THORLABS HRP350 User manual

HRP350, HRP350-EC
High Power HeNe Laser
Systems
Operating Manual

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 2 www.thorlabs.com
Table of Contents
Part 1.Safety ............................................................................................................................................4
CE Compliance ..........................................................................................................................................................5
Part 2.Description ...................................................................................................................................6
Laser Head .................................................................................................................................................................6
Laser Power Supply ...................................................................................................................................................7
HeNe Laser Overview................................................................................................................................................7
HeNe Applications.....................................................................................................................................................7
HeNe Linewidth.........................................................................................................................................................8
HeNe Polarization.................................................................................................................................................... 10
Part 3.Unpacking ..................................................................................................................................11
3.1.Unpacking...............................................................................................................................................11
Shipping Inventory ..................................................................................................................................................11
Part 4.Set-up..........................................................................................................................................12
4.1.Mounting the Laser Head......................................................................................................................12
4.2.Assembly .................................................................................................................................................12
Part 5.Operation....................................................................................................................................13
5.1.Alignment Procedure.............................................................................................................................14
Tools Required.........................................................................................................................................................14
Procedure ................................................................................................................................................................. 14
Part 6.Troubleshooting.........................................................................................................................15
6.1.Technical Failures..................................................................................................................................15
6.2.Application Trouble Shooting...............................................................................................................15
Noise, Oscillations, and Fluctuation Sources........................................................................................................... 16
Part 7.Specifications .............................................................................................................................17
7.1.Mechanical Drawing..............................................................................................................................17
Part 8.Regulatory ..................................................................................................................................18
Part 9.Thorlabs Worldwide Contacts ...................................................................................................19

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 3 www.thorlabs.com
Table of Figures
Figure 1Laser Head, Front................................................................................................................... 6
Figure 2Power Supply......................................................................................................................... 7
Figure 3Optical Resonator Cavity....................................................................................................... 8
Figure 4HeNe Gain Curve Showing Cavity Modes............................................................................ 9
Figure 5HeNe Energy Levels.............................................................................................................. 9
Figure 6HeNe Visible Laser Lines.................................................................................................... 10
Figure 7Laser System........................................................................................................................ 11
Figure 8Laser Rear Panel .................................................................................................................. 13
Figure 9Laser Shutter Control, Picture shows the Shutter CLOSED................................................ 13
Figure 10Dimensional Drawing .......................................................................................................... 17

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 4 www.thorlabs.com
Part 1. Safety
WARNING
Laser Radiation – Avoid Exposure to Beam – Class 3R Laser Product
The laser described in this operating manual emits visible light. This laser is safe to operate provided
that the user complies with all safety warnings. It is recommended that all personnel who will operate or
be in the vicinity of the laser during operation read and be familiar with this manual as well as be made
aware of the following safety warnings.
•Never look directly into the laser light source or at scattering laser light from reflective surfaces.
Laser light is hazardous to the eyes. Never stare down the beam into the source.
•Install the laser so that the laser beam is not at eye level.
•Whenever the laser is operating and the beam is not in use, block the beam with the shutter on
the output aperture. Avoid direct exposure to the laser beam.
•As a precaution against accidental exposure to either the laser beam or its reflection, operators
should wear laser safety glasses designed for this type of laser.
•High voltage is present at all times when the key switch on the control box is in the “ON”
position.
•Ensure that the laser head is securely connected to the power supply. To prevent faulty operation,
be sure that the male connector is fully seated in the back of the power supply.
•The power cord and plug are provided with a ground line. To avoid possible shock, ensure that
the plug is properly connected to a ground point at the electrical connection.
•Do not attempt to open the sealed laser housing or the power supply. The power supply and laser
are not user-accessible and service operations inside the enclosure must only be performed by
authorized and trained personnel. Opening the laser or power supply will result in loss of
warranty.
•Do not perform any operating or maintenance procedure not described in the user’s manual.
•Do not operate this product if the cover has been removed.
•This product is for indoor use only. To prevent potential fire or shock hazard, do not expose the
unit to any source of excessive moisture.
•Operating this product in the presence of flammable gases or fumes is extremely hazardous.
•Disconnect the power cord before replacing fuses.
•Clean the laser head and power supply with a dry, soft cloth. Do not use liquids.

