Taga PF-USB Series User manual
PF-USB Series [230-240V]
POWER NOISE FILTERS
FOR USE WITH AUDIO-VIDEO EQUIPMENT
WITH USB CHARGING FUNCTION
Instruction Manual
Edition 02-2022
2
Introduction
Thank you for purchasing this TAGA Harmony power lter.
PF-USB series power lters combine functions of power noise ltering and charging via USB.
The electricity network in our homes or workplaces is exposed to different interferences for
instance electromagnetic interference (EMI) generated by appliances connected to the same
network (refrigerators, air conditioners, computers etc.).
These interferences are not only produced inside your house or ofce but by all appliances in
your building or even outside it and can differ on the time of day or week when the trafc on the
electrical network changes.
All these interferences which we call noises can get into your AC power and interfere with your
system.
This “dirty” electricity can have a negative effect on performance of your audio-video system.
TAGA Harmony power noise lter is a great way to limit the negative noises from your electricity
and to isolate your system from the contaminated power.
Thanks to the PF-USB power lters you will be able to enjoy a better quality of your audio and
video equipment.
The contaminated electricity has also a negative impact on internal circuits and power supplies
of your equipment and because the PF-USB lter works as a buffer between the wall socket and
your gear it will help to increase the longevity of connected components.
The built-in charging function via USB may be used for charging variety of devices such as
smartphones etc.
The removable Schuko-IEC C13 power cable gives an option to upgrade the system with a
premium audiophile power cable in any time.
Cleaning
Do not use strong or abrasive cleaners. Use a damp, soft cloth for cleaning.
Specications and the latest instruction manual edition
Full technical specications and the latest edition of the instruction manual
are available on www.TagaHarmony.com.
Contents
Safety Instructions 3
Controls and Displays 5
Hooking Up the Filter 6
Operation 7
Kit Content 12
3
Safety Instructions
EN_safety_10-21
IMPORTANT
READ THIS SECTION CAREFULLY BEFORE PROCEEDING!
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT EXPOSE THIS PRODUCT TO
RAIN OR MOISTURE. DO NOT REMOVE COVER (OR BACK). NO USER-SERVICEABLE PARTS INSIDE.
REFER SERVICING TO QUALIFIED SERVICE PERSONNEL.
WARNING: TO REDUCE THE RISK OF FIRE OR ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPARATUS TO RAIN OR MOISTURE, AND OBJECTS FILLED WITH
LIQUIDS, SUCH AS VASES, SHOULD NOT BE PLACED ON THIS APPARATUS.
CAUTION: TO PREVENT ELECTRIC SHOCK, FULLY AND SECURELY INSERT
THE POWER CABLE PLUG INTO THE POWER OUTLET, AND POWER CABLE
CONNECTOR INTO THE UNIT SOCKET (IF THIS UNIT IS NOT EQUIPPED WITH AN
INTEGRATED [ATTACHED] POWER CORD).
CAUTION: FOR CONTINUED PROTECTION AGAINST RISK OF FIRE, REPLACE
THE FUSE (IF THE UNIT IS EQUIPPED WITH A USER REPLACEABLE FUSE) ONLY
WITH THE SAME AMPERAGE AND VOLTAGE TYPE. IN CASE WHEN THE UNIT IS
NOT EQUIPPED WITH A USER REPLACEABLE FUSE - REFER REPLACEMENT TO
QUALIFIED SERVICE PERSONNEL.
WARNING: THE UNIT MAY BECOME HOT. ALWAYS PROVIDE ADEQUATE
VENTILATION TO ALLOW FOR COOLING. DO NOT PLACE THE UNIT NEAR
A HEAT SOURCE, OR IN SPACES THAT CAN RESTRICT VENTILATION.
An exclamation mark in a triangle is intended to alert the user to the presence
of important operating and maintenance (servicing) instructions in the literature
accompanying the appliance.
The triangle containing a lightning symbol is intended to alert the user to the presence
of uninsulated dangerous voltages within the product’s enclosure that may be of
sufcient magnitude to constitute a risk of electric shock to persons.
4
Safety Instructions
1. Read Instructions - All the safety and operating instructions
should be read before the product is operated.
2. Retain Instructions - The safety and operating instructions should
be retained for future reference.
3. Heed Warnings - All warnings on the product and in the operating
instructions should be adhered to.
4. Follow Instructions - All operating and use instructions should
be followed.
5. Cleaning - Unplug this product from the power outlet before
cleaning. Do not use liquid cleaners or aerosol cleaners.
6. Water and Moisture - Do not use this product near water - for
example, near a bath tub, wash bowl, kitchen sink or laundry tub;
in a wet basement; or near a swimming pool; and the like. These
precautions also apply to the power cord.
7. Accessories - Do not place this product on an unstable cart,
stand, tripod, bracket or table. The product may fall, causing seri-
ous injury to a child or adult and serious damage to the product.
