TMG TMG-PT2020F User manual

►www.tmgindustrial.com 0/20 TOLL FREE:1-877-761-2819
Main Specifications :

►www.tmgindustrial.com 1/20 TOLL FREE:1-877-761-2819
MAIN SPECIFICATIONS :
-Assembly size : W6 x L6 x H3.1 (m) / 19.7 x 39.4 x10.2 (ft)
-Shoulder wall clearance height : 2 m / 6.6 ft
PRIOR TO ASSEMBLY
Please read the instructions carefully before installation. It is important to follow your local safety regulations and
industry standards during installation. Regulations may include but are not limited to :
- Safety helmets, protective eyewear, and clothing
- Safety harnesses for all elevated workers
- Proper ladder, cage, and safety operation
Check all components and parts before installation. All parts are marked with a part number, please refer to the parts list
to make sure you have all parts.
Choose a day with low or no wind to install, assembly is hard in heavy wind. Do not make any alterations to the structure.
Do not hang any weights on the frame during installation, including parts. We are not responsible for any damages or
injuries caused by inappropriate installation, unauthorized modifications or extreme weather.
This building is not intended for human occupancy.
Choose a solid flat level ground area to set up the building. Do not install the building on soft ground, wetland, uneven
surfaces, sloped surfaces, or on top of structures that are not rated to hold its weight.
Be aware of the surrounding area. Do not set up the building near snowdrifts, open flames or exposed electrical
wires. Do not keep heat sources near the fabric cover. Keep the building surroundings clear at all times.

►www.tmgindustrial.com 2/20 TOLL FREE:1-877-761-2819
FRAME STRUCTURE DIAGRAM.

►www.tmgindustrial.com 3/20 TOLL FREE:1-877-761-2819
TMG-PT2020F PART LIST
PARTS
CODE
GRAPHICAL
DESCRIPTION
LENGTH
QTY
1
Peak arch tube
L480mm
2
1A
Peak arch tube
L480mm
2
2
Rafter tube
L1421mm
16
3
Rafter connection pipe
L262mm
4
3A
Rafter connection pipe
L276mm
4
4
Shoulder tube
L445mm
4
4A
Shoulder tube
L445mm
4
5
Column tube
L1877mm
8
6
Lower cross tube
L2030mm
6
7
Roof purlin
L1930mm
17
8
Ceiling cross bar
L1520mm
8
9
Center vertical supporting rod
L577mm
4
10
Diagonal bracing bar
L960mm
4
11
Lower cross tube
L1930mm
4
12
connector tube
L262mm
4
13
Tube clamp
(φ42)
8

►www.tmgindustrial.com 4/20 TOLL FREE:1-877-761-2819
14
Hex bolt and nuts
M10x30
28
15
Hex bolt and nuts
M6x60
8
16
Ground pegs
L180mm
24
17
Tension hook
L45mm
4
18
Ground pegs
L305mm
4
19
Connecting piece
L65mm
4
20
Ball rope
L150mm
180
21
Roof cover
L6m
1
22
Side cover
W2220xL5940mm
2
23
Front and rear fabric panels
W3280xL5980mm
2
24
Braided rope
L5m
4
25
V-spring buckle
(φ8)
78

►www.tmgindustrial.com 5/20 TOLL FREE:1-877-761-2819
STEP 1 :INSTALL V-SPRING BUCKLE
NO.
PART
QTY
2
16
5
8
7
17
11
4
25
78

►www.tmgindustrial.com 6/20 TOLL FREE:1-877-761-2819
STEP 2 : ASSEMBLE FRONT AND REAR TRUSSES.
NO.
PART
QTY
NO.
PART
QTY
1
1×2
8
2×2
2
4×2
9
1×2
3
2×2
14
4×2
4
2×2

►www.tmgindustrial.com 7/20 TOLL FREE:1-877-761-2819
STEP 3 : ASSEMBLE MIDDLE TRUSSES.
NO.
PART
QTY
NO.
PART
QTY
1A
1×2
8
2×2
2
4×2
9
1×2
3A
2×2
14
4×2
4A
2×2

►www.tmgindustrial.com 8/20 TOLL FREE:1-877-761-2819
STEP 4 : CONNECT THE FRONT TRUSS AND THE 2ND TRUSS THROUGH PURLINS ( #7 ).
NO.
PART
QTY
7
5

►www.tmgindustrial.com 9/20 TOLL FREE:1-877-761-2819
STEP 5 : REPEAT ABOVE STEP TO PUT UP ALL OTHE TRUSSES (FROM 3RD TO 7TH TRUSS), AND CONNECT ALL
PURLINS ( #7 ).
NO.
PART
QTY
7
10

►www.tmgindustrial.com 10/20 TOLL FREE:1-877-761-2819
STEP 6 : INSTALL ROOF COVER ( #21 ) .
NO.
PART
QTY
21
1

►www.tmgindustrial.com 11/20 TOLL FREE:1-877-761-2819
STEP 7 : ASSEMBLE PART ( #5 ).
NO.
PART
QTY
5
8
Note: 4-5people are
required to lift or use the
crane is a better choice.

►www.tmgindustrial.com 12/20 TOLL FREE:1-877-761-2819
STEP 8 : INSTALL THE DIAGONAL BRACING BARS ( #10 ).
NO.
PART
QTY
10
4
13
8
14
8

►www.tmgindustrial.com 13/20 TOLL FREE:1-877-761-2819
STEP 9 : TENSION THE ROOF COVER.
NO.
PART
QTY
17
4
20
50

►www.tmgindustrial.com 14/20 TOLL FREE:1-877-761-2819
STEP 10 : ASSEMBLE PART ( #6 ).
NO.
PART
QTY
6
6
15
8
19
4

►www.tmgindustrial.com 15/20 TOLL FREE:1-877-761-2819
STEP11 : ASSEMBLE PART ( #7,#11,#12 ).
NO.
PART
QTY
NO.
PART
QTY
7
2
12
4
11
4
14
4

►www.tmgindustrial.com 16/20 TOLL FREE:1-877-761-2819
STEP 12 : FIXED BASEPLATE.
NO.
PART
QTY
16
24

►www.tmgindustrial.com 17/20 TOLL FREE:1-877-761-2819
STEP 13 : INSTALL THE FRONT AND REAR FABRIC PANELS ( #23 ).
NO.
PART
QTY
23
2
20
50

►www.tmgindustrial.com 18/20 TOLL FREE:1-877-761-2819
STEP 14 : INSTALL SIDE COVER ( #24 ).
NO.
PART
QTY
22
2
20
80

►www.tmgindustrial.com 19/20 TOLL FREE:1-877-761-2819
STEP 15 : FIXED FOUR CORNERS.
NO.
PART
QTY
18
4
24
4
