Toro 139-2638 User manual

Form No. 3453-614 Rev C
Roll-Over Protection System Kit
TimeCutter®HD or Titan®Zero-Turn-Radius Riding Mower
Model No. 139-2638
Installation Instructions
Store this document with the Operator’s Manual for the traction unit.
Safety
Rollover Protection System
(ROPS) Safety
•The ROPS is an integral safety device. Do not
remove any of the ROPS components from the
machine.
•Ensure that the seat belt is attached and that you
can release it quickly in an emergency.
•Keep the roll bar in the fully raised and locked
position and always wear your seat belt whenever
the roll bar is up.
•Check carefully for overhead objects before you
drive under them, and do not contact them.
•Replace damaged ROPS components. Do not
repair or alter them.
•There is no rollover protection when the roll bar
is down.
•Wheels dropping over edges, over steep banks, or
into water can cause a rollover, which may result
in serious injury or death.
•Do not wear the seat belt when the roll bar is down.
•Lower the roll bar only when absolutely necessary;
raise it as soon as clearance permits.
•In the event of a rollover, take the machine to an
Authorized Service Dealer to inspect the ROPS.
•Use only Toro approved accessories and
attachments for the ROPS.
Safety and Instructional
Decals
Safety decals and instructions are
easily visible to the operator and are
located near any area of potential
danger. Replace any decal that is
damaged or missing.
decal107-3069
107-3069
1. Warning–there is no rollover protection when the roll bar is
down.
2. To avoid injury or death from a rollover accident, keep the
roll bar in the raised and locked position and wear the seat
belt. Lower the roll bar only when absolutely necessary; do
not wear the seat belt when the roll bar is down.
3. Read the Operator's Manual; drive slowly and carefully.
© 2022—The Toro® Company
8111 Lyndale Avenue South
Bloomington, MN 55420
Register at www.Toro.com. Original Instructions (EN)
Printed in the USA
All Rights Reserved *3453-614*

Installation
Loose Parts
Use the chart below to verify that all parts have been shipped.
Procedure Description Qty. Use
1No parts required –Prepare the machine.
Weight 5
Plate 1
Carriage bolt (3/8 x 2 inches) 2
2
Nut (3/8 inch) 2
Install the weights (machines with both
48in deck and bagger installed only).
Left lower roll bar 1
Right lower roll bar 1
Bolt (1/2 x 4 inches) 4
Washer 6
Locknut (1/2 inch) 6
Left support bracket 1
Right support bracket 1
Bolt (1/2 x 1-1/4 inches) 2
3
Bolt (1/2 x 1-3/4 inches) 2
Install the lower tubes and seat belt.
Left seat-belt bracket—Machines
without MyRide only 1
Right seat-belt bracket—Machines
without MyRide only 1
Seat-belt assembly 1
Seat-belt buckle 1
Bolt (1/2 x 1-1/4 inches) 4
Locknut (1/2 inch) 4
Self-tapping screw (1/4 x 5/8 inch) 2
4
Bolt (7/16 x 1-1/4 inches)—Machines
with MyRide only 2
Install the seat belt.
Roll bar 1
Side plate 4
Bolt (1/2 x 3 inches) 8
Flat spacer 4
Washer 6
Locknut (1/2 inch) 8
Bumper 3
Cylindrical spacer 4
5
Lanyard with pivot pin, washer, and
hairpin cotter 1
Install the roll bar.
Determine the left and right sides of the machine from the normal operating position.
2

1
Preparing the Machine
No Parts Required
Procedure
1. Park the machine on a level surface.
2. Disengage the PTO, engage the parking brake,
and move the motion-control levers outward to
the NEUTRAL-LOCK position.
3. Shut off the engine and remove the key.
2
Installing the Weights
Machines with Both 48in Deck and
Bagger Installed
Parts needed for this procedure:
5Weight
1 Plate
2Carriage bolt (3/8 x 2 inches)
2Nut (3/8 inch)
Procedure
1. Remove the retaining rod and suitcase weight
(Figure 1).
g305332
Figure 1
1. Retaining rod 2. Suitcase weight
3

2. Install the 5 weights under the weight tray
(Figure 2).
g305331
Figure 2
1. Nut (2) 3. Weight (5)
2. Weight tray 4. Carriage bolt (2)
3. Install the plate at the front of the weight tray
(Figure 3).
g305330
Figure 3
1. Plate
4. Install the suitcase weight behind the plate and
install the retaining rod (Figure 1).
3
Installing the Lower Tubes
and Seat Belt
Parts needed for this procedure:
1Left lower roll bar
1 Right lower roll bar
4Bolt (1/2 x 4 inches)
6 Washer
6Locknut (1/2 inch)
1Left support bracket
1 Right support bracket
2Bolt (1/2 x 1-1/4 inches)
2Bolt (1/2 x 1-3/4 inches)
Procedure
Note: The engine and left and right pods are not
shown in the gures.
1. Raise and support the machine so that the rear
wheels are off the ground.
2. Remove the rear wheels.
3. Loosely install the left and right lower roll bar
tubes using 2 bolts (1/2 x 4 inches), 2 washers,
and 2 locknuts (1/2 inch) for each tube (Figure
4).
Note: Ensure that the battery cables route
between the right pod and the right roll bar.
4

