GE F60 User manual

832762A2.CDR
F60 Feeder Protection System
UR Series Instruction Manual
F60 Revision: 5.8x
Manual P/N: 1601-0093-V1 (GEK-113551)
Copyright © 2010 GE Multilin
GE Multilin
215 Anderson Avenue, Markham, Ontario
Canada L6E 1B3
Tel: [phone] Fax: [phone]
Internet: http://www.GEmultilin.com
g
GE Multilin
Title Page
IISO9001:2000
G
E
M
U
L
T
I
L
I
N
R
E
G
I
S
T
E
R
E
D
GE Multilin's Quality Management
System is registered to
ISO9001:2000
QMI # 005094
UL # A3775
*1601-0093-V1*
LISTED
52TL
IND.CONT. EQ.
E83849

g
GE Multilin
ADDENDUM
This addendum contains information that relates to the F60 Feeder Protection System, version 5.8x. This addendum
lists a number of information items that appear in the instruction manual GEK-113551 (revision V1) but are not included
in the current F60 operations.
The following functions and items are not yet available with the current version of the F60 relay:
• Signal sources SRC 3 to SRC 6.
Version 4.0x and higher releases of the F60 relay includes new hardware (CPU and CT/VT modules).
• The new CPU modules are specified with the following order codes: 9E, 9G, 9H, 9J, 9K, 9L, 9M, 9N, 9P, 9R, and 9S.
• The new CT/VT modules are specified with the following order codes: 8F, 8G, 8H, 8J 8L, 8M, 8N, 8R.
The following table maps the relationship between the old CPU and CT/VT modules to the newer versions:
The new CT/VT modules can only be used with the new CPUs (9E, 9G, 9H, 9J, 9K, 9L, 9M, 9N, 9P, 9R, and 9S), and
the old CT/VT modules can only be used with the old CPU modules (9A, 9C, 9D). To prevent any hardware mis-
matches, the new CPU and CT/VT modules have blue labels and a warning sticker stating “Attn.: Ensure CPU and
DSP module label colors are the same!”. In the event that there is a mismatch between the CPU and CT/VT module,
the relay will not function and a DSP ERROR or HARDWARE MISMATCH error will be displayed.
All other input/output modules are compatible with the new hardware.
With respect to the firmware, firmware versions 4.0x and higher are only compatible with the new CPU and CT/VT mod-
ules. Previous versions of the firmware (3.4x and earlier) are only compatible with the older CPU and CT/VT modules.
MODULE OLD NEW DESCRIPTION
CPU 9A 9E RS485 and RS485 (Modbus RTU, DNP)
9C 9G RS485 and 10Base-F (Ethernet, Modbus TCP/IP, DNP)
9D 9H RS485 and redundant 10Base-F (Ethernet, Modbus TCP/IP, DNP)
--- 9J RS485 and multi-mode ST 100Base-FX
--- 9K RS485 and multi-mode ST redundant 100Base-FX
--- 9L RS485 and single mode SC 100Base-FX
--- 9M RS485 and single mode SC redundant 100Base-FX
--- 9N RS485 and 10/100Base-T
--- 9P RS485 and single mode ST 100Base-FX
--- 9R RS485 and single mode ST redundant 100Base-FX
--- 9S RS485 and six-port managed Ethernet switch
CT/VT 8A 8F Standard 4CT/4VT
8B 8G Sensitive ground 4CT/4VT
8C 8H Standard 8CT
8D 8J Sensitive ground 8CT
-- 8L Standard 4CT/4VT with enhanced diagnostics
-- 8M Sensitive ground 4CT/4VT with enhanced diagnostics
-- 8N Standard 8CT with enhanced diagnostics
-- 8R Sensitive ground 8CT with enhanced diagnostics
Addendum

GE Multilin F60 Feeder Protection System v
TABLE OF CONTENTS
1. GETTING STARTED 1.1 IMPORTANT PROCEDURES
1.1.1 CAUTIONS AND WARNINGS ........................................................................... 1-1
1.1.2 INSPECTION CHECKLIST ................................................................................ 1-1
1.2 UR OVERVIEW
1.2.1 INTRODUCTION TO THE UR ........................................................................... 1-2
1.2.2 HARDWARE ARCHITECTURE ......................................................................... 1-3
1.2.3 SOFTWARE ARCHITECTURE.......................................................................... 1-4
1.2.4 IMPORTANT CONCEPTS ................................................................................. 1-4
1.3 ENERVISTA UR SETUP SOFTWARE
1.3.1 PC REQUIREMENTS ........................................................................................ 1-5
1.3.2 INSTALLATION.................................................................................................. 1-5
1.3.3 CONFIGURING THE F60 FOR SOFTWARE ACCESS .................................... 1-7
1.3.4 USING THE QUICK CONNECT FEATURE....................................................... 1-9
1.3.5 CONNECTING TO THE F60 RELAY............................................................... 1-15
1.4 UR HARDWARE
1.4.1 MOUNTING AND WIRING............................................................................... 1-16
1.4.2 COMMUNICATIONS........................................................................................ 1-16
1.4.3 FACEPLATE DISPLAY .................................................................................... 1-16
1.5 USING THE RELAY
1.5.1 FACEPLATE KEYPAD..................................................................................... 1-17
1.5.2 MENU NAVIGATION ....................................................................................... 1-17
1.5.3 MENU HIERARCHY ........................................................................................ 1-17
1.5.4 RELAY ACTIVATION....................................................................................... 1-17
