Toro 51130T User manual

FormNo.3408-767RevC
PowerPlex™33cm40VMAX
StringTrimmer
ModelNo.51130—SerialNo.317000001andUp
ModelNo.51130T—SerialNo.317000001andUp
Registeratwww.Toro.com.
OriginalInstructions(EN)*3408-767*C

ThisproductcomplieswithallrelevantEuropean
directives.Fordetails,pleaseseetheseparate
productspecicDeclarationofConformity(DOC)
sheet.
Introduction
Thistrimmerisintendedtobeusedbyresidential
homeownerstotrimgrassasneeded.Itisdesigned
touseonlybatterypackmodels88525(providedwith
model51130)or88526.
Readthisinformationcarefullytolearnhowtooperate
andmaintainyourproductproperlyandtoavoid
injuryandproductdamage.Youareresponsiblefor
operatingtheproductproperlyandsafely.
YoumaycontactTorodirectlyatwww.T oro.comfor
productandaccessoryinformation,helpndinga
dealer,ortoregisteryourproduct.
Model51130Tdoesnotincludeabatteryora
charger.
Safety
WARNING:Whenusingelectricgardeningappliances,
alwaysfollowbasicsafetyprecautionstoreduce
theriskofre,electricshock,andpersonalinjury,
includingthefollowing:
WARNING
Failuretofollowallwarningsandinstructions
mayresultinelectricshock,reand/or
seriousinjury.
Readallsafetywarningsandallinstructions.
Saveallwarningsandinstructionsforfuture
reference.
Theterm“powertool”inallofthewarningsrefers
toyourmains-operated(corded)powertoolor
battery-operated(cordless)powertool.
1.Workareasafety
A.Keeptheworkareacleanandwelllit.
Clutteredordarkareasinviteaccidents.
B.Donotoperatepowertoolsinexplosive
atmospheres,suchasinthepresence
ofammableliquids,gasses,ordust.
Powertoolscreatesparks,whichmayignite
thedustorfumes.
C.Keepchildrenandbystandersaway
whileoperatingapowertool.Distractions
cancauseyoutolosecontrol.
D.Avoiddangerousenvironments.Donot
useappliancesindamporwetlocations.
2.Personalsafety
A.Stayalert;watchwhatyouaredoing
andusecommonsensewhenoperating
apowertool.Donotuseapowertool
whileyouaretiredorundertheinuence
ofdrugs,alcohol,ormedication.A
momentofinattentionwhileoperatingpower
toolsmayresultinseriouspersonalinjury.
B.Usepersonalprotectiveequipment.
Alwaysweareyeprotection.Protective
equipmentsuchasadustmask,non-skid
safetyshoes,ahardhat,orhearing
protectionusedforappropriateconditions
willreducepersonalinjuries.
C.Preventunintentionalstarting.Ensure
theswitchisintheOFFpositionbefore
connectingtopowersourceand/or
batterypackandpickinguporcarrying
thetool.Carryingpowertoolswithyour
ngerontheswitchorenergizingpower
toolsthathavetheswitchoninvites
accidents.
©2017—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN554202
Contactusatwww.Toro.com.
PrintedinChina
AllRightsReserved

D.Donotoverreach.Keepproper
footingandbalanceatalltimes.This
enablesbettercontrolofthepowertoolin
unexpectedsituations.
E.Dressproperly.Donotwearloose
clothingorjewelry.Keepyourhair,
clothing,andglovesawayfrommoving
parts.Looseclothes,jewelry,orlonghair
canbecaughtinmovingparts.
F.Keepyourhandsandfeetawayfromthe
cuttingarea.
3.Powertooluseandcare
A.Donotforcethepowertool.Usethe
correctpowertoolforyourapplication.
Thecorrectpowertoolwilldothejob
betterandsaferattherateforwhichitwas
designed.
B.Donotusethepowertooliftheswitch
doesnotturnitonandoff.Anypowertool
thatcannotbecontrolledwiththeswitchis
dangerousandmustberepaired.
C.Removethebatterypackfromthepower
toolbeforemakinganyadjustments,
changingaccessories,orstoringpower
tools.Suchpreventivesafetymeasures
reducetheriskofstartingthepowertool
accidentally.
D.Storeidlepowertoolsoutofthereach
ofchildrenanddonotallowpersons
unfamiliarwiththepowertoolorthese
instructionstooperatethepowertool.
Powertoolsaredangerousinthehandsof
untrainedusers.
E.Storeidleappliancesindoors.Whennot
inuse,appliancesshouldbestoredindoors
inadryandhighorlocked-upplace,outof
thereachofchildren.
F.Maintainpowertools.Checkfor
misalignmentorbindingofmoving
parts,breakageofparts,andanyother
conditionthatmayaffecttheoperation
ofpowertools.Ifdamaged,havethe
powertoolrepairedbeforeuse.Many
accidentsarecausedbypoorlymaintained
powertools.
G.Maintainappliancewithcare.Keep
cuttingedgesharpandcleanforbest
performanceandtoreducetheriskof
injury.Followinstructionsforlubricatingand
changingaccessories.Keephandlesdry,
clean,andfreefromoilandgrease.
H.Keepcuttingtoolssharpandclean.
Properlymaintainedcuttingtoolswithsharp
cuttingedgesarelesslikelytobindandare
easiertocontrol.
I.Usethepowertoolinaccordancewith
theseinstructionsandinthemanner
intendedfortheparticulartypeofpower
tool,takingintoaccounttheworking
conditionsandtheworktobeperformed.
Usingthepowertoolforoperationsdifferent
fromthoseintendedcouldresultina
hazardoussituation.
J.Keepguardsinplaceandinworking
order.
K.Checkfordamagedparts.Beforeusing
theappliance,carefullycheckaguardor
otherpartthatisdamagedtodetermine
thatitwilloperateproperlyandperform
itsintendedfunction.Checkforalignment
ofmovingparts,bindingofmovingparts,
breakageofparts,mounting,andanyother
conditionthatmayaffectitsoperation.A
guardorotherpartthatisdamagedshould
beproperlyrepairedorreplacedbyan
authorizedservicecenterunlessindicated
elsewhereinthismanual.
4.Service
Haveyourpowertoolservicedbya
qualiedrepairpersonusingonlyidentical
replacementparts.Thiswillensurethatthe
safetyofthepowertoolismaintained.
5.BatterySafety
A.Donotchargeapplianceinrainorinwet
locations.
B.Donotusebattery-operatedappliancein
therain.
C.Useonlythefollowingtypeandsize
battery(ies):TorobatteryModel88525or
88526.
D.Removeordisconnectthebatterybefore
servicing,cleaning,orremovingmaterial
fromthegardeningappliance.
E.Donotdisposeofthebattery(ies)ina
re.Thecellmayexplode.Checkwith
localcodesforpossiblespecialdisposal
instructions.
F.Donotopenormutilatethebattery(ies).
Releasedelectrolyteiscorrosiveandmay
causedamagetotheeyesorskin.Itmay
betoxicifswallowed.
G.Exercisecareinhandlingbatteriesinorder
nottoshortthebatterywithconducting
materialssuchasrings,bracelets,andkeys.
Thebatteryorconductormayoverheatand
causeburns.
SAVETHESEINSTRUCTIONS
3

