ThermoFisher Scientific Microliter 48 x 2 sealed User manual

Thermo Scientific
Microliter 48 x 2
sealed
Instruction Manual
50120031-e• 05/ 2020
Visit us online to register your warranty:
thermofisher.com/labwarranty

WEEE Conformity
This product is subject to the regulations of the EU Waste Electrical & Electronic
Equipment (WEEE) Directive 2012/19/EU. It is marked by the following symbol:

Thermo Scientific 75003602 Microliter 48 x 2sealed i
T
Preface .......................................................................................................................................iii
Scope of Supply ........................................................................................................................iii
Precautions ...............................................................................................................................iii
Chapter 1 Rotor Specifications ..............................................................................................................1-1
Technical Data ........................................................................................................1-2
230 V, 50 / 60 Hz ventilated ................................................................................1-2
230 V, 50 / 60 Hz refrigerated .............................................................................1-3
120 V, 60 Hz ventilated .......................................................................................1-4
120 V, 60 Hz refrigerated ....................................................................................1-5
230 V, 50 / 60 Hz ventilated ................................................................................1-6
230 V, 50 / 60 Hz refrigerated .............................................................................1-7
120 V, 60 Hz ventilated .......................................................................................1-8
120 V, 60 Hz refrigerated ....................................................................................1-9
100 V, 50 / 60 Hz ventilated ...............................................................................1-10
100 V, 50 / 60 Hz refrigerated .............................................................................1-11
230 V, 50 / 60 Hz ventilated ...............................................................................1-12
230 V, 50 / 60 Hz refrigerated .............................................................................1-12
120 V, 60 Hz ventilated ......................................................................................1-13
120 V, 60 Hz refrigerated ....................................................................................1-13
Chapter 2 Accessories .............................................................................................................................2-1
Chapter 3 AutoLock™.............................................................................................................................3-1
Rotor Installation .....................................................................................................3-2
Removing the Rotor .................................................................................................3-3
Aerosol-tight rotors ...................................................................................................3-3
Chapter 4 Rotor Loading ..........................................................................................................................4-1
Before Run ...............................................................................................................4-2
Proper Loading .........................................................................................................4-2
Improper Loading ....................................................................................................4-3
Maximum Loading ...................................................................................................4-3
Cycle Counter ..........................................................................................................4-4
Chapter 5 Aerosol-tight Applications ...................................................................................................5-1
Basic Principles .........................................................................................................5-2
Fill Level ...................................................................................................................5-2
Checking the Aerosol-Tightness ...............................................................................5-2
Table of Contents

Contents
ii 75003602 Microliter 48 x 2sealed Thermo Scientific
Chapter 6 Maintenance and Care ......................................................................................................... 6-1
Cleaning intervals .................................................................................................... 6-2
Cleaning .................................................................................................................. 6-2
Disinfection ............................................................................................................. 6-3
Decontamination ..................................................................................................... 6-4
Autoclaving .............................................................................................................. 6-5
Service of Thermo Fisher Scientific .......................................................................... 6-6
RCF-Values ...............................................................................................................A-1
Chemical Compatibility Chart ...............................................................................B-1

Thermo Scientific 75003602 Microliter48 x 2 sealed iii
P
Preface
Before starting to use the rotor, read through this Operating Instructions carefully and follow the
instructions.
The information contained in the Operating Instructions is the property of Thermo Fisher Scientific;
it is forbidden to copy or pass on this information without explicit approval.
Failure to follow the instructions and safety information in this instruction manual will result in the
expiration of the seller’s warranty.
Scope of Supply
If any parts are missing, please contact the nearest Thermo Fisher Scientific representative.
Precautions
In order to ensure safe operation of the Microliter 48 x 2 sealed, the following general safety
regulations must be followed:
•Do not remove the magnet at the rotor bottom.
•Do not use rotors which show any signs of corrosion and / or cracks.
•Use only with rotors that have been loaded properly.
•Never overload the rotor.
Article Number Quantity Check
75003602 Microliter 48 x 2 sealed 1
76003500 Rubber seal grease 1
70009824 Anti-corrosion oil 1
50120031 Instruction Manual 1

Preface
iv 75003602 Microliter 48 x 2sealed Thermo Scientific
•Use only accessories which have been approved by Thermo Fisher Scientific. Exceptions to this
rule are commercially available glass or plastic centrifuge tubes, provided they have been approved
for the speed or the RCF value of the rotor.
•Please observe the safety instructions.
Please pay particular attention to the following aspects:
•Rotor installation: Check that the rotor is locked properly into place before operating the
centrifuge.
•Always balance the samples.
Maximum sample density at maximum speed: 1.2g
ml
-
-----
This symbol refers to general hazards.
ATTENTION means that material damage could occur.
WARNING means that injuries or material damage or contamination could occur.
This symbol refers to biological hazards.
Observe the information contained in the instruction manual to keep yourself and your
environment safe.

