Titan Attachments 72RBGRAP User manual

ROCK BUCKET GRAPPLE
72RBGRAP, 82RBGRAP
115012, 115013
Operator’s Manual
Read the Operator’s Manual entirely. When you see this
symbol, the subsequent instructions and warnings are
serious follow without exception. Your life and the lives
of others depend on it!

2
IMPORTANT SAFETY INFORMATION
THESE ARE STANDARD PRACTICES THAT MAY NOT APPLY TO THE PRODUCTS
DESCRIBED IN THIS MANUAL.
SAFETY AT ALL TIMES
Thoroughly read and understand the instructions given in this manual before operation. Refer
to the “Safety Label” section, read all instructions noted on them. Do not allow anyone to
operate this equipment who has not thoroughly read and comprehended this manual. Do not
allow anyone who has not adequately trained in the safe operation of the equipment.
•The operator should be familiar with all functions of the unit.
•Operate implement from the driver’s seat only.
•Make sure all guards and shields are in place and secured before operating the tool.
•Do not leave a tractor or implement unattended with the engine running.
•Dismounting from a moving tractor could cause severe injury or death.
•Do not allow anyone to stand between tractor and implement while backing up to
implement.
•Keep hands, feet, and clothing away from power-driven parts.
•Wear snug-fitting clothing to avoid entanglement with moving parts.
•Watch out for wires, trees, etc., when raising implements. Make sure all persons are clear
of the working area.
•Turning the tractor too tight may cause implement to ride upon wheels. This activity could
result in injury or equipment damage.
•Do not carry passengers on the tool at any time.
LOOK FOR THE SAFETY ALERT SYMBOL
The SAFETY ALERT SYMBOL indicates a potential hazard to personal safety, and individuals
must take safety precautions. When you see this symbol, be alert and carefully read the
message that follows it. In addition to the design and configuration of equipment, hazard
control and accident prevention depend on the awareness, concern, prudence, and proper
training of personnel involved in the operation, transport, maintenance, and storage.

3
BE AWARE OF SAFETY ALERT WORDS
DANGER: Indicates imminently hazardous practices. A situation that, if not avoided, will result
in death or severe injury. The signal word is limited to the most extreme situation, typically for
machine components that, for functional purposes, cannot be guarded.
WARNING: Indicates a potentially hazardous situation that, if not avoided, could result in death
or severe injury, and includes hazards that are exposed when guards remove. Use warnings to
alert against unsafe practices.
CAUTION: Indicates a potentially hazardous situation that may result in minor or moderate
injury if not avoided. It may also be used to alert against unsafe practices.
FOR YOUR PROTECTION
Thoroughly read and understand the “Safety Label” section, read all instructions noted on them.
SHUTDOWN AND STORAGE
•Lower machine to the ground, put the tractor in park, turn off the engine, and remove the
key.
•Detach and store implements in an area where children typically do not play
USE SAFETY LIGHTS AND DEVICES
•Slow-moving tractors, self-propelled equipment, and towed implements can create a
hazard when driven on public roads. They are challenging to see, especially at night.
•Flashing warning lights and we recommend turn signals whenever driving on the public
road.
TRANSPORT MACHINERY SAFELY
•Comply with state and local laws
•The maximum transport speed for implement is 20 mph, DO NOT EXCEED. Never travel at
a rate that does not allow adequate control of steering and stopping. Some rough terrain
requires a slower speed.
•Sudden braking can cause a towed load to swerve and upset. Reduce speed if the towed
load is not equipped with brakes.
Use the following maximum speed – tow load weight ratios as a guideline:
•20 mph when weight is less than or equal to the weight of the tractor.
•10 mph when weight is double the weight of the tractor.
IMPORTANT: Do not tow a load that is more than double the weight of the tractor.
KEEP RIDERS OFF MACHINERY
•Riders obstruct the operator’s view; they could be struck by foreign objects or thrown
from the machine.
•Never allow children to operate equipment.
•Practice Safe Maintenance
•Understand procedure before doing work. Use proper tools and equipment; refer to

4
Operator’s Manual for additional information.
•Work in a clean, dry area
•Lower the implement to the ground, put the tractor in park, turn off the engine, and
remove the key before maintenance.
•Allow implement to cool completely.
•Do not grease or oil implement while it is in operation.
•Inspect all parts. Make sure details are in good condition and installed correctly.
•Remove the buildup of grease, oil, or debris.
•Remove all tools and unused parts from implementation before operation.
PREPARE FOR EMERGENCIES
•Be prepared if a fire starts.
•Keep a first aid kit and fire extinguisher handy
•Keep emergency numbers for doctor, ambulance, hospital, and fire department near the
phone.
WEAR PROTECTIVE EQUIPMENT
•Wear protective clothing and equipment appropriate for the job. Avoid loose-fitting
clothing.
•Prolonged exposure to loud noise can cause hearing impairment or hearing loss. Wear
suitable hearing protection such as earmuffs or earplugs.
•Operating equipment safety requires the full attention of the operator. Avoid wearing
radio headphones while operating machinery.
AVOID HIGH-PRESSURE FLUIDS HAZARD
•Escaping fluid under pressure can penetrate the skin causing severe injury.
•Avoid the hazard by relieving pressure before disconnecting hydraulic lines or performing
work on the system.
•Ensure all hydraulic fluid connections are tight and all hydraulic hoses and lines are in
good condition before applying pressure to the system.
•Use a piece of paper or cardboard, NOT BODY PARTS, to check for suspected leaks.
•Wear protective gloves and safety glasses or goggles when working with hydraulic
systems.
•If an accident occurs, see a doctor immediately. Remember, any fluid injected into the skin
must be treated within a few hours, or gangrene may result.
TIRE SAFETY
•Tire changing can be dangerous, and trained personnel should be the only ones using
correct tools and equipment.
•When inflating tires, use a clip-on chuck and extension hose long enough to allow you to
stand to one side and NOT in front of or over the tire assembly. Use a safety cage if
available.
•When removing and installing wheels, use wheel handling equipment adequate for the
weight involved.

