Standard rollator
User manual
Version 2.0.0 EN

2
TOMTAR / User manual for the FAKTO+ rollator / Version 2.0.0 EN
NOTE
For better visibility nd our user
manual also online under www.
dietz-rehab.de as PDF le with
zoom function.
Thank you for purchasing a
FAKTO+ rollator from DIETZ.
Please read this user manual carefully before rst using the new FAKTO+.
It contains important safety instructions and valuable tips on correctly
using and caring for the FAKTO+ rollator. If you have any questions or
require additional information, please contact the specialist retailer which
supplied the wheelchair to you.
These operating instructions contain all of the instructions necessary for
adjusting and operating the FAKTO+ rollator.
USER MANUAL

01 Important Information
General information . . . . . . . . . . . . . . . . . . . .4
Intended use. . . . . . . . . . . . . . . . . . . . . . . . . .4
Indication . . . . . . . . . . . . . . . . . . . . . . . . . . . .4
Contraindication . . . . . . . . . . . . . . . . . . . . . . .4
Signs and symbols . . . . . . . . . . . . . . . . . . . . .5
02 Product description
Scope of delivery . . . . . . . . . . . . . . . . . . . . . . .5
Set up Rollator . . . . . . . . . . . . . . . . . . . . . . . .6
03 Build up the rollator
Assembly . . . . . . . . . . . . . . . . . . . . . . . . . . . .7
Unfolding the rollator . . . . . . . . . . . . . . . . . . .7
Assamble the push handles . . . . . . . . . . . . . .7
Adjustment of the push handles . . . . . . . . . . .8
Checking for correct assembly . . . . . . . . . . . .8
04 Using the rollator
Folding mechanism . . . . . . . . . . . . . . . . . . . . .9
Brake and parking brake . . . . . . . . . . . . . . . . .9
Readjusting the brakes . . . . . . . . . . . . . . . . . .9
Readjusting the brakes at the cable . . . . . . . .10
05 Accessories
Basket (tted as standard) . . . . . . . . . . . . . .10
Rack (tted as standard) . . . . . . . . . . . . . . . .10
Cane holder (tted as standard) . . . . . . . . . .10
Tray (tted as standard) . . . . . . . . . . . . . . . .11
Curb climber (tted as standard) . . . . . . . . . .11
Single hand brake (optional) . . . . . . . . . . . . .11
Umbrella (optional) . . . . . . . . . . . . . . . . . . . .11
Backrest (optional) . . . . . . . . . . . . . . . . . . . .12
06 Safety instructions
Safety instructions. . . . . . . . . . . . . . . . . . . . .12
07 Instructions for general use
Servicing / maintenance. . . . . . . . . . . . . . . . .13
Maintainance schedule . . . . . . . . . . . . . . . . .14
Fault-nding and rectication . . . . . . . . . . . .16
Cleaning . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Desinfection . . . . . . . . . . . . . . . . . . . . . . . . .17
Forwarding / reusing . . . . . . . . . . . . . . . . . . .17
Storage. . . . . . . . . . . . . . . . . . . . . . . . . . . . .17
Disposal . . . . . . . . . . . . . . . . . . . . . . . . . . . .18
Product labelling . . . . . . . . . . . . . . . . . . . . . .18
08 Manufacturer declarations
Warranty. . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Lifetime. . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Liability. . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
09 Technical documentation
Specications . . . . . . . . . . . . . . . . . . . . . . . .20
Product tests. . . . . . . . . . . . . . . . . . . . . . . . .20
Capture identication data . . . . . . . . . . . . . .21
3
EN
USER MANUAL CONTENTS