Thermo Scientific 75003602 Microliter 48 x 2sealed 1-1
1
Rotor Specifications
Contents
•“Technical Data” on page 1-2

1-2 75003602 Microliter 48 x 2sealed Thermo Scientific
1Rotor Specifications
Technical Data
Technical Data
Table 1-1. 230 V,50 / 60 Hz ventilated
Centrifuge Multifuge X3 Multifuge X3 F Multifuge X1
Catalog # 75004500 75004530 75004210
Weight empty [kg] 2.4 2.4 2.4
Max. cycle number 50,000 50,000 50,000
Maximum permissible load [g] 48 x 4 48 x 4 48 x 4
Maximum speed nmax [rpm] 15,200 15,200 15,200
Maximum RCF value at nmax 25,314 25,314 25,314
Max. / min. radius [cm] 9.8 / 5.9 9.8 / 5.9 9.8 / 5.9
Pitch angle [°] 45 45 45
Accel. / braking time [s] 45 / 45 45 / 45 45 / 45
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running
time 120 minutes
19 19 16
Aerosol-tight*
*Tested by HPA, Porton-down, UK
yes yes yes
Permissible temperature range
autoclavable °C
121 121 121
Centrifuge Megafuge 40
Catalog # 75004503
Weight empty [kg] 2.4
Max. cycle number 50,000
Maximum permissible load [g] 48 x 4
Maximum speed nmax [rpm] 15,200
Maximum RCF value at nmax 25,314
Max. / min. radius [cm] 9.8 / 5.9
Pitch angle [°] 45
Accel. / braking time [s] 45 / 45
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running
time 120 minutes
19
Aerosol-tight*
*Tested by HPA, Porton-down, UK
yes
Permissible temperature
range autoclavable °C
121

1 Rotor Specifications
Technical Data
Thermo Scientific 75003602 Microliter 48 x 2sealed 1-3
Table1-2. 230 V,50 / 60 Hz refrigerated
Centrifuge Multifuge X3 R Multifuge X3 FR Multifuge X1 R
Catalog # 75004515 75004536 75004250
Weight empty [kg] 2.4 2.4 2.4
max. cycle number 50,000 50,000 50,000
Maximum permissible load [g] 48 x 4 48 x 4 48 x 4
maximum speed nmax [rpm] 15,200 15,200 15,200
maximum RCF value at nmax 25,314 25,314 25,314
max. / min. radius [cm] 9.8 / 5.9 9.8 / 5.9 9.8 / 5.9
Pitch angle [°] 45 45 45
Accel. / braking time [s] 45 / 45 45 / 45 45 / 45
aerosol-tight*yes yes yes
permissible temperature range
autoclavable °C
121 121 121
*Tested by HPA, Porton-down, UK
Centrifuge Megafuge 40R
Catalog # 75004518
Weight empty [kg] 2.4
max. cycle number 50,000
Maximum permissible load [g] 48 x 4
maximum speed nmax [rpm] 15,200
maximum RCF value at nmax 25,314
max. / min. radius [cm] 9.8 / 5.9
Pitch angle [°] 45
Accel. / braking time [s] 45 / 45
aerosol-tight*yes
permissible temperature range
autoclavable °C
121
*Tested by HPA, Porton-down, UK