5
MAINTENANCE
REPLACEMENT TEETH
•Teeth on the grapple can be easily replaced by removing the pin and inserting a new
tooth. Please contact Titan for purchasing replacements (LW80KIT).
GREASE POINTS
•It is recommended that grease is re-applied to the lubrication points every 8 hours of use.

6
PARTS DIAGRAM / EXPLODED VIEW

7
ASSEMBLY INSTRUCTIONS
−No assembly required
KEY
PART
DESCRIPTION QTY
(1 & 2) P115012-1 TOP JAW ROCK BUCKET GRAPPLE 2
(3)
P115012-3
FRAME ROCK BUCKET GRAPPLE 1
(4) P115012-4 RBGRAP CYLINDER 2
(5)
P115012-5
PIN FOR GRAPPLE 4
(6)
P115012-6
PIN FOR CYLINDER 4
(7)
P115012-7
SHIELD FOR CYLINDER 2
(8)
P115012-8
WASHER FOR SHILED 4
(9) P115012-9 SPRING WASHER FOR SHIELD 4
(10)
P115012-10
NUT M10 4
(11)
P115012-11
T-CONNECTOR 2
(12)
P115012-12
HOSE A- FEED/RETURN 2
(13)
P115012-13
HOSE B 2
(14) P115012-14 HOSE C 2
(15)
FFC12F
FEMALE FLAT FACE COUPLER ½ THREAD 1
(16)
FFC12M
MALE FLAT FACE COUPLER ½ THREAD 1
(17)
P115012-17
TOOTH 6 / 7
(18)
P115012-18
PIN FOR TOOTH 6 / 7
(19) P115012-19 RETAINER 6 / 7
(20)
P115012-20
BOLT M10*15 8

8
SPECIFICATION CHART
MODEL
82" FINE
GRADE
SKELETON
ROCK
GRAPPLE
RAKE
72" FINE
GRADE
SKELETON
ROCK
GRAPPLE
RAKE
60" FINE
GRADE
SKELETON
ROCK
GRAPPLE
RAKE
72”
SKELETON
ROCK
BUCKET
GRAPPLE
RAKE
82”
SKELETON
ROCK
BUCKET
GRAPPLE
RACK
MPN 82RBFGGRAP 72RBFGGRAP 60RBFGGRAP 72RBGRAP 82RBGRAP
MAX
OPENING
35.5-IN. 35.5-IN. 35.5-IN. 35.5-IN. 35.5-IN.
OVERALL
WIDTH
83-IN. 73-IN. 61-IN. 73-IN. 83-IN.
INSIDE
WIDTH
82-IN. 72-IN. 60-IN. 72-IN. 82-IN.
TINE
SPACING
3-IN. 3-IN. 3-IN. 4-IN. 4-IN.
INSIDE
DEPTH
38-IN. 38-IN. 38-IN. 38-IN. 38-IN.
TEETH
6-IN. LONG
LW80
6-IN. LONG
LW80
6-IN. LONG
LW80
6-IN. LONG
LW80
6-IN. LONG
LW80
CUTTING
EDGE
1-IN. 1-IN. 1-IN. 1-IN. 1-IN.
PRODUCT
WEIGHT
1,218 LB. 1,050 LB. 849 LB. 1,056 LB. 1,200 LB.

9
ACKNOWLEDGEMENT OF RISK AND RELEASE OF LIABILITY
The use of any equipment, including this one, involves the potential risk of injury. Apart from any
warranty claim that might be presented for a claimed defect in material or workmanship of the product,
you accept and assume full responsibility for any and all injuries, damages (both economic and non-
economic), and losses of any type, which may occur, and you fully and forever release and discharge
Titan, its insurers, employees, officers, directors, associates, and agents from any and all claims,
demands, damages, rights of action, or causes of action, present or future, whether the same be known
or unknown, anticipated, or unanticipated, resulting from or arising out of the use of said equipment.
This equipment must be used with care by capable and competent individuals under supervision, if
necessary.
WARNING
Do not overfill! Mower should be level
when checking oil in gear box.
some activities might be able to cause
electric shock
Sharp objects may be involved.
Use protective cover during maintenance.
TITAN LIMITED WARRANTY: TERMS, EXCLUSIONS AND LIMITATIONS OF REMEDIES
This product comes with a one (1) year limited warranty that can be found at
www.palletforks.com/warranty.html. Please review the same for all details regarding the Titan Limited
Warranty.
THE TITAN LIMITED WARRANTY FOUND AT WWW.PALLETFORKS.COM/WARRANTY.HTML IS
EXCLUSIVE AND IS IN LIEU OF ALL OTHER WARRANTIES, EXPRESS OR IMPLIED, INCLUDING ANY
IMPLIED WARRANTY OF MERCHANTABILITY AND/OR FITNESS FOR A PARTICULAR PURPOSE, EACH
OF WHICH IS HEREBY DISCLAIMED.

10
NEED HELP? CONTACT US FIRST.
1-800-605-7595
[e-mail]
www.palletforks.com
© 2021 Titan Brands