GENERAL INFORMATION
This user manual is intended provide all users
and support staff with a basis for ensuring the
safe use of the FAKTO+.
The manual contains information on the prepa-
ration, use, maintenance and servicing of your
rollator. In order to make the most of the device
in a sensible manner and to maintain handling
reliability, you should always comply with the
specied handling instructions. Make sure that
the user manual can always be accessed by the
user.
This user manual is included in the scope of de-
livery. We reserve the right to make changes to
the versions shown in this manual as a result of
technical further development. Reprints, trans-
lations and reproductions of this manual in any
form, in whole or in part, require the written
approval of DIETZ GmbH.
The copyright is owned by the manufacturer.
This user manual is not subject to an updating
service. You can nd out the latest status by
contacting DIETZ GmbH.
INTENDED USE
The FAKTO+ Arthritis is designed for persons
with restricted mobility with a maximum body
weight of 130 kg for use as a walking aid and,
to a limited extent, as a seating device for tem-
porary rest.
It is used both domestically as well as in hospi-
tals and is designed exclusively for use on solid
and level indoor surfaces.
INDICATION
The use of the FAKTO+ is indicated for:
c Restricted mobility due to a restriction of
the active or passive musculoskeletal
system
c Coordination problems when walking
c Reduced load-bearing capacity
CONTRAINDICATIONS
The use of the FAKTO+ is not indicated for:
c False sensations,
c Severe disequilibrium
c User weights of above 130 kg.
The FAKTO+ must not be used as a climbing
aid, a transport aid for large loads or for any
similar purposes.
The FAKTO+ is not suitable for children.
4
TOMTAR / User manual for the FAKTO+ rollator / Version 2.0.0 EN
01 IMPORTANT INFORMATION

SYMBOLS
These symbols indicate passages of text that
are helpful for using and operating the product
in every day life.
WARNING
It is mandatory to observe and comply with
warnings.
They inform you of circumstances that could re-
sult in injury and/or damage to the wheelchair
or surroundings if the warnings are not ob-
served.
NOTE
Tips and advice to simplify using the func-
tions.
SCOPE OF DELIVERY
The scope of delivery of the FAKTO+ includes
the following components and accessories:
c FAKTO+ rollator
c User manual
c Basket
c Tray
c Cane holder
c Plastic rack
c Curb climber
Optional accessories:
c Single hand brake
c Umbrella
c Backstrap
On receipt of the wheelchair, please immediately
check to make sure that the contents are complete
and undamaged. If the contents are noticeably
damaged, inform the freight company immedi-
ately.
WARNING
Keep packaging and protective lms away from
children, there is danger of suffocation!
WARNING
Do not burn transparencies! Burning can pro-
duce toxic gases.
5
EN
01 IMPORTANT INFORMATION 02 PRODUCT DESCRIPTION

NOTE
The image above is designed to help you clearly identify the individual components of your FAKTO+.
Therefore, please always refer to it when reading the user manual.
Clamp lever
Folding lock
Brake pad
Front wheel (swivel wheel)
Basket
Main frame
Adjusting screw brake
Adjusting screw brake cable
Brake cable
Brake lever
Rack
hook, basket
headband, basket
Seat
Reector, red, rear
Reector, white, front/side
Clip of rack
Product label / warning sign
Push handle
Grip
Cane holder, upper part
Rear wheel
Tray
Curb climber Cane holder, low part
6
TOMTAR / User manual for the FAKTO+ rollator / Version 2.0.0 EN
SET UP FAKTO+
02 PRODUCT DESCRIPTION

ASSEMBLY
Place the individual parts of your rollator on the
oor. The handlebars are already connected to
the main frame by the brake cables. Place them
to the right and left of the main frame.
Unfolding the rollator
Hold the main frame by the seat's grip hole (1,
pic. 1) and position it on the oor with the front
wheels (swivel wheels). The grip hole must be
on the side facing away from you.
Bend over the main frame and grip the part of
the frame that faces away from you to unfold
the frame (2, pic. 1).
Now you can place the rollator with all four
wheels on the oor and fully unfold it by press-
ing on the seating surface.
1
2
Abb. 1
To lock the folding mechanism, fold down
the lever until it engages firmly in the guide
(1, pic. 2).
1
Abb. 2
NOTE
To use FAKTO+ Arthritis correctly, it must be ad-
justed to your individual size. You should have
an employee of your medical supply store or
another trained person do this.
Assamble the push handles
Loosen the clamp levers and insert the push
handle (2, pic. 3) into the vertical tubes (3, pic.
3) of the frame (1, pic. 3).
1
4
Abb. 3
25
3
7
EN
02 PRODUCT DESCRIPTION 03 BUILD UP THE ROLLATOR

