DET02AFC Operating Manual — Fiber Input Si Photodetector
Description:
The DET02AFC is a ready-to-use, high-speed Si photodetector for use with FC/PC connectorized fiber optic cables
in visible wavelength optical systems. The unit comes with an FC/PC bulkhead connector, detector, and 12V bias
battery enclosed in a compact aluminum housing. The FC/PC connector provides easy coupling to fiber-based light
sources. The output uses an SMA jack to minimize size and maximize frequency response. The bandwidth is
1.2GHz and will operate over the spectral range of 400-1100nm. A NIR version, the DET01CFC, is also available
and operates in the 800-1700nm spectral range.
The DET02AFC includes one #8-32 tapped mounting hole with a 0.25″mounting depth, while the DET02AFC/M has
one M4 tapped mounting hole with a 6.35mm mounting depth. A 12V A23 battery is included.
Specifications*:
Detector: Si PIN Output Voltage1 (Hi-Z): 0-10V
Active Diameter: Ø0.25mm Output Voltage2 (50Ω): 0-410mV
Wavelength Range (λ): 400-1100nm Output: SMA (DC coupled)
Peak Wavelength (λp): 730nm (typ) Dark Current3 (ID): 50pA (500pA max)
Peak Response [typ, ℜ(λp)]: 0.46A/W (typ) Shunt Resistance (Rsh): 20GΩ
Input: FC/PC fiber connector Weight: 0.18lbs
Rise Time (tR): 50ps (typ) Storage Temp: 0-40°C
Fall Time (tf): 250ps (typ) Operating Temp: 0-40°C
Ball Lens Size: Ø0.059″(Ø1.5 mm) Battery: A23, 12VDC, 40mAh
Diode Capacitance (CJ): 0.94pF (typ) NEP (730nm): 9.5x10-15W/√Hz (max)
Min Load Resistance: 50ΩBias Voltage (VR): 12V
Damage Threshold: 18mW
*All measurements performed with a 50Ωload unless stated otherwise.
1. Into high impedance. Max voltage is dependent on battery voltage. New batteries typically show 12-13V, while drained
batteries show 9V or less.
2. Calculated range based on peak responsivity and damage threshold.
3. Measured with specified bias voltage.
Figure 1
15829-S01 Rev D 3/18/2008
Page 1 of 5

Operation
Thorlabs’ DET series is ideal for measuring pulsed and CW light sources. The DET02AFC includes a reversed-
biased PIN photodiode, and a bias battery packaged in a rugged housing. The SMA output signal is the direct
photocurrent out of the photodiode anode and is a function of the incident light power (P) and wavelength (λ). The
spectral responsivity [ℜ(λ)] can be obtained from Figure 1 to estimate the amount of photocurrent to expect. Most
users will wish to convert this photocurrent to a voltage (VOUT) for viewing on an oscilloscope or DVM. This is
accomplished by factoring in an external load resistance (RLOAD). The output voltage is derived as:
VOUT = P * ℜ(λ) * RLOAD
It should be noted that the load resistor will react with the photodetector junction capacitance (CJ) to limit the
bandwidth. For best frequency response, a 50Ωterminator should be used. The bandwidth (fBW) and the rise-time
response (tR) can be approximated using the diode capacitance (CJ) and the load resistance (RLOAD) as shown
below:
fBW = 1 / (2 * π* RLOAD * CJ)
tR= 0.35 / fBW
For maximum bandwidth, we recommend using a 50Ωcoax cable with a 50Ωterminating resistor at the opposite
end of the coax. This will also minimize ringing by matching the coax with its characteristic impedance. If bandwidth
is not important, you may increase the amount of voltage for a given input light by increasing RLOAD.
Circuit Schematic
Figure 2
Setup
•Unpack the optical head and install the battery as described in “Battery Replacement.”
•(Optional) Install a Thorlabs TR series ½″diameter post into one of the #8-32 (M4) tapped holes, located on
the bottom and side of the sensor, and mount into a PH series post holder.
•Attach a 50Ωcoax cable to the output of the DET. Select and install a terminating resistor to the remaining
end of the cable and connect to a voltage measurement device. See the “Operation” section to determine
resistor values. Thorlabs sells a 50Ωterminator (T4119) for best frequency performance, a variable
terminator (VT1) for output voltage flexibility, and SMA-to-SMA (CA29xx series) and SMA-to-BNC (CA28xx
series) coaxial cables. Note that the input impedance of your measurement device will act as a terminating
resistor. A load resistor is not necessary when using current measurement devices.
•Install a fiber source to the DET02AFC photodetector FC/PC connector. Thorlabs recommends cleaning the
end of the fiber each time it is connected with the detector.
15829-S01 Rev D 3/18/2008
Page 2 of 5

15829-S01 Rev D 3/18/2008
Page 3 of 5
Battery Replacement
Thorlabs delivers each DET with an A23 12V battery. This battery is readily available through Thorlabs, as well as
most retail stores. The battery supplied will deliver about 40 hours with a 1mA load, roughly equivalent to a
continuous 1.5mW light source at peak wavelength. The supply current when no light is applied is very small and
should not significantly degrade the battery.
•Locate the battery cap directly below the output SMA.
•Unthread the cap and remove the battery.
•Install the new battery into the battery slot, positive side in, and thread the cap back into the DET. The
battery spring should be located in the battery cap, not in the housing. The battery polarity is located on the
housing. Be careful not to cross-thread the cap into the housing. The design of the DET02AFC will not allow
damage to occur if the battery is installed backward. In this situation, the photodetector will operate;
however, it will be unbiased.
Troubleshooting
If there is no signal response…
•verify all connections are secure.
•verify the proper terminating resistor is installed if using a voltage measurement device.
•verify that the optical signal wavelength is within the specified wavelength range.
•verify that the fiber is correctly connected.
•verify the fiber is not broken.
If the output appears AC coupled with long rise times…
the battery level may be low and in need of changing. Rise time will degrade as the battery voltage levels drop. We
recommend changing the battery when voltage drops below 9V, because at this point the battery level will drop
quickly.
Maintaining the DET02AFC
It is always good practice to clean the fiber ends before installing them into the FC connector. Dirt buildup will
eventually affect lighting into the detector.
There are no serviceable parts in the DET02AFC optical sensor. The housing may be cleaned with a soft damp
cloth. If you suspect a problem with your DET02AFC, please call Thorlabs and an engineer will be happy to assist
you.
