TIPTEL Ergophone 6070 User manual

Operating instructions (en)
tiptel Ergophone 6070/6071
tiptel

Important information
This telephone is intended for inexperienced users. The factory set-
tings only make available functions that are generally used most of-
ten. This manual therefore concentrates on this functionality.
Use menu option "User level settings" in the "Settings" menu to switch
the phone from "Beginner mode" to "Advanced mode". This then
gives you additional functions.
Note: If you change settings in the "Advanced mode" setting,
these changes remain available even if you later revert
back to "Beginner mode" mode.
All options in the main menu described in this manual are in the facto-
ry settings for the device. You can mask the main menu options that
you do not intend to use via menu option "Visibility main menu" in the
"Settings" menu.
For safety reasons, the battery switches off before it is totally
discharged. If you have not used the telephone for a long time,
wait up to 10 minutes after you have plugged in the charger. This
switches the battery back on and the charging process starts.

Table of contents
3
Table of contents
Important information............................................................... 1
Table of contents...................................................................... 3
Safety information .................................................................... 7
Initial use................................................................................... 8
Check the contents ...............................................................8
Installing the SIM card, memory card and battery................8
Switching on the telephone...................................................9
Setting date and time ............................................................9
Charging the battery..............................................................10
Telephone controls .................................................................. 12
Controls on the keypad.........................................................12
Controls on the back .............................................................13
Controls on the left ................................................................14
Controls on the right..............................................................14
Controls on the underside.....................................................14
General information on using the phone ................................ 15
Custom setup ........................................................................... 16
Using the phone as you want to ...........................................16
Call signalling as you want it.................................................17
Making calls as you want to ..................................................17
Making and receiving calls ...................................................... 19
Receiving calls.......................................................................19
Rejecting calls .......................................................................19
Calling with direct dial ...........................................................19
Dialling with the redial function .............................................19
Calling with speed dial ..........................................................20
Dialling from the contacts......................................................20
Functions available during a call...........................................21

Table of contents
4
Contacts.................................................................................... 22
Options ..................................................................................22
Call......................................................................................22
Send text message.............................................................23
Add new contact.................................................................23
Edit......................................................................................24
Delete..................................................................................24
More options.......................................................................24
Main contacts ........................................................................24
Messages (SMS) ...................................................................... 26
Viewing received messages..................................................26
Sending messages................................................................26
Writing message text.............................................................27
More message options.......................................................27
Silent mode............................................................................... 28
Call history................................................................................ 29
Displaying missed calls.........................................................29
Camera...................................................................................... 30
Image viewer .........................................................................30
Storage ..................................................................................31
Image size .............................................................................31
Transferring photos to a computer........................................31
Radio ......................................................................................... 32
Radio mode options ..............................................................32
Channel list .........................................................................32
Auto search.........................................................................32
More options.......................................................................33
Sound recorder......................................................................... 34
Recorder options...................................................................34
New record .........................................................................34
List.......................................................................................
34
Settings...............................................................................34
More options.......................................................................35

Table of contents
5
Alarm ......................................................................................... 36
Calculator.................................................................................. 37
Tasks......................................................................................... 38
Services .................................................................................... 39
Bluetooth................................................................................... 40
Settings ..................................................................................... 41
Phone Settings ......................................................................41
Time and date.....................................................................41
Tone settings ......................................................................42
Volume................................................................................42
Alert type.............................................................................42
Language............................................................................42
More phone settings...........................................................43
Userlevel settings ..................................................................43
Security settings ....................................................................44
More settings............................................................................ 44
Call settings ...........................................................................44
Visibility main menu...............................................................45
Order main menu ..................................................................45
Network settings....................................................................46
Emergency settings...............................................................46
Connectivity...........................................................................46
Restore factory settings.........................................................46
Connection to a computer ....................................................... 47
Emergency call ......................................................................... 48
Testing of the emergency call function .................................49
Setup of emergency calls......................................................50
Emergency button on/off....................................................50
Emergency numbers ..........................................................50
Cancelling an emergency call...............................................51
Important information on emergency call functions .............
52

Table of contents
6
Appendix ................................................................................... 53
Service...................................................................................53
Guarantee..............................................................................53
CE sign ..................................................................................54
Ecological information...........................................................55