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 5 www.thorlabs.com
WARNING
Use of controls or adjustments or performance of procedures other than those specified
herein may result in hazardous radiation exposure. Avoid unnecessary exposure to laser or
collateral radiation that exceeds the accessible emission limits listed in the safety regulation
guidelines 21 CFR Subchapter J 1040.10 and 1040.11. This federal regulation is
administered by the National Center for Devices and Radiological Health under the Food
and Drug Administration.
Each Visible Helium-Neon Laser System that is certified to be in compliance with the CDRH
regulations is equipped with a key-switch, remote interlock connector, laser radiation emission indicator,
time delay relay (built into the power supply), a beam attenuator (a manual shutter located in the front
bezel of the laser housing), and all appropriate warning labels. To ensure continued compliance, verify
on an annual basis or, if the product has been subjected to adverse environmental conditions, such as
fire, flood, mechanical mishandling, or solvent spillage that your system’s safety features listed above
are available and operational.
For further information and assistance on laser safety, contact the following agencies:
Laser Institute of America
13501 Ingenuity Drive, Suite 128
Orlando, FL 32826
** Safety Guides **
American National Standards Institute, Inc.
25 West 43rd Street
New York, NY 10036
** Safety Guides**
Food and Drug Administration
Center for Devices and Radiological Health
2098 Gaiter Road
Rockville, MD 20850
CE Compliance
For European customers who require a CE-approved laser system, Thorlabs certifies that our laser heads
and lab power supplies meet the appropriate CE requirements. In order for the CE regulations to be met,
all Thorlabs power supplies must be used with an input line cord with a length of less than three meters.
The factory-included line cord has a length of approximately two meters. Other cords may be used, but
they must have a length of no longer than three meters in order for the laser system to remain CE
compliant.

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 6 www.thorlabs.com
Part 2. Description
Thorlabs’ high-power red (632.8) Helium-Neon gas lasers have a maximum stable output power of
50.0 mW and a fundamental Gaussian beam. The laser comes in two versions, one for 115 VAC and
another for 220 VAC voltage source. The output beam is linearly polarized.
Laser Head
This laser head comes equipped with a manual shutter installed in the front bezel of the laser housing
(see Figure 1 below). The front bezel has four #4-40 UNC holes to secure the optional accessory
mounting ring and other industry standard HeNe accessories. This laser also comes with a 3 ft long, high
voltage cable for connecting to the power supply. This particular laser head is designed to operate at an
optimum performance level when used with the required Thorlabs power supply.
Figure 1 Laser Head, Front
Manual Beam Shutter
Shutter slides side to side and is
marked ON and OFF
Laser Aperture
4 #4-40 UNC
Mounting Holes

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 7 www.thorlabs.com
Laser Power Supply
The laser includes a power supply that is specially designed to be used with the HeNe laser and is CE-
certified. The power supply is enclosed in a protective housing and is CDRH compliant with a built-in 3
to 5 second time delay, a 3-port, high-voltage connector, a key safety switch, an interlock connector, and
a removable input power cable. The power supply comes pre-configured for either 120 VAC or
240 VAC use. This configuration cannot be changed by the user and can only be setby the factory.
Figure 2 Power Supply
HeNe Laser Overview
A helium-neon laser, typically called a HeNe laser, is a small
gas laser with many industrial and scientific uses. The
primary wavelength they are used at is 632.8 nm, in the red
portion of the visible spectrum.
The gain medium of the laser is a mixture of helium and
neon gases in a 5:1 to 20:1 ratio that is contained at low
pressure in a sealed glass tube. The excitation source for
these lasers is a high voltage electrical discharge through an
anode and cathode at each end of the glass tube. The optical
cavity of the laser consists of a flat, high-reflecting mirror at
one end of the laser tube, and an output coupler mirror with
approximately 1% transmission at the other end.
HeNe Applications
•Metrology
•Cleanroom Monitoring Equipment
•Food Sorting
•Flow Cytometry
•Confocal Microscopy
•Imaging and Medical Equipment
•Opacity Monitoring
•Alignment
•Maritime Visual Guidance
Systems

