Titan SDML-1000D Instruction manual

INSTALLATION, OPERATION,
& MAINTENANCE MANUAL
MODEL:
SDML-1000D / SDML-1000D-XLT
1,000 LB CAPACITY PNEUMATIC MOTORCYCLE/ATV LIFT
*OPTIONAL EQUIPMENT SHOWN
FOLLOW THIS MANUAL CAREFULLY TO ENSURE THE MACHINE WILL
FUNCTION CORRECTLY AND PROVIDE MANY YEARS OF DEPENDABLE SERVICE.
FAILURE TO FOLLOW THESE INSTRUCTIONS AND SAFETY WARNINGS MAY
RESULT IN PERSONAL INJURY OR PROPERTY DAMAGE. USE OF STRAPS IS
RECOMMENDED - SOLD SEPARATELY. KEEP THIS MANUAL IN A SAFE DRY PLACE
FOR FUTURE REFERENCE.
®

PO Box 7069 Greenwood, IN 46142
1.888.908-4826 FAX [phone]
www.titanlifts.com
TITAN MARKETING, LLC
®
To Our Valued Customers:
Thank you for purchasing a Titan Lifts®product. We hope this high quality equipment provides you with years of
dependable service.
It is unfortunate that rare situations may occur with the products you purchase from Titan Lifts®. We value your
business as well as the trust you have and need to maintain your relationship with us. Titan Lifts®carries liability
coverage that may protect our customers if a situation does occur. However, as in all accidents there must be
proof of liability for a claim to be made. Our insurance company requires the following procedures be observed in
order to consider a claim:
A. The claimant must contact the Titan Lifts®distributor immediately with the facts of the situation.
B. If any equipment is damaged, including vehicles or shop equipment, Titan Lifts®must be given the
opportunity to send an impartial representative to the site for proper assessment of the situation.
C. The Vehicle cannot be moved until either an impartial representative has reviewed the accident or clear
and precise pictures are taken that reect all the pertinent information for an impartial representative to be able
to access the information from a distance. Titan Lifts®or its representatives must approve the pictures before
anything can be moved.
D. If any potential liability is determined on behalf of Titan Lifts®, two estimates must be submitted for
damages to be reimbursed.
It is imperative that the claimant complies with these procedures, because without proper assessment of the
situation a claim will be denied.
ARBITRATION NOTICE
The installation or use of this equipment shall constitute an acknowledgement that the user agrees to resolve any
and all disputes or claims of any kind whatsoever, which relate in any way to the equipment, by way of binding
arbitration, not litigation. No suit or legal action may be led in any state or federal court. Any arbitration shall be
governed by the Federal Arbitration Act, and administered by the American Mediation Association, Indianapolis
Indiana. The maximum amount that an arbitrator may award and all damages shall not exceed the retail value of
this equipment.
WARRANTY NOTICE
This equipment must be assembled and used in the manner according to the documentation provided to be
covered by warranty.
Damaged or missing components must be reported within 72 hours of receipt to your freight carrier and to the
distributor. Claims must be led to cover cost.
If you have any questions or if we can be of any further assistance, please don’t hesitate to contact a Titan Lifts®
representative at 1-888-908-4826. Thank you for the opportunity to continue to serve your lift equipment needs.

CONTENTS
INSTRUCTIONS .................................................. 1
UNPACKING AND SET-UP *REFER TO PARTS LIST FIG. 1 ..................................................1
OPERATION & MAINTENANCE............................ 2
SAFETY PRECAUTIONS .......................................3
FRONT WHEEL CLAMP ........................................4
INSTALLATION DRAWING ...................................4
FRONT EXTENSION ............................................4
INSTALLATION DRAWING ...................................4
SIDE EXTENSIONS ..............................................5
INSTALLATION DRAWING (XLT ONLY) .................5
PARTS LIST (FIG. 1) .............................................6
PARTS LIST (FIG. 1) - CONTINUED.........................7
FOOT VALVE PARTS DETAIL (FIG. 2).....................8
ROLLER DROP-OUT PARTS DETAIL (FIG. 3) ...........9

