THUNDER TIGER P-51D MUSTANG User manual

JE6809
Assembly Manual
Warranty
This kit is guaranteed to be free from defects in material and workmanship at the date of purchase.
It does not cover any damage caused by use or modification. The warranty does not extend beyond
the product itself and is limited only to the original cost of the kit. By the act of building this user-
assembled kit, the user accepts all resulting in liability for damage caused by the final product. If the
buyer is not prepared to accept this liability, it can be returned new and unused to the place of
purchase for a refund. Neither your dealer nor Thunder Tiger Distributors, can accept kits for return if
construction has begun.
Notice: Adult Super Vision Required
This is not a toy. Assembly and flying of this product requires adult supervision.
Read through this book completely and become familiar with the assembly and flight of this airplane.
Inspect all parts for completeness and damage. Browse www. thundertiger. com for customer service
if you encounter any problems.
1
No.4580
1/8 P-51DMUSTANG
Specifications:
Wing Span:56 1/4(1430mm)
Length: 50"(1269mm)
2
Wing Area:38.15dm
Weight: 5lbs. (2450-2650g)
24

INTRODUCTION
Tools-Model assemblycan be much easierif theproper
tools are used. Therefore we have included in our
checklist toabove, a complete listingof allthe toolswe
used to assemble our prototype models. As you will
notice, many household tools can be utilized during
construction.
Engine The Thunder TigerPRO-46 and F-54S are the
ideal engines for this airplane. These quiet running
engines are easy tostart, require no special break in
periods, are very easy tomaintain and will lastfor years.
Flight Equipment There are several “support” items
that youwill need to purchasein orderto getyour engine
running andyour plane in theair.These arelisted atthe
bottom.
ITEMS NEEDED
Introduction
Introduction.....................................2
Other Items Required.......................2
Items Need Check List.....................3
Parts Drawing..............................4-5
Pre-Assembly Notes......................6
Wing..........................................7-9
Tail...........................................10-11
.................................12Landing Gear
TABLEOF CONTENTS
Achecklist isalso providedon thenext pagewhich willmake shoppingfor theseitems easier.
OTHER ITEMSREQUIRED FORASSEMBLY
Radio - A4- channel radio with4 standard servos is
required. Most lower priced 4-channel radios only
come with threestandard servos so you may need to
purchase the fourth servo separately. If you fly witha
Nitro Powerunit then5 servosare required.
OBL FlightEquipment Needed CheckList
2~3 APC 12X8EPropeller
4SIP 14.8V4000mAh Lipo BatteryPack
Comprehensive ItemsNeeded Check List
4-Channel Radiowith 4Standard Servos
TwoExtended Cords(12"), one Ycord.
5-Minute Epoxy(4 ouncesor so)
30-Minute Epoxy(4 ouncesor so)
"Thin" InstantAdhesive(1/2 ounce)
"Thick" InstantAdhesive(1/2 ounce)
Hobby Knifeand Blades
Epoxy MixingSticks and/orBrushes
Sandpaper (150 grit)
Masking Tape
Rubbing Alcohol
Paper Towels
Ruler
90 DegreeTriangle
Waxed Paper
Fine-Point, Felt-TipPen
Misc. HouseholdTools
Drill and Bits(1/16", 5/64",1/8",1/4",5/16")
Nitro Flight EquipmentNeeded Check List
Foam RubberPadding forthe radio
Stick onLead Stripfor balancingthe plane
3 or 4Props (see engineinstructions)
10%-15% GlowFuel
Fuel Pumpor Bulb
Electric Starteror "Chicken Stick"
Glow starter
Extra GlowPlug(s)
Silicon Tubing
OBLPower Unit....................................13
Radio.................................................14
Canopy............................................15
Nitro Power Unit..............................16-18
Retract.....................................19-20
Decal.......................................21
Balance.............................................22
Your Next Choice ..............................23
Adhesives- You willneed twotypes ofadhesives for the
Tiger Trainer - Epoxy and Instant (cyanoacrylate )
adhesives. We recommend that you purchase both 5-
minute and 30-minute epoxy to cutdown onassembly
time, butyou can getby with only30-minute epoxy iftime
is no important. Youwill also needa small bottleof both
"Thick" and"Thin" instantadhesive.
Battery: Recommend the useof a14.8V 4000mAh Lipo
battery.
Charger: Select a quality field charger to charge the
battery.
OBL Power
Brushless Motor: If you would use electric motor
instead of a Nitro Engine then the OBL36/07-46A
( No.2367 ) is a perfect choice to install on Tiger
Trainer OBL.
Controller: ACE BLC-40A ( No.8027 ) is a perfect
controller that controllingOBL motorefficiently.
Congratulations onthe purchaseof ourfinest scale ARF. As themost successfulfighters inWW2, atruly
incredible aircraft changed thewar for allied air forces, the P-51D Mustang has enjoyeda reputationas
America' sfavorite fighter. Itis anaircraft notonly combinedspeed withagility, but alsohad along range
and powerfulpunch. ThunderTigeris veryproud topresent the P-51D with its majesticflying capabilities
and great looks toall R/C hobbyists alikeworldwide. Nowevery pilot can flythis most famous fighter
flying fieldtither byNitro orElectric power.
No.9041
BLC-40A
Power UnitRequired
Nitro power
No.9800
32
14.8V Lipo 4000mAh

