in an ISO9001 certified facility, this
instrument has been shipped to you from our manufacturing facility in a
safe condition. This instrument must be used as described in this
manual. Any use of this instrument in a manner other than described
here might result in instrument damage and/or operator injury.

Using this Manual
Typographical Conventions
1-2 iCAP 7000 Plus Series ICP-OES Operating Manual (P/N BRE0004150, Revision C) Thermo Scientific
Typographical Conventions
This section describes typographical conventions that have been
established for Thermo Fisher Scientific manuals.
Signal Words
Make sure that you follow the precautionary statements presented in
this manual. The special notices appear different from the main flow of
text:
Viewpoint Orientation
The expressions left and right used in this manual always refer to the
viewpoint of a person that is facing the front side of the instrument.
Data Input
Throughout this manual, the following conventions indicate data input
and output via the computer:
•Messages displayed on the screen are represented by capitalizing the
initial letter of each word and by italicizing each word.
•Input that you enter by keyboard is identified by quotation marks:
single quotes for single characters, double quotes for strings.
•For brevity, expressions such as “choose File > Directories” are used
rather than “pull down the File menu and choose Directories.”
•Any command enclosed in angle brackets < > represents a single
keystroke. For example, “press <F1>” means press the key labeled
F1.
•Any command that requires pressing two or more keys
simultaneously is shown with a plus sign connecting the keys. For
example, “press <Shift> +<F1>” means press and hold the <Shift>
key and then press the <F1> key.
•Any button that you click on the screen is represented in bold face
letters. For example, “click Close”.
NOTICE
Points out possible material damage and other important information
in connection with the instrument.
Tip Highlights helpful information that can make a task easier.

Using this Manual
Typographical Conventions
Thermo Scientific iCAP 7000 Plus Series ICP-OES Operating Manual (P/N BRE0004150, Revision C) 1-3
Topic Headings
The following headings are used to show the organization of topics
within a chapter:
Chapter 1 Chapter Name
Second Level Topics
Third Level Topics
Fourth Level Topics

Using this Manual
Reference Documentation
1-4 iCAP 7000 Plus Series ICP-OES Operating Manual (P/N BRE0004150, Revision C) Thermo Scientific
Reference Documentation
This iCAP 7000 Plus Series ICP-OES Operating Manual represents the
Original Operating Instructions. In addition to this manual, Thermo
Fisher Scientific provides other documents for the iCAP 7000 Plus
Series ICP-OES that are not part of the Original Operating
Instructions. Reference documentation for the iCAP 7000 Plus Series
ICP-OES includes the following:
•iCAP 7000 Plus Series ICP-OES Pre-Installation Requirements Guide
•iCAP 7000 Plus Series ICP-OES Quick Start Guide
•iCAP 7000 Series ICP-OES Accessories Guide
•Qtegra for iCAP 7000 Series ICP-OES Software Manual
The Qtegra iCAP 7000 Plus Series ICP-OES Online Help page provides
help with running your instrument, including software guides. See
Figure 1-1.
Figure 1-1. Qtegra ISDS Software Help topics

Using this Manual
Contacting Us
Thermo Scientific iCAP 7000 Plus Series ICP-OES Operating Manual (P/N BRE0004150, Revision C) 1-5
Contacting Us
There are several ways to contact Thermo Fisher Scientific.
Assistance
❖To get brochures and ordering information
❖To contact Customer Service
❖To get user manuals for your product
1. With the serial number (S/N) of your instrument, request access on
our customer SharePoint as a customer.
For the first login, you have to create an account. Follow the
instructions given on screen. Accept the invitation within six days
and log in with your created Microsoft™ password.
2. Download current revisions of user manuals and other
customer-oriented documents for your product. Translations into
other languages may be available there as well.
Suggestions to the Manual
❖To suggest changes to this manual
•Send your comments to:
Editors, Technical Documentation
Thermo Fisher Scientific (Bremen) GmbH
Hanna-Kunath-Str. 11
28199 Bremen
Germany
•Send an e-mail message to the Technical Editor at
[e-mail]
You are encouraged to report errors or omissions in the text or index.
Thank you.
Web site www.thermofisher.com/ICP-OES
Web site www.unitylabservices.com
Customer
SharePoint
www.thermoscientific.com/Technicaldocumentation

