Main Specifications:
6.0x H3.2 (m) / 10ft x 19.68ft x 10.3ft
Inside size: W2.64x L5.86x H3.15 (m)
urtain/Net: W4.45 x H2.1 (m)
urtain: 180G polyester
Prior to assembly:
Please go through the whole instruction manual completely. It is very important to follow
your local safety regulations and industry standards during installation.
Regulations may include but are not limited to:
- Safety helmets, protective eyewear, protective glove and clothing
- Safety harnesses for all elevated workers
- Proper ladder and safety operation
Check all components and parts before installation. All parts are marked with a part
number, please refer to the parts list to ensure you have all parts.
Choose a day with low or no wind to install, it is hard to assemble with heavy wind. Do
not make any alterations to the structure. Do not hang any weight on the frame during
installation, including parts. We are not responsible for any damages or injuries caused by
inappropriate installation, unauthorized modifications or extreme weather.
Check the parts list below to make sure all parts are received prior to assembly.

►www.tmgindustrial.com P2 / 15 Toll Free: 1-877-761-2819
TMG-LGZ20 Part List
Parts
code
Graphical
Description
Length
Qty
A
Post
100x100mm
4
A1
Middle post
100x100mm
2
B
Cross beam
28x140mm
2
C1
Left cross beam
28x140mm
2
C2
Right cross beam
28x140mm
2
D1
Left support
1.2x60mm
6
D2
Right support
1.2x60mm
6
E
Steel corner
20x20mm
12
F
Post cover
100x140mm
4
F1
Middle post cover
100x100mm
2
G1
Large galvanized
sheet (Left)
4
G2
Large galvanized
sheet (Right)
4
H1
Small galvanized
sheet (Left)
4
H2
Small galvanized
sheet (Right)
4
I1
Middle galvanized
sheet (up)
6

►www.tmgindustrial.com P3 / 15 Toll Free: 1-877-761-2819
I2
Middle galvanized
sheet (down)
6
J
Long beam
37x48mm
4
K1
Short beam
32x48mm
10
K2
Short beam
connection
1.2x60mm
10
L
Top cover
1.2*200mm
2
L1
Left big top
20x100mm
1
L2
Right big top
20x100mm
1
M1
Short support
25x25mm
8
M2
Long support
25x25mm
6
N1
Connection for
support
4
N2
Connection for
support
10
O
Middle edge strip
25x28mm
6
O1
Left edge strip
25x28mm
4
O2
Right edge strip
25x28mm
4
Q1
Angle cover
4
Q2
Flat cover
10
R
Decorative cover
6
W
Middle cross beam
1

►www.tmgindustrial.com P4 / 15 Toll Free: 1-877-761-2819
X1
Curtain
1
X2
Net
1
a M6x16 180
b M6x45 30
d Hook 3
e M4x10 14
f M4x4 46
g Nut 60
hgas ket 60
i M4.2x20 24
j M6x80 24

►www.tmgindustrial.com P5 / 15 Toll Free: 1-877-761-2819
Step 1: Install Post A
Install decorative cover R on all post A/A1, use screw a to fix steel corner E on the
post and tighten the screw.
Parts
code
Graphical
Qty
Parts
code
Graphical
Qty
A
4
R
6
A1 2 a 12
E 2 i 24
j 24

►www.tmgindustrial.com P6 / 15 Toll Free: 1-877-761-2819
Step 2: Install Cross Beam B/ left beamC1/ right beamC2/ middle beam W
Take out the cross beam B /C1 /C2 /W and post cover F
Connect the cross beam B /left C1 /right C2 and post cover F to Post A/A1 with
screws b .
Connect Middle beam W and post cover F1 to Post A1 with screws b .
Parts
code
Graphical
Qty
Parts
code
Graphical
Qty
B
2
W
1
C1
2
b
28
C2
2
F
4
F1
2