1
INSTRUCTIONS
WARNING: READ ENTIRE MANUAL AND COMPLY WITH ALL SAFETY AND SERVICE
PRECAUTIONS. DEATH, PERSONAL INJURY AND/OR PROPERTY DAMAGE MAY OCCUR IF
INSTRUCTIONS ARE NOT FOLLOWED CAREFULLY.
UNPACKING AND SET-UP *REFER TO PARTS LIST FIG. 1
1. Carefully unpack the lift making sure that all of the parts have been included.
2. Remove the lift and all parts from delivery pallet and place on a clean, solid at surface.
3. Safely, manually lift the Deck Plate (57) so that the Safety Bar (46) sits within the rst safety
latch. It is recommended at least two people perform this function.
4. XLT ONLY: Remove one of the Stabilization Pipe Caps (26) from the Stabilization Bar (27). Slide
the stabilization bar through the square tubing of the Outside Lifting Arm (28) and place the
stabilization cap back on the end. Secure the Stabilization Bar in place with the steel Ball Pins
(25).
5. If using the Front Extension (55), slide the front extension over the front of the deck plate so
that the support pipe holes align. Hold the front extension in place by connecting the Eye Bolts
(56) with a Washer Φ10 (23) and Nut M10 (24) (Optional Equipment).
6. Take the Fixed Clamp (63) and bolt it to the Deck Plate (57) or Front Extension (55) using the
provided bolts (64), Washers Φ10 (23) and Nuts M10 (24). Insert the Tire Stop (61) onto the
Fixed Clamp using the Pin (62) (Optional Equipment).
7. Take the Crank Assembly (60) and bolt it to the Deck Plate (57) or Front Extension (55) using
the Provided Bolts (64.1), Washers Φ10 (23) and Nuts M10 (24). Bolt Moveable Clamp (84) to
Crank Assembly (60) using the provided Bolts (81) (Optional Equipment).
8. If using the Side Extensions (52), slide the Support Pipes (53) through Support Pipe holes in
the front and rear of the Deck Plate (57). Slide the Side Extensions over the Support Pipes and
secure in place with the Quick Pins (54).
9. Hook the Ramp (58) and Extension Panels (51) onto the back of the Deck Plate (57) and Side
Extensions (52).
10. Take ends of Air Hose (2) and attach to Foot Operated Air Valve (1) and the Front Cover (6) of
the cylinder.
11. Attach compressed air to the Foot Operated Air Valve (1) to 100 PSI air supply and raise the lift
by moving the valve to the up position. Requires 90-100PSI air supply.
WARNING: Roller Dropout Plate (78) must be removed prior to unloading the motorcycle
from the lift & replaced with the Standard Dropout (59). Do NOT operate motorcycle on Roller
Dropout (78). Roller Dropout (78) is not to be used as a dyno device.
WARNING: The lift may be damaged and/or personal injury may result if the
pressure exceeds the maximum 100 PSI rating.
NOTE: Use caution that mounting bolts for Fixed Clamp (63) do not interfere with the frame
support bar movement when using the front extension.
NOTE: Standard Dropout Plate (59) can be removed for easy rear wheel removal. Roller
Dropout Plate (78) can be installed after motorcycle is loaded for easy rear wheel cleaning
or maintenance.

2
OPERATION & MAINTENANCE
*REFER TO PARTS LIST FIG. 1
* TEST THE LIFT SEVERAL TIMES FOR PROPER OPERATION BEFORE ATTEMPTING TO LIFT A LOAD.
1. All moving parts have been lubricated at the factory and should be re-lubricated before
the rst use and at least once every six months to prevent damage. Grease ttings are
located at each frame pivot shaft and at the top ends of the inside frame assembly.
2. Lightly oil cylinder rod at least once every six months or when it becomes dry.
3. Squirt some oil through the bleed hole in the plate at the end of the cylinder to lubricate
piston and seal every six months.
4. The pivot shaft set screws should be checked frequently to be sure they are tight. These
are located at the top end of the inside frame assembly.
5. Do NOT use this product if worn or damaged. Examine lift for structural cracks, bends,
or other signs of damage prior to each use. Check all hoses and connections before
each use to ensure proper working condition.
6. Keep lift clean, dry, and well maintained to extend longevity of the product.
7. Roll motorcycle onto Deck Plate (57) until wheel is inside the Clamp (84 & 63).
8. Tighten the clamp to the tire by using the crank handle on the Moveable Clamp (60).
9. Load must be centered on the table at all times.
10. Load must be rmly positioned and secured on the table at all times.
11. To raise the lift, make sure that the compressed air is connected and use the Foot
Operated Air Valve (1) until you reach the desired working height.
12. IMPORTANT: After reaching the desired working height, lower the lift so that the Safety
Bar (46) sits rmly in the safety latch and all pressure is off of the Cylinder (20). Remove
air supply from Foot Operated Air Valve (1).
13. When nished working, attach air supply to Foot Operated Air Valve (1), raise the lift to
release the Safety Bar (46) and place it back into Deck Plate (57). Slowly release the air
from the Cylinder (20) until the lift rests gently on the ground.
WARNING
The warnings, precautions and instructions in this manual cannot
cover all possible conditions and situations that may occur. The
operator must understand that the operator must supply common
sense and examine caution factors when using this product to
determine safety in all circumstances being used.

