TOPIC-LIGHT COB200W User manual

LED ZOOM PAR64 COB 200W 3200K IP X4
1
User Manual
LED ZOOM PAR64 COB 200W 3200K IP X4
COB200W

LED ZOOM
2
Table of contents
1. Safety
instructions ...............................................................................................................................3
1.1. FOR SAFE AND EFFICIENT
OPERATION ............................................................................3
2. Technical
Information ..........................................................................................................................4
3. Menu structure
....................................................................................................................................4
4. DMX Table
...........................................................................................................................................7
4.1. DMX Mode 1 (1
Channel) .............................................................................................................7
4.2. DMX Mode 2 (2
Channel) ............................................................................................................ 8
4.3. DMX Mode 3 (3
Channel) ............................................................................................................ 8
4.4. DMX Mode 4 (4
Channel) ............................................................................................................ 8
4.5. DMX Mode 5 (5
Channel) .............................................................................................................9
4.6. DMX Mode 6 (6 Channel) ..........................................................................................................
..9
4.7. DMX Mode 7 (7 Channel) ..........................................................................................................
..10
PAR64 COB 200W 3200K IP X4

LED ZOOM
3
1. Safety instructions
This device is suitable for indoor use only.
All modifications to the device will void the warranty.
Repairs are to carry out by skilled personnel only.
Use only fuses of the same type and original parts as spare parts.
Protect the unit from rain and humidity to avoid fire and electric shocks.
Make sure to unplug the power supply before opening the housing.
1.1.
FOR SAFE AND EFFICIENT OPERATION
Be careful with heat and extreme temperature
Avoid exposing it to direct rays of the sun or near a heating appliance.
Not put it in a temperature bellow 32°F /0°C, or exceeding 104°F /40°C.
Keep away from humidity, water and dust
Do not place the set in a location with high humidity or lots of dust.
Containers with water should not be placed on the set.
Keep away from sources of hum and noise
Such as transformer motor, tuner, TV set and amplifier.
To avoid placing on un-stable location
Select a level and stable location to avoid vibration.
Do not use chemicals or volatile liquids for cleaning
Use a clean dry cloth to wipe off the dust, or a wet soft cloth for stubborn dirt.
If out of work, contact sales agency immediately
Any troubles arose, remove the power plug soon, and contact with an engineer for repairing,
do not open the cabinet by yourself, it might result a danger of electric shock.
Take care with the power cable
Never pull the power cable to remove the plug from the receptacle, be sure
to hold the plug. When not using the device for an extended period of time, be sure to
disconnect the plug from the receptacle.
PAR64 COB 200W 3200K IP X4

LED ZOOM
4
Important: Damages caused by the disregard of this user manual are not subject to
warranty. The dealer will not accept liability for any resulting defects or
problems. Make sure the electrical connection is carried out by qualified
personnel. All electrical and mechanical connections have to be carried out
according to the European safety standards.
2. Technical Information
- DMX 512 control
- DMX Modes with 1, 2, 3, 4, 5, 6, 7 Channels
- Sound controlled via built-in microphone
- Adjustable sound sensitivity; Linear and curve lighting option
- Function: Built-in programs
Strobe effect with adjustable speed
Dimmer
Master/slave
- LED-display
- 3 Pin XLR in/out (waterproof); Powercon in/out (waterproof)
- 1 x 200W COB LEDs Warm White
- Beam Angle: 10 ~ 40 degree, manual adjustable
- Power Max. 250W
- Power input AC 100-240V, 50/60Hz
- Weight: 4.5kgs (L*W*H = 480 x 305 x 275mm)
3. Menu structure
Master-Slave mode as “A SL” or “A HO”, all of the settings are controlled by four buttons: “MODE,
Up, Down and Enter”.
Press “MODE” to switch functions (10 functions can be selected):
R E S T
A D
——>RESET ALL SETTING
“REST”: Function Code
——>MASTER-SLAVE MODE SETTING
“A”: Function Code
“D”: Set the machine as a master
PAR64 COB 200W 3200K IP X4

LED ZOOM
5
Press the “MODE” then press the “ENTER” to begin your setting. Press “UP” and “DOWN” to switch the
modes with the shining Function Code. Be sure to press the “ENTER” button to save your changing, it
won’t be saved if the button has not been pressed. Moreover, the saving data still exists even after power
off and then on.
MASTER SLAVE MODE SETTING
C 1
D 0 0 1
F 0 0 0
A H O
2 8 _ C
U 2 5 5
A D
A H O
A S L ——>SLAVE MODE
The machine only accept the signal that send from host-machine, it won’t accept
the signal from the console.
——>Press “MODE” -> “Enter” and Press UP/Down button to setting.
Press “Enter” to confirm the DMX condition and forbid the Master Slave
Mode.
——>DMX ADDRESS SETTING
“D”: Function Code
“001”: DMX Address
——>Temperature setting
“C”: Function Code
“28”: Show temperature of LED PCB
——>DMX AMOUNT SETTING
“C”: Function Code
“1”: Channel amounts
——>SINGLE COLOR SETTING
“U255”: 0-255 setting for white color
——>SINGLE MODE SETTING, work only on the situation of
“F”: Function Code
“000”: Function number
——>The machine will send signal to all connected slave-machines.
PAR64 COB 200W 3200K IP X4