►www.tmgindustrial.com P7 / 15 Toll Free: 1-877-761-2819
Step 3: Install Left support D1 & right support D2
Take out the D1 and D2 , Connect Left & Right support D1&D2 to the cross beams
B/C1/C2 and post A /A1with screws a.
Parts
code
Graphical
Qty
D1
6
D2
6
a
36

►www.tmgindustrial.com P8 / 15 Toll Free: 1-877-761-2819
Step 4: Install Big top / Top cover / short beam
Take out Left L1 and Right L2,Connect them with screw a
Connect Top cover L with screw e, gasket h and nut g
Connect 1piece short beam K1 and 1piece connection K2 with screw a, then Install
the rest of 9 pieces K1&K2 in the same way.
Parts
code
Graphical
Qty
Parts
code
Graphical
Qty
K1
10
e
12
K2
10
g
12
L
1
h
12
L1
1
L2
1
a
14

►www.tmgindustrial.com P9 / 15 Toll Free: 1-877-761-2819
Step 5: Install long beam J and short beam K1
Take out J , Connect long beam J to Post cover F, L1 and L2 respectively with screw
a.
Take out the installed K1 of Step 4 , Connect K1 and L1/L2 with screw a, Connect
K2 and beam B , C1 , C2 with screws a.
Parts
code
Graphical
Qty
J
4
a
56

►www.tmgindustrial.com P10 / 15 Toll Free: 1-877-761-2819
Step 6: Install support M1 and M2 on the top
Take out M1, M2 , N1 and N2,Connect N1& G1 , N2& K1 with screw a
Then connect M1and M2 , N1/N2 with screw a
Parts
code
Graphical
Qty
Parts
code
Graphical
Qty
M1
8
N2
10
M2
6
a
42
N1
4

►www.tmgindustrial.com P11 / 15 Toll Free: 1-877-761-2819
Step 7: Connect the galvanized sheet G1 &H1 , G2 &H2, I1 & I2
Connect Left side G1 and H1 with screw f, gasket h and nut g
Connect Right side G2 and H2 with screw f, gasket h and nut g
Connect Middle I1 and I2 with screw f, gasket h and nut g
(note: screw f and gasket h are above the sheet ,nut g is below the sheet
Parts
code
Graphical
Qty
Parts
code
Graphical
Qty
I1
6
H2
4
I2
6
f
42
G1
4
g
42
G2
4
h
42
H1
4

►www.tmgindustrial.com P12 / 15 Toll Free: 1-877-761-2819
Step 8: Install the galvanized sheet top on Left /Right side
Take out the installed galvanized sheet G1 and G2 of Step 7
As shown the diagram, insert the galvanized sheet G1& G2 into Left /Right side, and
fix the edge strip O1(left )& O2(right), Angle cover Q1 and flat cover Q2 on the sheet
with screw a
Parts
code
Graphical
Qty
Parts code
Graphical
Qty
O1
4
Q2
6
O2
4
a
10
Q1
4

►www.tmgindustrial.com P13 / 15 Toll Free: 1-877-761-2819
Step 9: Install the Top cover L
Take out the Installed top cover L of Step4 , use hook d to Connect L and L1/L2
Parts code
Graphical
Qty
d
3

►www.tmgindustrial.com P14 / 15 Toll Free: 1-877-761-2819
Step 10: Install the galvanized sheet I2

Take out the Installed galvanized sheet I2 of Step 7
As shown the diagram, insert the galvanized sheet I2 into the middle position , and fix
the edge strip O and flat cover Q2 on the sheet with screw a
Parts
code
Graphical
Qty
Parts code
Graphical
Qty
O
2
a
8
Q2
2

►www.tmgindustrial.com P15 / 15 Toll Free: 1-877-761-2819
Step 11: Install CurtainX1 and Net X2
Hang the curtain X1 and the net X2 above on the hook of beam B. (Note: Inside net
/outside curtain)
Parts code
Graphical
Qty
X1
1
X2
1