360cc (12oz)
AS6471 Fuselage
AS6472 Wing
Fuselage(1)
Left Wing(1) Right Wing(1)
Wing Bolt(2)
Plywood
Wing Joiners(3) Servo Case(2) 2X8mm Washer
Wood Screw(8) Machine
Guns(2)
Retract Servo
Mount(4)
AS6473 HorizontalTail
Horizontal Tail
CA Hinge(6)
CA Hinge(3)
AS6474 Vertical Tail
VerticalFin/Rudder(1)
Captain Eddy(1)
No.3019
Captain Eddy
AS6475 Cowling
Cowling(1)
2X8mm Washer
Wood Screw(6)
3296 Wheel
Wheel(2)
AS6477 Canopy
Canopy(1)
Cockpit(1) 2X8mm Washer
Wood Screw(5)
AS6478 Linkages
Straight
Threaded End(2)
Clevis(4)
Z-Bend ThreadedEnd 2)
3264 FuelTank
Tank(1)
Silicone
Tub(1) Fuel Stopper(1) Straight Nipple(1)
Cap(1) Crank
Weight(1) 90-degree
Nipple(1)
AS6007 ScaleTailGear
3X12mm
Wood Screw(1)
3X15mm
Wood Screw(1) 3X3mm Set Screw(1)
AS6479
Control Horn
Control Horn(4) Back
Plate(4)
2X20mm
Screw(4) 2X15mm
Screw(4)
PE0009 EZConnector
1.5mm
Hex Wrench
EZ Connector(1)
3X3mm
Set Screw(1)
M2 Washer(1)
M2 Nut(1)
No.3278-Y Spinner
Spinner
Back Plate(1)
Spinner(1)
3X15mm Self-
Tapping Screw(4)
AS6458 OBLMotor Mount
6/32X18mm
Screw (4) Sink Head
Screw (4)
OBL MotorMount (1)
Main Gear
Wire
3X12mm
Wood Screw(8)
Landing
Gear Strap(4)
Collar(2)
3X5mm Screw(2)
Left Mount
Beam (1) Right Mount
Beam (1)
No.3 03 Adjustable
Engine
1Mount
3X18mm
Wood Screw(4)
Engine MountPlate(1)
AS6476 Decal
Fillet ( / , / )1L1R
1/4" Blind
Nut(2)
Scoop(1)
Radiator(1)
Landing
Gear Mount(2)
Fairing(1)
Elevator Joiner
Exhaust Vent(2)
Aileron Pushrod(2)
Inner Tube(1/L,1/S)
Guide Tube(1)
Throttle Pushrod(1)
Tail Gear(1) Tail Wheel(1)
Collar(1)
Wheel Well(1/L,1/R)
Wheel Door(1/L.1/R) Wheel DoorRetainer
AS6481 LandingGear AS6480 WheelDoor
JE6767
JE6783 JE6784 JE6785
PARTS DRAWINGS PARTS DRAWINGS
Radiator Vent(1)
6/32X24mm
Screw (4)
Retract GearPushrod(2)
3X16mm Sink
Wood Screw(8)
AS6482 WheelDoor
Retainer
No.3023 Retract
Servo Link
Retract Servo Link(2)
E Clip(2) M2 Nut(2)
54

