Titan SF16G User manual

16” SCROLL SAW SF16G
SAFETY AND OPERATING MANUAL

GUARANTEE
This product carries a Screwfix Direct Ltd guarantee of 12 months. If your product
develops a fault within this period, you should,in the first instance contact Screwfix
Direct Ltd on Freephone 0500 41 41 41. If the fault occurs within the first 12 months,
you may return the goods for a full refund or we will repair or replace the goods if
you prefer. When repair is not practical or identical goods are not available, alternative
goods of similar specification and quality will usually be provided but, failing this, you
will be offered a partial or full refund depending on the time period since purchase.
This guarantee specifically excludes losses caused due to:
- Fair wear and tear
- Misuse or abuse
- Lack of routine maintenance
- Failure of consumable items (such as batteries)
- Accidental damage
- Cosmetic damage
- Failure to follow manufacturer’s guidelines
- Loss of use of the goods
- Repairs attempted by anyone, unless authorised by Screwfix Direct Ltd.
This guarantee does not affect your statutory rights. This guarantee is only valid in the UK.
For further technical advice, spare parts or repair service (outside of guarantee) please
contact the customer helpline number on 0845 607 6380.
Congratulations on your purchase of a power tool from Screwfix Direct
Ltd. We want you to continue getting the best performance from it so this
handbook includes information on safety, handling and care. Please retain this
handbook in case you need to refer to any of the information in the future.
Your power tool comes with a 12-month guarantee,so should it develop
a fault within this period contact Screwfix Direct Ltd on Freephone 0500 41
41 41.

16” SCROLL SAW SF16G
SAFETY INSTRUCTIONS
WARNING! Read all instructions. Failure to follow all instructions listed
below may result in electric shock, fire and/or serious injury.
SAVE THESE INSTRUCTIONS
1. Keep the work area clean.
Cluttered areas and benches invite injuries.
2. Consider work area environment.
Do not expose power tools to rain. Do not use power tools in damp or wet loca-
tions. Keep the work area well lit. Do not use tools in the presence of flammable
liquids or gases.
3. Guard against electric shock.
Avoid body contact with earthed or grounded surfaces (e.g. pipes, radiators,
ranges, refrigerators).
4. Keep children away.
Do not let persons, especially children, not involved in the work touch the tool or
the extension cord and keep them away from the work area.
5. Store idle tools.
When not in use, tools should be stored in a dry, high or locked up place, out of
reach of children.
6. Do not force the tool.
It will do the job better and safer at the rate for which it was intended.
7. Use the right tool.
Do not force small tools to do the job of a heavy-duty tool. Do not use tools for
purposes not intended, for example, do not use circular saws to cut tree limbs or
logs.
8. Dress properly.
Do not wear loose clothing or jewellery, they can be caught in moving parts. Non-
skid footwear are recommended when working outdoors. Wear protective hair
covering to contain long hair.
9. Use protective equipment.
Use safety glasses. Use face or dust mask if working operations create dust.
10. Connect dust extraction equipment.
If the tool is provided for the connection of dust extraction and collecting equip-
ment, ensure these are connected and properly used.
11. Do not abuse the cord.
Never yank the tool to disconnect it from the socket. Keep the cord away from
heat, oil and sharp edges.
12. Secure work.
Where possible use clamps or a vice to hold the work. It is safer than using your
hand.
13. Do not overreach.
Keep proper footing and balance at all times.
14. Maintain tool with care.
Keep cutting tools sharp and clean for better and safer performance. Follow
instructions for lubrication and changing accessories. Inspect tool cord periodi-
cally and if damaged have them replaced by an authorised service facility. Inspect
extension cords periodically and replace if damaged. Keep handles dry, clean and
free of oil or grease.

15. Disconnect tools.
When not in use, before servicing and when changing accessories such as blades,
bits and cutters, disconnect tools from the power supply.
16. Remove adjusting keys and wrenches.
From the habit of checking to see that keys and adjusting wrenches are removed
from the tool before turning it on.
17. Avoid unintentional starting.
Ensure switch is in the “off” when plugging in.
18. Use outdoor extension leads.
When tool is used outdoors, use only extension cords intended for outdoor use
and so marked.
19. Stay alert.
Watch what you are doing. Use common sense. Do not operate tool when you are
tired.
20. Check damaged parts.
Before further use of the tool, it should be carefully checked to determine that it
will operate properly and perform its intended function. Check for alignment of
moving parts, binding of moving parts, breakage of parts, mounting and any other
conditions that may affect its operation. A guard or other part that is damaged
should be properly repaired or replaced by an authorised service centre unless
otherwise indicated in this instruction manual. Have defective switches replaced
by an authorised service facility. Do not use the tool if the switch dose not turn it
on and off.
21. Warning.
The using of any accessory or attachment other than those recommended in this
instruction manual may present a risk of personal injury.
22. Have your tools repaired by qualified person.
This electrical tool complies with the relevant safety requirements. Repairs should
only be carried out by qualified persons using original spare parts, otherwise this
may result in considerable danger to the user.
HEALTH ADVICE
WARNING! When drilling, sanding, sawing or grinding, dust particles will be
produced. In some instances, depending on the materials you are working with,
this dust can be particularly harmful to you (e.g. lead from old gloss paint).
You are advised to consider the risks associated with the materials you are working
with and to reduce the risk of exposure. You should:
-- Work in a well-ventilated area.
--Work with approved safety equipment, such as those dust masks that are specially
designed to filter microscopic particles.