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 8 www.thorlabs.com
Figure 3 Optical Resonator Cavity
Typical HeNe Parameters
Beam Diameter (D) 1 mm
Cavity Length (L) 0.15 m (0.5 mW) to 1 m (50 mW)
Reflectivity at High Reflector (HR) >99.99%
Transmission at Output Coupler (OC) ~1%
HeNe lasers tend to be small, with cavity lengths of around 15 cm up to 0.5 m and optical output powers
ranging from 1 mW to 100 mW. Thorlabs offers output powers up to 50 mW.
HeNe Linewidth
A red HeNe laser wavelength is 632.816 nm in air, though it is often reported as either 632 nm or
633 nm. The wavelength gain curve is actually made of several longitudinal modes that fluctuate within
the range due to thermal expansion of the cavity and other external factors.
The linewidth of a HeNe laser is specific to the application. The axial mode structure of the HeNe laser
is characterized by the number of modes, the free spectral range (FSR), and the Doppler width (see
Figure 4 below). The linewidth of individual axial modes is usually small (~kHz) and is primarily
determined by external factors and measurement timescales rather than fundamental laser parameters. In
most interferometric applications, the most relevant parameter is the coherence length, which is
determined by the axial modes that are furthest apart. For a red HeNe laser, the coherence length is
approximately 30 cm.
D
L
Anode
High
Reflector
Output
Coupler
Helium-Neon Gas Mixture
Glass Tube
Laser Bore Tube
Cathode

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 9 www.thorlabs.com
Figure 4 HeNe Gain Curve Showing Cavity Modes
The laser process in a HeNe laser starts with the collision of electrons from the electrical discharge with
the helium atoms in the gas. This excites helium from the ground state to a long-lived, metastable
excited state. Collision of excited helium atoms with ground-state neon atoms results in excited neon
electrons.
Figure 5 HeNe Energy Levels
The number of neon atoms entering the excited states builds up until population inversion is achieved.
Spontaneous and stimulated emission between the states results in emission of 632.82 nm light along
with other emission wavelengths. From these states, the electrons quickly decay to the ground state. The
HeNe laser’s power output is limited because the neon upper level saturates with higher current, while
the lower level varies linearly with current.
Neon Gain
Curve
FWHM ~1.5 GHz
Frequency
Gain/Output Power
Lasing
Cavity Modes
Lasing
Threshold
FSR ~1000 MHz
Short (0.2 m) Laser
FSR ~200 MHz
Long (1 m) Laser
Energy (Electron Volts)
Ground States
Metastable Collision
Metastable Collision
e Impact
3S2
1S
3S2S2
1S
2P4
3P4
(20.66 eV)
(20.30 eV)
(20.61 eV)
(19.78 eV) (19.78 eV)
(18.70 eV)
1
2
5
10
21
20
19
18
17
16
(16.70 eV)
(3391.2 nm Laser)
(632.8 nm Laser)
(1152.3 nm Laser)
Diffusion
Helium Neon

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 10 www.thorlabs.com
The laser cavity can be designed with the correct mirrors and length to promote other wavelengths of
laser emission. There are infrared transitions at 3.39 μm and 1.15 μm wavelengths, and a variety of
visible transitions, including a green (543.365 nm, sometimes called GreeNe laser), a yellow
(593.932 nm), a yellow-orange (604.613 nm), and an orange (611.802 nm) transition. The typical red,
633 nm wavelength output of a HeNe laser actually has a much lower gain compared to other
wavelengths, such as the 1.15 μm and 3.39 μm lines.
Figure 6 HeNe Visible Laser Lines
HeNe Polarization
Unpolarized (Randomly Polarized) Beam
The output of an unpolarized HeNe laser consists of a rapidly fluctuating, linearly polarized beam whose
polarization orientation changes on a nanosecond time scale. Unpolarized lasers are ideal for
applications where there are no polarizing elements in the beam path. Depending on the time scale of an
application, large power fluctuations are possible.
Polarized Beam
The state of polarization in a polarized HeNe laser beam is linear, making these lasers ideal for
polarization-sensitive applications.
500 550 650
Wavelength (nm)
HeNe Visible Laser Lines
750600 700

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 11 www.thorlabs.com
Part 3. Unpacking
3.1. Unpacking
Inspect the packing container for any damage that may have occurred during shipment. Contact your
local Thorlabs customer service office for assistance. Packing materials are specifically designed to
protect against shipping damage. Please keep this container and reuse if your system needs to be
returned to Thorlabs for service or evaluation.
Carefully remove the laser system from the packing container. Inspect for damage, including dents and
scratches. There should not be anything rattling around inside the laser head. Rarely, during shipping,
the glass tube may break.
Figure 7 Laser System
Shipping Inventory
The equipment included in this shipment should match the packing slip attached to the box. Verify that
the correct product was shipped to you by matching the item number on the box. If the shipment is
incomplete, or if an incorrect item was shipped to you, please notify Thorlabs immediately.
This package should contain:
•Square Laser Head
•Power Supply Module
•2 Keys for Power Supply
•Remote Interlock for Power Supply
•Manual and Quick Start Selection Guide
Power Suppl
y
Module
AC Power Cord
Make sure the plug is the
correct version for your
region
Laser Head
Laser head with manual shutte
r
Accessories
Power switch keys and interlock
connecto
r