LED ZOOM
6
WHILE IN MASTER-SLAVE MODE, ONLY ONE HOST MACHINE CAN BE EXISTED, IF NOT, IT
MAY CAUSE SIGNAL CONFLECTS.
DMX CHANNEL SETTING
DMX ADDRESS SETTING
SINGLE MODE SETTING:
C 1
C 2
C 3
C 4
C 5
C 6
C 7
D 0 0 1
F 0 0 0
F 0 1 0
——>Default in C1, DMX Channel: CH. 1
——>DMX Channel: CH. 3
——>Press “MODE” to begin your setting, and press “ENTER” to select the mode.
Select the UP/DOWN from F010～F120, press “ENTER” to save your setting.
Original setting “F000”, the light goes off.
——>Default in D001, DMX Address from “D001-D512”, Press “ENTER” to
save the setting.
——>DMX Channel: CH. 5
——>DMX Channel: CH. 6
——>DMX Channel: CH. 7
——>SINGLE WHITE F010~F019 strobe, speed low to high
——>DMX Channel: CH. 2
——>DMX Channel: CH. 4
PAR64 COB 200W 3200K IP X4

LED ZOOM
7
TEMPERATURE CONTROL
RESET TO DEFAULT
Default as following:
MASTER-SLAVE MODE:
Controlled by DMX512 console. The machine accepts DMX512 signals and DMX dimming signals.
4. DMX Table
4.1.
DMX Mode 1 (1 Channel)
DMX Channel DMX Value Function
1. White Dimming 1~255 Adjust LEDs dimmer low to high
F 0 2 0
F 0 3 0
F 1 2 0
2 8 _ C
R E S T
——>SOUND ACTIVE MODE: Color jump and Strobe. Adjust the strobe speed from
F030(slow)～F039(fast). Shut down the light in 5 seconds mute.
——>FADE IN/OUT: Adjust the speed from F020(slow)～F029(fast).
——>Show the temperature of LED PCB.
——>FULL BRIGHTNESS
——> RESET TO DEFAULT: Press “ENTER” to reset all setting.
PAR64 COB 200W 3200K IP X4

LED ZOOM
8
4.2.
DMX Mode 2 (2 Channel)
4.3.
DMX Mode 3 (3 Channel)
DMX Channel DMX Value Function
1. White Dimming 1~255 Adjust LEDs dimmer low to high
2. STROBE 1~255 1-255 =STROBE low to high
3. Linear and curve lighting
option
0~9 Linear
10~255
6 selectable dimming curves
10~49 1s; 50~99 2s; 100~149 3s;
150~199 4s; 200~249 5s;
250~255 6s
4.4.
DMX Mode 4 (4 Channel)
DMX Channel DMX Value Function
1. W1 Dimming 1~255 Adjust LEDs dimmer low to high
2. W2 Dimming 1~255 Adjust LEDs dimmer low to high
3. W3 Dimming 1~255 Adjust LEDs dimmer low to high
4. W4 Dimming 1~255 Adjust LEDs dimmer low to high
DMX Channel DMX Value Function
1. White Dimming 1~255 Adjust LEDs dimmer low to high
2. STROBE 1~255 1-255 =STROBE low to high
PAR64 COB 200W 3200K IP X4

LED ZOOM
9
4.5.
DMX Mode 5 (5 Channel)
DMX Channel DMX Value Function
1. White Dimming 1~255
Turn on the light and White Dimming
and color is controlled by CH2, 3, 4, 5
2. W1 Dimming 1~255 Adjust LEDs dimmer low to high
3. W2 Dimming 1~255 Adjust LEDs dimmer low to high
4. W3 Dimming 1~255 Adjust LEDs dimmer low to high
5. W4 Dimming 1~255 Adjust LEDs dimmer low to high
4.7.
DMX Mode 6 (6 Channel)
DMX Channel DMX Value Function
1. White Dimming 1~255
Turn on the light and White Dimming
and color is controlled by CH2, 3, 4, 5
2. W1 Dimming 1~255 Adjust LEDs dimmer low to high
3. W2 Dimming 1~255 Adjust LEDs dimmer low to high
4. W3 Dimming 1~255 Adjust LEDs dimmer low to high
5. STROBE 1~255 1-255 =STROBE low to high
6. Linear and curve lighting
option
0~9 Linear
10~255
6 selectable dimming curves
10~49 1s; 50~99 2s; 100~149 3s;
150~199 4s; 200~249 5s;
250~255 6s
PAR64 COB 200W 3200K IP X4

LED ZOOM
10
4.7.
DMX Mode 7 (7 Channel)
DMX Channel DMX Value Function
1. White Dimming 1~255
Turn on the light and White Dimming
and color is controlled by CH2, 3, 4, 5
2. W1 Dimming 1~255 Adjust LEDs dimmer low to high
3. W2 Dimming 1~255 Adjust LEDs dimmer low to high
4. W3 Dimming 1~255 Adjust LEDs dimmer low to high
5. W4 Dimming 1~255 Adjust LEDs dimmer low to high
6. STROBE 1~255 Adjust strobe low to high (the color is
controlled by CH2-CH5).
7. Linear and curve lighting
option
0~9 Linear
10~255
6 selectable dimming curves
10~49 1s; 50~99 2s; 100~149 3s;
150~199 4s; 200~249 5s;
250~255 6s