1.5.5 RELAY PASSWORDS ..................................................................................... 1-18
1.5.6 FLEXLOGIC™ CUSTOMIZATION................................................................... 1-18
1.5.7 COMMISSIONING ........................................................................................... 1-19
2. PRODUCT DESCRIPTION 2.1 INTRODUCTION
2.1.1 OVERVIEW........................................................................................................ 2-1
2.1.2 ORDERING........................................................................................................ 2-2
2.1.3 REPLACEMENT MODULES ............................................................................. 2-6
2.2 SPECIFICATIONS
2.2.1 PROTECTION ELEMENTS ............................................................................... 2-9
2.2.2 USER-PROGRAMMABLE ELEMENTS........................................................... 2-12
2.2.3 MONITORING.................................................................................................. 2-13
2.2.4 METERING ...................................................................................................... 2-14
2.2.5 INPUTS ............................................................................................................ 2-14
2.2.6 POWER SUPPLY ............................................................................................ 2-15
2.2.7 OUTPUTS ........................................................................................................ 2-16
2.2.8 COMMUNICATIONS........................................................................................ 2-17
2.2.9 INTER-RELAY COMMUNICATIONS............................................................... 2-18
2.2.10 ENVIRONMENTAL .......................................................................................... 2-18
2.2.11 TYPE TESTS ................................................................................................... 2-19
2.2.12 PRODUCTION TESTS .................................................................................... 2-19
2.2.13 APPROVALS ................................................................................................... 2-20
2.2.14 MAINTENANCE ............................................................................................... 2-20
3. HARDWARE 3.1 DESCRIPTION
3.1.1 PANEL CUTOUT ............................................................................................... 3-1
3.1.2 MODULE WITHDRAWAL AND INSERTION ..................................................... 3-6
3.1.3 REAR TERMINAL LAYOUT............................................................................... 3-8
3.2 WIRING
3.2.1 TYPICAL WIRING............................................................................................ 3-10
3.2.2 DIELECTRIC STRENGTH ............................................................................... 3-12
3.2.3 CONTROL POWER ......................................................................................... 3-12
3.2.4 CT AND VT MODULES ................................................................................... 3-13
3.2.5 PROCESS BUS MODULES ............................................................................ 3-15
3.2.6 CONTACT INPUTS AND OUTPUTS............................................................... 3-16
Table of Contents

vi F60 Feeder Protection System GE Multilin
TABLE OF CONTENTS
3.2.7 TRANSDUCER INPUTS/OUTPUTS.................................................................3-23
3.2.8 RS232 FACEPLATE PORT..............................................................................3-24
3.2.9 CPU COMMUNICATION PORTS.....................................................................3-24
3.2.10 IRIG-B...............................................................................................................3-27
3.3 DIRECT INPUT/OUTPUT COMMUNICATIONS
3.3.1 DESCRIPTION .................................................................................................3-28
3.3.2 FIBER: LED AND ELED TRANSMITTERS ......................................................3-30
3.3.3 FIBER-LASER TRANSMITTERS .....................................................................3-30
3.3.4 G.703 INTERFACE...........................................................................................3-31
3.3.5 RS422 INTERFACE .........................................................................................3-34
3.3.6 RS422 AND FIBER INTERFACE .....................................................................3-36
3.3.7 G.703 AND FIBER INTERFACE ......................................................................3-36
3.3.8 IEEE C37.94 INTERFACE................................................................................3-37
3.3.9 C37.94SM INTERFACE ...................................................................................3-39
3.4 MANAGED ETHERNET SWITCH MODULES
3.4.1 OVERVIEW ......................................................................................................3-41
