Tommy Swiss Leonardo B304 User manual

B304 Leonardo Bed – Installation Guide

Parts list
25 x Bolt A (27 x for King Size)
1 x Bolt B
7 x Bolt D (9 x for King Size)
4 x Bolt E
2 x Bolt F
4 x Bolt C
2 x Nuts (4 x for King Size)

Parts list - continued
4 x rectangle corner
brackets
2 x middle support beam
brackets (4 x in king size)
2 x triangle brackets
2 x support legs (4 x in
king size)
4 x corner legs

Parts list - continued
Footboard
Headboard
Lower Head Piece
Head Support Piece

Attach the side bar and brackets as shown below
Attach side metal bar with 5 x Bolt D
Attach brackets to end of
side panel with Bolts A
Join footboard to
side panel

Connect the headboard to the curved side panels
Screw in 2 x Bolt C on each side of the
headboard as shown above
Hook the headboard onto both side
panels via the hooks and tighten bolts

Join the back and attach middle support bar
Attach the lower headboard bar to
the 2 side panels with bracket shown
using 4 x Bolt A
Attach the middle beam
bracket as shown above
using 2 x Bolt A
Place middle beam on
bracket and secure tight
with 1 x Bolt D

Place the 2 support legs under the middle bar

Attach the headboard support piece
Attach the longer Bolt B at top and the
shorter Bolt A at bottom
Secure the back panel onto the
corresponding holes as shown

Fix the 4 wooden legs in each corner
Attach Bolt E onto the wooden corner
legs as shown above
Position the wooden leg under each corner
with the bolt matching the nut insert
Final step: join the wooden slats curving upwards with the plastic clips and click into place