PARTS CHECK LIST WING
1. Remove aileronfrom thewing, CAthree hingeson the
aileron.
2. Next attach theaileron on tothe wing andapply CAto
the hingearea. Makesure theaileron isfirmly secured
in place.
3. With the wing panel upside down, locate the servo well
and cut an X from corner to corner by using an hobby knife.
4. Use a sealing iron to tackdown thecovering inside
the servowell.
5. Secure the aileron servo in place, the hatchcover
shown isfor leftwing.
Connect servo to RX and turn on radio tomake sure
servo isin neutralposition thensecure thecontrol horn.
6.Attach the12" aileronextension leadto the servo and
tape theconnector toprevent fromloosening. Locatea
string which is in the servo well, tie the stringon the
connector anduse masktape totape theconnector so it
is easierto passthrough theribs.
Fuselage(1)
1/4" BlindNut(2)
Fillet(1/L,1/R)
Left Wing(1)
Right Wing(1)
Retract ServoMount(4)
Landing GearMount(2)
Scoop(1)
Fairing(1)
Plywood WingJoiners(3)
Servo Case(2)
Wing Bolt(2)
Machine Guns(2)
Radiator(1)
Horizontal Tail
Elevator Joiner
CA Hinge(6)
Wheel(2)
Fuel Tank(1)
Silicon Tub(1)
Fuel Stopper(1)
Straight Nipple(1)
Cap(1)
Crank Weight(1)
90-Degree Nipple(1)
EZ Connector(1)
1.5mm HexWrench(1)
Radiator Vent (1)
Captain Eddy(1)
Main GearWire(1)
Landing GearStrap(4)
Collar(2)
Wheel Well(1/L,1/R)
Wheel Door(1/L,1/R)
Wheel DoorRetainer
Left MountBeam(1)
Right MountBeam(1)
Engine MountPlate(1)
Wheel DoorRetainer
M2 Washer(1)
M2 Nut(3)
2X20 Screw(4)
2X15 Screw(4)
3X5mm Screw(2)
3X3mm SetScrew(2)
6/32X18mm Screw(4)
6/32X24 Screw(4)
3X12mm WoodScrew(9)
3X15mm WoodScrew(1)
3X18mm WoodScrew(4)
2X8mm WasherWood Screw(19)
3X15mm Self-Tapping Screw(4)
3X16mm SinkWood Screw(8)
E Clip(2)
Retract ServoLink(2)
Canopy(1)
Cockpit(1)
Straight ThreadedEnd(2)
Clevis(4)
Z-Bend ThreadedEnd(2)
Aileron Pushrod(2)
Inner Tube(1/L,1/S)
Guide Tube(1)
Throttle Pushrod(1)
Tail Gear(1)
Tail Wheel(1)
Collar(1)
Control Horn(4)
Back Plate(4)
VerticalFin/Rudder(1)
CA Hinge(3)
Spinner(1)
Spinner BackPlate(1)
OBL MotorMount(1)
Sink HeadScrew(4)
Cowling(1)
Exhaust Vent(2)
Retract GearPushrod(2)
Kit Contents:
76

WING WING
7. Locate the servowire exithole andremove covering
on the top wing nearwing root. UseNeedlenose Pliers
or Tweezers totake thestring outof thehole.
8. Drill four 1/16"(1.5mm) holes atfour corners. Secure
the servo case in place with 2x8mm washer wood
screws.
9. Install the control horn in place withtwo 2x 15mm
screws.
10. Threadthe clevis onthe aileron pushrodthen insert
the Z-bend end to servo horn and snapthe clevison
control horn. Adjustthe aileronwhen inneutral position,
finally install a piece of silicone tube tohold clevisin
place firmly.
11.Locate the three Dihedral WingJoiners and epoxy
the threeDihedral Joinerstogether.
12. Trial fit the joiners in each wing panel. If needed,
sand theedges lightlyso thatthe joinerfits in each wing
half smoothly.
13. Mixup anample amount of30-min. Epoxy andapply
to the wing root ribs oneach wing panel andDihedral
Joiner and make sure you haveplenty insidethe wing
joiner slot. Slide thewings together, tape around the
joint, andwipe offany excessepoxy.Set asidefor 1hour.
14. Trial fit and center the wing in fuselage,make the
drill mark where is1"(25mm) to the trailing edge and
center line.
15.Drill 1/8"(3mm)pilot holefirst. Removethe wingthen
enlarge holeup to1/4"(6.5mm) onthe wing.
16. Enlargewing mountholes to5/16"(8mm) theninstall
the blindnut fromthe bottom.
17. Trail securing the wingin placewith twonylon wing
bolts.
18. Gluethe radiatorin placeas wellas the scoop.
98
1"
1"