1Rotor Specifications
Technical Data
1-4 75003602 Microliter 48 x 2sealed Thermo Scientific
Table 1-3. 120 V,60 Hz ventilated
Centrifuge Multifuge X3 Multifuge X3F Multifuge X1
Catalog # 75004501 75004504 75004211
Weight empty [kg] 2.4 2.4 2.4
Max. cycle number 50,000 50,000 50,000
Maximum permissible load [g] 48 x 4 48 x 4 48 x 4
Maximum speed nmax [rpm] 15,200 15,200 15,200
Maximum RCF value at nmax 25,314 25,314 25,314
Max. / min. radius [cm] 9.8 / 5.9 9.8 / 5.9 9.8 / 5.9
Pitch angle [°] 45 45 45
Accel. / braking time [s] 45 / 45 45 / 45 55 / 50
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running
time 120 minutes
19 19 16
Aerosol-tight*
*Tested by HPA, Porton-down, UK
yes yes yes
Permissible temperature range
autoclavable °C
121 121 121
Centrifuge Megafuge 40
Catalog # 75004518
Weight empty [kg] 2.4
Max. cycle number 50,000
Maximum permissible load [g] 48 x 4
Maximum speed nmax [rpm] 15,200
Maximum RCF value at nmax 25,314
Max. / min. radius [cm] 9.8 / 5.9
Pitch angle [°] 45
Accel. / braking time [s] 45 / 45
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running
time 120 minutes
19
Aerosol-tight*yes
Permissible temperature
range autoclavable °C
121
*Tested by HPA, Porton-down, UK

1 Rotor Specifications
Technical Data
Thermo Scientific 75003602 Microliter 48 x 2sealed 1-5
Table1-4. 120 V, 60 Hz refrigerated
Centrifuge Multifuge X3 R Multifuge X3 FR Multifuge X1 R
Catalog # 75004516 75004537 75004251
Weight empty [kg] 2.4 2.4 2.4
Max. cycle number 50,000 50,000 50,000
Maximum permissible load [g] 48 x 4 48 x 4 48 x 4
Maximum speed nmax [rpm] 15,200 15,200 15,200
Maximum RCF value at nmax 25,314 25,314 25,314
Max. / min. radius [cm] 9.8 / 5.9 9.8 / 5.9 9.8 / 5.9
Pitch angle [°] 45 45 45
Accel. / braking time [s] 45 / 45 45 / 45 55 / 50
Aerosol-tight*yes yes yes
Permissible temperature range
autoclavable °C
121 121 121
*Tested by HPA, Porton-down, UK
Centrifuge Megafuge 40R
Catalog # 75004519
Weight empty [kg] 2.4
Max. cycle number 50,000
Maximum permissible load [g] 48 x 4
Maximum speed nmax [rpm] 15,200
Maximum RCF value atnmax 25,314
Max. / min. radius [cm] 9.8 / 5.9
Pitch angle [°] 45
Accel. / braking time [s] 45 / 45
Aerosol-tight*yes
Permissible temperature
range autoclavable °C
121
*Tested by HPA, Porton-down, UK

1-6 75003602 Microliter 48 x 2sealed Thermo Scientific
1Rotor Specifications
Technical Data
Table 1-5. 230 V,50 / 60 Hz ventilated
Centrifuge Sorvall Legend XT Sorvall Legend XF Sorvall Legend X1
Catalog # 75004505 75004532 75004220
Weight empty [kg] 2.4 2.4 2.4
Max. cycle number 50,000 50,000 50,000
Maximum permissible load [g] 48 x 4 48 x 4 48 x 4
Maximum speed nmax [rpm] 15,200 15,200 15,200
Maximum RCF value at nmax 25,314 25,314 25,314
Max. / min. radius [cm] 9.8 / 5.9 9.8 / 5.9 9.8 / 5.9
Pitch angle [°] 45 45 45
Accel. / braking time [s] 45 / 45 45 / 45 45 / 45
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running
time 120 minutes
19 19 16
Aerosol-tight*
*Tested by HPA, Porton-down, UK
yes yes yes
Permissible temperature
range autoclavable °C
121 121 121
Centrifuge Sorvall ST 40
Catalog # 75004509
Weight empty [kg] 2.4
Max. cycle number 50,000
Maximum permissible load [g] 48 x 4
Maximum speed nmax [rpm] 15,200
Maximum RCF value at nmax 25,314
Max. / min. radius [cm] 9.8 / 5.9
Pitch angle [°] 45
Accel. / braking time [s] 45 / 45
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running
time 120 minutes
19
Aerosol-tight*yes
Permissible temperature range
autoclavable °C
121
*Tested by HPA, Porton-down, UK