3
SAFETY PRECAUTIONS
1. Load should not exceed rated capacity for this lift - 1,000lb
2. 90-100PSI shop air needed. Do NOT exceed the 100 PSI rating.
3. Make sure the safety bar is down in the locked position while the lift is in the raised
position.
4. Move the lift only when it is lowered.
5. Do NOT ride vehicle onto lift.
6. Only trained people should operate the lift.
7. Foot operated air valve should be at least 3 feet away when operating. Remain clear of
the lift when raising or lowering.
8. Indoor use recommended.
9. Do NOT move lift while loaded.
10. Keep hands, tools and other extremities from under carriage and moving parts.
11. Maintain a safe working environment. The work area should be clean, dry, clutter free
and suciently lit.
12. Wear proper ANSI-approved safety attire. Do NOT wear loose tting clothing while
operating lift, long hair and sleeves should be secured.
13. Keep children and bystanders away from work area. Do NOT let children operate or play
on lift.
14. Do NOT use if under the inuence of drugs or alcohol. Operator must be alert at all
times when using heavy lift equipment.
15. Never operate the lift with someone on it.
16. Use this lift only for the work it is intended. Do NOT use this product for an application
for which it was not designed. Misuse can lead to personal injury and/or property
damage.
17. Industrial applications must follow OSHA requirements.
18. Do NOT use for aircraft purposes.
19. Have your lift serviced by a qualied technician using only identical Titan Lifts®
replacement parts and attachments. This will ensure that the safety of the lift is
maintained.
PLEASE READ THE FOLLOWING CAREFULLY
THE MANUFACTURER AND/OR DISTRIBUTOR HAS PROVIDED THE PARTS LIST AND ASSEMBLY
DIAGRAM IN THIS MANUAL AS A REFERENCE TOOL ONLY. THE MANUFACTURER OR DISTRIBUTOR
DOES NOT MAKE ANY REPRESENTATION OR WARRANTY OF ANY KIND TO THE BUYER THAT HE OR
SHE IS QUALIFIED TO MAKE ANY REPAIRS TO THE PRODUCT, OR THAT HE OR SHE IS QUALIFIED TO
REPLACE ANY PARTS OF THE PRODUCT. THE MANUFACTURER AND/OR DISTRIBUTOR EXPRESSLY
STATES THAT ALL REPAIRS AND PARTS REPLACEMENTS SHOULD BE PERFORMED BY CERTIFIED AND
LICENSED TECHNICIANS, AND NOT BY THE BUYER. THE BUYER ASSUMES ALL RISK AND LIABILITY
ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PRODUCT OR REPLACEMENT PARTS
THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
Product’s Serial Number:____________________________________________________________________
Note: If product does not have a serial number, record the month and year of purchase instead.
Note: Some parts are listed and shown for illustration purposes only, and are not available individually as
replacement parts.

4
FRONT WHEEL CLAMP
INSTALLATION DRAWING
FRONT EXTENSION
INSTALLATION DRAWING
60
63
61
56
55
56
23
57
24
63
60
62

5
SIDE EXTENSIONS
INSTALLATION DRAWING (XLT ONLY)
52
51
58
54
53
27
52
53
54
52
51
53
51
27
25
26

6
PARTS LIST (FIG. 1)
PLEASE MAKE SURE TO CONFIRM THAT ALL PARTS ARE INCLUDED.
(See Fig. 2)
(See Fig. 3)
.
(Optional
Equipment)

