Tommy Swiss 101 Series User manual

Confidential
101 series bed frame installation guide

Confidential
Optional 4 corners under the bed frame
• Position the 4 plastic corners feet in each of the corners
of the bed frame
• These can be locked in with the pointy screw
• Make sure 2 plastic corners are on either end of
headboard, and the other 2 plastic corners are on either
end of the footboard
• It is optional whether you use the pointy screw to lock in
the plastic corner feet
• It is also possible to place the bed on top of the plastic
feet without locking it in with the screw

Confidential
Join the 4 sides of the bed together as shown
• Do not attach the white side railings yet
• Attach the 4 sides together by hooking the sides using the golden brackets
• Tighten using the screws
• Once 4 sides are joined, screw on the white metal side railings as shown in photograph

Confidential
Fix the middle support beam
• Attach the middle beam supporter bracket to the middle of the headboard and footboard
• Position middle beam on top of the support bracket
• Attach the support feet underneath the middle support beam

Confidential
Attach all the wooden slats
• Attach all the wooden slats
• It is recommended to attach all the slats on
one side first
• Then attach the slats on the remaining side
• You may need to lift up the middle bar as
shown in the photograph if it is a little tight
positioning the slats
• Push down and lock all the slats in place
• The bed is complete!
