ASSEMBLY INSTRUCTIONS
Victor Futon Item# 79518GRY
Thank you for purchasing our product!
Please refer and use this assembly instruction to assemble the product.
Contact our customer service department in case there are any missing or damage parts or hardware. Replacement parts
are normally shipped within 2 or 3 days.
We appreciate your business!
Email: [email protected]
Within 30 days from delivery date
2-Person
Assembly
ASSEMBLY REQUIREMENTS
30 Minutes
Assembly Time
(Approximate)
Revision: 28/10/2016
ASSEMBLY PREPARATION:
1. Remove all packaging materials, staples and packing straps from the carton.
2. Refer to Parts List and Hardware List and ensure they are complete before you start assembling.
3. Place all fabric parts on a clean, flat and soft surface (e.g. carpet or rug) to prevent fabric from getting ripped.
1. KEEP ALL HARDWARE PARTS OUT OF REACH OF CHILDREN.
2. DISPOSE PLASTIC PACKAGING MATERIAL IMMEDIATELY TO AVOID ANY RISK OF SUFFOCATION TO
CHILDREN AND ANIMALS.
SAFETY PRECAUTION:
TIPS FOR ASSEMBLY:
1. Allow ample room for assembly and in close proximity to where product will be placed.
2. Assemble the product on a surface that does not scratch or damage the fabric of the furniture.
3. Please check all of the parts and quantities are included before assembly.
4. Identify all of the parts, hardware and quantities required for each step.
5. During assembly, do not over-tighten any fittings as this may cause damage.
6. DO NOT USE POWER TOOLS TO ASSEMBLE THIS PRODUCT.
7. Always place the product on a flat, stable surface.
8. Do not sit or stand on the partially assembled product; only use the product for which it is intended.
This product is for indoor and household use only - not for commercial use.
•Use a slightly damp cloth to clean the product. Do not use bleach or abrasive cleaning material.
•Check all the fittings periodically and re-tighten as necessary. Do not use the product if any of the parts is
damaged or broken.
CARE AND MAINTENANCE

2/9
ASSEMBLY INSTRUCTIONS
Victor Futon Item# 79518GRY
Hardware List
Parts List
A. Legs x4 B. Allen Key x1 C . Screw x16pcs
Futon x1 Back Cushion x1
a) Place the futon as shown on a material that does not damage or stain the fabric.
b) Align screw holes on the leg bracket to the screw holes on the base plate at the bottom-side of
futon. (Note: The legs should angle outwards. The rear leg brackets are to be aligned squarely to
each rear corner and the front leg brackets are to be aligned diagonally to each front corner.)
c) Use Allen Key (B) to drive and tighten Screw (C) in a clock wise direction to fasten the legs to the
bottom of futon base.
The assembly of the futon is complete.
STEP 2 - Assemble Legs
STEP 1
Remove Back Cushion and box
containing hardware under the
Back Rest section of the furniture. Back
Rest
B
C
A
Back
Rest
Base
Back
Cushion
Hardware
Box

Back Rest
Seat
ASSEMBLY INSTRUCTIONS
Victor Futon Item# 79518GRY
Place the furniture
right-side up from STEP
2 as shown.
Back Cushion
Using the Futon as a Couch
Step A
Set aside Back Cushion.
Step B
Open the zipper on the Seat to access
legs. Pull-out the legs in the direction
as shown to set legs in a vertical
position.
Seat
Zipper to
access legs
Step D
Open the zipper on the Back
Rest to access legs. Pull out
the legs in the direction as
shown to set legs in a
vertical position.
Back Rest zipper to
access legs.
Back Rest
Step C
Pull back to unfold and
lay the Seat flat to rest
on the legs.
Using the Futon as a Couch
Step E
Push down the Back Rest
backwards to set the Back
Rest flat down to rest on the
legs
Back Rest
Step F
Put the Back Cushion in
place.
The futon Bed is set.
Back Rest
Put Back Cushion
in place.
Bring the Back Rest to a vertical
position towards the seat.