16” SCROLL SAW SF16G
ADDITIONAL SAFETY INSTRUCTIONS FOR YOUR SCROLL
SAWS
1. Never stand on your scroll saw.
Standing on your Scroll Saw or its stand could cause serious injury and damage
to the machine. Do not store materials above or near the tool so that it is
necessary to stand on the tool or its stands to reach them.
2. Check damaged parts.
If any part of the Scroll Saw is damaged, before further use, check carefully that it
will operate properly and perform its intended operation. Any guard or other part
that is damaged should be correctly repaired or replaced.
3. Safe working practices.
Never operate the scroll Saw if taking medication that can cause drowsiness or
when having consumed alcohol or drugs.It is recommended that the Scroll saw
be bolted to a bench with sufficient working space around it.
4. Do not leave the scroll saw running unattended.
Turn off power to machine and unplug mains cable. Do not stop the machine with
work still in contact with the blade.
5. General description
The Scroll Saw is a static indoor machine not suitable for use outdoor. The
machine uses a single-phase alternating current 230V~50Hz motor. Do not
attempt to cut pieces of material too small to hold by hand outside the blade
guard. Avoid awkward hand positions where a sudden slip could cause a hand to
move into the blade.
Avoid the risk of the workpiece jumping upwards, ensure the blade teeth point
downward toward the table.
To avoid blade breakage always adjust blade tension correctly.
6. To avoid losing control of the work piece or tool:
When cutting a large piece of material make sure it is fully supported at table
height. Hold the work piece firmly against the table. Do not force the material
while cutting. Only feed the material fast enough so that the blade maintains a
smooth cutting speed. Use caution when cutting off material which is irregular in
cross section, which could pinch the blade before the cut is completed. A piece of
moulding for example must lay on the table and not be permitted to rock while
being cut. Use caution when cutting off round material such as dowel rods or
tubing . They have a tendency to roll while being cut causing the blade to bite.
Use a Vblock to control the piece. When backing the blade out of the workpiece,
the blade may bind in the kerf (cut) this is usually caused by sawdust clogging up
the kerf. If this happens, turn off the Scroll Saw, remove plug from power source
outlet, wedge open the kerf, and then back the blade out of the workpiece. To
avoid misuse or accidents due to inattention, never leave the scroll saw work area
with the power on or before the machine has come to a complete stop.
Do not perform layout, assembly or set up work on the table while saw is in
operation. Turn the saw off and remove plug from power supply before installing
or removing an accessory or attachment. Never turn your scroll saw on before
clearing the table of all objects (tools scraps of wood etc).
7. Damaged or missing parts.
Should any part of this Scroll Saw be missing, bent or fail in any way or any
electrical component fail to perform properly, shut off the power switch and

remove the plug from power supply.
Replace damaged, missing and/or failed parts before resuming operation.
8. Think safety.
Safety is a combination of operator common sense and alertness whenever the
scroll saw is in operation. The operation of any power tool can result in foreign
objects being thrown in to the eyes, which can result in severe eye damage.
Always wear safety goggles before commencing power tool operation.
Warning:
Always wear safety goggles or face shield. Install blade with teeth pointing down
towards the table. Keep fingers a safe distance from the blade.
Never leave the scroll saw work area with the power on. Adjust blade tension by hand
(not with a tool) before turning on. Maintain control of the workpiece at all times, hold
firmly against the table.
SYMBOLS
Read the manual Warning Wear gloves
Wear dust mask,eye & ear protection
Conforms to relevant safety standards

16” SCROLL SAW SF16G
1. FRAME
2. DUST BLOWER
3. ARM BEARING (ON EACH SIDE)
4. TENSION KNOB
5. BENCH MOUNTING HOLES
6. BASE
7. BLADE GUIDE
8. BLADE
9. ON/OFF SWITCH
10. BEVEL SCALE
11. BEVEL SCALE POINTER
12. TABLE LOCKING KNOB
7
2
8
9
10
11
12
1
3
4
5
6