Abb. 4
Schieberichtung
90 °
Checking for correct assembly
Now check that the rollator has been correctly
assembled:
c The rollator must stand securely on all
four wheels.
c The clamping levers on the push handles
must be securely tightened.
c The push handles must be assembled so
that they are not able to rotate.
If you are unsure as to whether the rollator
is assembled correctly, please contact your
medical supply store or an authorised specialist
retailer.
The push handles can now be adjusted to the
correct height for you.
The lowest push tube height is achieved by
moving the tubes into the frame until it blocks.
Always be aware of the “MAX” marking (4, pic.
3) when adjusting to the highest position. The
push tubes must never be xed in place any fur-
ther above the marking than at the long main
knurling (5, pic. 3).
It must also be ensured that the handles are
aligned parallel to the direction of travel.
WARNING
Fix the push tubes in place no further than the
main knurling (4, pic. 3). This is the only way of
ensuring the safe use of the rollator!
Adjustment of the push handles
The push handles must be aligned parallel to
the direction of travel (forwards/straight), as
shown in the illustration (pic. 4).
Observe the warning information on your
rollator when performing this step. (See Product
labelling section)
WARNING
Never adjust the push grips exceeding the de-
scribed range. Upon exceeding this range the
stability and safety are compromised.
8
TOMTAR / User manual for the FAKTO+ rollator / Version 2.0.0 EN
03 BUILD UP THE ROLLATOR

Brake and parking brake
The brakes are operated using the brake
handles mounted on the handles.
To brake while moving, pull the two brake
handles towards you evenly (1, pic. 6).
1
Abb. 6
2
To brake the rollator safely and indenitely
when stationary, for example to sit, push the
brake handle rmly down (2, pic. 6). The brake
handle engages securely and audibly in this
position. Pull the brake handle towards you to
release it. You can clearly notice that the brake
is released.
Readjusting the brakes
The adjusting screw for the brake cables can be
found on the brake handles. Unscrew (counter-
clockwise) to increase the tension and reduce
the actuation travel of the brake lever (1, pic.
7). The screw is counter-locked with a nut (2,
pic. 7). You must always tighten this counter
nut after adjustment to prevent the brake
cables from loosening unintentionally.
USING THE ROLLATOR
Make yourself sufciently familiar with your
FAKTO+ before using it for the rst time so that
you feel condent when handling it.
Folding mechanism
1
2
Abb. 5
The folding mechanism must be locked after
each unfolding. Always ensure that the
unlocking lever is properly engaged in the
lower position.
Before unlocking or folding, rstly lock the
parking brakes (see next section). First remove
the tray and basket before unlocking and
folding. Now press the unlocking lever upwards
(1, pic. 5) and push the front and rear parts of
the main frame together (2, pic. 5).
Please also refer to the "Unfolding the rollator"
chapter.
WARNING
Take care of your hands and ngers when oper-
ating the folding lock and when unfolding or
folding up the rollator! Risk of clamping!
9
EN
04 USING THE ROLLATOR

1
Abb. 7
2
Readjusting the brakes at the cable
The brakes can also be readjusted using the
cable. This can be useful if the brake lever
adjustment described in the previous paragraph
is no longer effective. Here, too, you must
tighten the counter nut after adjustment has
been completed. When doing so, observe the
illustration in the “Structure of the FAKTO+”
section.
WARNING
Never fully unscrew the screw, otherwise the
brake will no longer work.
WARNING
If problems occur when adjusting the brakes,
please contact an authorised specialist retailer!
This is the only way of ensuring the safe use of
the rollator.
ACCESSORIES
Basket (tted as standard)
The wire basket suspended underneath the seat
is designed for the storage and transportation
of larger goods or items up to a maximum of
5 kg.
To remove the basket, lift if off the hooks un-
derneath the seat. The hook can now be folded
upwards so that you can pick up the basket.
To attach the basket to the rollator, simply t it
back onto the hooks.
Make sure that the basket is securely attached
before placing items inside.
Rack (tted as standard)
The plastic rack underneath the basket is de-
signed for the storage and transportation of
larger items such as shopping bags, up to a
maximum of 7 kg.
If you wish to clean the rack, you can remove it
upwards by detaching the retaining clips that
grip around the frame tube.
To re-attach the rack, push the clips back onto
the frame tube and check that the rack is se-
curely in place.
Cane holder (tted as standard)
The cane holder is tted to the right-hand side
of your rollator at the factory.
To insert your cane, rstly place the rubber
bottom of the cane into the bottom part of the
cane holder (part of the rack), and then click
the cane into the clip at the top of the cane
10
TOMTAR / User manual for the FAKTO+ rollator / Version 2.0.0 EN
04 USING THE ROLLATOR 05 ACCESSORIES