3.4.2 MANAGED ETHERNET SWITCH MODULE HARDWARE..............................3-41
3.4.3 MANAGED SWITCH LED INDICATORS .........................................................3-42
3.4.4 CONFIGURING THE MANAGED ETHERNET SWITCH MODULE .................3-42
3.4.5 UPLOADING F60 SWITCH MODULE FIRMWARE .........................................3-45
3.4.6 ETHERNET SWITCH SELF-TEST ERRORS...................................................3-47
4. HUMAN INTERFACES 4.1 ENERVISTA UR SETUP SOFTWARE INTERFACE
4.1.1 INTRODUCTION ................................................................................................4-1
4.1.2 CREATING A SITE LIST ....................................................................................4-1
4.1.3 ENERVISTA UR SETUP OVERVIEW................................................................4-1
4.1.4 ENERVISTA UR SETUP MAIN WINDOW..........................................................4-3
4.1.5 SETTINGS TEMPLATES ...................................................................................4-3
4.1.6 SECURING AND LOCKING FLEXLOGIC™ EQUATIONS ................................4-8
4.1.7 SETTINGS FILE TRACEABILITY.....................................................................4-10
4.2 FACEPLATE INTERFACE
4.2.1 FACEPLATE.....................................................................................................4-13
4.2.2 LED INDICATORS............................................................................................4-14
4.2.3 CUSTOM LABELING OF LEDS .......................................................................4-17
4.2.4 DISPLAY...........................................................................................................4-23
4.2.5 BREAKER CONTROL ......................................................................................4-23
4.2.6 KEYPAD ...........................................................................................................4-24
4.2.7 MENUS.............................................................................................................4-24
4.2.8 CHANGING SETTINGS ...................................................................................4-26
5. Z SETTINGS 5.1 OVERVIEW
5.1.1 SETTINGS MAIN MENU ....................................................................................5-1
5.1.2 INTRODUCTION TO ELEMENTS......................................................................5-4
5.1.3 INTRODUCTION TO AC SOURCES..................................................................5-5
5.2 PRODUCT SETUP
5.2.1 SECURITY..........................................................................................................5-8
5.2.2 DISPLAY PROPERTIES ..................................................................................5-12
5.2.3 CLEAR RELAY RECORDS ..............................................................................5-14
5.2.4 COMMUNICATIONS ........................................................................................5-15
5.2.5 MODBUS USER MAP ......................................................................................5-37
5.2.6 REAL TIME CLOCK .........................................................................................5-38
5.2.7 FAULT REPORTS ............................................................................................5-39
5.2.8 OSCILLOGRAPHY ...........................................................................................5-41
5.2.9 DATA LOGGER................................................................................................5-43
5.2.10 DEMAND ..........................................................................................................5-45
5.2.11 USER-PROGRAMMABLE LEDS .....................................................................5-46
5.2.12 USER-PROGRAMMABLE SELF-TESTS .........................................................5-49
5.2.13 CONTROL PUSHBUTTONS ............................................................................5-50
5.2.14 USER-PROGRAMMABLE PUSHBUTTONS....................................................5-52
5.2.15 FLEX STATE PARAMETERS ..........................................................................5-57

GE Multilin F60 Feeder Protection System vii
TABLE OF CONTENTS
5.2.16 USER-DEFINABLE DISPLAYS ....................................................................... 5-58
5.2.17 DIRECT INPUTS/OUTPUTS ........................................................................... 5-60
5.2.18 TELEPROTECTION......................................................................................... 5-68
5.2.19 INSTALLATION................................................................................................ 5-68
5.3 REMOTE RESOURCES
5.3.1 REMOTE RESOURCES CONFIGURATION ................................................... 5-70
5.4 SYSTEM SETUP
5.4.1 AC INPUTS ...................................................................................................... 5-71
5.4.2 POWER SYSTEM............................................................................................ 5-72