Use only with a cart, stand, tripod, bracket or table recommended
by the manufacturer or sold with the product. Any mounting of
the product should follow manufacturer’s instructions and should
use a mounting accessory recommended by the manufacturer.
8. Ventilation - This unit may be equipped with slots and openings
in the cabinet (housing) which are provided for ventilation and
to ensure reliable operation of the product and to protect it from
overheating and these openings must not be blocked or covered.
The openings should never be blocked by placing the product
on a bed, sofa, rug or other similar surface. This product should
be not placed in a built-in installation such as a bookcase or
rack unless proper ventilation is provided or the manufacturer’s
instructions have been adhered to. For products equipped with a
separate power supply unit, leave at least 5cm (2in.) of free space
on all sides and the top of the power supply.
9. Power Sources - This product should be operated only from the
type of power source indicated on the marking label (placed on
the product and/or, if applicable, on a separate power supply
unit). If you are not sure of the type of power supply in your home,
consult your product dealer or local power company. For products
intended to operate from battery power or other sources, refer to
the operating instructions.
10. Grounding and Polarity - some units for proper operation or
to take full advantage of their capabilities may require to be
connected to a grounded power outlet – refer to the user manual
for more information.
Some units may have markings for the live (L) and neutral (N)
conductors for power - in order to take full advantage of capa-
bilities of such products, it is recommended to properly connect
the polarity according to the markings on the unit - refer to the
user manual for more information. Connecting the polarity not in
accordance with the markings will not aect the durability and
reliability of the device.
11. Power-cord Protection - Power supply cords should be routed
so that they are not likely to be walked on or pinched by items
placed upon or against them, paying particular attention to cords
at plugs, convenience receptacles and the point where they exit
from the product.
12. Lighting - For added protection for this product during a lighting
storm or when it is left unattended and unused for long periods
of time, unplug it from the wall outlet and disconnect the antenna
or system cables. This will prevent damage to the product due to
lighting and power-line surges.
13. Overloading - Do not overload wall outlets, extension cords or
integral convenience receptacles as this can result in a risk of fire
or electric shock.
14. Object and Liquid Entry - Never push objects of any kind into this
product through openings as they may touch dangerous voltage
points or short-out parts that could result in a fire or electric
shock. Do not expose this apparatus to dripping or splashing and
ensure that no objects filled with water, such as vases are placed
on the apparatus.
15. Servicing - Do not attempt to service this product yourself as
opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified service
personnel.
16. Damage Requiring Service - Unplug this product from wall outlet
and refer servicing to qualified personnel under the following
conditions:
• when power supply cord or plug is damaged;
• if liquid has been spilled or objects have fallen into the product;
• if the product does not operate normally by following the oper-
ating instructions. Adjust only those controls that are covered by
the operating instructions as an improper adjustment of other
controls may result in damage and will require extensive work
by a qualified technician to restore the product to its normal
operation;
• if the product has been dropped or damaged in any way;
• if the product exhibits a distinct change in performance - this
indicates a need for a service.
1 7. Replacement Parts - when replacement parts are required, be
sure the technician has used replacement parts specified by the
manufacturer or with the same characteristics as the original
part. Unauthorized substitutions may result in fire, electric shock
or other hazards.
18. Safety Check - Upon completion of any service or repairs to this
product, ask the service technician to perform safety check to
determine that the products is in proper operating condition.
19. Wall of ceiling mounting - The product should be mounted to a
wall or ceiling only as recommended by the manufacturer.
20. Heat - The product should be situated away from heat sources
such as radiators, heat registers, stoves or other products (includ-
ing amplifiers) that produce heat.
21. [Refer to products equipped with vacuum tubes] Tube Cage or
cover - For your safety and to protect the vacuum tubes this
product may be equipped with the factory installed vacuum tube
cage or cover.
It is not recommended to remove the cage or cover unless it is
required to change the vacuum tubes.
When the cage or cover is removed - do not touch the vacuum
tubes - they may be hot and burn the skin!
22. Operating Environment - Operating environment temperature and
humidity of the unit: +5°C to +35°C (+41°F to +95°F); less than
85% RH (cooling slots not blocked).
EN_safety_10-21
5
Controls and Displays
4
1. Power Switch [ON (I) and OFF (0)]
2. Reset Button
3. Power Cable Input
4. USB-A Charging Ports
5. Power Sockets – FILTERED Output
32
1
/PF-400USB model shown/
5
6
Hooking Up the Filter
We recommend to use Schuko plugs in all power cables.
Total maximum power load (wattage rating): the total maximum power
consumption for all connected devices to the lter should not exceed
the maximum power load for this lter.
The total maximum power load for this ltrer is given in Kilowatts (kW)
or Watts (W) and is printed on the lter.