holder with a gentle pressure. See illustration in
the “Structure of the FAKTO+” section.
If it is more practical for you to have the cane
holder on the left-hand side, the sleeve (top
part of the cane holder) can be removed and
re-attached on the left-hand side. You do not
need to re-attach the bottom part of the cane
holder as there is already the option of tting a
cane on either side of the rack.
After re-attaching on the left-hand side, make
sure that the sleeve is closed and that the clip
on the cane holder is facing forwards. Check
that the cane can be inserted without colliding
with the brake cables or the handlebars.
Please contact your specialist retailer if you
need any help with assembly.
Tray (tted as standard)
The tray is designed for the transportation of
small items up to a maximum of 5 kg.
Place this on the seat. There are four pins on
the bottom of the tray that can be positioned
into the four holes in the seat.
WARNING
Do not use the tray to transport hot items or hot
drinks.
Curb climber (tted as standard)
The FAKTO+ is equipped with a curb climber
on the right-hand side. This is attached to the
inside of the wheel suspension on the right-
hand side and consists of 8-mm-thick metal
wire bent into a loop. Pressing on the metal
loop with the toes makes it easier to lift the
wheels and tackle curbs and other obstacles.
Before using the curb climber make sure that
you are standing securely on the other leg.
WARNING
Always be aware that pressing the curb climber
may impair your balance.
Single hand brake (optional)
If one of your hands does not have enough
strength to safely apply the brake, the FAKTO+
can be equipped with a single hand brake. This
will need to be attached to the rollator by an
authorised specialist retailer.
c Attaching a single hand brake to your rol-
lator requires you to have sufficient
strength in the hand that applies the
brake so as to ensure safe handling.
c The same usage and maintenance in-
structions apply as for the version with
brakes on both handlebars.
Umbrella (optional)
WARNING
Fitting an umbrella may affect the tilt stability
of your rollator!
Your FAKTO+ can be equipped with an umbrel-
la, which can also be used as a sunshade.
The installation of this optional accessory is
described in a separate user manual supplied
with the product. Have the umbrella tted by
an authorised specialist retailer, who will hand
11
EN
05 ACCESSORIES

over the user manual to you. Please observe
all of the usage and safety instructions in the
separate user manual for the umbrella!
Backstrap (optional)
An optional backstrap is available for your
FAKTO+. Have this tted by an authorised
specialist retailer.
The backstrap allows you to adopt a safe
position and helps you to nd the correct
position on the seat of your FAKTO+.
WARNING
Make sure that the brakes are locked before you
sit down, and be aware that leaning against the
backstrap will reduce the tilt stability.
WARNING
The seat is only designed to be used for short
periods, such as when taking a short break
when walking. For longer breaks, use conven-
tional seating!
SAFETY INSTRUCTIONS
By observing the intended use and following
the safety instructions, there is no danger of
using the FAKTO+ rollator
WARNING
Follow all safety instructions, otherwise there
may be a risk of injury!
c The rollator may only be on level, firm
ground.
c The rollator must be securely upright on
all four wheels.
c Before each use of the rollator, check that
all attached parts are properly fastened,
that the brakes are working and that the
folding mechanism is locked.
c Always lock both brakes before sitting on
the rollator's seat.
c The rollator’s seat is only designed to be
used for short periods, such as when
taking a break when walking!
c Attention: Please note that a shift of
balance due to body movements may
increase the risk of the rollator tipping
over. Always make sure the load on the
rollator is evenly!
c Do not hang any bags on the handles or
other parts of the rollator, as this will
increase the risk of it tipping over!
c Pay attention to the neighbouring
components when operating the folding
lock (unlocking lever). There is a risk of
entrapment if handled improperly!
c Never exceed the maximum combined
load of 130 kg for user and load!
12
TOMTAR / User manual for the FAKTO+ rollator / Version 2.0.0 EN
05 ACCESSORIES 06 SAFETY INSTRUCTIONS