TECHNICAL DATA
Voltage:
Input power:
No load speed:
Max. Width of cut:
Blade size:
Max. Depth of cut:
Max. Depth of cut:
Table size:
Weight:
230V~50Hz
85W
1,400min-1
406mm
128mm length
25 teeth / inch
50mm at 90O
25mm at 45O
365x200 mm
14.9Kg
NOISE AND VIBRATION DATA
A weight sound pressure
A weighted sound power
Noise and Vibration
66.4dB(A)
79.4dB (A)
2.598m/s2
ACCESSORIES
Blade 1 PC

16” SCROLL SAW SF16G
ASSEMBLY OF THE SCROLL SAW
Warning: For your own safety never
connect plug to power source until all
assembly steps are complete.
Caution: Never lift this saw by the arm,
which holds the blade or damage will occur
to your saw.
Locate the blade guard and carefully install it onto
the saw as shown. (See Fig2) Secure the blade
guard to the frame by a bolt, washer and knob.
Your scroll saw is fitted with a small blow pump
to help keep the blade and work area clean.
Insert pipe onto blower, point outlet pipe towards
blade.
Setting the table for horizontal or bevel
cutting
The Scroll Saw worktable can be tilted to the left
for bevel cutting up to 45O from 0O or horizontal
position. (See Fig3)
A bevel scale is provided under the worktables
as a convenient reference for setting the
approximate table angle for bevel cutting. When
greater precision is required, make practice
cuts and adjust the table as necessary for your
requirements.
To align the bevel indicator
Loosen the table locking knob and move the table
until it is approximately perpendicular or at a
right angle to the blade. (See Fig4)
Use a small set square to set the table at 90
degrees to the blade. When the space between
the set square and the blade is minimal, tighten
the bevel locking knob. The table should now be
approximately 90 degrees to the blade. (See Fig5)
Loosen the screw holding the bevel scale pointer
and adjust pointer to 0 degrees. Tighten screw.
Remember the bevel scale is a convenient guide
but should not be relied upon for precision. Make
practice cuts in scrap wood to determine if your
angle settings are correct. Adjust the table as
required.
Removing and installing blades
Warning: To avoid injury from accidental
starting, always turn switch “off” and
remove the plug from electrical outlet
Fig 2
Fig 3
Fig 4
Fig 5

Fig 6
Fig 7
Fig 8
before removing or replacing the blade.
Loosen tension on the blade by turning tension
knob check just until the tension spring is fully
compressed. (See Fig6) Remove blade by pulling
forward on blade and then lifting the blade
through the access hole in the table.
Slight downward pressure against the upper
arm may be helpful when removing blade from
upper holder. (See Fig7) Look at the blade holders
closely and notice the blade slots and pin recesses
in the blade holder. The blade holder is made so
you can position the blade for cutting from the
front or from the side of the saw. Cutting from
the side of the saw will be necessary when your
work piece exceeds 406mm (16 inch) in length.
With the blade positioned for side cutting the
table must always remain in the 0 degrees bevel
position. (See Fig8)
Warning: Do not attempt to cut a bevel
with the blade positioned for side
cutting.
Mounting the scroll saw to a bench
This saw must be mounted on a solid non
moving surface ie a heavy duty bench by
means of suitable bolts(not supplied).We also
recommend using a soft foam pad between the
saw and the work surface(not provided) which
will greatly reduce noice and vibration.
Do not over tighten mounting bolts
Leave some cushion in the foam pad for
absorbing noise and vibration.
To turn the machine on push the green button
marked “I”, To turn the machine off, push in the
red button marked “0”.
Note:
Never leave the machine unattended until it has
come to a complete stop. Your machine has been
fitted with the latest type of safety switch and
will automatically switch to the off position when
the machine is disconnected from the power
supply.
Fig 9
Pressure
Cutting material
forward

16” SCROLL SAW SF16G
OPERATION
Please read and understand the following
guidelines for your scroll saw before
attempting to use it:
There is a skill level associated with using a
Scroll saw. Until you have practiced with the
saw and built up your skill level, be prepared for
the possibility that you might snap the blades.
Following these simple guidelines will help you
achieve best results from your saw:
a) Do not aggressively push wood onto the
blade. Adopt a “feeding” motion and allow
the saw to cut the wood by guiding it onto the
blade. Remember the blade cuts on the down
stroke only.
b) Best results are achieved when cutting wood
less that 25mm thick. When cutting wood thicker
than this feed the wood slowly onto the blade
and be careful not to bend or twist the blade.
c) Replace your blade when it becomes blunt.
d) Be prepared to compensate for the blade
tendency to follow the grain of the wood.
e) As a guide to blade selection very fine narrow
blades should be used to cut in thin wood
(6mm). For wider timber use wider blades.Check
the instructions that come with the blades for
guidance.
f) As a general guide wider blades will not cut
curves as accurate as a narrow blade.
g) Do not apply side pressure to the blade
h) Blades will wear quicker when cutting
plywood or timber over 25mm thick.
Making interior scroll cuts
One of the features of this saw is that it
can be used to make scroll cuts on the interior
of a board without breaking or cutting into the
outline or perimeter of the board.
Warning: To avoid injury from
accidental starting, always turn switch