TAIL TAIL
19. Trim thefairing andCA the fairingin place.
20. Place the verticalfin inplace thendraw lines along
with thefin rooton fuselagetail.
21. Cut the covering inside the line you drew about
1/32" (1mm)then peelaway thecovering.
22. Epoxy the vertical fin in place. Nextcut awaythe
covering atthe rearfuselage where stablocated aswell
as thecovering ofjoiner slot.
23. Insert and centerthe horizontaltail inplace. Draw
lines alongthe fuselageon thehorizontal tail.
24. Removethe tailthen carefullycut theline inside the
lines you draw about 1/32" (1mm). Peel away the
covering.
25. Epoxy the horizontal tail in place with the joiner
attached.
26.CAthree hingeson eachelevator.
27. Next attach the elevator on horizontal tail and
secure the elevatorwith CAglue. Make sureelevators
move freely.
28. Locate two holesat thebottom tail,install tailgear
then secure the tail gear with3x15mm and 3x 12mm
wood screws.
29. CAthree hingeson therudder.
30. Trial fitthe rudderon verticalfin andtail geartorque
rod.Apply CAglue whensatisfied. Makesure therudder
moves freeafter cured.
1110

LANDING GEAR OBL POWER UNIT
31. Cutthe coveringat thelanding geararea as shown.
32. Locate the fixedgear mountand landinggear wire.
Insert thewire inplace.
33. Trail fitthe landinggear mountin place.Remove the
mount thenapply epoxy and gluethe gearmount firmly
in place. Ironthe covering onthe landing gearmount.
34. Use mounting strap as drilling guide then drill
5/64"(2mm) holes. Next secure the landinggear with
3x12mm wood screws.
35. Securethe wheelon landinggear with3x5mm screw
and collar.
36. Trim thevacuum formedwheel doorand retaineras
shown.
37. Securethe wheeldoor in place withthe retainerby
using theCA glue.
38. Installthe Outrunner(Thunder Tiger OBL36/07-46A
recommemended) on the OBL motor mount with four
sink head screws.
39. Installthe OBLmotor assembly on firewallwith four
6/32 x18mmWasher Screw.
41.Install the propellerthe spinner asshown then leave
2~3mm clearancebetween cowland spinnerbackplate.
Next drill 1/16"(1.5mm) holes then securethe cowl with
six 2x8mm washerwood screws.
42. Trim theexhaust ventand CAit onthe cowl.
Please skip topage 16 ifNitro Power Unitis used.
40. Trim thecool airinlet forbest performance.
1312

RADIO CANOPY
44. Inline with thepushrod outer tube,use control horn
as template to drill two 2mm holes then secure the
control hornwith two2x 20mmscrews andbackplate.
45. Locate the straight threaded end, Z bend threaded
end, inner tube and clevis then make sure one of inner
tube is 20-3/4" (527mm). Thread the Z-bend threaded
end first then insert the inner tube to the outer tube,
next thread the straight threaded end and the clevis.
Snap theclevis onthe controlhorn.
46. Dothe same procedure onelevator make sure the
inner tubeis 17.5"(445mm) in length.
47. Installthe servoin placeas shown. The topservo in
the photo is elevator servo. Thebottom one is rudder
servo. Adjust the pushrod when servos arein neutral
position.
48. Remove the Quick-Access Cover then secure the
Battery (14.8V 4000mAh recommended) with two
nylon ties. Refer the manual of Speed Control and
properly connect the Speed Controller, Receiver and
Battery. Protect the receiver with foam and secure the
receiver in fuselage. Insert a piece of foam after the
firewall, this is to prevent the battery from damage if
battery hitthe screwswhen heavylanding orcrash.
49. Cut away the covering on therear radiator. Ifuser
installs theengine instead of theelectric motorthen you
may skillthis step.
50. Locate and trimthe RadiatorVentthen CAthe vent
in place.
51. Route the antenna through the fuselage andexit
from the radiator vent. Tape the antennato the tailas
shown.
52. Firstlyapply instrument paneldecal in place. Next
trim the cockpit along the molded lines thenglue itin
the fuselage.Finally glue on theCap'n Eddy.
53. Trim thecanopy andapply canopydecal as shown.
54. Securethe canopyon fuselagewith thedecal.
43. Cut away the covering of elevator and rudder
pushrod exit holes on two side of rear fuselage.
Pull the outertube out alittle bit then CA theouter tube
in place.
1514