c Avoid exposing the wheelchair to direct
sunlight/low temperatures for long
periods of time as parts of the product
(e.g. frames, footrests, brakes and side
panels) may b come very hot (> 41°C) or
very cold (<0°C) and this may cause skin
injuries.
c Ensure that the rollator is not parked in
direct vicinity of emergency exits and
escape routes and blocks them.
c Never use the rollator under the influence
of alcohol or other substances that can
negatively affect your attention and
reaction ability!
c Only ever use the rollator in accordance
with its intended use! When using the
rollator, never approach obstacles such as
steps or curbs without applying the
brakes.
c The rollator is not suitable for children
and must not be subjected to improper
use!
c When sitting on the rollator, you must not
walk with your feet or be pushed by other
persons! This is an injury risk and may
cause damage to the product!
c Observe the road traffic regulations on
public road traffic.
c Wherever possible, wear light, eye-
catching clothing. This will allow you to
be seen more easily by other road users.
c Never use the rollator as a seat in a
vehicle or on public transport. This poses
an increased risk of falling!
c Never use escalators. The risk of falling
and injury is very high!
c Stairs must only be negotiated with the
help of accompanying persons if no
elevators or ramps are present.
c The wheel bearings can be damaged by
sand, seawater and road salt. Clean the
rollator thoroughly if it has been exposed
to conditions such as these.
c I f they cannot be bypassed, ruts, rails or
similar obstacles must always be crossed
at right angles (90°).
c The rollator must not be used to transport
heavy loads. Items must only be
transported using the rack, basket or tray,
as described in the “Accessories” section.
c Serious incidents that occur in relation to
the rollator must be reported to the
manufacturer and the responsible
authorities!
c If you notice any limitations in the
functioning of your rollator, please take it
to your authorised specialist retailer for
repair immediately.
SERVICING / MAINTENANCE
We recommend performing the inspections
listed in the maintenance schedule at regular
intervals to ensure that the rollator is always
safe to use.
Defective or neglected care and maintenance
of the rollator limits liability. The maintenance
schedule does not give any information con-
cerning the amount of work actually required
on the rollator.
13
EN
06 SAFETY INSTRUCTIONS 07 INSTRUCTIONS FOR GENERAL USE

MAINTENANCE SCHEDULE FAKTO+
What Description
Brakes/parking brakes:
Function
The rear wheels must not turn when the brake handles are pushed
forwards or locked (parking brake) or when the brake handles are
actuated (service brake).
The brakes must be re-adjusted following a replacement of the
bowden cables or the rear wheels. This must only be carried out by
an authorised specialist retailer.
x
Push handles:
Stability
1. It must be possible to securely lock the clamping levers on the
push handles.
2. The push handles must not wobble.
x
Folding lock and folding
mechanism:
Function & safety
1. It must be possible to operate the lever on the folding lock without any
issues.
2. It must be possible to connect and detach the two parts of the frame
without any issues. When doing so, it must be possible to push
the horizontal bar on the rear part of the frame into the runners on the
front part of the frame without any issues.
3. It must be possible to engage the lever right at the bottom in order to
lock it.
x
before use
monthly
NOTE
As the user, you will be the rst to notice possi-
ble damage. If you notice a fault as described in
the maintenance schedule or further defects
and functional impairments, contact an autho-
rised specialist dealer immediately.
NOTE
The inspections and measures stipulated in the
maintenance schedule must be performed by
the user or assistant if not otherwise stated.
WARNING
Repairs on the rollator must only be performed
by specialist shops using DIETZ original spare
parts to maintain the operational safety of the
rollator. The relevant spare parts catalogue can
be found on our website in the information of
the product in question.
NOTE FOR SPECIALIST DEALERS:
If the user indicates abnormalities on the rol-
lator, check all the inspection points listed in
the maintenance schedule on the rollator. The
checks must also be performed before putting
the rollator back into operation and after lon-
ger storage periods (> 4 months).
14
TOMTAR / User manual for the FAKTO+ rollator / Version 2.0.0 EN
07 INSTRUCTIONS FOR GENERAL USE

