Titon Overture DH Operating instructions

Overture DH - Long Base Plate
Fixing and Operating Instructions
Failure to adhere to these instructions invalidates your Titon Product Guarantee.
Paint or corrosion not covered by Guarantee.
1. Rout / drill door.
2. Cut screws (M5) and spindles (8mm Square) to length if
necessary.
3. Place spindles in position
4. Place both handles into position and insert xing screws,
leaving loose.
5. Fit Euro cylinder and tighten handle xing screws, do not
over tighten.
Cleaning
Door handles should only be cleaned using warm soapy water
and a soft cloth.
Do not clean any part with solvents or abrasive substances.
75
9216
210
R9.5
Ø10.5
Hole A Ø12
Ø10.5
Hole B Ø12
Hole A for Lever
Hole B for Pad
62
Routing / Drilling Detail
Supplied with:
2 shafts 70mm
2 screws M5 85mm long
2 screws M5 75mm long
TN8103 & TN8107
(Lever/Pad) (Lever/Lever)
Supplied with:
1 shafts 108mm
1 Shaft 95mm
2 screws M5 85mm long
2 screws M5 75mm long
TN8102 & TN8106
Fixing InstructionsDiagram
BM486 Iss01 © 2014
Page 1 of 3

Overture DH - Long Base Plate
Fixing and Operating Instructions
120
32
92
6.8
43.5
56
10.5
15
75
240
240
96
10.5
39
6.8
105
62
210
65
Diagram
BM486 Iss01 © 2014
Page 2 of 3
Lever/Pad

Overture DH - Long Base Plate
Fixing and Operating Instructions
BM486 Iss01 © 2014
Page 3 of 3
Lever/Lever
120
32
92
6.8
43.5
56
10.5
15
75
240 210
Diagram
