Thule Sidearm 594XT User manual

part description part number qty.
A 85370205602 1
B 8535972 2
C 8535973 2
D 7533579 1
E 7533710 1
F 853147704 2
G 7533704 1
H 8535976 2
I 919061211 2
J 8537557 2
K 951061211 2
L 8535960 2
M 7533591 1
N 8537006 1
O 8537026 1
P 8535513 3
Q 7530745 2
R 915065554 6
S 8530333 2
T 8536395 1
U7533236 2
V8533160 2
W 8530930 1
X 8537024 1
Y 853597602 2
Z 951081611 2
AA 938080011 2
BB 8537021 4
CC 915066554 6
DD 7530783 4
EE 8537441 3
FF 8537442 4
GG 915068054 6
HH
wheel tray 56" silver
screw phillips 10-32 x 1.5
10-32 nylon insert locknut
locking ratchet arm assembly
hook assembly
tube cap
base plate
M8 x 1.25 x 25mm
allen bolt M6 x 12
square nut
washer 6mm ID /
rql arm bearing half
bearing clamp
wheel strap assembly
lock cover 594
metal bracket
knob 3 wing high M6 x 1 nut
carriage bolt 6 x 55
plate square for wheel tray
lock cover plug
tray end cap with logo
lock plug
hex key M5
wheel loop coated 594
M8 x 1.25 x 20mm zinc II black
washer 8mm id 16mm od
lock nut M8
flat nylon washer M8
carriage bolt 6 x 65
knob 3-wing low M6x1 nut
plastic spacer mount
rubber leveling gasket
carriage bolt 6 x 80
road bike adapter 8535426 1
SIDEARM™594XT
PARTS INCLUDED
B
M
F
L G AA
BB
Y
C
Z H
X
A
EN O U P
GG CC WFF QDD
K
I
V
REE J
T S HH

NOTE: The 594 SidearmTM comes assembled for passenger side application.
Follow steps for driver side application before continuing.
Please refer to the fit guide at the back of these instructions to determine if your vehicle requires
the 55mm, 65mm or 80mm carriage bolts for fitting the carrier to your vehicle’s factory rack.
TOOLS REQUIRED
• 13mm wrench or adjustable wrench.
• #2 phillips screw driver.
• 1 - Tape measure
CARRIER INSTALLATION /
1
• Turn carrier over and loosen both bolts using 5mm hex wrench provided.
• Slide base plate in channel to the end of the tray. Separate the bracket from the tray.
2
• Install 2 carriage bolts into square holes in base
plate, closest to ratchet arm assembly, as illustrated.

CARRIER INSTALLATION
3
• Slide tray onto base plate. The edge of the base plate should be 16" from the
front edge of the wheel tray.
• Turn carrier over and tighten bolts with 5mm hex wrench provided.
CARRIER INSTALLATION /
4
CAUTION: Tray may have sharp edges.
• Drop 1 carriage bolt into 2 washer plates and
insert into tray channel on bottom of tray
as shown.
• Slide strap into tray channel.
• Buckle on same side of rachet arm.
• Flex tab up.
• Slide end cap on.
16"

5
• Attach rubber leveling gasket to bottom of rubber risers as shown. If you’re attaching to a
factory rack and it slopes, you should add a second rubber leveling gasket underneath the
first one on side closest to the vehicle door to level the bike carrier.
FRONT HARDWARE
6
•Place carrier on roof rack load bars with ratchet arm pivot centered over load bar.
• Install plastic spacer mount, rubber leveling gasket, metal bracket and 3-wing low knobs
onto bolts in that order around the load bar as illustrated.
• Tighten 3-wing knobs firmly.
FRONT HARDWARE
7
• Install 3-wing high knobs, plastic spacer mount, rubber leveling gasket, metal bracket
and bolts in that order around the load bar as illustrated.
• Tighten 3-wing knobs firmly.
REAR HARDWARE
8
• Install plastic spacer mount, rubber leveling gasket, metal bracket and 3-wing low knobs
onto bolts in that order around the load bar as illustrated.
• Tighten 3-wing knobs firmly.

NOTE: If not installing lock cylinders, please insert plastic lock
plugs into lock cylinder holes as shown.
LOCK PLUG INSTALLATION
9
•Insert change key into lock cylinder.
•Remove change key, insert key to lock and unlock.
•Insert lock plug on opposite side of grip, into the lock cylinder.
WARNING: Ensure ratchet arm is fully engaged to bicycle wheel before locking.
LOCKING FEATURES: BIKE TO CARRIER (LOCKS SOLD SEPARATELY)
10

NOTE: To secure cover with out lock core, use lock plug (853-6395)
LOCKING FEATURE: CARRIER TO VEHICLE (LOCKS SOLD SEPARATELY)
11
•Follow Lock core installation procedure above for lock cover. • Snap cover onto base plate. Turn key to lock.
LOADING BICYCLE
12
Position Ratcheting Arm in forward position.
• Press gray trigger on grip and hook assembly and slide
to fully extended position.
• Place bike in wheel tray with front wheel in contact with
wheel loop.
NOTE: Minimum bar spread spacing is 18"
(eighteen inches) and Maximum bar
spread is 36" (thirty-six inches).