What Description
Screw connections:
Securely fastened
All screw connections must be securely fastened.
Repeated loosening and re-tightening causes self-locking nuts
and screws to lose their effectiveness. These must therefore be
replaced by a specialist retailer if they have become loose.
x
Steering and running
wheels:
Mobility, function &
damage
1. The wheels must run in a straight line and must not wobble.
2. The wheels must move easily and quietly during travel.
3. Please clean the wheel hub if it is dirty or if uff has accumulated.
4. The wheels must not be damaged.
x
Steering and running
wheels:
Mobility, function
& damage
1. The wheels must not be damaged and must run quietly, in a straight
line and without wobbling.
2. Please clean the wheel hub if it is dirty or if uff has accumulated.
x
Push handles:
Stability &
damage
1. The handles and brake handles must be securely in place.
2. The push handles must not have any external damage or distortion,
and must not wobble.
3. It must be possible to securely lock the clamping levers.
x
Seat:
Contamination &
damage
1. The seat must be securely connected to the frame.
2. If the seat is dirty, clean in accordance with the cleaning instructions.
2. If damaged, have the seat replaced.
x
Frame, complete:
Function &
damage
1. The two parts of the frame must not be damaged or cracked.
2. Functional or surface damage must be rectied. x
Visual inspection:
Loose parts, fractures,
corrosion or other
damage
If this type of damage is detected, the rollator must
no longer be used, as safe operation is no longer guaranteed! x
Contamination:
Rollator, complete
The entire rollator must be cleaned in line with the level of contamination,
but at least once a month (see “Cleaning” section). x
before use
monthly
15
EN
07 INSTRUCTIONS FOR GENERAL USE

FAULT-FINDING AND RECTIFICATION
What Possible causes Measures
The front wheels do not
run in a straight line.
The wheel bearings are defective or
the wheel suspension is no longer
correctly attached.
Consult an authorised specialist
retailer.
The rollator is hard to
push.
The wheel axles/wheel hubs are dirty. Remove the dirt.
The brakes are incorrectly adjusted.
Consult an authorised specialist
retailer.
The wheel bearings are defective or
the wheel suspension is no longer
correctly attached.
The brake function is
insufcient or uneven.
The brakes are incorrectly adjusted or
the brake pad has worn out.
Consult an authorised specialist
retailer.
The seat is positioned at
an angle or is not securely
attached to the rollator.
The rollator is not fully unfolded. Fully unfold the rollator and engage
the folding lock.
The seat is defective or is incorrectly
screwed onto the rollator. Consult an authorised specialist
retailer.
The hinges on the folding mechanism
or the folding lock are defective.
Squeaking or grinding
noises Various causes Consult an authorised specialist
retailer.
The rollator does not
provide secure support or
does not stand reliably.
The push handles are not xed in
place properly or have been incorrectly
adjusted for the user.
Check the position of the push handles.
Check whether the clamping levers
on the push handles are securely
tightened.
The rollator has not been fully
unfolded and the folding lock has not
been engaged.
Fully unfold the rollator and engage
the folding lock.
The rollator frame or the push handles
are damaged.
Consult an authorised specialist
retailer.
16
TOMTAR / User manual for the FAKTO+ rollator / Version 2.0.0 EN
07 INSTRUCTIONS FOR GENERAL USE

CLEANING
c Regularly clean the rollator by wiping
with a damp cloth.
c In the event of heavier contamination, use
a mild cleaning agent and warm water.
c The wheels can be cleaned using a damp
brush with soft plastic bristles
c Remove dirt and fluff from the wheel
hubs.
c Only ever use standard mild cleaning and
disinfection products to clean the rollator.
Detailed information on disinfection can
be found in the following section.
WARNING
Do not use high-pressure cleaners, strong, cor-
rosive chemicals or scouring agents for cleaning
purposes.
WARNING
After cleaning, ensure that all materials are
completely dried in order to preserve their qual-
ity.
DISINFECTING
When manually reconditioning a used aid for
reuse, all of the aid’s components must be thor-
oughly treated/wiped with a disinfectant. Take
particular care to disinfect surfaces that come
into frequent contact with hands/skin, such as
handles.
WARNING
Observe the use and processing instructions is-
sued by the cleaning agent/ disinfectant manu-
facturer.
Please only use the following disinfectants; use
of other chemicals might damage the rollator:
c Aldehyde-free disinfectants based on
alcohol (max. 70% propylalcohol)
c Aldehyde-based disinfectant
FORWARDING / REUSING
The number of times the rollator can be reused
depends on the material wear conditions and
the functional capabilities of the respective
product. If the rollator is passed on to a new
user or specialist dealer for reuse, please re-
member to hand over all technical documents
that are necessary for safe usage. The rollator
must be cleaned and disinfected, and must
be checked for damage and approved by the
specialist retailer. To do so, please check all
the inspection points listed in the maintenance
schedule on the rollator.
STORAGE
To store the rollator, ensure that it is stored in a
dry place protected against direct, strong sun-
light and at a temperature of 0°C to +45°C.
Do not activated the locking brakes. Secure the
rollator against rolling away unintentionally.
After longer periods of storage (> 4 months),
please check all the inspection points on the
17
EN
07 INSTRUCTIONS FOR GENERAL USE