g222619
Figure 4
1. Bolt—1/2 x 4 inches (2) 4. Locknut (1/2 inch)
2. Washer (2) 5. Right lower roll bar
(installed)
3. Left lower roll bar tubes
4. Loosely install the left and right support brackets
using 1 bolt (1/2 x 1-1/4 inches), 1 locknut (1/2
inch), 1 bolt (1/2 x 1-3/4 inches), and 1 washer
for each bracket (Figure 5).
Note: Ensure that the battery ground cable
routes under the right support bracket and other
cables route above the right support bracket
(Figure 6).
g222622
Figure 5
1. Right support bracket
(installed)
4. Left support bracket
2. Bolt (1/2 x 1-3/4 inches) 5. Locknut (1/2 inch)
3. Washer (2) 6. Bolt (1/2 x 1-1/4 inches)
5

g239269
Figure 6
1. Right pod 3. Battery ground cable
2. Right support bracket 4. Cable
4
Installing the Seat Belt
Parts needed for this procedure:
1Left seat-belt bracket—Machines without MyRide only
1Right seat-belt bracket—Machines without MyRide
only
1Seat-belt assembly
1Seat-belt buckle
4Bolt (1/2 x 1-1/4 inches)
4Locknut (1/2 inch)
2Self-tapping screw (1/4 x 5/8 inch)
2Bolt (7/16 x 1-1/4 inches)—Machines with MyRide
only
Machines without MyRide
1. Install the left and right seat-belt brackets using
1 bolt (1/2 x 1-1/4 inches), 1 locknut (1/2 inch),
and 1 self-tapping screw (1/4 x 5/8 inch) for
each bracket (Figure 7). Torque the bolts to 102
N∙m (75 ft-lb).
g222620
Figure 7
1. Locknut (1/2 inch) 3. Self-tapping screw (1/4 x
5/8 inch)
2. Right seat-belt bracket 4. Bolt (1/2 x 1-1/4 inches)
2. Install the seat-belt assembly and buckle to the
brackets using 2 bolts (1/2 x 1-1/4 inches) and 2
locknuts (1/2 inch) as shown in Figure 8. Torque
the bolts to 102 N∙m (75 ft-lb).
g222621
Figure 8
1. Locknut (1/2 inch) 4. Bolt (1/2 x 1-1/4 inches)
2. Seat-belt buckle 5. Left seat-belt bracket
3. Right seat-belt bracket 6. Seat-belt assembly
6

Machines with MyRide
Install the seat-belt assembly and buckle to the seat
as shown in Figure 9.
•For seats with a welded nut, use 2 bolts (7/16 x
1-1/4 inches). Torque the bolts to 68 N∙m (50 ft-lb).
•For seats without a welded nut, use 2 bolts (1/2 x
1-1/4 inches) and 2 locknuts (1/2 inch). Torque the
bolts to 102 N∙m (75 ft-lb).
g388437
Figure 9
1. Seat-belt assembly 3. Locknut (seats without
welded nut only)
2. Bolt 4. Seat-belt buckle
5
Installing the Roll Bar
Parts needed for this procedure:
1 Roll bar
4Side plate
8Bolt (1/2 x 3 inches)
4 Flat spacer
6 Washer
8Locknut (1/2 inch)
3 Bumper
4Cylindrical spacer
1 Lanyard with pivot pin, washer, and hairpin cotter
Procedure
Note: Leave the bolts loose enough so that the parts
are free to shift around.
1. Install 2 side plates to both sides of the roll bar
using 3 bolts (1/2 x 3 inches), 2 at spacers, 3
washers, 1 cylindrical spacer, and 3 locknuts
(1/2 inch) on each side (Figure 10).
g222814
Figure 10
1. Bolt—1/2 x 3 inches (3) 5. Roll bar
2. Washer (3) 6. Bumper
3. Side plate (2) 7. Locknut—1/2 inch (3)
4. Flat spacer (2) 8. Cylindrical spacer
2. Install a bumper in the center of the roll bar
(Figure 10).
3. Install a bumper and cylindrical spacer to both
lower roll bar tubes (Figure 11).
g222812
Figure 11
1. Cylindrical spacer 2. Bumper
4. With the assistance of a second person, attach
the roll bar assembly and the lanyard washer
to the lower roll bar tubes using a bolt (1/2 x
3 inches) and locknut (1/2 inch) on each tube
(Figure 12).
7

g222813
Figure 12
1. Bolt (1/2 x 3 inches) 3. Locknut (1/2 inch)
2. Pivot pin
5. Raise the roll bar into the upright position and
lock it into place using the pivot pin and hairpin
cotter on both sides of the roll bar (Figure 13).
g222859
Figure 13
6. Torque all 1/2-inch bolts to 102 N∙m (75 ft-lb).
7. Install the rear tires. Torque the lug nuts to 95 to
122 N∙m (70 to 90 ft-lb).
8. Lower the machine to the ground.
8

Operation
Using the
Rollover-Protection System
WARNING
To avoid injury or death from rollover: keep
the roll bar in the fully raised, locked position
and use the seat belt.
Ensure that the seat is secured to the
machine.
WARNING
There is no rollover protection when the roll
bar is in the down position.
• Lower the roll bar only when absolutely
necessary.
• Do not wear the seat belt when the roll bar
is in the down position.
• Drive slowly and carefully.
• Raise the roll bar as soon as clearance
permits.
• Check carefully for overhead clearances
(i.e., branches, doorways, electrical wires)
before driving under any objects, and do
not contact them.
Important: Ensure that the seat is secured to
the machine.
Raising the Roll Bar
g222859
Figure 14
Lowering the Roll Bar
g222897
Figure 15
9

Maintenance
Checking the Seat Belt
Service Interval: Before each use or daily
Inspect the seat belt for wear, cuts, and proper
operation of the retractor and buckle. Replace the
seat belt if it is damaged.
Checking the Rollover
Protection System (ROPS)
Service Interval: Before each use or daily
Visually inspect the ROPS for loose hardware or any
other possible problem. Tighten the hardware or
correct the problem before operating.
10
