THOMSON THVEL491TT User manual

LED DISPLAY
TOWER FAN
THVEL491TT
INSTRUCTION MANUAL
IMPORTANT :
Carefully read this instruction manual
before switching on and keep it safe.

GB-2
WARNING!!!
If the power cord is damaged, it must be
replaced by the manufacturer, its service or
similarly qualified persons in order to avoid a
hazard.
The plug socket power cable must be
removed before cleaning the unit or
undertake maintenance operations.
WARNINGS
The product must be installed in
accordance with the national wiring rules.
This unit is intended for household and
domestic use.
1. Before connecting the appliance, check
that:
- The supply voltage is the same as the
nameplate,
- The power supply socket is suitable to the
device,
- The cable plug is adapted to the socket
The product is intended only for a socket
with a main voltage of 230 volts (50 Hz).

GB-3
2. Never insert fingers, pencils or other
objects through the grid when the
appliance is running.
3. Make sure the appliance is placed on a
stable surface when in use.
4. Do not use your appliance near a window.
The rain could cause an electrical shock.
5. Never leave the appliance running
unattended.
6. For security reasons, you MUST always
remove the plug from the outlet when not
in use, before cleaning or before
maintenance.
7. Do not use chemicals or detergents for
cleaning, it could easily damage or
deform your appliance.
8. Do not pull the cord to unplug from the
socket.
9. Do not use the unit with a damaged cord
or plug.
10. Never attempt to disassemble or repair the
device yourself. In the case of repairs by
someone not competent, the warranty is
void.

GB-4
11. The unit and the grid should not be
removed for maintenance or cleaning.
12. This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning use of
the appliance in a safe way and
understand the hazards involved.
13. Children shall not play with the appliance.
Cleaning and user maintenance shall not
be made by children without supervision.
14. This product complies with the
requirements of Directives 2014/35/EU
(repealing Directive 73/23/EEC amended
by Directive 93/68/EEC) and 2014/30/EU
(repealing Directive 89/336/EEC) .
15. Unplug the product when you move it.
16. Never run the product in the presence or
within reach of unsupervised children.
17. The battery must be removed from the
appliance before it is scrapped;
18. The battery is to be disposed of safely.

GB-5
19. The batteries in the remote control should
not be exposed to excessive heat such as
sunshine or fire.
20. Well assemble the product before use.
21. This appliance is intended to be used in
household.
22. If the supply cord is damaged, it must be
replaced by the manufacturer, its service
agent or similarly qualified persons in order
to avoid a hazard
23. Regarding the correct assembly of the
device, refer to page 6 of the
corresponding instructions.
24. For cleaning and maintenance instruction,
refer to page 8 of the corresponding
section
25. User instructions should be provided with
the device so that it can be used safely.
TECHNICAL SPECIFICATIONS :
Model n° THVEL491TT
Power supply 220-240V~50Hz
Power 60W
Classe II
Remote control battery CR2025, 3V

GB-6
ASSEMBLY INSTRUCTIONS
1. Unscrew the 3 screws under the base
2. Gently pull on the power cord. Pass the power cord through the hole in one of the two parts
of the base planned for this purpose.
3. Adjust the two parts of the base by sliding and "clip" together, then adjust the base to the
fan body. Insert the 3 screw in the base holes and well screw.
4. Finally, put the power cord into the path for this purpose under the base, to ensure the
necessary stability to your fan.
Air outlet
LED display
Base
Control panel and remote control storage

GB-7
LED DISPLAY
CONTROL PANEL REMOTE CONTROL
OPERATING INSTRUCTIONS
1. : On/Off
2. : Timer (Up to 8 hours)
Speed
Oscillation
Ventilation
Sleep
Ventilation Normal Ioniser
Ventilation
Natural
Mode AUTO
Room
temperature
indicator or
timer

GB-8
3. : Mode Auto : . If the ambient temperature is equal to or higher than 25 , the fan will
run, it stops if the temperature is below 25
4. : Oscillation.
5. : Allows you to select three different ventilation:
-Normal: conventional operating continuously at the selected speed (Low / Medium / High)
-Natural: intermittent operation
-Sleep: intermittent operation, ideal overnight
6. : Selection of 3 different speeds: Low / Medium / High
7. : Enable or disable the ionizer
8. Remote control: Requires 1pc CR2025 3V battery supplied in the remote control. Used
batteries must be safely disposed. Place them in collection bins provided (please ask your
dealer) to protect the environment.
Respect the polarity when inserting
BATTERY REPLACEMENT
1. Remove the battery holder by pressing
the locking tab A with your thumb and
pulling it out as per arrow B.
2. Replace the battery with the same type
and the (+) side facing up.
3. Gently push in the holder until securely
locked into place.
CAUTION: Danger of explosion if battery is
incorrectly replaced. Replace only with the
same or equivalent type.
CLEANING AND MAINTENANCE
1. Always disconnect the appliance from the mains by switching it off and removing the
plug from the power outlet before cleaning.
2. It is advisable to use a neutral detergent and a soft cloth and to rub dry. Do not use
solvents, acidic detergents, petrol or alcohol etc. to clean the plastic components, as
these could be deformed or damaged.
3. Do not allow water to penetrate the motor during cleaning.

GB-9
THVEL491TT
Description Symbol Value Unit
Maximum fan flow rate F 8,41 m3/min
Fan power input P 40,50 W
Service value SV 0,21 (m3/min)/W
Standby power consumption PSB 0,25 W
Off mode power consumption Poff - W
Fan sound power level LWA 58,94 dB(A)
Maximum air velocity c 4,67 meters/sec
Seasonal electricity consumption Q 13,24 kWh/a
Measurement standard for service
value
EN 60704-2-7: 1998,
EN 60704-1: 2010+A11: 2012
EN 50564: 2011
EN ISO 5801: 2008
Contact details for obtaining more
information
SCHNEIDER CONSUMER GROUP,
12 rue Jules Ferry, 93110 Rosny sous bois,
France
The European directive 2012/19/EC on Waste Electrical and Electronic
Equipment (WEEE), requires that old household electrical appliances must not be
disposed in the normal unsorted municipal waste stream. Old appliances must
be collected separately in order to optimize the recovery and recycling of the
materials they contain and reduce the impact on human health and the environment.
when you dispose of the appliance it must be separately collected.
Consumers should contact their local authority or retailer for information concerning the
correct disposal of their old appliance.
The warranty does not cover the wear parts of the product, nor the problems or damage
resulting from:
(1) surface deterioration due to normal wear and tear of the product;
(2) defects or deterioration due to contact with liquids and corrosion caused by rust or the
presence of insects;
(3) any incident, abuse, misuse, alteration, disassembly or Unauthorized repair;
(4) improper maintenance, improper use concerning the product or connection to an
incorrect voltage;
(5) any use of accessories not supplied or not approved by the manufacturer.
The guarantee will be cancelled if the nameplate and / or serial number of the product
are removed.
Imported by SCHNEIDER CONSUMER GROUP,
12 Rue Jules Ferry, 93110 Rosny sous Bois, France