WARNING: The support arm V-notch must be firmly seated against the tire and brake or fork. Failure to do so may result in bike instability. Always shake your bike to
ensure the hook is fully seated.
LOADING BIKE
13
• While holding the bike with one hand rotate the support arm, until it sits within 1" of the
bicycle brake or fork crown.
• Ratchet the arm tightly against the wheel. You should hear a minimum of 2 clicks past
initial contact with the tire.
SECURE REAR TIRE
14
Road bike only.
• Slide on adapter.
Mountain bike only.
• Invert or remove for
mountain bikes.
LOADING BIKE /
15
• Feed the strap throught the ratcheting cam.
• Close the cam handle.
NOTE: Cam strap should be tight against the rim of the bicycle.

DRIVERSIDE INSTALLATION
16
• Follow step 1 for Installation.
• Remove wheel loop using 13mm wrench and 5mm hex wrench.
DRIVERSIDE INSTALLATION
17
• Position wheel loop on opposite side of base plate.
• Install bolts, washers and lock nut and tighten firmly.
DRIVERSIDE INSTALLATION
18
• Loosen bolts on support arm pivot using 5mm hex wrench.
• Remove support arm and bracket from pivot tube..

NOTE Lock core in grip handle can be reversed using change key.
• Loosen and remove both screws on hook-grip assembly.
• Rotate hook 180°
• Re-install screws and nuts and tighten firmly.
• Repeat steps 3-7 of Installation for completion.
DRIVERSIDE INSTALLATION
19
• Remove bearing halves from
pivot tube.
• Rotate both bearing halves on
pivot tube.
• Re-install support arm, bracket
and fasteners with trigger on
grip handle facing down.
DRIVERSIDE INSTALLATION
20

ACURA
MDX '07-14 ü
RDX '07-14 ü
TSX Sport Wagon '11-14 ü
ZDX '10-13 ü
AUDI
Allroad '13-14 ü
A4 (Avant) Wagon '02-12 ü
A6 Wagon '06-11 ü
Q5 '09-14 ü
Q7 '07-14 ü
S4 Wagon '01-08 ü
BMW
X6 '09-14 ü
BUICK
Enclave '08-14 ü
Encore '13-14 ü
Ranier '04-07 ü
Rendezvous '02-07 ü
CADILLAC
CTS Sport Wagon 5DR '10-14 ü
Escalade / Escalade ESV '99-15 ü
Escalade EXT Pickup '02-15 ü
SRX (Except "Sport Models") '04-14 ü
CHEVROLET
Astro Van (Cargo & Passenger) '94-05 ü
Avalanche '02-13 ü
Blazer '95-05 ü
Captiva '11-14 ü
Equinox '05-14 ü
CHEVROLET (continued)
HHR '06-11 ü
Spark 5DR '13-14 ü
Suburban / Suburban Z71 '92-15 ü
Tahoe / Tahoe Z71 '95-15 ü
Tracker '02-04 ü
Trax '13-14 ü
Traverse '09-14 ü
Venture '97-04 ü
CHRYSLER
Pacifica '04-08 ü
PT Cruiser '01-10 ü
Town & Country '96-14 ü
Voyager / Grand Voyager '01-03 ü
DODGE
Caliber / SRT4 / SXT '07-12 ü
Caravan / Grand Caravan '96-14 ü
Durango / Durango Sport '98-14 ü
Journey '08-14 ü
Nitro '07-11 ü
FORD
Edge / Edge Sport '07-14 ü
Escape '01-14 ü
Escape (Glass Roof) '13-14 ü
Expedition / Expedition EL '97-14 ü
Explorer '91-14 ü
Explorer Sport '01-03 ü
Explorer Sport Trac '01-10 ü
Flex '08-14 ü
Freestar '04-07 ü
Taurus Wagon '96-06 ü
Windstar '98-03 ü
GMC
Acadia '07-14 ü
Denali '98-06 ü
Denali XL '00-06 ü
Envoy '98-01 ü
Jimmy '95-01 ü
Safari Van (Cargo & Passenger) '90-05 ü
Suburban '92-99 ü
Terrain '10-14 ü
Terrain Denali '12-14 ü
Yukon / Yukon XL '92-15 ü
Yukon Denali / Yukon Denali XL '07-15 ü
HONDA
Crosstour '10-14 ü
CR-V '02-14 ü
Element / Element SC '03-11 ü
Odyssey '01-14 ü
Passport '98-02 ü
Pilot '03-14 ü
Ridgeline / Ridgeline Sport '06-14 ü
LOAD BARS
RECOMMENDED
BOLT SIZE (mm)
55 65 80
THULE
AEROBLADE (ARB) BARS ü
RAPID AERO (RB) BARS ü
STEEL (LB) BARS ü
422 XSPORTER BARS ü
500 XSPORTER PRO BARS ü
PRO BARS ü
INNO
LOAD BAR ü
SPORTRACK
LOAD BAR ü
YAKIMA
ROUND BAR ü
WHISPBAR ü
VEHICLE MAKE, MODEL, AND YEAR
RECOMMENDED
BOLT SIZE (mm)
55 65 80
VEHICLE MAKE, MODEL, AND YEAR
RECOMMENDED
BOLT SIZE (mm)
55 65 80
2014 ACCESSORY TO FACTORY RACK FIT GUIDE
Circuit™526, Paceline™527 and Sidearm™594XT
NOTE: If your vehicle is not listed below, it may be a no fit. Please refer to www.thule.com for the most up-to-date fit information.