1 Rotor Specifications
Technical Data
Thermo Scientific 75003602 Microliter 48 x 2sealed 1-7
Table1-6. 230 V,50 / 60 Hz refrigerated
Centrifuge Sorvall Legend XTR Sorvall Legend XFR Sorvall Legend X1R
Catalog # 75004520 75004538 750042260
Weight empty [kg] 2.4 2.4 2.4
Max. cycle number 50,000 50,000 50,000
Maximum permissible load [g] 48 x 4 48 x 4 48 x 4
Maximum speed nmax [rpm] 15,200 15,200 15,200
Maximum RCF value at nmax 25,314 25,314 25,314
Max. / min. radius [cm] 9.8 / 5.9 9.8 / 5.9 9.8 / 5.9
Pitch angle [°] 45 45 45
Accel. / braking time [s] 45 / 45 45 / 45 45 / 45
Aerosol-tight*yes yes yes
Permissible temperature range
autoclavable °C
121 121 121
*Tested by HPA, Porton-down, UK
Centrifuge Sorvall ST 40R
Catalog # 75004524
Weight empty [kg] 2.4
Max. cycle number 50,000
Maximum permissible load [g] 48 x 4
Maximum speed nmax [rpm] 15,200
Maximum RCF value atnmax 25,314
Max. / min. radius [cm] 9.8 / 5.9
Pitch angle [°] 45
Accel. / braking time [s] 45 / 45
Aerosol-tight*yes
Permissible temperature
range autoclavable °C
121
*Tested by HPA, Porton-down, UK

1Rotor Specifications
Technical Data
1-8 75003602 Microliter 48 x 2 sealed Thermo Scientific
Table 1-7. 120 V, 60 Hz ventilated
Centrifuge Sorvall Legend XT Sorvall Legend XF Sorvall Legend 1X
Catalog # 75004506 75004533 75004221
Weight empty [kg] 2.4 2.4 2.4
Max. cycle number 50,000 50,000 50,000
Maximum permissible load [g] 48 x 4 48 x 4 48 x 4
Maximum speed nmax [rpm] 15,200 15,200 15,200
Maximum RCF value at nmax 25,314 25,314 25,314
Max. / min. radius [cm] 9.8 / 5.9 9.8 / 5.9 9.8 / 5.9
Pitch angle [°] 45 45 45
Accel. / braking time [s] 45 / 45 45 / 45 55 / 50
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running
time 120 minutes
19 19 16
Aerosol-tight*
*Tested by HPA, Porton-down, UK
yes yes yes
Permissible temperature
range autoclavable °C
121 121 121
Centrifuge Sorvall ST 40
Catalog # 75004510
Weight empty [kg] 2.4
Max. cycle number 50,000
Maximum permissible load [g] 48 x 4
Maximum speed nmax [rpm] 15,200
Maximum RCF value at nmax 25,314
Max. / min. radius [cm] 9.8 / 5.9
Pitch angle [°] 45
Accel. / braking time [s] 45 / 45
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running
time 120 minutes
19
Aerosol-tight*yes
Permissible temperature
range autoclavable °C
121
*Tested by HPA, Porton-down, UK

1 Rotor Specifications
Technical Data
Thermo Scientific 75003602 Microliter 48 x 2sealed 1-9
Table1-8. 120 V,60 Hz refrigerated
Centrifuge Sorvall Legend XTR Sorvall Legend XFR Sorvall Legend X1R
Catalog # 75004521 75004539 75004261
Weight empty [kg] 2.4 2.4 2.4
Max. cycle number 50,000 50,000 50,000
Maximum permissible load [g] 48 x 4 48 x 4 48 x 4
Maximum speed nmax [rpm] 15,200 15,200 15,200
Maximum RCF value at nmax 25,314 25,314 25,314
Max. / min. radius [cm] 9.8 / 5.9 9.8 / 5.9 9.8 / 5.9
Pitch angle [°] 45 45 45
Accel. / braking time [s] 45 / 45 45 / 45 55 / 50
Aerosol-tight*yes yes yes
Permissible temperature range
autoclavable °C
121 121 121
*Tested by HPA, Porton-down, UK
Centrifuge Sorvall ST 40R
Catalog # 75004525
Weight empty [kg] 2.4
Max. cycle number 50,000
Maximum permissible load [g] 48 x 4
Maximum speed nmax [rpm] 15,200
Maximum RCFvalue at nmax 25,314
Max. / min. radius [cm] 9.8 / 5.9
Pitch angle [°] 45
Accel. / braking time [s] 45 / 45
Aerosol-tight*yes
Permissible temperature range
autoclavable °C
121
*Tested by HPA, Porton-down, UK

