Titan T-2 Series User manual

POWER RACK
DIAGRAM NO.
1
4
8
3
7
2
6
5
14
13
12
11
10
9
DESCRIPTION
Back Leg
Jhook
Side Leg
Pull-up Bar
Spotter Bar
Molded Feet
Upper Side Support Brace
Upper Rear Support Brace
Upright Poles
Plastic Square Cap
Plastic Round Cap
Square Bolt M12*75
Nylon Lock Nut M12
Hex Bolt M12x80
1
2
8
2
20
1
28
4
2
2
4
1
2
4
QTYPART NUMBER (PN)
P400100-1
Jhook
P400100-3
P400100-4
P400100-5
P400100-6
P400100-7
P400100-8
P400100-9
P400100-10
P400100-11
P400100-12
P400100-13
P400100-14
PACKAGE NUMBER
1
2
2
2
2
1
1
1
1
1
1
1
1
1
MPN: PWR1-PWR2
SKU: 400100
UPC: 765857424125

PACKAGE 1 [PWR1]
(1) Back Leg 1 PC
(6) Molded Feet 4 PCS
(7) Upper Side Support Brace 2 PCS
(8) Upper Rear Support Brace 1 PCS
(9) Upright Poles 4 PCS
(10) Plastic Square Cap 4 PCS
(11) Plastic Round Cap 2 PCS
HARDWARE
• (12) Square Bolt M12*75 8 PCS
• (13) Nylon Lock Nut M12 28 PCS
• (14) Hex Bolt M12x80 20PCS
PACKAGE 2 [PWR2]
(2) Jhooks 2 PCS
(3) Side Leg 2 PCS
(4) Pull-up Bar 1 PCS
(5) Spotter Bar 2 PCS
8
11
14
7
1
9
12
6
2
10
4
7
13
3
5

STEP 1
Bolt the two (3) Side Legs to the (1) Back Leg using the (15) Hex Bolt M12x80.
STEP 2
Attach the four (9) Upright Poles to the (3) Side Legs. Use the (12) Square Bolts M12x75, insert
them from the bottom up.
(9) Upright Poles
(3) Side Legs
(3) Side Legs
(1) Back Leg

STEP 4
Attach the (8) Upper Rear Support Brace bar and the
(7) Upper Side Support Brace to rear (9) Upright Poles,
using the (15) Hex-bolt M12x80.
STEP 5
Attach the (4) Pull-up bar to (7) Upper Side Support Brace
using the (15) Hex-bolt M12x80.
(8) Upper Rear Support Brace
(7) Upper Side Support Brace
(9) Upright Poles
(7) Upper Side Support Brace
(4)