5.4.3 SIGNAL SOURCES ......................................................................................... 5-73
5.4.4 BREAKERS...................................................................................................... 5-76
5.4.5 DISCONNECT SWITCHES ............................................................................. 5-80
5.4.6 FLEXCURVES™.............................................................................................. 5-83
5.5 FLEXLOGIC™
5.5.1 INTRODUCTION TO FLEXLOGIC™............................................................... 5-90
5.5.2 FLEXLOGIC™ RULES .................................................................................. 5-100
5.5.3 FLEXLOGIC™ EVALUATION........................................................................ 5-100
5.5.4 FLEXLOGIC™ EXAMPLE ............................................................................. 5-101
5.5.5 FLEXLOGIC™ EQUATION EDITOR ............................................................. 5-105
5.5.6 FLEXLOGIC™ TIMERS................................................................................. 5-105
5.5.7 FLEXELEMENTS™ ....................................................................................... 5-107
5.5.8 NON-VOLATILE LATCHES ........................................................................... 5-111
5.6 GROUPED ELEMENTS
5.6.1 OVERVIEW.................................................................................................... 5-112
5.6.2 SETTING GROUP ......................................................................................... 5-112
5.6.3 LOAD ENCROACHMENT.............................................................................. 5-113
5.6.4 PHASE CURRENT ........................................................................................ 5-115
5.6.5 NEUTRAL CURRENT.................................................................................... 5-126
5.6.6 WATTMETRIC GROUND FAULT .................................................................. 5-134
5.6.7 GROUND CURRENT..................................................................................... 5-137
5.6.8 NEGATIVE-SEQUENCE CURRENT ............................................................. 5-139
5.6.9 BREAKER FAILURE...................................................................................... 5-146
5.6.10 VOLTAGE ELEMENTS.................................................................................. 5-155
5.6.11 SENSITIVE DIRECTIONAL POWER............................................................. 5-163
5.7 CONTROL ELEMENTS
5.7.1 OVERVIEW.................................................................................................... 5-166
5.7.2 TRIP BUS....................................................................................................... 5-166
5.7.3 SETTING GROUPS ....................................................................................... 5-168
5.7.4 SELECTOR SWITCH..................................................................................... 5-169
5.7.5 UNDERFREQUENCY.................................................................................... 5-175
5.7.6 OVERFREQUENCY ...................................................................................... 5-176
5.7.7 FREQUENCY RATE OF CHANGE................................................................ 5-177
5.7.8 SYNCHROCHECK......................................................................................... 5-179
5.7.9 AUTORECLOSE ............................................................................................ 5-183
5.7.10 DIGITAL ELEMENTS..................................................................................... 5-189
5.7.11 DIGITAL COUNTERS .................................................................................... 5-192
5.7.12 MONITORING ELEMENTS ........................................................................... 5-194
5.7.13 COLD LOAD PICKUP .................................................................................... 5-211
5.8 INPUTS/OUTPUTS
5.8.1 CONTACT INPUTS........................................................................................ 5-213
5.8.2 VIRTUAL INPUTS.......................................................................................... 5-215
5.8.3 CONTACT OUTPUTS.................................................................................... 5-216
5.8.4 VIRTUAL OUTPUTS...................................................................................... 5-218
5.8.5 REMOTE DEVICES ....................................................................................... 5-219
5.8.6 REMOTE INPUTS.......................................................................................... 5-220
5.8.7 REMOTE DOUBLE-POINT STATUS INPUTS .............................................. 5-221
5.8.8 REMOTE OUTPUTS...................................................................................... 5-221
5.8.9 RESETTING................................................................................................... 5-222
5.8.10 DIRECT INPUTS AND OUTPUTS ................................................................. 5-223