Using this Manual
Contacting Us
1-6 iCAP 7000 Plus Series ICP-OES Operating Manual (P/N BRE0004150, Revision C) Thermo Scientific

Thermo Scientific iCAP 7000 Plus Series ICP-OES Operating Manual (P/N BRE0004150, Revision C) 2-1
Chapter 2 System Accessories
In addition to the iCAP 7000 Plus Series ICP-OES, some of the system
accessories are required whereas others are optional.
Contents
•Required Accessories on page 2-1
•Optional Accessories on page 2-1
Required Accessories
The following accessories are mandatory. They can be ordered from
Thermo Fisher Scientific or an equivalent can be supplied by the user:
•Recirculating chiller unit (TF900 Turbine Pump Chiller, or
equivalent)
•Data station
Chapter 5, “Installation.” contains the required specifications for these
accessories.
Optional Accessories
The following accessories are optional:
•CETAC™ ASX-560 Autosampler1
•CETAC ASX-280 Autosampler1
•CETAC XLR-8 Autosampler1
•CETAC ASX 1400 Autosampler (stirring)1
•CETAC U-5000AT+ Ultrasonic Nebulizer
•IsoMist™ XR Programmable Temperature Spray Chamber2
•Hydride Generation Accessory
1requires dedicated RS232 or USB port on Data Station.
2requires dedicated USB port on Data Station.

System Accessories
Optional Accessories
2-2 iCAP 7000 Plus Series ICP-OES Operating Manual (P/N BRE0004150, Revision C) Thermo Scientific
•Argon Humidifier
•High Solids Sample Introduction kit
•HF Acid Sample Introduction kit
•Organics Sample Introduction kit
•Volatile Organics Sample Introduction kit
•Sheath Gas Adaptor
•Radial POP Interface
The above list is subject to change. Contact Thermo Fisher Scientific or
a local representative for a list of currently supported accessories.
Request site requirement guides for any purchased accessories.

Thermo Scientific iCAP 7000 Plus Series ICP-OES Operating Manual (P/N BRE0004150, Revision C) 3-1
Chapter 3 Functional Description
Contents
•Introduction on page 3-2
•Instrument Specification on page 3-4
•Sample Introduction System on page 3-11
•Internal Standards Kit on page 3-13
•Organic Solvent Analysis on page 3-14
•High Dissolved Solid Samples on page 3-16
•HF Samples on page 3-18

Functional Description
Introduction
3-2 iCAP 7000 Plus Series ICP-OES Operating Manual (P/N BRE0004150, Revision C) Thermo Scientific
Introduction
The Thermo Scientific iCAP 7000 Plus Series ICP-OES is a range of
inductively coupled plasma-optical emission spectrometers (ICP-OES),
which use an echelle optical design and a Charge Injection Device
(CID) solid-state detector to measure trace elemental concentrations in
a wide range of samples.
Typical samples that are analyzed by ICP-OES are liquids. They are
pumped through a nebulizer to produce a fine spray. The large droplets
are removed by a spray chamber and the small droplets then pass
through to the plasma.
The solvent is evaporated and the residual sample decomposes to atoms
and ions. These are excited by the electrical Radio Frequency (RF)
generated plasma, which is at a temperature of approximately 9000 K.
When they decay to a lower energy state, they emit a set of wavelengths
of light that is unique for each element. The intensity of this light is
measured and corresponds to the concentration of the element in the
original sample.
The iCAP 7000 Plus Series ICP-OES consists of several major
components:
•Plasma torch and sample introduction parts
•Radio frequency power generator
•Echelle polychromator optical system
Figure 3-1. iCAP 7000 Plus Series ICP-OES