PRODUCT LABELLING
Type plates and warning signs must always
remain legible. These are attached to the hori-
zontal connecting rod on the main frame of the
FAKTO+.
Please have any illegible or missing signs/stick-
ers replaced by your specialist retailer immedi-
ately. This includes the reector stickers.
This information/warning sign is located next
to the type plate and indicates that the push
handles must always be tted parallel to
the direction of travel. This is the only way of
ensuring the safe use of the rollator! See also
the sections “Assembling the push handles”
and “Adjusting the push handles”.
The following section explains the symbols and
information on the type plate in detail. The type
plate also contains the serial number of your
rollator.
*346NPU*
rollator listed in the maintenance schedule
before reusing/redeploying it.
WARNING
Do not store the rollator near a heat source or
store objects on it.
DISPOSAL
If you no longer need the rollator, please con-
tact your specialist dealer. They will then pick
up the rollator and either dispose it properly or
make further use of it. If this is not possible,
please take the wheelchair to your local recy-
cling facility.
18
TOMTAR / User manual for the FAKTO+ rollator / Version 2.0.0 EN
07 INSTRUCTIONS FOR GENERAL USE

Trademark
TYPE / Modell
REF = Item number
UDI = Unique Device Identifer
(01) UDI-DI
(10) Order number
(21) Serial number
Manufacturer/manufacturer's
trademark/contact address
Maximum load capacity/load
incl. payload
Date of manufacture
Total width of rollator
Total hight of rollator
(min.- max.)
The rollator can be used in-
and outside
Follow the user manual
Caution - note the safety
information in the user
manual
Medical Device
CE-Labelling
WARRANTY
Warranty services refer to all product defects
which are veriably attributable to material
or manufacturing aws. The warranty period
is 24 months as of receipt of notication of
readiness for shipping, but following delivery at
the latest. Damage which has occurred due to
natural wear, intent, and negligent or improper
operation or usage is excluded from the war-
ranty obligation. This also applies to the use
of unsuitable care products, lubricating oils or
greases.
LIFETIME
The expected product service life is ve years
when used daily and if used as intended. This
assumes compliance with the maintenance and
safety specications stipulated in this manual.
LIABILITY
The DIETZ GmbH is only liable if the product
is used under the specied conditions and for
the specied purpose. We recommend that the
products be handled appropriately and cared
for according to the instructions. DIETZ GmbH
is not liable for damage caused by components
and spare parts that have not been approved
by DIETZ GmbH. Repairs must only be carried
out by authorised specialist retailers or by the
manufacturer itself.
19
EN
08 MANUFACTURER DECLARATIONS

SPECIFICATIONS
Description Unit FAKTO+
Item number 346NPU
Frame: material / color steel tube, powder coated, weldet / mangan grey
Wheels: material / color / size PU, non marking / dark grey / 200/50 mm
Rack, brake lever: material / color Nylon glass ber reinforced / black
Grips: material / color PVC / black
Seat // tray: material / color PP / black // acrylic / transparent
Basket: material / color Steel, powder coated / grey
Length / width / hight mm 640 / 580 / 810
Seat: width x hight x depth mm 380 x 595 x 190
Dimensions folded, lying (L / W / H) mm 910 / 580 / 230
Total hight min. / max. mm 810 / 950
Diameter (turning radius) mm 1150
Static stability foreward ° 15 (according EN ISO 11199-3:2005)
Static stability backwards °7 (according EN ISO 11199-3:2005)
Static stability sideways °3.5 (according to EN ISO 11199-3:2005)
Weight without accessories / with
accessories kg 8.3 / 9.1
Maximum user weight incl. payload kg 130
Max. load accessories kg basket: 5 / tray: 5 / rack: 7
recomendet body height m1.55 - 1.85
PRODUCT TESTS
Complete test according rollator norm EN ISO 11199-2
Biocompatibility ISO 10993
20
TOMTAR / User manual for the FAKTO+ rollator / Version 2.0.0 EN
09 TECHNICAL DOCUMENTATION
