Topcon RL-H5B User manual

RL-H5B
RL-H5B
Note: In manual mode
• Self-leveling function is not active.
• Height alert function is not active.
On-Grade
Index
Maintenance
• Always clean the instrument after use.
• Wipe off moisture completely if the instrument gets wet during survey work.
• Never use an abrasive cleaner, ether, thinner, benzene, or other solvents.
Other precautions
• Before starting work or during operation, check that the instrument is function-
ing correctly and performance is normal.
• Protect the instrument from heavy shocks or vibration.
• Always make sure the instrument is completely dry before storing. Dry any
moisture with a soft, clean cloth.
• Remove batteries before storing when the instrument will not be used for peri-
ods on 1 month or more. Batteries may leak fluid when left inside the instru-
ment causing malfunction.
Exporting this product (Relating EAR)
This product is equipped with the parts/units, and contains software/technology,
which are subject to the EAR (Export Administration Regulations). Depending
on countries you wish to export or bring the product to, a US export license may
be required. In such a case, it is your responsibility to obtain the license. The
countries requiring the license as of Aug. 2017 are shown below. Please con-
sult the Export Administration Regulations as they are subject to change.
North Korea, Iran, Syria, Sudan, Cuba
URL for the EAR of the US: http://www.bis.doc.gov/policiesandregulations/ear/
index.htm
LASER SAFETY INFORMATION
The RL-H5B is classified as a Class 2 Laser Product according to IEC
Standard Publication 60825-1 Ed.3.0: 2014 and United States Government
Code of Federal Regulation FDA CDRH 21CFR Part1040.10 and 1040.11
(Complies with FDA performance standards for laser products except for
deviations pursuant to Laser Notice No.50, dated June 24, 2007.)
WARNING
• Use of controls or adjustments or performance of procedures other than those
specified herein may result in hazardous radiation exposure.
• Never intentionally point the laser beam at another person. The laser beam is inju-
rious to the eyes and skin. If an eye injury is caused by exposure to the laser
beam, seek immediate medical attention from a licensed ophthalmologist.
• Do not look directly into the laser beam. Doing so could cause permanent eye
damage.
• Do not stare at the laser beam. Doing so could cause permanent eye damage.
Beam aperture
NOMENCLATURE AND FUNCTIONS
HOW TO STORE
LS-80L
After using the instrument, store it as shown below.
(LS-80A/80B/90)
PRECAUTIONS
POWER SOURCE
EXCEPTIONS FROM RESPONSIBILITY
• The manufacturer, or its representatives, assumes no responsibility for any dam-
age, or loss of profits (change of data, loss of data, loss of profits, an interruption of
business etc.) caused by use of the product or an unusable product.
• The manufacturer, or its representatives, assumes no responsibility for any dam-
age, or loss of profits caused by usage different to that explained in this manual.
• The manufacturer, or its representatives, assumes no responsibility for consequen-
tial damage, or loss of profits due to heavy rain, strong wind, high-temperature and
humidity, or storing or use of the product under unusual conditions.
• Product failures caused by rebuilding are out of warranty.
• Cautions and warnings included in this manual do not cover all the possible events.
INSTRUCTION MANUAL
ROTATING LASER
RL-H5B
AA-size dry cell batteries
D-size dry cell batteries
(LS-B10/B10W)
Level Sensor Holder Model-6
Battery power lamp (Red)
Blinking:
The power is low, but laser is still usable.
(Blinking continues for one minute.)
Solid:
Dead batteries. Replace the batteries with
new ones. (The lamp is solid for five
minutes, then turned off automatically.)
Manual mode ON key
ON: Push twice continuously.
OFF: Push once.
Height alert OFF key
OFF: Push twice continuously.
ON: Push once.
Height alert function (Refer to the
description on the back page.)
Height alert OFF lamp (Red)
Height alert function is not active.
Manual mode ON lamp (Red)
Self-leveling does not function.
Self-leveling function
When the power is turned on, the laser beam is
automatically positioned within the accuracy
range by the self-leveling function.
Protective glass
Rotary head
Laser beam emits from here.
Handle Battery holder
Battery holder knob
Power switch
Turn the instrument ON or OFF.
Power lamp/Self-leveling lamp (Green)
Blinking quickly : Self-leveling is in process.