7
PARTS LIST (FIG. 1) - CONTINUED
NO. DESCRIPTION QTY NO DESCRIPTION QTY
1 FOOT OPERATED AIR VALVE - Fig. 2 1 44 PIN 2
2 AIR HOSE 1 45 R-PIN 2
3 SCREW CAP M10 4 46 SAFETY BAR (COLOR) 1
4WASHER Φ10 8 47 MACHINE BOLT 2
5 NUT 1 48 PIN 2
6 FRONT COVER 1 49 CYLINDER PIVOT SHAFT 1
7 NYLON O-RING 2 50 RETAINING RING 2
8 O-RING 1 51 RIGHT EXTENSION RAMP - XLT ONLY 2
9 O-RING 2 52 SIDE EXTENSION - XLT ONLY 2
10 SHAFT BUSHING 1 53 SUPPORT PIPE - XLT ONLY 2
11 PISTON ROD 1 54 QUICK PIN - XLT ONLY 4
12 RETAINING RING 1 55 *FRONT EXTENSION 1
13 PRESS RING 1 56 EYE BOLT 2
14 O-RING 1 57 DECK PLATE 1
15 PLASTIC O-RING 1 58 MAIN RAMP 1
16 O-RING 1 59 STANDARD DROPOUT PLATE (COLOR) 1
17 O-RING 1 60 CRANK ASSEMBLY (COLOR) 1
18 PISTON 1 61 TIRE STOP (COLOR) 1
19 BOLT 1 62 WHEEL STOP PIN 1
20 CYLINDER CASING 1 63 FIXED CLAMP (COLOR) 1
21 STAY BOLT 4 64 BOLT 18mm 6
22 CYLINDER END PLATE 1 64.1 BOLT 25mm 4
23 WASHER Φ10 12 65 WASHER PRESS RING 2
24 NUT M10 12 66 DOLLY WHEEL 2
25 STEEL BALL PIN - XLT ONLY 4 67 DOLLY BASE (COLOR) 1
26 STABILIZATION PIPE CAP - XLT ONLY 2 68 BOLT 2
27 STABILZATION BAR - XLT ONLY 1 69 DOLLY HANDLE (COLOR) 1
28 LIFTING ARM - OUTSIDE (COLOR) 1 70 FLAT HEAD MACHINE SCREW 24
29 INNER HEXAGON SCREW 2 71 NUT 2
30 COTTER 4 72 PRESS RING 2
31 BEARING 4 73 RUBBER VISE PAD - RIGHT 1
32 PRESS RING 2 74 RUBBER VISE PAD - LEFT 1
33 WHEEL (COLOR) 2 75 PLASTIC VISE END CAP - BLK 4
34 LIFTING ARM - INSIDE (COLOR) 1 76 PLASTIC WHEEL STOP END CAP - BLK 2
35 RETAINGING RING 2 77 VISE HANDLE - PLASTIC 1
36 BEARING 4 78 *ROLLER DROPOUT - Fig. 3 (COLOR) 1
37 PRESS RING 2 79 LONG RAMP 1
38 CONNECTION (COLOR) 1 80 LEFT EXTENSION RAMP - XLT ONLY 1
39 BOLT M10*45 2 81 BOLT (VISE ATTACHMENT) 4
40 ROLLER 2 82 RETAINING RING 4
41 WASHER Φ16 4 83 COMPLETE CYLINDER ASSEMBLY 1
42 LOCK NUT M16 2 84 MOVEABLE CLAMP (COLOR) 1
43 SAFETY BAR HANDLE 2 85 *COMPLETE VISE ASSEMBLY (COLOR) 1
*OPTIONAL EQUIPMENT

8
FOOT VALVE PARTS DETAIL (FIG. 2)
NO. DESCRIPTION QTY NO DESCRIPTION QTY
1 FOOT PEDAL 1 7 SNAP RING 1
2 RETAINING RING 1 8 LOCK NUT 1
3 WASHER 2 9 BASE 1
4 PLUNGER VALVE 1 10 HEXAGON BOLT 1
5 O-RING 3 11 AIR FITTING 1
6 NYLON BUSHING 1

9
ROLLER DROP-OUT PARTS DETAIL (FIG. 3)
NO. DESCRIPTION QTY
1 DROPOUT PLATE (COLOR) 1
2 RETAINING NUT M8 4
3 BEARING 4
4 ROLLER 2
5 PIN 2
6 BUSHING 4

EQUIPMENT MODEL:
TYPE OF POWER UNIT:
DATE OF PURCHASE:
PLACE PURCHASED:
NAME:
STREET:
CITY, STATE, ZIP:
PHONE:
EMAIL:
SERIAL NUMBER:
SERIAL NUMBER:
WARRANTY REGISTRATION
OPT OUT OF PROMOTIONS
In order to utilize the warranty on this Titan Lifts product, you must register your product with us. The
simplest way to do this is to visit TITANLIFTS.COM/WARRANTIES and submit your information online. If you
prefer to send your information through the mail, please ll out the form below and send this page to us at :
Titan Lifts
PO Box 7069
Greenwood, IN 46142
In order to receive your warranty, return this card
or visit TITANLIFTS.COM/WARRANTIES within 30 days.