56. CAthe filletto fuselageboth atside andsaddle.
Engine Installation
NITRO POWER UNIT
57. Locatethe enginemount hardware, then installthe
engine mount onfirewall with four6/32 x 24mmscrews.
58. Measure from the firewall to the front of thrust
washer at117mm(4-9/16"). Mark the enginemounting
hole position onthe engine mounts.
59. Secure theengine with four3x 18mm woodscrews.
60. Installthe guidetube inthe fuselage.Epoxy the tube
in place.
61. Installthe throttlepushrod. You mightneed to screw
off thethrottle lever first then attach toZ-bend throttle
pushrod end. Bendthe pushrod forsmooth movement.
62. Locatethe fueltank accessoriesthen assemblethe
fuel tank.
63. Installthe fueltank inplace thensecure it with nylon
tie band. Noteorientation of thetank.
64. Secure theEZ connector onthe servo hornwith M2
washer and M2nut. Make surethe connector isrotate
freely. ApplyCA onM2 nutfrom loosening.
65. Secure the throttle servo inservo tray theninstall
the servo hornas shown.Adjust the throttle and secure
the pushrodwith 3x3mmsetscrew.
66. Use a piece of paper and draw the exhaust port
position onthe paper.
Youmay need toenlarge drawing alittle bit.
55. Refer to page 21and apply alldecal in place.Next
glue on themachine guns.
NITRO POWER UNIT
1716

RETRACT
68. Trim awaythe drewarea andtrial fitthe muffler.
69. Trial fitthe muffler, nexttrim thecowl wheremight
contact carburetor.
70. DrillGlow Plugignition hole,needle valvehole and
muffler securinghole fordriver.
71. Install the propeller and spinner then secure the
cowl with six2x8mm wood screws.
74. Locatea plywoodtemplate, place iton the landing
gear areathen drawlines alongthe edgeof the template
on thewing.
73. Cutaway thecovering atlanding geararea.
75. Slightly cut away the coveringof theline youdrew.
Youmay findthe laser cut lineson theplanking.
76. Use hobby knifeand removethe plankingalong the
laser cut lines.
77. Use hobby knife cutthe wing root planking as shown.
At least 2"(5cm) inwidth for easy install theretractservo.
78. Locate four pieces plywood then CA two pieces
together,next gluethis servomount inplace.
67. Next attach the cowl in place, make sure drive
washer is exposedabout 2~3mm fromthe cowl. Make
marks onthe cowlbase onthe drawingon the paper.
NITRO POWER UNIT
1918
72. Installthe switch on fuselage, properly connectall
wires. Next wrapthe receiver andbattery with foamand
secure them infuselage.

RETRACT DECAL
81.ThreadM2 nutand retract linkto pushrod, nextattach
to theservo horn. Itmight need timeto adjustthe length
and tension of the wire so retract gear could work
smoothly. Finally attached the E Clip and secure the
servo horn onthe servo.
82.Trim andglue the wheelwell in place
83. CA the wheel door retainer on the landing gear.
Make sure the wheel door accommodateto thewheel
well andretract workssmoothly.
80. Connect the retract gear pushrod then threadthe
pushrod tothe retractservo thensecure theretract gear
in placewith four3x16 sinkscrews.
Your P-51D isnow ready to fly, carefully set up the
control throws and balance your planewell beforethe
flight; nevertake chancesor rushfly yourP-51D.
Refer tothe photosand applyall decals.
7
11
3
1
9
65
2
4
8
10
12
13
1 2 3 4
5 6
7 8
9 10
11 12
13
1
2
Top
Bottom
2120
79. Install the retract servo as shown. Note the
orientation ofthe servo.

