PA 4080 KB
keyboard combo
user manual

Musikhaus Thomann e.K.
Treppendorf 30
96138 Burgebrach
Germany
Telephone: [phone]
E-mail: [email protected]
Internet: www.thomann.de
28.07.2014, ID: 147171

Table of contents
1 General information................................................................................................................................. 5
1.1 Further information........................................................................................................................... 6
1.2 Notational conventions.................................................................................................................... 7
1.3 Symbols and signal words............................................................................................................... 7
2 Safety instructions..................................................................................................................................... 9
3 Features and scope of delivery ........................................................................................................ 14
4 Installation and starting up................................................................................................................ 15
4.1 Pin assignment.................................................................................................................................. 16
4.2 Tips on handling speakers............................................................................................................ 19
5 Connections and operating elements........................................................................................... 20
6 Operation.................................................................................................................................................... 26
7 Cleaning....................................................................................................................................................... 29
8 Troubleshooting...................................................................................................................................... 30
9 Technical specifications....................................................................................................................... 31
Table of contents
PA 4080 KB
3

10 Protecting the environment.............................................................................................................. 33
Table of contents
keyboard combo
4

1 General information
This manual contains important instructions for the safe operation of the unit. Read and follow
the safety instructions and all other instructions. Keep the manual for future reference. Make
sure that it is available to all those using the device. If you sell the unit please make sure that
the buyer also receives this manual.
Our products are subject to a process of continuous development. Thus, they are subject to
change.
General information
PA 4080 KB
5

1.1 Further information
On our website (www.thomann.de) you will find lots of further information and details on the
following points:
Download This manual is also available as PDF file for you to download.
Keyword search Use the search function in the electronic version to find the topics of
interest for you quickly.
Online guides Our online guides provide detailed information on technical basics
and terms.
Personal consultation For personal consultation please contact our technical hotline.
Service If you have any problems with the device the
customer service will gladly assist you.
General information
keyboard combo
6

1.2 Notational conventions
This manual uses the following notational conventions:
The letterings for connectors and controls are marked by square brackets and italics.
Examples: [VOLUME] control, [Mono] button.
1.3 Symbols and signal words
In this section you will find an overview of the meaning of symbols and signal words that are
used in this manual.
Letterings
General information
PA 4080 KB
7

Signal word Meaning
DANGER! This combination of symbol and signal word indicates an
immediate dangerous situation that will result in death or
serious injury if it is not avoided.
CAUTION! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in minor injury if it
is not avoided.
NOTICE! This combination of symbol and signal word indicates a pos‐
sible dangerous situation that can result in material and
environmental damage if it is not avoided.
Warning signs Type of danger
Warning – high-voltage.
Warning – danger zone.
General information
keyboard combo
8

2 Safety instructions
This device is intended to be used for amplification and playback of signals from musical
instruments and microphones. Use the unit only as described in this manual. Any other use or
use under other operating conditions is considered to be improper and may result in personal
injury or property damage. No liability will be assumed for damages resulting from improper
use.
This device may be used only by persons with sufficient physical, sensorial, and intellectual
abilities and having corresponding knowledge and experience. Other persons may use this
device only if they are supervised or instructed by a person who is responsible for their safety.
Intended use
Safety instructions
PA 4080 KB
9

DANGER!
Danger for children
Ensure that plastic bags, packaging, etc. are disposed of properly and are not
within reach of babies and young children. Choking hazard!
Ensure that children do not detach any small parts (e.g. knobs or the like) from
the unit. They could swallow the pieces and choke!
Never let children unattended use electrical devices.
DANGER!
Electric shock caused by high voltages inside
Within the device there are areas where high voltages may be present. Never
remove any covers.
There are no user-serviceable parts inside.
Safety
Safety instructions
keyboard combo
10

DANGER!
Electric shock caused by short-circuit
Always use proper ready-made insulated mains cabling (power cord) with a pro‐
tective contact plug. Do not modify the mains cable or the plug. Failure to do so
could result in electric shock/death or fire. If in doubt, seek advice from a regis‐
tered electrician.
CAUTION!
Possible hearing damage
The device can produce volume levels that may cause temporary or permanent
hearing impairment. Over an extended period of time, even levels that seem to
be uncritical can cause hearing damage.
Decrease the volume level immediately if you experience ringing in your ears or
hearing impairment. If this is not possible, keep a greater distance or use suffi‐
cient ear protectors.
Safety instructions
PA 4080 KB
11