Blinking slowly : Self-leveling is almost complete.
Solid : Self-leveling is complete.
Self-leveling function
(Refer to the description below.)
Sight
Control panel
LS-80L
(Level Sensor)
Beam receiving window
Turn the beam receiving window side towards RL-H5B
to detect the laser beam.
Indicator
The indicators are located on front and back sides of the
instrument.
LS-80L Indicator (Refer to the description on the
back page.)
On-Grade precision switch
Two on-grade precision options are available, normal
precision (±2mm) and high precision (±1mm). By
pressing this switch, the precision options are switched
alternately. Confirm the precision choice by the
indicator. (Normal precision is the default setting each
time the sensor is turned on.)
Power switch
The power switch turns ON or OFF by pressing.
Buzzer sound switch
Volume of the sensor buzzer can be alternately switched
to LOW/LOUD/OFF by pressing the switch.
Buzzer speaker
Auto-cut off function
The power will be turned off automatically if no laser
beam is detected for approximately 30 minutes.
(To turn on the level sensor, press the power switch
again.)
RL-H5B
Replacing the dry cell batteries
1Remove the DB-79B battery holder by turning battery holder knob to “OPEN” side.
2Install the new 4xD size dry cell batteries (alkaline) referring to the illustration on
the battery holder.*1), 2), 3)
3Install the battery holder. Tighten the battery cover knob to “LOCK” side.
*1 Replace all 4 batteries with new ones at the same time. Do not mix used and new
batteries, and do not mix different types of batteries together.
*2 Use alkaline dry cells.
Nickel hydrogen dry cells and nickel cadmium dry cells can be used too, but the
operating time is different from the time of alkaline dry cells.
*3 Generally, performances of dry cell deteriorate temporarily in low temperature, but
recover in normal temperature.
LS-80L
Replacing the dry cell batteries
1Keep pushing the battery cover in 1 direction, and then try to slide the
cover in 2 direction.
The cover does not move but it will be open.
2Take out the batteries and place new ones (2xAA size alkaline dry
cell batteries) into the battery box.
3Press the lid down and click to close.
DB-79B
CAUTION
• Perform checks at start of work and periodic checks and
adjustments with the laser beam emitted under normal
conditions.
• When the instrument is not being used, turn off the power.
• When disposing of the instrument, destroy the battery
connector so that the laser beam cannot be emitted.
• Operate the instrument with due caution to avoid injuries
that may be caused by the laser beam unintentionally
striking a person in the eye. Avoid setting the instrument
at heights at which the path of the laser beam may strike
pedestrians or drivers at head height.
Thank you for selecting our products.
• Please read this Instruction manual carefully, when using
this product.
• The specifications and general appearance of the instru-
ment, and the content of this manual are subject to change
without notice.
• Some of the diagrams shown in this manual may be simpli-
fied for easier understanding.
• Always keep this manual in a convenient location and read
it when necessary.
• Please read the Instruction manual of the paired instrument
in conjunction with this manual.
1020989-02-A
Class 2 Laser Product
• LS-70 cannot be stored.

OPERATION
CHECKS AND ADJUSTMENTS
A: Battery power
lamp
B: Power lamp /
Self-leveling lamp
D: Height alert OFF
lamp
C: Manual mode ON
lamp
How To Operate
1Set the instrument to the tripod or
smooth surface. Make sure instrument
is roughly level.
2Press power switch (ON).
3Press power switch on level
sensor (ON).
4Select the precision mode by
pressing the On-Grade
precision switch.
5Locate the on-grade position
“---” by moving the level sensor
up and down.
6Mark the position of On-Grade index.
(Top of the level sensor is 40mm [1 9/16”]
from index for offset marking.)
LS-80L Indicator Detective Range
Height Alert Function
When the instrument system detects a shock, this function informs
the operator of it.
• When the instrument’s installation status (height) is sharply changed
by the contact of the operator or the like, this function stops self-
leveling to keep the operation accuracy and informs the operator of
the situation. The three lamps blink at the same time as shown at
the right.
• After 1 minute has passed since the self-leveling function was
activated and the laser beam was emitted, this function works.
• The height alert function does not work in the “Manual” mode.
Shock is given to the instrument.
The three lamps blink at the same
time and the rotary head rotates at
low speed.