off and remove the plug before removing
or replacing the blade.
To make interior cuts in a board remove the
scroll saw blade as explained in the assembly
section. Drill a 6mm (1/4”) hole in the board you
will use to make interior cuts. Place the board
on the saw table with the hole in the board
over the access hole in the table. Install blade
through hole in the board, re-attach blade to
blade holders and adjust blade tension. (See
Fig9) When finished making the interior scroll
cuts simply remove the blade from the blade
holders as described in the assembly section
and remove the board from the table.

16” SCROLL SAW SF16G
TROUBLE SHOOTING
Warning:
For your own safety, turn switch “off” and remove the plug before
trouble shooting your scroll saw.
Problem
Breaking blades
Motor will not run
Vibration
Note: There will always
be some vibration
present when the saw is
running because of the
motor operation.
Blades run out.
Blades not in-line with
arm motion.
Problem cause
1.Wrong tension.
2.Over working blade.
3.Wrong blade
application.
4.Twisting blade in
wood.
1.Defective cable or plug.
2.Defective motor.
1.Improper mounting of
saw.
2.Unsuitable mounting
surface.
3.Loose table or table
resting against motor.
4.Loose motor mounting.
1.Blade holders not
aligned.
Remedy suggested
1.Adjust blade tension.
2.Reduce feed rate.
3.Use narrow blades for
cutting thin wood, wide
blades for thicker wood.
4.Avoid side pressure.
1.Replace parts before
using saw again.
2.Consult a service centre.
Any attempt to repair
this motor may create a
HAZARD unless a qualified
service technician does
repair.
1.See mounting
instructions in this manual
for proper mounting
technique.
2.The heavier your
workbench is the less
vibration will occur.
A plywood workbench will
not be as good as solid
timber bench.
Use common sense in
choosing a mounting
surface.
3.Tighten table lock knob.
4.Tighten motor mounting
screws.
1.Loosen cap screws
holding blade holders to
adjust position of blade
holder - retighten holders.

ENVIRONMENTAL PROTECTION
Waste electrical products should not be
disposed of with household waste. Please
recycle where facilities exist. Check with
your Local Authority or retailer for recycling
advice.
MAINTENANCE
Warning: For your own safety turns switch off
and remove the plug before maintaining or lubri-
cating your saw.
General:
An occasional coat of paste wax on the work-
table will allow the wood being cut to glide
smoothly across the work surface.
Motor:
If the power cable is worn, cut or damaged in
any way, have it replaced immediately.
DO NOT attempt to oil the motor bearings or
service the motor internal parts.
Arm bearings:
Lubricate the arm bearings after every 50 hours
of use.
To do so: Turn saw on its side.
Squirt a generous amount of SAE 20 oil around
the shaft end and bronze bearing.
Let the oil soak in overnight in this condition.
Next day repeat the above procedure for the op-
posite side of the saw.

16” SCROLL SAW SF16G
PLUG REPLACEMENT
The fuse in the main plug on the charger should
always be replaced with one of identical rating.
Check the voltage given on the charger matches
the supply voltage.
The fast charger include with you drill is supplied
with a fitted plug, however if you should need to
fit a new plug follow the instruction below.
IMPORTANT
The wire in the mains lead are coloured in
accordance with the following code:
Green & yellow ---Earth
Blue ---Neutral
Brown ---Live
The wire which is coloured green & yellow must
be connected to the terminal which is marked
with E or .
The wire that is coloured blue must be connected
to the terminal that is marked with the letter N.
The wire that is coloured brown must be
connected to the terminal that is marked with the
letter L.
A 13AMP (BS1363 or BS1363/A) plug must be
used and a 5 AMP fuse must be fitted.

Declaration of Conformity
We, Importer
Screwfix Direct Ltd
Mead Avenue
Houndstone Business Park
Yeovil
BA 22 8RT
Declare that the product
SCROLL SAW
SF16G
Complies with the essential health and safety requirements of the following directives:
89/336/EEC, 93/68/EEC – EMC Directive.
73/23/EEC, 93/68/EEC – Low Voltage Directive.
98/37/EC – Machinery Directive.
Standards and technical specifications referred to:
EN 61029-1/A12:2003
EN 55014-1 /A2:2002
EN 55014-2 /A1:2001
EN 61000-3-2:2000
EN 61000-3-3: /A1:2001
Authorised Signatory
Date: 15/09/05
Signature:
Name: Peter Harries
Screwfix Direct Ltd
Quality Manager
2005

16” SCROLL SAW SF16G