No. 4573
Unlimited Pylon Racer
Specifications:
Wing Span: 673/4" (1720mm)
Length: 60" (1525mm)
Weight: 5500g( 12 lbs.)
Engine: .90 2C,1.20 4C req'd
Radio: 5~8ch 6~8servos req'd
Specification:
Wingspan: 63" (1600mm)
Length: 55.5" (1410mm)
Weight: 10.5~11 lbs (4800–5000g)
Engine: .60~ .902C .91~1.20 4C
Radio: 5CH
Servo: 5 servosplus 1 retractservo
Unlimited Pylon Racer
The highly modified aircraft number 232 September Fury, owned and piloted by Mike Brown, qualified at a
blistering 468.266mph to take the third position at the 2002 National Championship Air Races(NCAR) and
established itself as the fastest SeaFury in history. Thunder Tiger is very proud to present the legendary Sept.
Fury with itsgreat speed toall R/C hobbyistsalike worldwide. Flyit now! Experiencethe unlimited pylonracer of this
fastest SeaFury!
World's FastestSea Fury!
John Penney pilotedthe popular Rare Bear and gotfirst place inUnlimited Class qualifyat 495.039 mphof the 10th
National ChampionshipsAir Race &AirShow,which was held inReno SteadField.
Thunder Tigeras officialsponsor is licensedto produce this1/6 Rare Bear. Pre-painted fiberglassfuselage and cowl,
scale details like panel line, aluminum spinner, and retract wells with gear door...etc. Now you canpilot this Rare
Bear 1/6 scale replica, the most popular unlimited pylon-racing machine from Thunder Tiger. Fly it low and fast to
experience thethrill and excitement ofpylon racing. Go Bear!
Fly low, gofast andturn left
No. 4571
Control Throws
1/2"
3/8"
3/8"
Aileron-Low Rate
Aileron-High Rate
Elevator-Low Rate
Elevator-High Rate
Locate A Good Flying Site
Academy of Model Aeronautics
5151 East Memorial DR
Muncie, IN 47302-9252
www.modelaircraft.org
A Note On Batteries
Congratulations
Set the control throws as followings for a starting point. After you
familiar with its flying characteristics then these control throw can
be tailored to fit your flying style.
IMPORTANT - Do not attempt to fly your model before
completing this very important section. Amodel that is not
properly balanced will be unstableand could cause serious
damage and/or injury. Adjust the battery location or add
weight as neededto achieve level balance.
Center of Gravity
The batteries arethe heartof your radio system. Make sure
you have fully charged batteries! With recharge-able
batteries, follow the manufacturers instructions to make
sure the batteries are fully charged, especial the first time
the radio is used. We would recommend you use larger
capacity(1000mAh NiMH battery for Nitro version,4000mAh
Lipo battery for Electric version) ifyou use high performance
servos as theywill drawmore currentthan ordinary servos.
If there is not a chartered club field in your community,
you will need tofind a large area freeof obstructions, and
has a smooth grass or asphalt surface to be used as a
runway. Forsafetysake, itshould be located wellaway from
houses, buildings, schools, power linesand airports.If you
will be flying within 6 miles of anairport, you should check
with the airportmanager beforeflying yourmodel.
Generally, the best place to fly your modelis atanAMA
(Academy of ModelAeronautics) charteredclub field. Your
local hobby dealer cantell youif thereis sucha clubin your
area orwrite theAMAfor information. It isalso agood idea
to jointhis organization before flying your model sincethey
offer liability insurance that can protect youif yourmodel
causes damage or injury toothers.
Measure theC.G. while plane isdry.The balancepoint is
about 41/2"(114mm) behind theleading edgeat wing root .
1"
Rudder-Low Rate
Rudder-High Rate
1/2"
4-1/2"(114mm)
Pick up modelat arrows.
Now that you have completed the assembly of your P -
51D we eel that you have a very capable and good
looking sports scale plane. We hope that you will enjoy
this model andget many hours of flying pleasurefrom its
use. Thank you for purchasing this P-51D from Thunder
Tiger and we look forward to providing you with other
great R/Cproducts inthe future.
3/4"
3/4"
1"
3/4"
3/4"
1"
1"
YOUR NEXT CHOICE
BALANCE
2322
