Tippmann GRYPHON User manual

ITEM QTY. PT. NO. DESCRIPTION ITEM QTY. PT. NO. DESCRIPTION
1 TA40003 1 Cover, Left 29 98-56 1 Valve Plug
2 TA40001 1 Receiver, Left 30 SL2-25 2 O-ring
3 TA40002 1 Receiver, Right 31 PA-31A 1 Snap Ring
4 TA40004 1 Cover, Right 32 98-32 1 Spring
5 TA06015 2 Screw, 10-32 x 0.840” LHSHCS 33 CA-27 1 Valve Seat
6 TA09920 14 Screw, #6 x 12.5mm phillips head self-tap 34 98-21N 1 Power Tube
7 TA40019 1 Logo/Nameplate, Left 35 02-40 1 O-ring, Barrel
8 98-26 4 Screw, 10-32 x .25” BHCS 36 02-22 1 Set Screw, 5/16-24 x 7/16
9 9-PA 1 Nut, 10-32 Hex - Black 37 TA40018 1 Gas Line Joint (1/8 NPT Plug Nu
t
10 TA40020 1 Screw, #6 x 21mm phillips head self-tap 38 02-17 1 Front Bolt
11 98-37N 1 Safety Pin 39 SL2-4 1 O-ring
12 98-55 1 O-ring, Red 40 TA01016 1 Linkage Arm
13 FA-07 1 O-ring, Black 41 98-33 5 Dowel Pin, 1/8 x 5/8
14 98-18 1 Trigger Return slide 42 02-35 1 Sear
15 98-19 2 Dowel Pin, 1/8 x 1/4 43 CA-36 1 Dowel Pin, 1/8 x 5/8 - Black
16 98-20 1 Spring 44 TA40013 2 Spring
17 TA40011 1 Trigger Adapter (Complete Assembly: items #14, 16, and 17) 45 TA40009 1 Trigger
18 TA40015 1 Rear Bolt 46 TA10010 1 Trigger Link
19 98-12A 2 O-ring 47 TA40008 1 Air Supply Adapter (ASA)
20 CA-14 1 Spring 48 TA40007 1 Feed Elbow Clamp Ring
21 CA-15 1 Guide Pin 49 TA40016 1 Gas Line
22 TA05005 1 Rear Bolt Plug 50 FA-18 1 Ball Latch
23 TA40014 1 Rear Bolt Handle 51 TA40005 1 Front Grip Inset Panel
24 98-57 1 O-ring 52 TA40017 2 O-ring, Gas Line
25 PA-28 1 Valve Stem Cup Seal 53 TA40006 1 Barrel Adapter
26 CA-29 1 Valve Stem Cup 54 TA40012 1 Barrel
27 CA-30N 1 Valve Plunger 55 TA40021 1 Logo/Nameplate Right
28 98-25N 1 Valve Body
Gryphon Parts List