It is also available in the specications on www.TagaHarmony.com.
1. Make sure the lter is turned off (the Power Switch is in the down OFF position
and the Power Cable is removed from the wall outlet).
2. Using power cables (only a power cable for the lter is supplied with this product)
connect your audio-video equipment to the Power Sockets – FILTERED Output.
POWER SOCKETS - all power output sockets in this lter are ltered.
Electrical noises are ltered and limited.
Note! Check „Operation” for other useful operating instructions.
3. Your lter is ready for operation.
Power cable Power cable
7
Operation
This unit requires a single-phase 3-conductor electrical outlet.
Information about polarity
If it is required in your system, use the below drawings showing the polarity in the
power sockets of this lter.
L – LIVE | N – NEUTRAL
Power Socket Input
1. Plug the Power Cable to the lter and into the electrical outlet.
2. Turn on the lter (the Power Switch should be in the upper ON position).
Charging via USB
3. If you want to charge compatible devices: using a USB cable (not supplied with this
product) insert one end into a free USB-A Charging Port and the other end to the
device you want to charge.
Note! Charging may lower the efciency of the power noise ltering - we recommend
not charging any devices during critical listening.
USB cable
USB cable
Power Sockets - FILTERED Output
(Power lter front panel facing left)
8
Operation
CHARGING - IMPORTANT SAFETY REMARKS!
In order not to void your warranty and to avoid damaging this lter
and / or connected audio-video equipment and devices, strictly follow
the below remarks:
• The USB-A Charging Ports are only intended for charging devices
which are compatible with the USB-A Charging Ports technical data
printed on the lter:
Output: DC – direct current and voltage provided in Volts.
Max total load: – maximum total load when all USB-A Charging Ports
are used simultaneously.
[Maximum load for a single USB-A Charging Port = the Max total
load divided by a number of devices being charged].
The total load generated by all devices connected to the charger must
not exceed the Maximum total load.
• The number of devices which may be charged simultaneously is limi-
ted to a number of USB-A Charging Ports this lter is equipped with.
Never connect more than 1 device to a single USB-A Charging Port.
• When charging use only a recommended USB cable for your device
and replace faulty cables immediately.
• When you want to turn off the power lter we recommend to turn off
your audio-video equipment rstly.
• This power lter is not a uninterruptible power supply unit (UPS).
It will not operate when the input power source fails (no power
or too low voltage).
4. Turn on your audio-video equipment and enjoy your system.
5.Reset – the Power Output Sockets will be powered off when the maximum power
load is exceeded (check on the rear panel or in specications).
Press the RESET button to restore the power supply.
9
Notes
10
Notes
11
Notes
www.TagaHarmony.com
We strongly advise to contact a professional installer or dealer in order to install
TAGA Harmony products.
We recommend using high quality TAGA Harmony cables and other installation
accessories.
TAGA EUROPE
POLPAK POLAND Sp. z o.o.
AL.JEROZOLIMSKIE 331A
05-816 REGUŁY k/WARSZAWY, POLAND
Email: Sales@TagaHarmony.com
Kit Content:
Power Filter 1 EA
Power Cable 1 EA
Instruction Manual 1 EA
IMPORTANT!
Your product is marked with the symbol as showed on the left.
For EU (European Union) member users:
According to the WEEE (Waste electrical and electronic equipment)
Directive, do not dispose of this product as household waste or commercial waste.
Waste electrical and electronic equipement should be appropriately collected and
recycled as required by practices established for your country.
For information on recycling of this product, please contact your local authorities, your
household waste disposal service or the shop where you purchased the product.
Your product is marked with the symbol as showed on the left.
For EU (European Union) member users:
This product has been tested and found in compliance with
requirements of the European Community
2014/30/EU (EMC) & 2014/35/EU (LVD) directives.
Disposal of old electrical & electronic equipment
(applicable in the European Union and other countries with separate
collection systems)
This symbol on the product or on its literature and packaging indicates that this
product shall not be treated as household waste. Instead it shall be handed over
to the appropriate collection point for the recycling of electrical and electronic
equipment. By ensuring that this product is disposed of correctly, you will help
to prevent potential negative consequences for the environment and human
health, which could be caused by inappropriate waste handling of this product.
The recycling of materials will help to conserve natural resources. For more
detailed information about recycling of this product, please contact your local
government ofce, your household waste disposal service or the shop where
you purchased the product.
Disposal of the product
Your product is marked with the symbol shown on the left.
As its manufacturer, hereby we declare that the product is in compliance with the
following EU directives and regulations:
2014/30/EU (EMC) & 2014/35/EU (LVD) & 2011/65/EU (RoHS)
The full text of the EU declaration of conformity is available from the
manufacturer.
EU declaration of conformity
This manual suits for next models
1
Table of contents
Other Taga Protection Device manuals