1Rotor Specifications
Technical Data
1-10 75003602 Microliter 48 x 2sealed Thermo Scientific
Table 1-9. 100 V,50 / 60 Hz ventilated
Centrifuge Sorvall Legend XT Sorvall Legend XF Sorvall Legend 1X
Catalog # 75004507 75004534 75004223
Weight empty [kg] 2.4 2.4 2.4
Max. cycle number 50,000 50,000 50,000
Maximum permissible load [g] 48 x 4 48 x 4 48 x 4
Maximum speed nmax [rpm] 15,200 15,200 15,200
Maximum RCF value at nmax 25,314 25,314 25,314
Max. / min. radius [cm] 9.8 / 5.9 9.8 / 5.9 9.8 / 5.9
Pitch angle [°] 45 45 45
Accel. / braking time [s] 45 / 45 45 / 45 60 / 50
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running
time 120 minutes
19 19 21
Aerosol-tight*
*Tested by HPA, Porton-down, UK
yes yes yes
Permissible temperature range
autoclavable °C
121 121 121
Centrifuge Sorvall ST 40
Catalog # 75004511
Weight empty [kg] 2.4
Max. cycle number 50,000
Maximum permissible load [g] 48 x 4
Maximum speed nmax [rpm] 15,200
Maximum RCF value at nmax 25,314
Max. / min. radius [cm] 9.8 / 5.9
Pitch angle [°] 45
Accel. / braking time [s] 45 / 40
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running
time 120 minutes
19
Aerosol-tight*yes
Permissible temperature range
autoclavable °C
121
*Tested by HPA, Porton-down, UK

1 Rotor Specifications
Technical Data
Thermo Scientific 75003602 Microliter 48 x 2 sealed 1-11
Table1-10. 100 V, 50 / 60 Hz refrigerated
Centrifuge Sorvall Legend XTR Sorvall Legend XFR Sorvall Legend X1R
Catalog # 75004522 75004540 75004263
Weight empty [kg] 2.4 2.4 2.4
Max. cycle number 50,000 50,000 50,000
Maximum permissible load [g] 48 x 4 48 x 4 48 x 4
Maximum speed nmax [rpm] 15,200 15,200 15,200
Maximum RCF value at nmax 25,314 25,314 25,314
Max. / min. radius [cm] 9.8 / 5.9 9.8 / 5.9 9.8 / 5.9
Pitch angle [°] 45 45 45
Accel. / braking time [s] 45 / 45 45 / 45 60 / 60
Aerosol-tight*yes yes yes
Permissible temperature
range autoclavable °C
121 121 121
*Tested by HPA, Porton-down, UK
Centrifuge Sorvall ST 40R
Catalog # 75004526
Weight empty [kg] 2.4
Max. cycle number 50,000
Maximum permissible load [g] 48 x 4
Maximum speed nmax [rpm] 15,200
Maximum RCF value at nmax 25,314
Max. / min. radius [cm] 9.8 / 5.9
Pitch angle [°] 45
Accel. / braking time [s] 45 / 45
Aerosol-tight*yes
Permissible temperature
range autoclavable °C
121
*Tested by HPA, Porton-down, UK

1-12 75003602 Microliter 48 x 2sealed Thermo Scientific
1Rotor Specifications
Technical Data
Table 1-11. 230 V, 50 / 60 Hz ventilated
Centrifuge SL 40 SL 40 F
Catalog # 75004512 75004542
Weight empty [kg] 2.4 2.4
Max. cycle number 50,000 50,000
Maximum permissible load [g] 48 x 4 48 x 4
Maximum speed nmax [rpm] 15,200 15,200
Maximum RCF value at nmax 25,314 25,314
Max. / min. radius [cm] 9.8 / 5.9 9.8 / 5.9
Pitch angle [°] 45 45
Accel. / braking time [s] 45 / 45 45 / 45
Sample heating at nmax [°C] referred to
ambient temperature of 23 °C, running
time 120 minutes
19 19
Aerosol-tight*
*Tested by HPA, Porton-down, UK
yes yes
Permissible temperature range
autoclavable °C
121 121
Table 1-12. 230 V,50 / 60 Hz refrigerated
Centrifuge SL 40R SL 40 FR
Catalog # 75004527 75004543
Weight empty [kg] 2.4 2.4
Max. cycle number 50,000 50,000
Maximum permissible load [g] 48 x 4 48 x 4
Maximum speed nmax [rpm] 15,200 15,200
Maximum RCF value at nmax 25,314 25,314
Max. / min. radius [cm] 9.8 / 5.9 9.8 / 5.9
Pitch angle [°] 45 45
Accel. / braking time [s] 45 / 45 45 / 45
Aerosol-tight*yes yes
Permissible temperature
range autoclavable °C
121 121
*Tested by HPA, Porton-down, UK