Height alert status [How to reset]
1Turn off the power switch.
2Check whether the instrument is installed
correctly.
3Turn on the power switch. Self-leveling starts
again. After self-leveling is finished, the laser
beam is emitted.
4Make sure that the laser beam is set at the
correct height. Then, restart the operation.
Higher than datum position
(Buzzer sound: High frequent beep sound)
Move the sensor downward.
High precision mode
Normal precision mode
Datum position
(Buzzer sound: Continuous beep sound)
Lower than datum position
(Buzzer sound: Low frequent beep sound)
Move the sensor upward.
Battery remaining display
Height alert warning of rotating laser*1
A flash and a buzzer sound signifies
that the height alert function of rotating
laser is operating.
Rotating laser battery warning*2
A flash shows that the rotating
laser power is low.
Note: The warning displays *1 and *2 are the functions that the level sensor
detects alarm signal from the rotating laser.
The level sensor can be canceled the alarm detection from the rotating laser.
To be canceled the detection; Press the power switch while pressing the
buzzer sound switch when powering on.
(1) Battery is sufficient.
(2) The power is low, but
laser is still usable.
(3) Dead battery.
Replace the dry battery
with new one.
Lamp Position
Power switchManual mode
ON key
Height alert
OFF key
Checking and adjusting calibration
Checking cone error
Horizontal calibration of the laser beam can be checked by the user.
[Checking]
1Set up a tripod approx. 50m (160ft) from a wall. Mount the instrument on
the tripod, facing the X1 side toward the wall.
2Turn the instrument on and allow self-leveling to complete.
3Put the level sensor in fine detection mode by pressing the On-
Grade precision switch.
4By using the level sensor, mark the center position of laser beam on
the wall. (X1)
5Turn off the instrument.
Loosen the tripod screw, rotate the instrument 180 degrees and re-
secure it on the tripod. The X2 side of the instrument faces toward
the wall.
When rotating the instrument, avoid changing the height.
6Turn the unit on again and allow self-leveling to complete.
7By using the level sensor, mark the center position of laser beam on
the wall. (X2)
8If the difference value of marked two laser beam heights (difference
value of X1 and X2) are less than 5mm, adjustments are not needed.
The difference value is greater than 5mm, adjust the instrument as
described in right.*
9Check the Y side as the same way.
To discontinue calibration the instrument, press the Power switch.
Perform the following check after completing horizontal calibration procedure.
[Checking]
1Set up the laser centered between two walls approximately 40m (131ft) apart. Orient the instrument so one axis, either X or Y, is facing the walls.
2Locate and mark the position of the rotating laser beam on both walls using the level sensor.
3Turn off the instrument and move the instrument closer to wall A (1m to 2m /3 ft to 6 ft). Do not change the axis orientation of the instrument. Turn the
instrument on.
4Again locate and mark the position of the rotating laser beam on both walls using the level sensor.
5Measure the distance between the first and second marks on each wall. If the difference between each set of marks is less than 4mm (5/32 of an inch),
no error exists.
* If the difference value is greater than 4mm (5/32 inch), contact your local dealer.
* If the difference value is greater than 40mm (±90”), it exceeds the
adjustment range. Please contact your local dealer.
Wall A Wall B Wall A Wall B
Approx. 40m
Datum
position
Cone error
Use the table below to determine operation errors indicated by blinking lamps on the control panel.
(For the lamp indication, refer to “Lamp position”.)
If corrective action listed does not correct error, please contact your local dealer.
Lamp Indication Error Code Corrective Action
Lamp B, C and D blink in turn Self-leveling range error Correct tilt of the instrument until it less than 5 degrees.
Lamp A lights Battery power error Replace the four alkaline dry cell batteries with new ones
at a time.
Lamp B, C and D blink
simultaneously
Height alert error Turn power off, rough level the instrument, then turn
power on again. Check height of laser beam as it may
have changed.
Lamp D blinks quickly Calibration error Repeat calibration procedure. If error repeats contact your
local dealer.
Lamp A, B, C and D blink
simultaneously
Internal error Turn power off, then on again in stable locations. If error
repeats contact your local dealer.
