Topcom PB-5200 User manual

TOPCOM TECHNOLOGY CO., LTD.
Specification for Power bank
Suitable for most digital devices with DC 5V input
Date : 2011/11/15
From : Linda Lin
HEADQUARTER:
TOPCOM TECHNOLOGY CO., LTD
ADDRESS : No.99-9, Sec 1, Huanjung Rd,
Taichung 40672, Taiwan
TEL : [phone]
FAX : [phone]
www.topcomtech.com.tw
FACTORY:
TOPCOM TECHNOLOGY SHENZHEN CO.,
LTD
ADDRESS: 4F, Building E, Zhongxi Industrial
Park, Tongyu Industrial Zone, Buyong
Village, Shajing Town, Baoan District,
Shenzhen City, Guangdong Province,
China

TOPCOM TECHNOLOGY CO., LTD.
UNIVERSAL POWER BANK Page:1/7
1
INDEX
1.Subject……………………………………………………………………2
2.Product Specification……………………………………………………2
3.Features ….………………………………………………………………3
4. Operation Instruction ………………………………………..…....…3~4
5. Problems and Solutions…………………………………………………5
6. Caution …………………………………………………………………..5
7. Limited Warranty………………………………………………………..5
8. Accessories……………………………………………………………….5
9. Package…………………………………………………………………. 6

TOPCOM TECHNOLOGY CO., LTD.
UNIVERSAL POWER BANK Page:2/7
2
1.Subject
This power bank is mainly for charging when the portable products are with less power. Can be used to
charge anytime, anywhere and be the good friend of people.
2.Product Specification
Model PB-5200
Input Voltage DC 5V
Input Current 500 / 1000 mA
Output Voltage DC 5.1V
Output Current 2.1A ( Max.)
Power/
Capacity Indicator
Input / Output Port
Dimension (mm) 102*66*16
zThe system is built-in smart IC controller to automatically detects the input power and selects proper
current 500mA or 1000mA to charge the power bank. it will automatically detect the connected
power supply capacity before charging. When the power capacity of equipment more than 1000mA,
the power bank will accept the charge with 1000mA, if the supply capacity is less than 1000mA, the
power bank will accept the charge via 500mA. The system refuses to charge the power bank if output
voltage is under 5V or current under 500mA.
zRequired Environment
* Operating Temperature : 0-40℃
* Operating Relative : 5~95%RH
*:Storage Tmperature : -20~85℃

TOPCOM TECHNOLOGY CO., LTD.
UNIVERSAL POWER BANK Page:3/7
3
3. Features
●Built-in high-tech, high efficiency cells, powerful with long cycle life.
●One or two USB ports to allow charging one or two devices simultaneously..
●Allow the power bank to charge digital devices while the power bank is charged.
●Double protection design: One for battery, other one for system with over charge, over voltage, over
current and short circuit protection.
●Intelligent display of LED to indicate the charging status and power levels.
●Suitable for most digital devices with DC 5V input, such as tablet PC、smart phone、iPhone、iPod、
MP3、MP4、GPS、PSP..etc.
4. Operation Instruction
# How to recharge power bank
1. Charging Equipment : USB port of computer, AC USB adapter, Switching power adapter with USB
connector.
2. Connect the cable to the power sources and power bank (Photo 1)
3. In 5 seconds after connection, one power level LED flashes to indicate the power bank is charged
properly. After fully charged, 3 LEDs turn to solid light.

TOPCOM TECHNOLOGY CO., LTD.
UNIVERSAL POWER BANK Page:4/7
4
# How to charge your digital device
● If 3 Power capacity LEDs flash , it indicates the power sources is not proper for charging, try other
power sources.
●The power bank can charge two devices simultanesouly. Hower, when one device draws certain
amount power 2A~2.1A,such as iPad, you may not able to use both USB port. If ouput cutrrent is
over 3A, it may deactivate the power bank and all the lights off. If this occurs, just disconnect your
digital devices and charge the power bank to reset it.
1. Use the original cable or optional cable with suitable connector.
2. Connect the cable to the power bank and your digital device (As below photo )
3. Press the on/off button to check the charging status
Charging status indication:
1. Power indicator: the power LED lights up to indicate power bank is functioning well.
2. Power capacity Indicator : The power capacity LEDs light up according to the possess power
capacity. All lights off means it runs out of power.
