TKH security FD2005v2M User manual

© TKH Security B.V.
FD2005v2M
5MP Vandal Fixed Dome Camera
Quick Start Guide
Unpack Installation Notices Connectors
Connector Definition Camera Cabling Waterproof Notice
Find additional manuals, the
datasheet, the EU Declaration of
Conformity, and the latest firmware
for this product at:
tkhsecurity.com
CAUTION INSTALLATION SHALL BE PERFORMED BY
QUALIFIED PERSONNEL ONLY. INSTALLATION SHALL BE IN
ACCORDANCE WITH LOCAL PROCEDURES. THE CAMERA
CONTAINS BATTERIES. DO NOT REPLACE IN RISK OF
EXPLOSION.
BATTERY REPLACEMENT SHALL NOT BE APPLIED IN VIEW
OF THE RISK OF EXPLOSION. LE REMPLACEMENT DES
PILES NE DOIT PAS ÊTRE APPLIQUÉ AU RISQUE
D'EXPLOSION. DISPOSE OF USED BATTERIES ACCORDING
TO THE INSTRUCTIONS. METTRE AU REBUT LES
BATTERIES USAGÉES CONFORMÉMENT AUX
INSTRUCTIONS..
FOR “PoE” INPUT CONNECTION, USE ONLY WITH UL
LISTED I.T.E WITH “PoE” OUTPUT. DESCRIPTION FOR THE
“PoE” IS INTENDED TO BE CONNECTED TO NOT EXPOSED
(OUTSIDE PLANT) NETWORKS OR EQUIVALENT
STATEMENT IN INSTALLAION INSTRUCTIONS.
POUR LA CONNEXION DâÇÖENTREE "PoE", UTILISER
UNIQUEMENT AVEC UN I.T.E. LISTE AVEC UNE SORTIE
"PoE". LA DESCRIPTION DE "POE" EST CONÇUE POUR
ÊTRE CONNECTÉE À DES RÉSEAUX OR NON ÉNONCÉS
(INSTALLATIONS EXTÉRIEURES), DANS LES
INSTRUCTIONS D’INSTALLATION DE L’INSTALLATION.
Subject to modification. Actual product and accessories may differ in appearance.
Figure 1 Camera Connectors
Table 1 Connector definition
No.
Connector Definition
1
Alarm I/O
Alarm I/O connection
2
Audio I/O
Line In and Line Out connection
3
RJ
-45 Port
(Contact Siqura for a
compatible PoE
injecter.)
For network and PoE connections
4
Power(DC 12V)
Power Connection
5
Reset Button
Press the button with a proper tool for at
least 20 seconds to restore the system.
6
Micro SD
Card Slot
Insert the SD card into the card slot to store
videos and snapshots. Do not remove the
SD card when the camera is powered on.
2021 | Vision 1 (20211123) | FD2005v2M QSG
Quick Start Guide
Security Torx
Screws(4x) &
Plastic Screw
Anchors (4x)
Camera Unit
Mounting Plate Duster
CAT-6 RJ45 conduit
& Pin pusher
Conduit
1
23
4
56
Please make sure the
rubber is properly aligned
during installation.
Figure 2 Cabling
Figure 3 Rubber
RESET BUTTON TAKES 10 SECONDS TO BE
EFFECTIVE. IT WILL RESTORE FACTORY
DEFAULT SETTINGS, INCLUDING IP ADDRESS,
USERNAME AND PASSWORD.
© TKH Security B.V.
Auto detect with SDM2
Browser-based Viewer
Accessing the Camera - DHCP
1st time camera login
Accessing the camera –Fixed IP
1st time camera login
Tkhsecurity.com
Enter to the camera
product page, Link &
Download section
IP = 10.x.y.z
Network Switch
DHCP
1
2 3
SDM2-vx.xx-setup.zip
Look for SDM2
x6W@oM0a!9#F
11
Set a strong password
qwer1234
x6W@oM0a!9#F
IP = 192.168.1.x
IP = 192.168.1.x
Network Switch
DHCP
30s
DHCP
IP = 10.x.y.z
2021 | Vision 1 (20211123) | FD2005v2M QSG
IT IS NOT RECOMMENDED TO CONTINUOUSLY
(24/7) RECORD WITH THE MICRO SD CARD, AS
THE CAMERA MAY NOT SUPPORT LONG-TERM
CONTINOUS DATA READ/WRITE. CONTACT THE
MANUFACTURER OF THE MICRO SD CARD FOR
INFORMATION REGARDING THE RELIABILITY
AND THE LIFE EXPECTANCY.