P.O. Box 7069 • Greenwood, IN 46142 • Ph. 888-908-4826 • Fx. 317-215-2770 • www.titanlifts.com
LIMITED WARRANTY
The Titan 2 Post lifts and 4 Post lifts are backed by a standard 1 year replacement parts warranty and a 5 year structural
warranty from the date of purchase, to the original purchaser only. The 1 year replacement parts warranty covers power
units, hydraulic cylinders, and all other assembly components such as, but not limited to: turn plates, slip plates, cables,
chains, valves, switches etc. This does not cover normal wear items such as but not limited to rubber lifting pads and nylon
slide blocks. Titan HD2P-9000ACE-D and HD2P-9000AFE 2 Post lifts are backed by a 2 year replacement parts warranty
and a 5 year structural warranty from the date of purchase, to the original purchaser only. The 2 year replacement parts
warranty covers power units, hydraulic cylinders, and all other assembly components such as, but not limited to: turn
plates, slip plates, cables, chains, valves, switches etc. This does not cover normal wear items such as but not limited to
rubber lifting pads and nylon slide blocks.
Titan Mid Rise Scissor lifts are backed by a standard 1 year replacement parts warranty and a 5 year structural warranty
from the date of purchase, to the original purchaser only. The 1 year replacement parts warranty covers power units,
hydraulic cylinders, and all other assembly components such as, but not limited to: turn plates, slip plates, cables, chains,
valves, switches etc. This does not cover normal wear items such as but not limited to rubber lifting pads and nylon slide
blocks.
Titan Standard Duty and Heavy Duty motorcycle lifts are backed by a standard 1 year replacement parts warranty from
the date of purchase, to the original purchaser only. The 1 year replacement parts warranty covers power units, hydraulic
cylinders, pneumatic cylinders, and all other assembly components such as, but not limited to: cables, caster wheels,
valves, switches, wheel vises etc. This does not cover normal wear items such as but not limited to rubber wheel vise pads.
Titan Bulldog Moto Cradle Wheel Chock is warrantied for replacement parts, only to the original purchaser, for a period of 2
years from the date of purchase.
XL Tool by Titan Wheel Service Machines and Helper Arm Assemblies are backed by a standard 1 year replacement parts
warranty from the date of purchase, to the original purchaser only. The 1 year replacement parts warranty covers internal
boards, motors, pneumatic cylinders, and all other assembly components such as, but not limited to: cabinet, switches,
valves, ttings etc. This does not cover normal wear items such as but not limited to: rubber pads, jaw protectors, air hoses,
quick nut assemblies.
Titan shop equipment products and accessories are warrantied for replacement parts only to the original purchaser for
a period of 90 days from the date of purchase. This 90 day replacement parts warranty covers products such as but not
limited to: EZ -Mover Jacks, Mini Jacks, tie down products, wheel service accessories, Bulldog Moto Cradle Wheel Chock
accessories, dollies, stands, Light Duty Motorcycle Lifts, etc.
For all warranty considerations, Titan Marketing, LLC will supply replacement parts only during the warranty period. The
original purchaser is responsible for all shipping, handling, and any labor charges incurred. All defective parts must be
returned to Titan for inspection and examination. Any parts that are found to be defective will be replaced or repaired
to proper working order. Other items not listed above may be considered general wear parts and therefore, will not be
covered under warranty. These warranties do not extend to defects caused by ordinary wear, abuse, misuse, shipping
damage, improper installation, voltage or lack of required maintenance. Titan Marketing, LLC is not to be held responsible
for any failure that results from an accident, purchaser/operator abuse, neglect, or failure to operate products in
accordance with instructions provided in the owner’s manual(s) supplied. Damage caused by rain, excessive humidity,
corrosive environments or other contaminants are not covered under warranty. THESE WARRANTIES DO NOT EXTEND
TO ANY COSMETIC DEFECT NOT INTERFERING WITH EQUIPMENT FUNCTIONALITY OR ANY INCIDENTAL, INDIRECT, OR
CONSEQUENTIAL LOSS, DAMAGE, OR EXPENSE THAT MAY RESULT FROM ANY DEFECT, FAILURE OR MALFUNCTION OF
A TITAN MARKETING LLC PRODUCT OR THE BREACH OR DELAY IN PERFORMANCE OF THE WARRANTY.

WARNING
The warnings, precautions and instructions in this manual cannot
cover all possible conditions and situations that may occur. The
operator must understand that the operator must supply common
sense and examine caution factors when using this product to
determine safety in all circumstances being used.
®
PO Box 7069 Greenwood, IN 46142
1.888.908-4826 FAX [phone]
www.titanlifts.com
TITAN MARKETING, LLC
Copyright © 2016 by Titan Marketing, LLC. All rights reserved. No portion of this manual or any artwork contained herein may be
reproduced in any shape or form without the express consent of Titan Marketing, LLC. Diagrams within this manual may not be
drawn proportionally. Due to continuing improvements, actual product may differ slightly from the product described herein. Tools
required for assembly and service may not be included.
Patent No.: US 8,104,588 B2
CA 2,729,670 Revision 9
