Toro TITAN Zero-Turn-Radius Manual

FormNo.3360-964RevA
TITANZero-Turn-RadiusRidingMowers
ModelNo.AllModels
SetupInstructions
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Nopartsrequired–Connectthebattery.
2Nopartsrequired–Setupthemotioncontrolleversandthe
Seat.
IgnitionKey1
Hosecoupling1
Operator’sManual1
EngineOperator’sManual1
3
OperatorTrainingMaterial1
CompletetheSetup.
Note:Determinetheleftandrightsidesofthemachinefromthenormaloperatingposition.
1
ConnectingtheBattery
NoPartsRequired
Procedure
1.Locatethebatteryandnegativebatterycableinthe
centerofthemachine.
2.Removetheblackplasticcapfromthenegative
batterypost.Removethefastenersfromthenegative
batterycableandusethemtosecurethenegative
batterycabletothenegativebatterypost(Figure1).
G010257
1
2
3
5
4
Figure1
1.Bolt4.Negativebatterypost
2.Washer5.Nut
3.Negativebatterycable
©2009—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.OriginalInstructions(EN)
PrintedintheUSA.
AllRightsReserved

2
SettingUptheMotionControlLeversandtheSeat
NoPartsRequired
Procedure
1.Removetheupperbolt(3/8x1inch)andwasher;loosenthelowerbolt(3/8x1inch)asshowninFigure2.
2.Aligntheholesinthemotioncontrolleverwiththeholesinthecontrolarmshaftandinstalltheboltandwasher
removedpreviously(Figure2).Handtightenallfasteners.Repeatthisforbothcontrolslevers.Movethe
motioncontrolleversintotheneutrallockposition.
G010256
Figure2
3.Setuptheseatasfollows(Figure3):
G010258
A B C
DC C
Figure3
A.Removethehairpincottersontheseatrodsecuringtheseattothemachine.
2

B.Slidetheseatrodoutfromthebracketsandseatframe.
C.Rotatetheseat180degreesandinstallitintothebracketyouremoveditfrom,usingtherodandhairpin
cottersremovedpreviously.
D.Connecttheinterlockswitchcabletotheseat.
E.Lowertheseatintotheoperatingposition(Figure4).
F.Movethecontrolleversbacktothecenterposition(neutral)asshowninFigure4.
G009802
E F
Figure4
4.Verifythemotioncontrolleversareproperlyaligned(Figure5).Adjustasnecessary.Tightenallfasteners.
G009803
Figure5
3

3
CompletingtheSetup
Partsneededforthisprocedure:
1IgnitionKey
1Hosecoupling
1Operator’sManual
1EngineOperator’sManual
1OperatorTrainingMaterial
Procedure
CheckingtheTirePressure
Checkthefrontandreartiresforproperination.Refer
toCheckingtheTirePressureintheOperator’sManualfor
therecommendedinationpressure.
CheckingtheSideDischargeChute
Removethepackingrestraintholdingthesidedischarge
chuteupandlowerthechuteintoplace.
CheckingtheEngineOilLevel
Beforeyoustarttheengineandusethemachine,check
theoillevelintheenginecrankcase;refertoChecking
theOilLevelintheOperator’sManual.
CheckingtheHydraulicOilLevel
Beforeyoustarttheengineandusethemachine,check
thehydraulicoillevelinthereservoirbehindtheseat;
refertoCheckingtheOilLevelintheOperator’sManual.
CheckingtheMowerAdjustment
Themowerdeckwasleveledatthefactory.Ifthemower
isnotcuttinglevel,adjusttheside-to-sidelevelandthe
front-to-rearbladeslope.SeetheOperator’sManual
fortheproperprocedure.
ReviewtheRemainingParts
Keepallthefollowingitemswiththemachine:
•IgnitionKey
•Hosecoupling
•Operator’sManual
•EngineOperator’sManual
•ViewtheOperatortrainingmaterial.