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 12 www.thorlabs.com
Part 4. Set-up
4.1. Mounting the Laser Head
The square housing sits securely on a flat surface, and no special mounting hardware is needed. The
front bezel has four #4-40 UNC holes to secure standard HeNe optional accessories.
4.2. Assembly
It is suggested that the HeNe Laser Quick Start Guide be used to assemble the laser system. Below are
the steps needed to assemble the laser system.
1) This laser system includes either a 120 or 240 VAC power supply designated by the part number
– HRP350 or HRP350-EC respectively. The power supply does not need to be manually set for
the appropriate regional current, but the correct mains voltage cord must be used.
2) Plug the three-hole, high-voltage cable from the laser into the front of the power supply. Confirm
that the plug is well-seated. Failure to plug the connector all the way in can result in the laser
failing to lase or arcing and damaging the power supply or laser head.
3) Connect the phono plug into the power supply.
4) Insert the interlock connector and twist until it locks in place. The power indicator light will turn
on, even if the interlock is not inserted or inserted fully, and the laser will not lase.
Incorrectly Inserted Correctly Inserted
5) Insert the power switch keys into the power supply.
Connector not
locked into place

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 13 www.thorlabs.com
Part 5. Operation
To operate the laser system, follow the following procedures.
1) Make sure the laser is pointing safely away from people and is securely mounted.
2) Turn the key safety switch on the back of the unit. NOTE: There is a 3 to 5 second CDRH safety
delay before the voltage turns on.
Figure 8 Laser Rear Panel
3) Open the aperture by sliding the lever left so the ON label is visible.
Figure 9 Laser Shutter Control, Picture shows the Shutter CLOSED.
3-Port, High-Power Connector Power On/Off Key
Power ON/OFF safety key.
Lever Slides
OffOn
Power Mains
Phono Plu
g
Power On LED
Lights when key switch is
turned, not when laser is lasing.
Interlock Connector
Make sure the interlock is
connected and fully seated.
Fuses

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 14 www.thorlabs.com
4) Some models may take up to 60 seconds to begin to lase (typically the 7" versions). If the laser
has not started lasing 20 seconds after turning the power on, you can turn the unit off and then
back on again. This will not damage the laser. Be sure to give enough time to allow the CDRH
safety delay to elapse before turning the system off and on.
5.1. Alignment Procedure
During shipment or rough handling, the Thorlabs model HRP350 and HRP350-EC laser may become
slightly misaligned and suffer a reduction in output power. The following procedure should be used to
optimize the laser alignment.
Tools Required
•(2) 1/16" Allen Wrench
•(1) Optical Power Meter
Procedure
1) Locate the two access holes for the alignment screws. These are located on the side of the
housing approximately 175 mm from the rear, at the top edge of the side label.
2) Insert one Allen key into each access hole and set up the optical power meter to monitor the laser
output power. Carefully tighten one of the adjustment screws only enough to produce a
measurable change in the laser output power. If the laser power increases, continue to tighten the
screw until a maximum in the laser output is observed. If the laser power decreases, loosen the
screw until the laser is at a maximum power. Repeat this procedure for the second adjustment
screw. In cases where large adjustments are made, it may be necessary to repeat this procedure a
second time in order to obtain the optimal performance.
WARNING
Avoid Exposure – Use of controls or adjustments or performance of procedures other than
those specified herein may result in hazardous radiation exposure. (FDA caution statement
21 CAR 1040.10(h)(1)(IV)). It will also void your warranty.
WARNING
Unauthorized modifications to the laser or power supply may cause irreversible damage to
the system, as well as result in possible hazardous radiation exposure. These modifications
will also void all warranties. Repairs to such modified equipment will be charged at the
current repair rate, plus the cost of any required parts.
!
!
!
!