5.8.11 TELEPROTECTION INPUTS AND OUTPUTS.............................................. 5-226
5.8.12 IEC 61850 GOOSE ANALOGS...................................................................... 5-228
5.8.13 IEC 61850 GOOSE INTEGERS..................................................................... 5-229
5.9 TRANSDUCER INPUTS AND OUTPUTS
5.9.1 DCMA INPUTS .............................................................................................. 5-230

viii F60 Feeder Protection System GE Multilin
TABLE OF CONTENTS
5.9.2 RTD INPUTS ..................................................................................................5-231
5.9.3 DCMA OUTPUTS ...........................................................................................5-233
5.10 TESTING
5.10.1 TEST MODE ...................................................................................................5-236
5.10.2 FORCE CONTACT INPUTS...........................................................................5-237
5.10.3 FORCE CONTACT OUTPUTS.......................................................................5-238
6. ACTUAL VALUES 6.1 OVERVIEW
6.1.1 ACTUAL VALUES MAIN MENU.........................................................................6-1
6.2 STATUS
6.2.1 CONTACT INPUTS ............................................................................................6-3
6.2.2 VIRTUAL INPUTS ..............................................................................................6-3
6.2.3 REMOTE INPUTS ..............................................................................................6-3
6.2.4 REMOTE DOUBLE-POINT STATUS INPUTS ...................................................6-4
6.2.5 TELEPROTECTION INPUTS .............................................................................6-4
6.2.6 CONTACT OUTPUTS ........................................................................................6-4
6.2.7 VIRTUAL OUTPUTS ..........................................................................................6-5
6.2.8 AUTORECLOSE.................................................................................................6-5
6.2.9 REMOTE DEVICES............................................................................................6-5
6.2.10 DIGITAL COUNTERS.........................................................................................6-6
6.2.11 SELECTOR SWITCHES ....................................................................................6-6
6.2.12 FLEX STATES....................................................................................................6-6
6.2.13 ETHERNET ........................................................................................................6-7
6.2.14 HI-Z STATUS......................................................................................................6-7
6.2.15 DIRECT INPUTS ................................................................................................6-7
6.2.16 DIRECT DEVICES STATUS ..............................................................................6-8
6.2.17 IEC 61850 GOOSE INTEGERS .........................................................................6-8
6.2.18 EGD PROTOCOL STATUS................................................................................6-8
6.2.19 TELEPROTECTION CHANNEL TESTS.............................................................6-9
6.2.20 INCIPIENT FAULT DETECTOR .........................................................................6-9
6.2.21 ETHERNET SWITCH .......................................................................................6-10
6.3 METERING
6.3.1 METERING CONVENTIONS ...........................................................................6-11
6.3.2 SOURCES ........................................................................................................6-14
6.3.3 SENSITIVE DIRECTIONAL POWER ...............................................................6-20
6.3.4 SYNCHROCHECK ...........................................................................................6-20
6.3.5 TRACKING FREQUENCY................................................................................6-20
6.3.6 FREQUENCY RATE OF CHANGE ..................................................................6-21
6.3.7 FLEXELEMENTS™..........................................................................................6-21
6.3.8 IEC 61580 GOOSE ANALOG VALUES ...........................................................6-22
6.3.9 WATTMETRIC GROUND FAULT.....................................................................6-22
6.3.10 TRANSDUCER INPUTS AND OUTPUTS ........................................................6-22
6.4 RECORDS
6.4.1 FAULT REPORTS ............................................................................................6-23
6.4.2 EVENT RECORDS...........................................................................................6-23
6.4.3 OSCILLOGRAPHY ...........................................................................................6-24
6.4.4 DATA LOGGER................................................................................................6-24
