Timberkits Trombone Player User manual

Chuffy Train

2
(UK) Symbols in these instructions. (FR) Symboles des instructions. (ESP) Simbolos en estas instrucciones. (IT) Simboli in queste istruzioni. (Ger)
Symbole in dieser anleitung
(UK) Waiting time.
(FR) Temps d’attente.
(ESP) Tiempo de espera.
(IT) Tempo d’attesa.
(DE) Wartezeit.
(UK) Glue.
(FR) Coller.
(ESP) Pegar.
(IT) Incollare.
(DE) Leimen
(UK) Don’t glue.
(FR) Ne pas coller.
(ESP) No pegar.
(IT) Non incollare.
(DE) Nicht leimen.
(UK) Glue guard. Prevents glue getting between moving parts during build. Remove after 2 minutes.
(FR) Piece de protection contre la colle. Pendant l’assemblage, eviter tout depôt de colle sur les pieces en mouve-
ment. Enlever apres 2 minutes.
(ESP) Parte de protection de el pegamento. Durante la fase de esambalje, evitar que el pegamento se ponga sobre
partes que se mueven. Quitar despues de dos minutos .
(IT) Pezzo di protezione della colla. Durante l’assemblaggio evitare che la colla vada su parti non statiche . Imuo-
vere dopo due minuti.
(DE) Karton. Verhindert das eindringen von leim zwischen die bewegliche teile während der
montage. Zwischen die beweglichen Teile.
(UK) Wax surface to lubricate.
(FR) Appliquer la cire sur cette surface.
(ESP) Aplica la cera sobre esta supercie.
(IT) Applicare la cera su questa supercie
(DE) Wax Oberäche zu schmieren.
Helpful hints/conseils utiles/consejos utiles/suggerimentutili/nützliche tipps
(UK) Check all parts present in trays
(FR) Vérier que toutes les pièces soient présentes dans les bacs
(ESP) Controlar que hay todas la partes en la caja
(IT) Controllare tutte le parti presenti nel kit
(DE) Bitte prüfen sie, ob alle benötigten teile vorhanden sind
(UK) Read all instructions and look at all diagrams
(FR) Lire toutes les instructions et regarder toutes les gures
(ESP) Leer las intrucciones y guardar a los diagrames
(IT) Leggere tutte le istruzioni e guardare i diagrammi
(DE) Lesen sie alle anweisungen und betrachten sie die schaubilder
(UK) Check assembly before gluing
(FR) Vérier le montage avant collage
(ESP) Controlar el montaje antes de empezar a pegar
(IT) Controllare l’assemblaggio prima di incollare
(DE) Montage prüfen vor dem einklebern
(UK) Some parts may need sanding
(FR) Certaines pièces nécessiteront d’être poncées.
(ESP) Algunas parte necesitan de ser suavizadas
(IT) Alcune parti potrebbero aver bisogno di levigatura
(DE) Möglicherweise müssen manche teile geschlien werden
Colouring tips/conseils concernant l’application de peinture/ consejos para Pintar/ suggerimenti per colorare/
lackiertipps
(UK) Do not apply paint to parts which move against one another. It is easier to paint some parts before
assembling
(FR) Ne pas appliquer de peinture sur les parties qui se déplacent l’une contre l’autre. Il est conseillé de pein
dre avant assemblage
(ESP) No aplique la pintura sobre las partes que se tocaran. Resulta mas facil pintar las partes antes de montar.
(IT) Non applicare la pittura su quelle parti dove ce attrito con un’altra parte. è piu semplice pitturare alcune
parti prima della fase di assemblaggio.
(DE) Teile, die aneinander reiben, sollten nicht lackiert werden. Fertig lackierte teile sind o leichter zu
montieren
Visit our website to view instruc-
tional videos where you see this
symbol.
www.timberkits.com
!
Pay special attention to this section.
New Symbols in our
Instructions

Trombone Player 3
If you need help or advice you can call our
Timberkits Human Support System!
Luise Willis
01650 521635
Or you can visit our website for tips, advice and instructional videos. All
these can be found in Resources/Advice Videos on our website.
www.timberkits.com

4
12 & 14
4 & 13
40
17
18 20

Trombone Player 5
16 16
50
36 33
10
15
42
9 6 23
7 & 7
8
4946
11

6
25
21 24
34
32
28
35
29
22
31
2
26
39 30
41 37
43 43
38
45
44 44
3 3 5 1 1 1
27 27 27 27 27 27
8mm x 44mm47
6mm x 106mm
48
6mm x 25mm
3mm x 38mm
3mm x 34mm
3mm x 31mm
3mm x 28mm
2mm x 24mm
3mm x 21mm
3mm x 16mm 3mm x 12mm
19
48

Trombone Player 7
1
1
6mm x 106mm
2
6mm x 25mm
2
3mm x 28mm
3
10mins
4

8
3
3a
3b
5
6
The best way of glueing in this section is to...
1. Use Glue Guard
2. Slide on spacer 5 with no glue
3. Apply glue to shaft after spacer in place
4. Fit cam #6
This will ensure the drive shaft is not accidentlly
glued to the side panel.

Trombone Player 9
10mins
3c
3d
1
7
8
561
7
8
Ensure all cams are aligned at the
same angle as
demonstrated in illustration.

10
4
4a
4b
9
10
3mm x 16mm
Ensure all cams are aligned at the
same angle as shown on page 9.
55a
5b
7

Trombone Player 11
6
6a 11
3
6b
6c

12
7
7a
7b
7c
12
1
13
10mins
10mins

Trombone Player 13
15mins
8
7d
14
15
16
16
10mins

14
917
3mm x 16mm
10
19
18 10mins
15mins
7mm
7mm
11

Trombone Player 15
12
20
3mm x 31mm
3mm x 16mm
13
When waggle stick (part #20) is in place within the torso, secure using peg
3mm x 38mm by inserting through hole A and through the hole (B) in
waggle stick. When fully inserted dab a spot of glue over the end as shown.
B
B
A
3mm x 38mm

16
15mins
14
Hold stool in place with your hand and turn
handle. Test that the waggle stick moves
backwards and forwards freely before glueing
in place. You can adjust the position of the
stool a little if need be.
9mm

Trombone Player 17
15 21
22
23
10mins
24
25
26
3mm x 12mm
3mm x 16mm
3mm x 34mm
15c
15a
15d
15e
15b
37

18
16
27

Trombone Player 19
17
3mm x 16mm
To make the pose look more natural we
suggest gluing the right leg angled slightly
outwards
3mm x 16mm

20
28
20a
18 3mm x 21mm
19 3mm x 12mm
20
29
30
3mm x 12mm
31
20b
21 21a 21b
32 33
34
Insert a 3mm x 12mm peg into part #29 without gluing to
ensure part #31 aligns correctly.
Then remove the peg.
3mm x 12mm
