Titan Attachments 48TRENCHER User manual

OWNER’S MANUAL
MPN(s): 48TRENCHER
SKU(s): 191503
UPC(s): 840009205682

2
SAFETY INSTRUCTIONS
•Before use, read this manual in its entirety.
•Be familiar with the host machine’s specifications and parameters.
•Be familiar with the trencher’s specifications and parameters.
•Wear safety clothing, protective glasses during use to ensure safety.
•Do not modify the equipment under any circumstance. For part replacements, please contact
Titan Attachments Customer Service.
•Never operate the host machine or trencher while under the influence of drugs or alcohol.
•Do not leave the host machine’s cab while the engine is still running.
•Always inspect trencher and host machine before operation.
OPERATIONAL DANGER HAZARDS
•ALWAYS ensure bystanders are at least 25 FT away from trencher during use. Contact with
moving parts will result in injury or death.
•ALWAYS survey working area first. Contact with live underground or overhead cables will
result in death or serious injury
•High pressure fluid hazard. Incorrect hydraulic handling can result in injury or death. Release
pressure on system. Use cardboard or piece of wood to identify leaks.
•NEVER wear loose clothing that could become entangled in the trencher.
•NEVER operate with any damaged or missing parts.
•NEVER perform any maintenance unless host machine is completely turned off.

3
TRENCHER KEY COMPONENTS
1. Crumber Arm
2. Chain
3. Teeth
4. Chain Tensioning Assembly
5. Hydraulic Motor
6. Hydraulic Hoses
7. Manual Side Shift Adjustment Pin
8. Mount Plate
9. Auger
10. Skid Plate

4
TRENCHER SPECIFICATIONS

5
OPERATION INSTRUCTION
PRE-OPERATION CHECKLIST
1. Check for any loose or missing guards and shields on the trencher.
2. Inspect hoses and hose connections for any leaks. Replace hoses and hose connections as
necessary.
3. Check the chain tension before operating the trencher.
4. Lubricate the trencher’s grease points. Please refer to the “Maintenance Instructions” section
for this information.
5. Check for any loose fasteners. Tighten the fasteners as necessary.
6. Refer to operating machine user’s manual for pre-start instructions.
7. Review and understand this manual and operating machine manual.
ATTACHING AND DETACHING TRENCHER
1. Follow all safety instructions before attaching the trencher.
2. Attach the trencher to the skid steer mount plate. Verify all pins are secured in the correct
position.
3. Connect the hydraulic hoses. Verify that the hoses are clear of any moving parts.
4. Case Drain line required to operate this implement
OPERATION PROCEDURES
•Test the functions of the trencher in a clear, open area with skid steer in idle. Understand the
controls of the trencher and operating machine before beginning operation.
•ALWAYS survey the area prior to working and consider the ground conditions. Avoid
underground hazards such as utility lines, hidden stumps, etc.
Starting the Trencher
1. Set trencher parallel to ground, but not yet making contact.
2. Start the trencher by increasing engine speed in the operating machine. Ensure the chain is
moving in the correct direction. Slowly increase the trencher’s chain speed.
3. Increase the trencher’s chain speed until full speed.

6
ENGAGING GROUND:
1. With trencher chain operating and weight applied to the skid plate, gradually rotate the
trencher downward so it penetrates the ground. Always keep the skid plate pressed to the
ground when cutting.
2. When the flat face of the skid plate is firmly in contact with the ground, slowly reverse the
skid steer machine. Avoid stalling the chain.
STOPPING THE TRENCHER:
1. Set engine speed to low idle and raise the trencher above ground level.
2. Stop operating machine’s engine and shut off the operating machine.
CHAIN TENSION ADJUSTMENT:
1. Check chain tension by measuring the clearance between the chain and the main boom. Clearance
should be 1.5-2”.
2. Adjust the tension by turning the tensioner assembly on the sides of the boom. Shown below.

7
MAINTENANCE INSTRUCTIONS
1. DAILY INSPECTIONS
a. Check chain tension meets recommend spec above.
b. Check for tooth wear: designed for varying trenching conditions this
implement comes installed with alternating tooth styles. When replacing
teeth, we recommend maintaining this alternating assembly.
c. Check for any loose hardware and tighten as necessary.
d. Check hydraulic assembly for leaks and any damage to hoses
2. GREASE POINTS:
a. Motor Bearing Grease Point

8
PARTS DIAGRAM / EXPLODED VIEW

9

10

11
This concludes the 48TRENCHER Owner’s Manual.