NOTICE!
Risk of fire
Do not cover the device nor any ventilation slots. Do not place the device near
any direct heat source. Keep the device away from naked flames.
NOTICE!
Operating conditions
This device has been designed for indoor use only. To prevent damage, never
expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and
strong vibrations.
Safety instructions
keyboard combo
12

NOTICE!
Power supply
Before connecting the device, ensure that the input voltage (AC outlet) matches
the voltage rating of the device and that the AC outlet is protected by a residual
current circuit breaker. Failure to do so could result in damage to the device and
possibly injure the user.
Unplug the device before electrical storms occur and when it is unused for long
periods of time to reduce the risk of electric shock or fire.
Safety instructions
PA 4080 KB
13

3 Features and scope of delivery
Special features of this four-channel keyboard combo:
n80 watt RMS output power
nBuilt-in spring reverb, foot-switchable (FS not included)
n1 × MIC input (XLR, balanced) and 1 × LINE input (1/4" phone socket) per channel
nVolume, tone and reverb control per channel
n2 additional CD/Tape in and outputs
nMaster section with 3-band EQ
nExternal effects loop
n12" Celestion speakers and tweeter
nIntegrated tripod mounting flange
nIncl. casters and pull-out handle
Features and scope of delivery
keyboard combo
14

4 Installation and starting up
Unpack and carefully check that there is no transportation damage before using the unit. Keep
the equipment packaging. To fully protect the device against vibration, dust and moisture
during transportation or storage use the original packaging or your own packaging material
suitable for transport or storage, respectively.
Establish all connections as long as the unit is switched off. Use the shortest possible high-
quality cables for all connections.
NOTICE!
Possible property damage by magnetic fields
Loudspeakers produce a static magnetic field. Therefore, maintain an appropriate
distance to devices that can be adversely affected or damaged by an external
magnetic field.
Installation and starting up
PA 4080 KB
15

4.1 Pin assignment
You can use XLR plugs with balanced or unbalanced wiring. In the following, we will give you
an overview of the various options.
Balanced XLR mounting sockets are used for signal inputs. Drawing and table indicate the XLR
pin assignment for plugs to be used.
Balanced wiring:
1 Ground, shielding
2 Positive signal (+)
3 Negative signal (–)
XLR connections for signal
inputs
Installation and starting up
keyboard combo
16

Unbalanced wiring:
1 Ground, shielding
2 Signal
3 Bridged to pin 1
Drawing and table indicate the pin assignment of a 1/4" phone jack to be used.
TS jack, unbalanced:
1 Signal
2 Ground, shielding
1/4" phone sockets for signal
inputs
Installation and starting up
PA 4080 KB
17

TRS jack, unbalanced:
1 Signal
2, 3 Ground, shielding
TRS jack, balanced:
1 (Tip) Positive signal (+)
2 (Ring) Negative signal (–)
3 (Sleeve) Ground, shielding
Installation and starting up
keyboard combo
18

4.2 Tips on handling speakers
We recommend you to set up the speakers in a way, that the sound signals can reach the audi‐
ence unobstructedly. It will often be helpful to mount the speakers on tripods. Thus, the sound
will be evenly spread with maximum range throughout the audience area.
Always use high grade cable to connect your equipment. Otherwise you won't reach max‐
imum sound quality.
For optimum results both impedance and power handling of the speakers must match the
requirements of the amplifier. Always follow the technical specifications of the speakers! The
overall impedance of the connected loudspeakers must not deceed the minimum output
impedance of the amp. The amps max. RMS output power should be 50 % above the power
handling capacity of the connected speakers.
If you notice distortion during operation, either the amp or the speaker is overloaded. This may
permanently damage the amp or the speaker. Always reduce the volume when you hear dis‐
tortion.
Installation and starting up
PA 4080 KB
19

5 Connections and operating elements
Top panel
Connections and operating elements
keyboard combo
20