6.4.5 BREAKER MAINTENANCE .............................................................................6-25
6.4.6 HI-Z RECORDS................................................................................................6-25
6.5 PRODUCT INFORMATION
6.5.1 MODEL INFORMATION...................................................................................6-26
6.5.2 FIRMWARE REVISIONS..................................................................................6-26
7. COMMANDS AND
TARGETS
7.1 COMMANDS
7.1.1 COMMANDS MENU...........................................................................................7-1
7.1.2 VIRTUAL INPUTS ..............................................................................................7-1
7.1.3 CLEAR RECORDS.............................................................................................7-2
7.1.4 SET DATE AND TIME ........................................................................................7-2
7.1.5 RELAY MAINTENANCE.....................................................................................7-3

GE Multilin F60 Feeder Protection System ix
TABLE OF CONTENTS
7.2 TARGETS
7.2.1 TARGETS MENU............................................................................................... 7-4
7.2.2 TARGET MESSAGES ....................................................................................... 7-4
7.2.3 RELAY SELF-TESTS......................................................................................... 7-4
8. SECURITY 8.1 PASSWORD SECURITY
8.1.1 OVERVIEW........................................................................................................ 8-1
8.1.2 PASSWORD SECURITY MENU ....................................................................... 8-2
8.1.3 LOCAL PASSWORDS ....................................................................................... 8-2
8.1.4 REMOTE PASSWORDS ................................................................................... 8-3
8.1.5 ACCESS SUPERVISION................................................................................... 8-3
8.1.6 DUAL PERMISSION SECURITY ACCESS ....................................................... 8-4
8.2 SETTINGS SECURITY
8.2.1 SETTINGS TEMPLATES................................................................................... 8-6
8.2.2 SECURING AND LOCKING FLEXLOGIC™ EQUATIONS ............................. 8-10
8.2.3 SETTINGS FILE TRACEABILITY .................................................................... 8-12
8.3 ENERVISTA SECURITY MANAGEMENT SYSTEM
8.3.1 OVERVIEW...................................................................................................... 8-15
8.3.2 ENABLING THE SECURITY MANAGEMENT SYSTEM ................................. 8-15
8.3.3 ADDING A NEW USER ................................................................................... 8-15
8.3.4 MODIFYING USER PRIVILEGES ................................................................... 8-16
9. THEORY OF OPERATION 9.1 HIGH-IMPEDANCE (HI-Z) FAULT DETECTION
9.1.1 DESCRIPTION................................................................................................... 9-1
9.1.2 ENERGY ALGORITHM...................................................................................... 9-1
9.1.3 RANDOMNESS ALGORITHM ........................................................................... 9-2
9.1.4 EXPERT ARC DETECTOR ALGORITHM ......................................................... 9-2
9.1.5 SPECTRAL ANALYSIS ALGORITHM ............................................................... 9-2
9.1.6 LOAD EVENT DETECTOR ALGORITHM ......................................................... 9-2
9.1.7 LOAD ANALYSIS ALGORITHM ........................................................................ 9-3
9.1.8 LOAD EXTRACTION ALGORITHM................................................................... 9-3
9.1.9 ARC BURST PATTERN ANALYSIS ALGORITHM............................................ 9-3
9.1.10 ARCING SUSPECTED ALGORITHM................................................................ 9-3
9.1.11 OVERCURRENT DISTURBANCE MONITORING ............................................ 9-3
9.1.12 HI-Z EVEN HARMONIC RESTRAINT ALGORITHM ......................................... 9-3
9.1.13 HI-Z VOLTAGE SUPERVISION ALGORITHM .................................................. 9-4
9.2 FAULT LOCATOR
9.2.1 FAULT TYPE DETERMINATION....................................................................... 9-5
10. COMMISSIONING 10.1 TESTING
10.1.1 TESTING UNDERFREQUENCY AND OVERFREQUENCY ELEMENTS....... 10-1
A. FLEXANALOG AND
FLEXINTEGER
PARAMETERS
A.1 PARAMETER LISTS
A.1.1 FLEXANALOG ITEMS .......................................................................................A-1
A.1.2 FLEXINTEGER ITEMS ....................................................................................A-13
B. MODBUS
COMMUNICATIONS
B.1 MODBUS RTU PROTOCOL
B.1.1 INTRODUCTION................................................................................................B-1
B.1.2 PHYSICAL LAYER.............................................................................................B-1
