Timberkits Chuffy Train User manual

Chuy Train

(UK) Symbols in these instructions. (FR) Symboles des instructions. (ESP) Simbolos en estas instrucciones. (IT) Simboli
in queste istruzioni. (Ger) Symbole in dieser anleitung
(UK) Waiting time.
(FR) Temps d’attente.
(ESP) Tiempo de espera.
(IT) Tempo d’attesa.
(DE) Wartezeit.
(UK) Glue.
(FR) Coller.
(ESP) Pegar.
(IT) Incollare.
(DE) Leimen
(UK) Don’t glue.
(FR) Ne pas coller.
(ESP) No pegar.
(IT) Non incollare.
(DE) Nicht leimen.
(UK) Glue guard. Prevents glue getting between moving parts during build. Remove after 2
minutes.
(FR) Piece de protection contre la colle. pendant l’assemblage, eviter tout depôt de colle sur les
pieces en mouvement. Enlever apres 2 minutes.
(ESP) Parte de protection de el pegamento. durante la fase de esambalje, evitar que el pegamento
se ponga sobre partes que se mueven. Quitar despues de dos minutos .
(IT) Pezzo di protezione della colla. Durante l’assemblaggio evitare che la colla vada su parti non
statiche . Imuovere dopo due minuti.
(DE) Karton. Verhindert das eindringen von leim zwischen die bewegliche teile während der
montage. Zwischen die beweglichen teile.
(UK) Wax surface to lubricate.
(FR) Appliquer la cire sur cette
surface.
(ESP) Aplica la cera sobre esta su-
percie.
(IT) Applicare la cera su questa
supercie
(DE) Wax Oberäche zu schmieren.
Helpful hints/conseils utiles/consejos utiles/suggerimentutili/nützliche tipps
(UK) Check all parts present in trays
(FR) Vérier que toutes les pièces soient présentes dans les bacs
(ESP) Controlar que hay todas la partes en la caja
(IT) Controllare tutte le parti presenti nel kit
(DE) Bitte prüfen sie, ob alle benötigten teile vorhanden sind
(UK) Read all instructions and look at all diagrams
(FR) Lire toutes les instructions et regarder toutes les gures
(ESP) Leer las intrucciones y guardar a los diagrames
(IT) Leggere tutte le istruzioni e guardare i diagrammi
(DE) Lesen sie alle anweisungen und betrachten sie die schaubilder
(UK) Check assembly before gluing
(FR) Vérier le montage avant collage
(ESP) Controlar el montaje antes de empezar a pegar
(IT) Controllare l’assemblaggio prima di incollare
(DE) Montage prüfen vor dem einklebern
(UK) Some parts may need sanding
(FR) Certaines pièces nécessiteront d’être poncées.
(ESP) Algunas parte necesitan de ser suavizadas
(IT) Alcune parti potrebbero aver bisogno di levigatura
(DE) Möglicherweise müssen manche teile geschlien werden
Colouring tips/conseils concernant l’application de peinture/ consejos para Pintar/ suggerimenti per colorare/
lackiertipps
(UK) Do not apply paint to parts which move against one another. It is easier to paint some parts before
assembling
(FR) Ne pas appliquer de peinture sur les parties qui se déplacent l’une contre l’autre. Il est conseillé de pein
dre avant assemblage
(ESP) No aplique la pintura sobre las partes que se tocaran. Resulta mas facil pintar las partes antes de montar.
(IT) Non applicare la pittura su quelle parti dove ce attrito con un’altra parte. è piu semplice pitturare alcune
parti prima della fase di assemblaggio.
(DE) Teile, die aneinander reiben, sollten nicht lackiert werden. Fertig lackierte teile sind o leichter zu
montieren
Visit our website to view
instructional videos where you
see this symbol.
www.timberkits.com
!
Pay special attention to this
section.
New Symbols in our
Instructions
1

If you need any help with
building this model please feel free to
contact our Timberkit Human, Luise Willis by calling
01650 521635
Allthough this model is very simple and designed for children
some adult supervision is recommened.
We also recommed wearing old clothes as the glue is dicult
to wash out if it is allowed to go hard. Enjoy!
You can visit our website for tips and tutorials
www.timberkits.com
2

21
21
17
15
16
10
4
8
7
18
9
22 20
19
19
19
19
19
19
19
19
19
19
19 19
5mmx18mm
5mmx
12mm 5mmx
20mm 5mmx
32mm
5mmx
30mm
5mmx
16mm
9mmx
32mm
9mmx
63mm
9mmx
116mm
6
3
24
23 25
26

4
2
1
3
5
11
14
12
13

1
10
10
2
1
2
15
15
Use all 5mmx18mm pegs.
Top Tip!
Glue the top of the peg
before pushing it all the way
through its hole
Make sure the big holes
are perfectly aligned. You
may want an adult to help
here.
5

3
3
9mmx63mm
10
6

4
4
4
7

5
5
10
8
Part 4 needs to be able to
turn freely so that it can be
positioned correctly in section 11.

10
6
7
89
9mmx32mm
9mmx116mm
6
7
89
10
5mmx12mm
5mmx12mm
9

The legs can be quite
sti when pushing them into
place. You may want an
adult to help here.
11
11
11
11
10
10
10
Carefully turn your model upside
down and put a generous blob of glue
around the joint where the 9mm x
63mm post comes up through part 5.
Leave to dry for 15 mins
15

11
11
12 12
NO!

12
13
13
10

Put plenty of glue around the
end of the 9mm x 63mm post
and leave to completely dry
before turning the model over
13
14
14
15
15
30

14
15
16
17
18
19
19
16
17
10
10
5mmx35mm
5mmx16mm
5mmx35mm

10
19
19
20
15
18
5mmx30mm
5mmx20mm
You may want an
adult to help screw
this part in

16
21
19
19
19
19
10
19
10
5mmx35mm 5mmx35mm

21
19
19
10
20
22 20
17
5mmx20mm
5mmx35mm
5mmx35mm
You may want an
adult to help screw
this part in

19
19
22
10
18
5mmx20mm
You may want an
adult to help screw
this part in

19
21
The peg at the front of the
engine must be located in front
of the drive lever part no 2.
Hook the part no’s 20 into 22 as
you position the train.
