Top Hygien Top Lyft User manual
Top Hygien +46 (0)31-943526
Instructions for use
Top Lift - facilitates for a person who has difficulties in getting up and sitting down.
This instruction contains important information for users of this product. Everyone who uses the
product must study and fully understand the contents of the instruction. Bear in mind keeping the
instruction so that it´s always available for the user of the product. Top Hygien will take on no
responsibility if the product is changed, modified or assembled in a different way from what is
described in this instruction.
General information
Top Lift facilitates for a person who has difficulties in getting up and sitting down when going to the
toilet. With a simple press of a button the sitting height is raised or lowered to the wanted level. The
lift is assembled directly on the water closet and is neither needed to be fastened to the wall or to be
supported against the floor. This makes it easy to install and simplifies cleaning.
The height is regulated up and down with buttons folded in the armrest or with a hand control
assembled directly on to the china without having to make holes in the floor or in the wall. The
armrests can be easily folded up to facilitate moving sideways. Top Lift can be combined with bidet
chair Bidéra Automatic or Futura.
Intended use for Top Lift
Read the instruction concerning the lift and its fittings before use. It´s important to fully understand
the contents of the instruction. Please contact Top Hygien if there are any uncertainties or if you
have any questions.
Top Lift is intended for mounting on an already existing floor attached water closet aiming at
facilitating going to the toilet for a person who has difficulties getting up and sitting down. The lift is
also suited for wallattached water closets on condition that the water closet and its installation is
dimensioned for the user´s weight and its own wight ( consult the technical specification).
The lift must only be provided with the intended original water closet or bidet chair Bidéra Automatic
or Futura from Top hygien.
The lift must be installed by a person qualified according to the istallation instructions from Top
hygien.
The lift must not in any case be modified! Any questions will be answered by Top hygien.
Don´t use and don´t assemble any parts on the lift from a third party who isn´t approved by Top
hygien. If unapproved fittings are used Top hygien can no longer guarantee that the security
regulations will be fullfilled.
Always make sure that the lift when cleaned or maintained cannot be handled by mistake.
Always follow the manufacturer´s recommendations according current maximum weight and
distribution of load.
Guarantees will only be valid if the product is used under the present circumstances and for the
intended purpose. Top hygien disclaim the responsibility for damages or errors caused by negligence,
accident or improper use.
Top Hygien +46 (0)31-943526
Security instructions
Make sure that the Lift is assembled according to the instructions before use.
See to it that the user and every possible companion is fully in agreement with how the lift works.
Children are not allowed to use or play with the product.
If the lift is handled by another person than the one sitting on the lift the former must make sure that
the lifting is correctly performed.
Notice that the lift can make a possible squeezing risk.
Always when the lifting function is used make sure that no clothes, hands, feet or other parts of the
body could be squeezed. Also be aware that there could be a squeezing risk between the lift and
other products e g the toilet paper holder attached to the wall or basin.
Do not use an extension cable if not absolutely necessary. Use of unsuitable extension cables might
increase the risk of fire and electrical shock.
See to it that nobody can step or stumble on the cable and that it is not the object of another kind of
strain or risk of injury.
The electronic box of the lift or other incapsulated electrical components must only be opened or
manipulated by a qualified person.
Repairing shall be carried out by educated personnell. Always contact Top hygien about lifting
problems.
Technical specification
Lifting capacity
User´s weight 160 kg
Maximum height from china edge 32 cm
Weight
35 kg
Operating unit
Voltage 230 V ~ 50 Hz
Operating voltage 24 V Dc
Top Lift can also be provided battery powered.
Electronic capsule class: IP 66
Measures
Total breadth 58 cm
Distance between armrests 57 cm
Control
Simple handling with buttons in the armrests or by hand control.
N.B. The manufacturer reserves without preceding notice the right to change weights, measures or
other technical data mentioned in this instruction.
Supervision and maintenance
To have a lift free from problems for many years it should be regularly supervised.
Check the product for any component damages and that screws and fastening devices are tightened
and securely fixed. Do not tighten any screw too tight.
See to it that contacts and cables are undamaged and securely fixed.
If defective parts are discovered they should be immedeately exchanged by a qualified person.
Inspect the lift visually to check that armrests etc are in their right position and fixed to the water
Top Hygien +46 (0)31-943526
closet according to the manufacturer´s instruction.
If you are uncertain about any functions of the lift you should contact Top hygien or your aid´s
central.
Advice concerning maintenance
Top lift is very reliable and doesn´t need any specific maintenance except for superficial cleaning and
regularly looking after ( as above).
Regularly clean the Top lift with soap solution and afterwards dry with a damp cloth. If need be use
disinfectant.
Disconnect the current to the lift so that it won´t be operated during cleaning.
Transport and storage
The lift should be stored in room temperature.
During transport the original packing should be used if possible.
Environment and sorting according to source
All electrical parts are dismantled and sorted as electrical components.
Plastic details are sent to burning and recycling.
Metal parts, wheels and aluminium are scrapped.
Old batteries are left to an environmental station.
The product goes with the EU directives
93/42/EEG and 2007/47/EG
and
The law (1993:584) concerning medical technical products
LVFS 2003:11 Swedish Medical Products Agency instructions on medical technical products
EMC - directive 2014/30/EU
Standards EN 6100 - 6 - 3:2007 + A1:2011
EN 6100 - 6 - 1: 2007
Users guide
Top Hygien +46 (0)31-943526
Operating
Top lift is operated upwards and downwards with the operating box or the buttons in the armrests.
When sitting down the Lower the lift at the same When getting up you
sitting ring should be in time you move on to the raise the sitting ring
a high position. The armrests sitting ring. Stop at the at the same time as
are possible to tip up to suitable level so you can you move forward. As
facilitate moving. support with your feet. straight legs as
possible when you
dismount.
Top Hygien +46 (0)31-943526
Assurance of consistency
We as responsible manufacturer and supplier certifies according to our own judgement that the
product fullfills applicable demands in the regulations below:
Law (1993:584) concerning medical technical products
LVFS 2003:11 Swedish Medical Products Agency instructions on medical technical products
Directives from the European Council on medical products 93/42/EEC and 2007/47/EG
EMC directive 2014/30/EU
The standards: EN 6100 - 6 -3:2007 + A 1 : 2011
EN 6100 - 6 - 1 : 2007
Product type Toilet sitting ring with a built in lifting device
Name of the product Top Lift
Intended use Toilet sitting ring with bulit in lifting device for
disabled persons.
The lift is assembled on the already existing toilet
chair.
Örebro 2017 - 04 - 01
Anna Westbeck
Anna Westbeck
Managing director
Top Hygien + 46 (0) 31 943526
[email protected] www.tophygien.se