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 15 www.thorlabs.com
Part 6. Troubleshooting
6.1. Technical Failures
Problem Fix
No light being emanated from the
laser Make sure that aperture is open.
Check to make sure:
•the power supply is set to the correct voltage,
•is plugged into a working outlet,
•the power cord is fully seated into the power supply,
•the phono plug is connected,
•the 3-port, high-power plug is firmly seated into the power supply,
and
•the aperture is open.
The laser can take up to 60 sec to begin to lase. Turning the power off then
on again can speed up the start time without damaging the laser. Note: there
is a built in CDRH safety delay of 4 - 5 seconds. Be sure to wait longer
than 5 seconds to turn the laser off then on.
The laser does not work and there is
something rattling around inside
the laser head tube
The glass gas tube may have broken during shipping. Please contact your
local tech support office for help.
The power supply does not turn on
The power supply Laser On
Indicator does not light
Make sure the power supply is plugged in.
There is a clicking noise in either the
power supply or laser Arcing in the laser head or the power supply can result in a flickering laser or
the laser not igniting at all. Turn off the power and contact your local tech
support office immediately.
The laser has low output power The laser requires 30 minutes to meet published specifications. Make sure to
let it warm up.
Make sure the laser is mounted correctly. See page 12 for proper mounting
techniques.
6.2. Application Trouble Shooting
Some sources of trouble for a HeNe laser do not come from the laser failing or being out-of-spec.
Instead, these lasers are not suited to the application. One common mis-application comes from a HeNe
laser, especially a low power one (0.5 mW) being used in a metrology application.
Environment is an important consideration as well. Dirty environments can cause the optics to become
contaminated and the power output to drop below expected levels. Unstable output beams can be caused
by noisy environments with large sources of vibrations. Proper mounting on an optical table can reduce
the effects of ambient vibrations. Temperature is also a factor. If the environment where the laser is
being used fluctuates in temperature, the output power can experience a large amplitude change. Even
blowing on the laser tube can cause the output power to fluctuate significantly.
Randomly polarized lasers are actually rapidly changing, single polarization lasers. Averaged over time,
these lasers appear as randomly polarized light. However, any polarization optics in the path (intentional
or unintentional) can cause large variations in the output power. These applications should only be used
with a polarized laser.

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 16 www.thorlabs.com
While a HeNe laser is less sensitive to variations caused by back reflections, they are not immune to it.
Large retro-reflections back into the laser can cause unpredictable power changes. A free-space isolator
can be used to reduce or eliminate these effects. If possible, only a small angular deviation is needed to
eliminate the back reflections.
These HeNe lasers are ill-suited to any application or experiment where single frequency or long
coherence length is required.
Noise, Oscillations, and Fluctuation Sources
There are many sources of noise, oscillations and fluctuations of the output of a HeNe laser. One of the
most common is from longitudinal modes drifting into and out of the gain curve. The frequency of these
fluctuations vary from very slow, less than a hertz, to as much as several kHz depending on the stability
of the environment.
Other, more constant sources of fluctuations include the following (with corresponding frequencies):
•Line noise from AC high voltage power supplies (50/60 Hz, 100/120 Hz, etc)
•Switching noise from DC high voltage power supplies (40 kHz)
•Plasma oscillation (tens of MHz)
•Transverse mode beat notes (hundreds of MHz)
•Axial mode beats (at FSR, hundreds of MHz)

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 17 www.thorlabs.com
Part 7. Specifications
Item # HRP350 HRP350-EC
Wavelength 633 nm
Min Output Power 35.0 mW
Maximum Output Power 50.0 mW
Noise (30 Hz – 10 MHz) <1% rms
Polarization Linear > 500:1
Mode Structure TEM00 > 99%
Beam Diameter 1.22 mm
Beam Divergence 0.66 mrad
Beam Drift1<0.2 mrad
Long Term Beam Drift <0.05 mrad
Longitudinal Mode Spacing 163 MHz
Starting Voltage <10 kV (DC)
Operating Voltage (DC) 3200 V
Operating Current 9.00 mA
Series Resistors in Housing 94 KΩ
Shock 15 g for 11 msec
CDRH/CE Classification IIb/3B
Weight 5400 g
Fuse ACG-5 5 amp
Listed, 448H, Min Fuse
IR 10kA 125 VAC
ACG-5 5 amp
Listed, 448H, Min Fuse
IR 200A 250 VAC
7.1. Mechanical Drawing
Figure 10 Dimensional Drawing
1After 30 minute Warm-Up
Ø1.417"
(Ø36 mm)
3.75"
(95.3 mm)
3.75"
(95.3 mm)
4-40 Unc Thread
4 Places
Laser
Beam
40.16"
(1020 mm)