B.1.3 DATA LINK LAYER............................................................................................B-1
B.1.4 CRC-16 ALGORITHM........................................................................................B-2

x F60 Feeder Protection System GE Multilin
TABLE OF CONTENTS
B.2 MODBUS FUNCTION CODES
B.2.1 SUPPORTED FUNCTION CODES ................................................................... B-3
B.2.2 READ ACTUAL VALUES OR SETTINGS (FUNCTION CODE 03/04H) ........... B-3
B.2.3 EXECUTE OPERATION (FUNCTION CODE 05H)........................................... B-4
B.2.4 STORE SINGLE SETTING (FUNCTION CODE 06H)....................................... B-4
B.2.5 STORE MULTIPLE SETTINGS (FUNCTION CODE 10H) ................................ B-5
B.2.6 EXCEPTION RESPONSES............................................................................... B-5
B.3 FILE TRANSFERS
B.3.1 OBTAINING RELAY FILES VIA MODBUS........................................................ B-6
B.3.2 MODBUS PASSWORD OPERATION............................................................... B-8
B.4 MEMORY MAPPING
B.4.1 MODBUS MEMORY MAP ................................................................................. B-9
B.4.2 DATA FORMATS............................................................................................. B-64
C. IEC 61850
COMMUNICATIONS
C.1 OVERVIEW
C.1.1 INTRODUCTION ............................................................................................... C-1
C.1.2 COMMUNICATION PROFILES ......................................................................... C-1
C.2 SERVER DATA ORGANIZATION
C.2.1 OVERVIEW ....................................................................................................... C-2
C.2.2 GGIO1: DIGITAL STATUS VALUES ................................................................. C-2
C.2.3 GGIO2: DIGITAL CONTROL VALUES.............................................................. C-2
C.2.4 GGIO3: DIGITAL STATUS AND ANALOG VALUES FROM RECEIVED GOOSE
DATAC-2
C.2.5 GGIO4: GENERIC ANALOG MEASURED VALUES.........................................C-2
C.2.6 MMXU: ANALOG MEASURED VALUES ..........................................................C-3
C.2.7 PROTECTION AND OTHER LOGICAL NODES............................................... C-3
C.3 SERVER FEATURES AND CONFIGURATION
C.3.1 BUFFERED/UNBUFFERED REPORTING........................................................ C-5
C.3.2 FILE TRANSFER ............................................................................................... C-5
C.3.3 TIMESTAMPS AND SCANNING ....................................................................... C-5
C.3.4 LOGICAL DEVICE NAME ................................................................................. C-5
C.3.5 LOCATION ........................................................................................................ C-5
C.3.6 LOGICAL NODE NAME PREFIXES.................................................................. C-6
C.3.7 CONNECTION TIMING ..................................................................................... C-6
C.3.8 NON-IEC 61850 DATA ...................................................................................... C-6
C.3.9 COMMUNICATION SOFTWARE UTILITIES..................................................... C-6
C.4 GENERIC SUBSTATION EVENT SERVICES: GSSE AND GOOSE
C.4.1 OVERVIEW ....................................................................................................... C-7
C.4.2 GSSE CONFIGURATION.................................................................................. C-7
C.4.3 FIXED GOOSE .................................................................................................. C-7
C.4.4 CONFIGURABLE GOOSE ................................................................................ C-7
C.4.5 ETHERNET MAC ADDRESS FOR GSSE/GOOSE .......................................... C-9
C.4.6 GSSE ID AND GOOSE ID SETTINGS............................................................ C-10
C.5 IEC 61850 IMPLEMENTATION VIA ENERVISTA UR SETUP
C.5.1 OVERVIEW ..................................................................................................... C-11
C.5.2 CONFIGURING IEC 61850 SETTINGS .......................................................... C-12
C.5.3 ABOUT ICD FILES .......................................................................................... C-13
C.5.4 CREATING AN ICD FILE WITH ENERVISTA UR SETUP..............................C-17
C.5.5 ABOUT SCD FILES......................................................................................... C-17
C.5.6 IMPORTING AN SCD FILE WITH ENERVISTA UR SETUP........................... C-20
C.6 ACSI CONFORMANCE
C.6.1 ACSI BASIC CONFORMANCE STATEMENT ................................................ C-22
C.6.2 ACSI MODELS CONFORMANCE STATEMENT............................................ C-22
C.6.3 ACSI SERVICES CONFORMANCE STATEMENT.........................................C-23
C.7 LOGICAL NODES
C.7.1 LOGICAL NODES TABLE ............................................................................... C-26