LS-80L
Beam detection width: 50 mm (2.0 in)
On-Grade precision: High: ±1 mm (±0.04 in)
Normal: ±2 mm (±0.08 in)
Beam detection indication: Liquid crystal (both sides) and
buzzer
Power source: 2 x AA size dry cell batteries
Operating time (at 20°C): Approx. 120 hour
(Using alkaline manganese dry
cell batteries)
Automatic shutoff: after 30 minutes
(without beam detection)
Dust and water resistance: IP66 (IEC60529: 2001)
Operating temperature: -20 to 50°C (-4 to 122°F)
Storage temperature: -30 to 60°C (-22 to 140°F)
Size: 146(L)x76(W)x26(H) mm
Weight: 0.19 kg (0.41 lbs)
(with dry cell batteries)
RL-H5B
Laser source: Laser diode (Visible, 635 nm)
IEC Class 2
Laser output: 0.9 mW
Self-leveling range: ±5°
Accuracy: ±20”
Rotational speeds: 600 r.p.m
Operating range: Diameter Approx. 2 to 400 m (When
using LS-80L)
Power source/Operating time at 20°C (68°F):
4 x D size dry cell batteries (alkaline) /
100 hours
Dust and water resistance: IP66 (Based on the standard IEC60529)
Operating temperature: -20 to 50°C (-4 to +122°F)
Storable temperature range: -30 to 60°C (-22 to +140°F)
Remote warning display: RL-H5B height alert warning
(Warning is displayed on the indicator
of LS-80L.)
RL-H5B battery warning (Warning is
displayed on the indicator of LS-80L.)
Size: 172(L)x211(W)x205(H) mm
Laser beam height: 171.8 mm (Height from the instrument’s
bottom surface to the center point of laser
beam)
Weight: 2.3 kg (5.1 lbs) (with dry cell batteries)
Tripod screw: 5”/8X11 threads for surveying instrument
If the height alert OFF lamp blinks quickly and the power is not automatically turned off when pressing the height alert OFF key to
memorize the height, the height exceeds the adjustment range. Please contact your local dealer.
[To calibrate the X axis]
1Face the X1 side of the instrument toward a wall, press the Power switch while pressing the height alert OFF key. Then the
height alert OFF lamp will light, and manual mode ON lamp will blink. (X axis is selected.)
2Press the height alert OFF key to calibrate the X axis. The manual mode ON lamp will light. When self-leveling finishes,
the laser beam will emit.
3Using the level sensor, mark the on-grade height of laser beam on a wall.
4Rotate the instrument 180 degrees to face X2 side toward a wall.
5In the same way as step 3, mark the on-grade height of laser beam on a wall.
6Press the manual mode ON key or power switch to make adjustment so that the laser beam height may be at the center
between the positions of Step 3 and Step 5.
7Press the height alert OFF key to memorize the new laser beam calibration. The height alert OFF lamp will blink. Power
will shut off automatically when the calibration memorization is complete.
The X axis adjustment is completed now.
[To calibrate the Y axis]
1Face the Y1 side of the instrument (Control panel side) toward a wall, press the Power switch while pressing the height alert OFF
key. Then the height alert OFF lamp will light, and manual mode ON lamp will blink. (X axis is selected.)
2Press the power switch once again. The self-leveling lamp will blink. (Y axis is selected.)
3Press the height alert OFF key to calibrate the Y axis. The self-leveling lamp will light.
4Using the level sensor, mark the on-grade height of laser beam on a wall.
5Rotate the instrument 180 degrees to face Y2 side toward a wall.
6In the same way as step 4, mark the on-grade height of laser beam on a wall.
7Press the manual mode ON key or power switch to make adjustment so that the laser beam height may be at the center
between the positions of Step 4 and Step 6.
8Press the height alert OFF key to memorize the new laser beam calibration. The height alert OFF lamp will blink. Power
will shut off automatically when the calibration memorization is complete.
The Y axis adjustment is completed now.
ERROR CODE
http://www.topcon.co.jp
GLOBAL GATEWAY http://global.topcon.com/
Please see the following website for contact addresses.
© 2017 TOPCON CORPORATION
ALL RIGHTS RESERVED
SPECIFICATIONS
X1
X2
Y1
Approx. 50m
level sensor
Wall
X1
X2
X1
X2 Laser beam
X1 Laser beam
Approx. 50m
Control panel
Handle
Y2
Laser point of X2
Laser point of X1