1
P
A
C
t
A
o
I
f
8
I
r
8
I
T
p
T
l
1
2112-S01 Re
v
P
art 8.
A
s required
C
ommunity
t
o return “e
n
•This
•Sold
•Mar
k
•Sold
•Curr
e
•Still
c
A
s the WE
E
o
f life take
b
•Pure
driv
e
•Com
p
•Mec
h
•Left
o
I
f you wish
t
f
or further i
n
8
.1. Wa
s
I
f you do no
t
r
ecovery. D
o
8
.2. Ec
o
I
t is well kn
o
T
he aim of
p
roducts in t
h
T
he intent o
f
l
ife products
v
CB, August
3
Regula
t
by the W
E
and the cor
r
n
d of life” u
n
offer is vali
d
after Augus
t
k
ed correspo
to a compa
n
e
ntly owned
c
omplete, n
o
E
E directive
b
ack service
OEM prod
u
r cards)
p
onents
h
anics and o
p
o
ver parts o
f
t
o return a
T
n
formation.
s
te Treat
m
t
return an “
e
o
not dispos
e
o
logical
B
o
wn that W
E
the Europe
a
h
e future.
f
the WEEE
will thereb
y
3
1, 2010
t
ory
E
EE (Waste
r
esponding
n
n
its without
i
d
for Thorla
b
t
13, 2005
ndingly wit
h
n
y or institu
t
by a comp
a
o
t disassem
b
applies to s
e
does not re
fe
u
cts, that m
e
p
tics
f
units disas
s
T
horlabs un
i
m
ent is
Y
e
nd of life”
u
e
of the unit
B
ackgrou
E
EE pollute
s
a
n RoHS d
i
directive is
y
avoid neg
a
Electrical
n
ational law
i
ncurring di
s
b
s electrical
h
the crosse
d
t
e within the
a
ny or instit
u
b
led and not
e
lf-containe
d
fe
r to other
T
e
ans assem
b
s
embled by
t
i
t for waste
r
Y
our Ow
n
u
nit to Thor
l
in a litter bi
n
nd
s
the enviro
n
i
rective is t
to enforce
t
a
tive impact
s
Page 18
and Electro
s, Thorlabs
s
posal charg
and electro
n
d
out “whee
l
EC
u
te within th
e
contaminat
e
d
operation
a
T
horlabs pro
d
b
lies to be b
u
t
he user (P
C
r
ecovery, pl
n
Respon
l
abs, you m
u
n
or at a pu
b
n
ment by re
l
o reduce t
h
t
he recyclin
g
s
on the env
i
o
nic Equip
m
offers all e
n
es.
n
ic equipme
l
ie bin” log
o
e
EC
ed
a
l electrical
a
d
ucts, such
a
u
ilt into a u
C
B’s, housin
g
ease contac
t
n
sibility
u
st hand it t
o
b
lic waste di
l
easing toxi
c
h
e content
o
g
of WEEE.
i
ronment.
R
e
m
ent Directi
v
n
d users in t
h
nt:
o
(see right)
and electro
n
a
s:
u
nit by the
u
g
s etc.).
t
Thorlabs
o
o
a compan
y
sposal site.
c
products d
u
o
f toxic sub
s
A controlle
e
d HeNe Las
e
www.th
v
e) of the
E
h
e EC the p
n
ic products
,
u
ser (e. g. O
E
o
r your near
e
y
specialize
d
u
ring deco
m
s
tances in
e
d recycling
Wheelie Bi
n
e
r System
orlabs.com
E
uropean
ossibility
,
this end
E
M laser
e
st dealer
d
in waste
m
position.
e
lectronic
of end of
n
Lo
g
o

Red HeNe Laser System
12112-S01 Rev CB, August 31, 2010 Page 19 www.thorlabs.com
Part 9. Thorlabs Worldwide Contacts
For technical support or sales inquiries, please visit us at www.thorlabs.com/contact for our most up-
to-date contact ininformation.
USA, Canada, and South America
Thorlabs, Inc.
s[email protected]
[e-mail]
Europe
Thorlabs GmbH
[email protected]
France
Thorlabs SAS
[email protected]
Japan
Thorlabs Japan, Inc.
[email protected]
UK and Ireland
Thorlabs Ltd.
[email protected]
[e-mail]
Scandinavia
Thorlabs Sweden AB
[email protected]
Brazil
Thorlabs Vendas de Fotônicos Ltda.
[email protected]
China
Thorlabs China
[email protected]

Thorlabs,
I
435 Route 2
0
N
ewton, NJ
0
Phone: (973
)
www.thorla
b
I
nc.
0
6N
0
7860 USA
)
579-7227 ♦
F
b
s.com
ax: [phone]