Safety information
7
Safety information
Only use the phone at places where it is permitted. The use of mobile
phones is generally prohibited in hospitals and aircraft, and at petrol
stations.
Do not open the device yourself and do not attempt repairs on your
own. Repairs may only be carried out by qualified specialists.
Do not expose the telephone to smoke, chemicals, humidity, dust or
excessive heat (direct sunlight).
Keep the telephone and accessories away from children.
The telephone's speaker can be set to a very loud volume. Check the
volume before use to avoid damaging your hearing.
When driving, only use the telephone with an approved hands-free
set. Observe national legislation governing the use of mobile tele-
phones.
Keep the telephone 20cm away from an implanted pacemaker. Im-
mediately switch off the telephone if you feel or suspect any impair-
ment.
Do not use any power supply unit other than the one supplied.
Only use original accessories and batteries.
The telephone is not waterproof. Avoid contact with liquids.
Do not rely exclusively on your mobile telephone's emergency call
function in emergencies. Establishing an emergency connection may
not always be possible for technical reasons.
Dispose of the device and the battery in line with environmental
guidelines. Your local waste disposal provider offers collection points
for electronic waste and batteries. Do not dispose of the device or
battery in household waste or throw into a fire.
Dispose of packaging material in line with local regulations.

Initial use
8
Initial use
Check the contents
Included in the delivery:
tiptel Ergophone 6070/6071 mobile phone
Power supply unit
Charger cradle
Headset
Li-Ion 3.7 V/1000mAh battery pack
Operating instructions
Installing the SIM card, memory card and battery
The SIM card, battery and any memory card must be installed prior to
initial use.
SIM cards are available from your service provider.
A memory card (not included) is required to send multimedia mes-
sages (MMS), to save photos with the integrated camera and to rec-
ord voice notes with the integrated recorder. The tiptel Ergophone
6070/6071 supports Micro SD memory cards with a capacity up to 8
GB - these can be purchased on the accessories market and in elec-
tronics shops.
Fig. 1 Fig. 2 Fig. 3 Fig. 4

Initial use
9
To insert the SIM card, a memory card and the battery, the casing
cover at the back of the device must be removed. Press the casing
cover and sliding it downward until it can be removed (Fig. 1).
Carefully install the SIM card in the card holder. Push the SIM card
under the metal clamp with the contacts pointing downwards and the
notch facing the SOS button (Fig. 2).
To insert an SD memory card, push the metal clip towards the key-
pad lock switch, and fold it upwards (Fig. 3). After inserting the card
and closing the metal holder, push the holder towards the Radio
switch such that it secures the card and can no longer be opened
upwards. Exercise extra care here. If the metal holder does not slide
easily, it is usually an indication that the card is not inserted correctly.
The battery is inserted next (only possible in the correct position - Fig.
4).
Then replace the case cover and slide it towards the SOS button until
it clicks into place.
Switching on the telephone
To switch on the phone, press the red hang-up button for about
3 seconds.
You are then prompted to enter the SIM card PIN (if enabled for the
SIM card). Use the keypad to enter the PIN and then press the left
display button (OK).
Note: In "Settings" "Security Settings", you can change the
SIM card PIN and enable/disable the prompt.
Setting date and time
After switching on for the first time (and when the battery is removed
for longer periods), the telephone automatically synchronises date
and time from the service provider network.

Initial use
10
If your service provider does not support this functionality, the date
and time must be set manually. To do this, press the left display but-
ton under "Menu", then keep pressing the "down arrow" button
until "Settings" is displayed. Then press the button under
"OK" three times to access "Settings", then "Phone Settings", then
"Time and date". Select "Set date" then "Set time", and use the keypad
to enter the current date and time.
You can close the settings by repeatedly pressing the button
under "Back", and also by pressing the red hang-up button once.
The correct date and time are then shown on the display.
Charging the battery
A charger cradle and a power supply unit are supplied with your tele-
phone. Insert the small connector on the power supply unit into the
jack on the rear of the charger cradle then plug the power supply unit
into the wall socket.
Note: Stickers with arrows are affixed to the charger connector
and the charger cradle. The two arrows must be pointing
at each other when the connector is plugged into the
charger cradle. If it is not easy to insert the connector in-
to the jack, check the direction and avoid applying force.
Place the telephone into the charger cradle to charge the battery.
Note: Instead of charging via the charger cradle, the power
supply plug can also be connected directly to the jack
on the underside of the telephone. The battery can also
be charged via a computer's USB connector. In both
cases, the arrow on the connector must be pointing to-
wards the front of the phone (towards the keypad).
