Topgreener TGWF500D User manual

INSTALLATION INSTRUCTIONS
• Control your lights with your smart devices without the need of any hubs.
• Easy to configure, easy to use Smart App
• Save energy by automating the ON/OFF times or using the timer
• Compatible with Amazon Alexa, Google Assistant, Android, and iOS
(see system requirements below )
SPECIFICATIONS
Model: TGWF500D
Wi-Fi Dimmer Switch
FEATURES
Protocol........................................................................................…...IEEE 802.1b/g/n
Wireless Type...................................................................................................2.4GHz
Operating Temperature.................................................................32°-104°F (0°-40°C)
Voltage ......................................................................................................120V~60Hz
System Requirements.......................................Android 4.1 or higher/ iOS 8 or higher
•Wi-Fi Internet connection of 2.4GHz
•Smart Device such as a Smart Phone or Tablet with an operating
system of Android version 4.1 or higher or iOS 8 or higher
•Installation of the TOPGREENER Smart App on the Smart Device
REQUIREMENTS
© 2018 TOPGREENER, Inc. ● CA, U.S.A. ● WWW.TOPGREENER.COM ● 0201180114-01
WARRANTY
This device is warranted to be free of material and workmanship defects for 1 year from the date of purchase. Original receipt or proof of purchase from an authorized retailer must be presented upon warranty claim.
ALL claims must be verified and approved by Top Greener, Inc. Warranties from other Top Greener products may vary. This warranty is nontransferable and does not cover normal wear and tear or any malfunction,
failure, or defect resulting from misuse, abuse, neglect, alteration, modification, or improper installation. To the fullest extent permitted by the applicable state law, Top Greener shall not be liable to the purchaser or
end user customer of Top Greener products for direct, indirect, incidental, or consequential damages even if Top Greener has been advised of the possibility of such damages. Top Greener’ total liability under this or
any other warranty, express or implied, is limited to repair, replacement or refund. Repair, replacement or refund are the sole and exclusive remedies for breach of warranty or any other legal theory.
WARNING
Turn the POWER OFF at the circuit breaker before installing the Dimmer
Read and understand these instructions before installing. This device is intended for installation
in accordance with the National Electric Code and local regulations. It is recommended that a
qualified electrician performs this installation.
Use copper wire only
Incandescent........................................................................................................600W
CFL/LED/Self Ballasted..................................................................................2A 150W
MULTIGANG INSTALLATION
When installing more than one control in the same wall box, it may be necessary to
remove the side tabs before installing (see below). Using pliers, bend each tab back
and forth until they break off. Repeat for each tab to be removed. Removal of tabs WILL
REDUCE MAXIMUM LOAD CAPACITY.
Dimmable
LED/CFL
Load Capacity when Tabs
are removed from:
0 Sides 1 Side
2 Sides
150W 150W150W
LED/CFL Derating Chart
Tabs Removed for Multigang installation
When using the Dimmer to control LED/CFL lights in conjunction with another
Dimmer within the same wall box to control Incandescent /Halogen lights follow the De-
rating Chart below for Maximum Capacity on EACH device. If you are using ONLY
LED/CFL bulbs on ALL Dimmers, DO NOT USE this De-rating Chart. Follow the LED/
CFL De-rating Chart above.
Then the Maximum COMBINED Wattaged for the
Incandescent/Halogen bulbs on EACH attached dimmer:
If NO Tabs are
removed then
Max Wattage is:
If 1 side of Tabs
are removed then
Max Wattage is: are removed then
Max Wattage is:
If 2 sides of Tabs
0W
1-25W
26-50W
51-75W
76-100W
101-125W
126-150W
600W
500W
400W
300W
200W
100W
0W
500W
400W
300W
200W
100W
50W
0W
400W
300W
200W
100W
50W
0W
0W
If the combined
Wattage of ALL
LED/CFL bulbs
on 1 dimmer is:
NOTE: This device is not compatible with standard 3-way
nor 4-way switches. 3-way and 4-way switching requires the
TGWF3K auxiliary switch. For 3-Way or 4-way wiring, follow the
instruction on the TGWF3K auxiliary switch
WIRING DIRECTIONS
First, find out if you will be controlling the lights from one location or
multiple locations. Next, identify all the wires. Once you've identified
the wires, follow the diagram below for wiring.
