Topgreener TDOS5 User manual

12
INSTALLATION INSTRUCTIONS
SPECIFICATIONS
DESCRIPTION
3
WARNING
Turn the POWER OFF at the circuit breaker before installing
the sensor
Read and understand these instructions before installing. This device is intended
for installation in accordance with the National Electric Code and local regulations.
It is recommended that a qualified electrician perform s this installation. Make sure
to turn off the circuit breaker or fuse(s) and make sure power is off before wiring the
device.
Use copper wires only.
WIRING DIRECTIONS
As illustrated in Figure 1, The TDOS5 has a 180° detection range with a maximum distance
of 20’ detection in front of the sensor and 10' on the sides. For maximum results, the sensor
must be properly installed between the height of 4’ to 5’ and away from obstructions such as
walls, furniture and transparent barriers like Low-E glass.
The TDOS5 uses advanced passive infrared sensor to detect heat emitted motion. The
sensor switch can turn on a load and keep it on as long as it detects motion. The sensor will
automatically shut off the load at the end of the selected time delay. The countdown of the
selected time delay starts after the last motion detected. The sensor is customizable with dials
that can adjust Time Delay, detection Range, ambient Light Level, and a switch to change
between Occupancy/ Vacancy modes.
1. Test and Label all wires before installing the sensor. You must have a HOT,
NEUTRAL, and LOAD wires in the switch box. DO NOT connect the
WHITE (Neutral) wire and the RED (Load) wire on the sensor
together. Otherwise, the load will keep flashing.
2. Connect RED wire from sensor to the LOAD wire.
3. Connect BLACK wire from sensor to the HOT wire.
4. Connect WHITE wire from sensor to the NEUTRAL wire.
NEUTRAL WIRE IS REQUIRED.
5. Connect GREEN wire from sensor to the GROUND wire.
ADJUSTMENT
TDOS5
OCCUPANCY / VACANCY (2-IN-1)
SENSOR SWITCH
Incandescent ............................. ............................... ........... ........ ...............................… 500W
Time Delay........................................ ................................... ..................…… 15Sec to 30Mins
Light Level.................................................. ................................. .................. 30 Lux--Daylight
Fluorescent ............ .................. ............. ................................................. ...................... .... 500VA
Operation Temperature................................ .................................... ...................... 32 ºF--131ºF
Voltage .............. ............................... ................................. ..... ............. ....... ........ 120VAC,60Hz
Motor .............................................. ................................... .....................................…… 1/ 8Hp
COVERAGE
Figure 1
Max. 10'
on the sides
Max. 20'
from front
Installation
Height: 4' - 5'
Detection Range
Wiring Diagram
Hot
Black
Ground
Green
Load
Red
Neutral
White
The control panel cover is also the push button on the switch. Remove the push-button cover
plate by prying from the bottom of the push-button and pulling outward.
Control Panel Cover
LED Indicator
OFF OCC VAC
TIME
TEST
Min
10 20
Min
30
Min RANGE LIGHT
3
3
2
Mounting flange
Fresnel Lens
OFF OCC VAC
4
1
2
4
1
(Push Button)
Time dial
This dial adjusts the time delay. Default position: 15 Seconds (Test mode) Adjustable:
from 15 Seconds to 30 Minutes (clockwise)
Range dial
This dial adjusts the detection range. Default position: Center at 65%Adjustable: 30%
(Position 1) to 100% (Position 4).
Note: Use the greater setting for larger coverage area.
Light dial
The sensor may be adjusted to operate at the desired level of ambient light.
• To do so, turn the dial counter clockwise for sensor to detect motion and operate
during low light or no light. Turn the dial clockwise for sensor to operate when
there’s more light in the area or even during daylight.
OCC
Mode
OFF
VAC
Description
Circuit is permanently opened.
(switched off)
Occupancy Mode:
Automatic On, Automatic Off
after set time delay.
Position
Left
Center
Right
Vacancy Mode: Manual On only,
Automatic Off after set time
delay.
Push-button Function
Manually toggles
None
Manually toggles
On / Off the load.
On/Off the load.
Off/ Occupancy/ Vacancy Mode Switch