HUMMER
H3 '05-10 ü
H3T '09-10 ü
HYUNDAI
Elantra GT 5DR '13-14 ü
Entourage '07-10 ü
Santa Fe '01-14 ü
Santa Fe Sport '13-14 ü
Tucson '05-14 ü
INFINITI
EX 35 '08-12 ü
EX 37 '13 ü
FX 35 '03-13 ü
FX 45 '03-08 ü
FX 50 '09-13 ü
QX4 '97-03 ü
QX50 '14 ü
QX56 '04-13 ü
QX60 '14 ü
QX70 '14 ü
QX80 '14 ü
ISUZU
Ascender '03-10 ü
Rodeo '98-04 ü
JEEP
Cherokee '14 ü
Commander (Standard Crossbars) '06-10 ü
Compass / Rallye '07-14 ü
Grand Cherokee '93-14 ü
Liberty '02-12 ü
Patriot '07-14 ü
KIA
Borrego '09-12 ü
Carens '07-14 ü
Rondo '07-14 ü
Sedona '02-14 ü
Sorento '03-14 ü
Soul '10-14 ü
Sportage '11-14 ü
LAND ROVER
Evoque 5DR '12-14 ü
LR2 '07-14 ü
LR3 '05-09 ü
LR4 '10-14 ü
Range Rover / Range Rover Sport '98-14 ü
LEXUS
GX '03-14 ü
LX '99-14 ü
RX '04-14 ü
LINCOLN
Aviator '03-05 ü
MKX '07-14 ü
Navigator '98-14 ü
MAZDA
CX-5 '12-14 ü
CX-9 '07-14 ü
MPV '00-06 ü
Protégé 5 Wagon '02-03 ü
Tribute '01-11 ü
MERCURY
Mariner '05-10 ü
Monterey '04-07 ü
Mountaineer '96-10 ü
Sable Wagon '96-05 ü
Villager '93-02 ü
MINI
Clubman '08-14 ü
MITSUBISHI
Endeavor '04-11 ü
Montero Sport '97-00 ü
NISSAN
Armada '04-14 ü
Frontier 4DR Crew Cab '00-14 ü
Murano '03-14 ü
Pathfinder '96-14 ü
Quest '99-14 ü
Rogue '08-13 ü
Xterra '00-14 ü
OLDSMOBILE
Bravada '91-04 ü
Silhouette '97-04 ü
PONTIAC
Aztek '01-05 ü
Montana '99-05 ü
Torrent '06-09 ü
Trans Sport '97-98 ü
Vibe '03-10 ü
PORSCHE
Cayman '06-13 ü
SATURN
Outlook '07-10 ü
Vue '02-05 ü
VEHICLE MAKE, MODEL, AND YEAR
RECOMMENDED
BOLT SIZE (mm)
55 65 80
VEHICLE MAKE, MODEL, AND YEAR
RECOMMENDED
BOLT SIZE (mm)
55 65 80
2014 ACCESSORY TO FACTORY RACK FIT GUIDE
Circuit™526, Paceline™527 and Sidearm™594XT

SUBARU
Baja 4DR '03-07 ü
Forester '98-14 ü
Impreza 5DR '12-14 ü
Impreza WRX / WRX STI 4DR '02-14 ü
Impreza WRX / WRX STI 5DR '02-14 ü
Legacy Wagon '95-99 ü
Outback Sport '02-11 ü
Outback Sport / WRX / STI Wagon '02-11 ü
Outback Wagon '00-14 ü
Tribeca '06-14 ü
XV Crosstrek '12-14 ü
SUZUKI
Grand Vitara '06-13 ü
XL-7 '07-09 ü
TOYOTA
4Runner '90-14 ü
FJ Cruiser '07-14 ü
Highlander '01-14 ü
Land Cruiser '98-14 ü
Matrix '03-14 ü
RAV4 '01-12 ü
Sequoia '01-14 ü
Sienna '98-14 ü
Tacoma 4DR Quad Cab '05-14 ü
Venza '09-14 ü
VOLKSWAGEN
Golf Wagon (Canada) '10-14 ü
Jetta SportWagen '09-14 ü
Routan '09-14 ü
Tiguan '08-14 ü
Touareg '04-14 ü
VOLVO
V50 '05-11 ü
V70 '98-10 ü
V70 XC '98-10 ü
XC60 '09-14 ü
XC70 '01-14 ü
XC90 '03-14 ü
VEHICLE MAKE, MODEL, AND YEAR
RECOMMENDED
BOLT SIZE (mm)
55 65 80
2014 ACCESSORY TO FACTORY RACK FIT GUIDE
Circuit™526, Paceline™527 and Sidearm™594XT
