ThermoPro TP-63A User manual

V20191029 EN FR
Model No.: TP-63A
English................ 2 Français................ 25
Wireless Indoor/outdoor Humidity And Temperature Monitor
Instruction Manual
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku

2. One remote sensor (Transmitter).
Indoor Base Station (Receiver) Features
Introduction
Congratulations on your purchase of the wireless indoor/
outdoor humidity and temperature monitor. You will now
be able to know the outdoor/indoor temperature and
humidity while sitting inside.
Components
1. One base station unit (Receiver). 01 Large LCD display
02 Remote Low Battery Icon
03 Outdoor temperature
04 Base Station Low Battery Icon
05 Indoor temperature
06 Outdoor humidity
07 Indoor humidity
08 Backlight Touch Button
09 Wall Mount
10 Magnet
11 Stand
12 Battery compartment
13 CHANNEL SYNC
14 °F/°C ALL-TIME/24
15 MAX/MIN CLEAR
EN EN
-2- -3-
09
10
11
13 14 15
12
SIDE
01
02
04
05
03
06
07
08
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku

5. Humidity range: 10% ~ 99%.
6. Temperature display unit: °C and °F selectable.
7. Temperature Resolution: 0.1 °C/°F.
8. Humidity Resolution:1%.
1. LCD display: Displays the current outdoor humidity/
temperature and indoor humidity/temperature.
2. Battery Compartment: Holds 2 AAA batteries to power
the unit.
3. Tabletop, wall-mountable and magnet-mountable design.
4. Indoor Temperature range: -4 °F~158°F(-20°C~70°C).
9. Low battery indication.
10. Backlight.
MAX/MIN/CLEAR: Press once to display the maximum or
minimum temperature and humidity; Press and hold to
clear the history data.
°F/°C/All-time/24: Press to select the temperature display
in ºC or ºF; After pressing the MAX/MIN button, and the
display shows the maximum or minimum temperature and
humidity. Touch this button once to set the maximum and
minimum data recording time interval between ALL TIME
or 24 hours.
Buttons
: Touch once to turn on/off backlight. If the button is
not pressed in 15 seconds, the backlight will automatically
turn off.
Note: Both ALL TIME and 24 hours represent the last time
EN EN
-4- -5-
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku

CHANNEL/SYNC: Press to switch between the temperature
readings from up to 3 outdoor remote sensors; Press and
hold this button to enter the synchronization mode.
after you manually cleared the history data or installed a
new battery.
Temperature & Humidity Trend
1. indicates the temperature & humidity is in an upward
trend.
2. indicates the temperature & humidity is in a no
change trend.
3. indicates the temperature & humidity is in a
downward trend.
Outdoor Remote Sensor (Transmitter) Features
1. Built-in rechargeable lithium battery: Type 18650.
01 LED
02 Reset
03 Wall Mount
04
ON/OFF
07 Humidity Sensor
08 Temperature Sensor
Charging Socket
05
06 Channel Selector
EN EN
-6- -7-
01
02
03
04
05
06
07
08
2. Rain-proof and design.wall-mount
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku

Buttons
To access CHANNEL SELECTOR and RESET buttons, you
need to unscrew the cover as per Fig.
CHANNEL Selector (1,2,3): Slide to set Channel 1,2 or 3.
RESET: Press once to reset the remote sensor.
: Press and hold for 2 seconds to turn ON/OFF the unit.
(ON: Flash 1 time, OFF: Flash 3 times)
Synchronize Remote Sensors with The Base
Station
1. Bring the remote sensor near the base station;
2. Once the batteries are installed into the base station, the
RF indicator will flash for 3 minutes, indicating that
the base station is in synchronization mode and is waiting
for remote sensors to be registered.
3. Set the CHANNEL selector on the back of the remote
sensor unit to position 1 or 2 or 3. The unit is preset on
Channel 1 and you can always leave it unchanged unless
you have purchased more than 1 remote sensor.
EN EN
-8- -9-
3. Outdoor Temperature range: -31 ~158°F(-35 ~70°C). °F °C
4. Humidity range: 10% ~ 99%.
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku

4. Press and hold the ON/OFF button on the back of the
remote sensor for 2 seconds to turn on the remote sensor.
If done correctly, the temperature/humidity of the remote
sensor will appear on the base station.
5. If the RF indicator no longer flashes and the remote
sensor temperature is not displayed on the base station.
Press and hold the CHANNEL/SYNC button on the back of
the base station for 3-4 seconds until the RF indicator
flashes again to set it back in synchronization mode;
6. If you have additional remote sensors, repeat the above
steps to synchronize the additional remote sensors.
Please note the additional sensors should be set to a
different channel.
remote channel you want displayed permanently on the
base station. If you wish to cycle through all the channels,
press the CHANNEL/SYNC button until you observe a
circular arrow on the base station LCD display, the unit
will auto-scroll, changing from channel to channel every 5
seconds. Press CHANNEL button until you observe the
circular arrow disappear, the unit will stop cycling.
EN EN
-10- -11-
7. If you have registered more than one sensor, press the
CHANNEL/SYNC button on the base station to select the
CH1
CHAN EL
SYNC
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku

Installing Batteries
1. Base station: open the battery compartment of the base
station and insert two “AAA” batteries with correct
polarity.
installed in the remote sensor. Although there could be
some power in the rechargeable battery before the unit
leaves the manufacturing facility, it is always good to
fully recharge the remote sensor before using by
following the steps below:
a. Connect the charger to the charging socket located on
the back of the remote sensor;
b. Plug the charger into a standard AC outlet;
c. The red light on the remote sensor will light up;
d. Charge it for at least 4 hours until the light changes from
red to green which indicates charging is complete.
EN EN
-12- -13-
If the low battery icon for remote sensor appears, please
charge the remote sensor as soon as you can.
Note, the package does not INCLUDE a wall adapter.
Simply use any cellphone wall charger with USB socket to
charge the battery.
If the low battery icon for base station appears, please
replace the batteries with new batteries.
Low Battery Warning
If the battery power (base station or remote sensor) is low,
there will be low battery icon showing on the base station
display.
2. Remote sensor: A built-in rechargeable lithium battery is
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku

3. The base station and remote sensor can both be wall
mounted.
Maximum & Minimum Recorded Temperature
& Humidity
1. Press MAX/MIN/Clear button once to display the highest
indoor and outdoor temperatures/humidity recorded.
MAX is shown on the display.
2. Press MAX/MIN/Clear button again to display the lowest
indoor and outdoor temperatures/humidity recorded.
3. To clear and reset the max/min records, press and hold
MAX/MIN/Clear for 3 seconds.
display, press ALL-TIME/24 button once to select the
data recording time interval between ALL TIME or 24
hours.
4. When the MAX or MIN records are shown on the LCD
EN EN
-14- -15-
MIN is shown on the display.
2. The remote sensor (transmitter) can be placed on a flat
surface indoors or outdoors. Make sure the sensor is
within the wireless distance from the base station and
with minimal obstructions. Although the remote sensor
is designed to be rain-proof, it still must always be put in
a dry place avoiding direct rainfall.
Place the Base Station and Remote Sensor
1. The indoor base station (receiver) should always be
placed in a well ventilated indoor area and located away
from vents, heating or cooling elements, direct sunlight,
windows, doors, or any other openings.
Note: Both ALL TIME and 24 hours represent the time since
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku

If the base station is attached to a refrigerator or a
metal object by magnet, the transmission range may be
shorter. Remove the base station from the refrigerator
Warnings
Do not subject the unit to excessive force, shock, dust,
temperature or humidity.
Do not immerse the unit in water.
Do not dispose of this unit in a fire. IT MAY EXPLODE.
Keep unit away from children. The unit or parts of the
unit might be a choking hazard.
Dispose of the unit legally and recycle when possible.
Do not remove any screws.
EN EN
-16- -17-
Signals from other electronic devices may cause
interference. Place the base station and receiver away
from these devices.
Relocate the base station or the remote unit until the
connection is established again.
Repeat the synchronization process as described above.
you last time manually cleared the history data or battery
installation.
Hints and Tips
If the receiver can't connect to the transmitter, try the
following:
or the metal object or place the base station and remote
sensor as close as possible.
1. Transmission Frequency: 433MHz.
Specifications
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku

Warning: Changes or modifications to this unit not
expressly approved by the party responsible for compliance
could void the user's authority to operate the equipment.
9. Power: 2 X AAA 1.5V for base unit and 18650 lithium
battery 3.7V for remote sensor.
EN EN
-18- -19-
NOTE: This equipment has been tested and found to comply
with the limits for a Class B digital device, pursuant to Part
15 of the FCC rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses and
can radiate radio frequency energy and, if not installed and
used in accordance with the instructions, may cause harmful
interference to radio communications. However, there is no
guarantee that interference will not occur in a particular
8. Humidity tolerance: ±2% from 30% to 80%; ±3% below
30% and above 80%.
7. Temperature tolerance: +/- 2.0 °F (+/- 1.1 °C).
2. Maximum Transmit Power: 8mW.
3. Transmission range up to 200 feet in open area. (range
maybe shorter based on interference present).
4. Indoor Temperature range: -4°F~158°F (-20°C~70°C).
6. Humidity range: 10% ~ 99%.
5. Outdoor Temperature range: -31 ~158°F(-35 ~70°C).°F °C
FCC STATEMENT OF COMPLIANCE
This device complies with Part 15 of the FCC rules.
Operation is subject to the following two conditions:
1) This device may not cause harmful interference.
2) This device must accept any interference received,
including interference that may cause undesired operation.
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku

- Connect the equipment into an outlet on a circuit different
from that to which the receiver is connected. Consult the
dealer or an experienced radio/TV technician for help.
Disposal
Meaning of the “Dustbin” Symbol
Declaration of Conformity
Hereby, the manufacturer declares that this product
complies with the basic requirements and applicable
Protect our environment: do not dispose
of electrical equipment in the domestic
waste.
Please return any electrical equipment
that you will no longer use to the collec-
tion points provided for their disposal.
This helps avoid the potential effects of
incorrect disposal on the environment
EN EN
-20- -21-
- Increase the separation between the equipment and the
receiver.
installation. If this equipment does cause harmful
interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is
encouraged to try to correct the interference by one of more
of the following measures:
- Reorient or relocate the receiving antenna.
regulations of the Radio Equipment Directive 2014/53/EU,
the EMC Directive 2014/30/EU. The complete declaration
of conformity can be found at:
https://itronicsmall.com/eu-declaration-of-conformity/
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku

Limited one-year warranty
ThermoPro warrants this product to be free of defects in
parts, materials and workmanship for a period of one year,
from date of purchase.
Should any repairs or servicing under this warranty be
required, contact Customer Service by phone or email for
instructions on how to pack and ship the product to
ThermoPro.
Pb = contains lead
Cd = contains cadmium
Hg = contains mercury
Li = contains lithium
This symbol can be found on batteries/rechargeable
batteries which contain hazardous.
Your town or local authority can provide information
about public collection points.
Take spent batteries to the appropriate collection
or to a dealer.
point
The batteries must be removed from the appliance.
CAUTION Batteries/rechargeable batteries must
not be disposed of with household waste!
:
Information concerning where the
equipment can be disposed of can be
obtained from your local authority.
EN EN
-22- -23-
This will contribute to the recycling and
other forms of reutilisation of electrical
and electronic equipment.
and human health.
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku
© Sunnysoft s.r.o., distributor pro Českou republiku a Slovenskou republiku