Single-Pole installation
Yellow
FCC COMPLIANCE STATEMENT
FCC Grant of Equipment Authorizations of this device and transmitters installed in this device can be found at FCC website by entering the FCC ID number on the device.
Caution: Changes or modifications not expressly approved by the part responsible for compliance could void the user’s right to operate the equipment.
This device complies with Part 15 of the FCC Rules. Operation is subject to the following two conditions: (1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation of the device.
This equipment has been tested and found to comply with the limits for a Class B digital device, pursuant to part 15 of the FCC rules. These limits are designed to provide reasonable
protection against harmful interference in a residential installation. This equipment generates, uses and can radiate radio frequency energy and, if not installed and used in accordance with
the instructions, may cause harmful interference to radio communications. However, there is no guarantee that interference will not occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception, which can be determined by turning the equipment off and on, the user is encouraged to try to correct the interference by one or
more of the following measures:
•Reorient or relocate the receiving antenna.
•Increase the separation between the equipment and receiver.
•Connect the equipment into an outlet on a circuit different from that to which the receiver is connected.
•Consult the dealer or an experienced radio/TV technician for help.

INITIAL SETUP FOR Wi-Fi CONTROL
1. Connect the TGWF500D, then
turn on the circuit breaker.
2. Connect your Smart Device (phone or tablet) to the same 2.4GHz
Wi-Fi network that your TGWF500D outlet will be connecting to.
2.4GHz Wi-Fi
3. Use your phone to search for “TOPGREENER” from App Store or Google Play.
4. Once installed, open the App and follow the on-screen instructions to register
then login. Follow the instructions in the App to connect the Smart Plug to your
network. Over time, the App may be updated for a better experience or added
features, so be sure to follow the in-App instructions closely:
a. Login to the App
b. Navigate to the Devices tab and click on "Add Device" or the "+"
button
c. Select the device type "In-wall dimmer".
d. When prompted to "power on the device and confirm", push and
hold the bottom button on the TGWF500D for 5 seconds and the
LED indicator on the device will start blinking rapidly.
•When LED starts blinking, press "Confirm the indicator
rapidly blinking"
e. Enter your Wi-Fi password when prompted and click on confirm
f. After successfully adding the device, you can change the name
of it as desired
NOTE:
By default, the app will only allow one user to control the Dimmer.
To add users, go to your "profile" on the app and click on "Device
Sharing" and follow the on-screen instructions.
MANUALLY OPERATING THE DIMMER
•To turn the lights ON to the last used brightness level, press and
release the top Dimmer Paddle
•To brighten the lights, press and hold the top Dimmer Paddle and
release when the desired level is reached
•To dim the lights, press and hold the bottom Dimmer Paddle and
release when the desired level is reached
•To save the brightness level and turn off the lights, press and release
the bottom Dimmer Paddle
CHANGING THE FACE COVER
To replace the face cover, use a flat screwdriver and insert the tip at the gap
shown in the diagram above and pry cover off.
To re-install, simply align the cover and snap back on.
a. b. c.
d. e. f.
LED INDICATOR ON DEVICE
•Solid Green: Device is plugged in to a power source, but it has not
been paired.
•Slow Blinking Green: Device is attempting to pair with the
controller while in APN mode. When LED turns off, the device has
paired successfully
•Fast Blinking Green: Device is attempting to pair with the controller
while in Easy mode. When LED turns off, the device has paired
successfully
•Solid Blue: The device is paired and the power is turned ON
•No Light: The device is paired and the power is turned OFF.
Dimmer
Switch
Paddle
LED
Indicator
Air Gap Switch on
the TGWF500D
The Air Gap Switch located below the Dimmer Switch Paddle is designed
for your safety. With push buttons switches, it is difficult to know if the switch
is in the On or the Off position without having to use a tester. This switch
eliminates the hazard of having to change a light bulb on a possibly live fixture.
Use the Air Gap Switch to Power Off before you change the bulb.