SoundPressure
Thisunithasasoundpressurelevelattheoperator’s
earof83.1dBA,withanUncertaintyValue(K)of3
dBA.
Thesoundpressurelevelwasdeterminedaccording
totheproceduresoutlinedinENISO11201.
SoundPower
Thisunithasaguaranteedsoundpowerlevelof96
dBA,whichincludesanUncertaintyValue(K)of1.02
dBA.
Thesoundpowerlevelwasdeterminedaccordingto
theproceduresoutlinedinENISO11094.
Hand/ArmVibration
Measuredvibrationlevelforrighthand=2.19m/s2
Measuredvibrationlevelforlefthand=2.06m/s2
UncertaintyValue(K)=1.5m/s2
Themeasuredvaluesweredeterminedaccordingto
theproceduresoutlinedinENISO20643.
Important:Thevibrationemissionduringactual
useofthepowertoolcandifferfromthedeclared
totalvaluedependingonthewaythetoolis
used.Theoperatorshouldtakesafetymeasures
basedonanestimationofexposureintheactual
conditionsofuse.
4

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyarea
ofpotentialdanger.Replaceanydecalthatisdamagedormissing.
decal136-2482
136-2482
1.Stringtrimmeredger
decal136-2484
136-2484
1.Presstorotate.
decal136-2489
136-2489
1.Doubleinsulated2.Donotdiscard.
decal136-2490
136-2490
1.Doubleinsulated2.Donotdiscard.
decal136-2499
136-2499
1.ReadtheOperator’s
Manual.
3.Donotoperateinwet
conditions.
2.Donotburnthebattery.4.Donotdiscard.
decal136-2501
136-2501
1.Donotdiscard.3.Residential
2.Doubleinsulated4.ReadtheOperator’s
Manual.
5

decal136-2504
136-2504
1.Thebatterypackis
charging.
3.Thebatterypackistoo
warm.
2.Thebatterypackisfully
charged.
4.Thebatterypackneedsto
bereplaced.
decal136-2534
136-2534
1.Thebatterydoesnot
comeoutoftheboxfully
charged.
4.Stop—followthese
instructionsbeforerst
use.
2.Placethebatteryinthe
batterycharger.
5.ReadtheOperator’s
Manual.
3.Waituntilthebatteryis
fullychargedbeforethe
rstuse.
decal136-2539
136–2539
1.Chargethebatterywherethetemperatureisbetween0°C
and40°C(32°Fand104°F).
decal136-2535
136-2535
1.Warning—keep
bystandersawayfromthe
machineinalldirections.
2.Thrownobject
hazard—keepbystanders
awayfromthemachine.
decal136-2537
136-2537
1.Warning—readtheOperator’sManual;wearhearing
protection;weareyeprotection;donotoperateinwet
conditions.
6

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
1Nopartsrequired–Mountthebatterycharger(optional).
2Nopartsrequired–Unfoldthehandle.
3Auxiliaryhandle1Installtheauxiliaryhandle.
Guard1
4Phillipsheadscrew3
Mountingtheguardtothebaseofthe
trimmer.
5Wireedgeguard1Installingtheedgeguard
Note:Thebatterypackisnotfullychargedwhenyoupurchaseit.Beforeusingthetoolforthersttime,refer
toChargingtheBatteryPack(page12).
1
MountingtheBattery
Charger(Optional)
NoPartsRequired
Procedure
Ifdesired,mountthebatterychargersecurelyona
wallusingthewall-mountkeyholesonthebackof
thecharger.
Mountitindoors(suchasagarageorotherdryplace),
nearapoweroutlet,andoutofthereachofchildren.
RefertoFigure1forassistanceinmountingthe
charger.
Note:Slideandtwistthechargeroverthe
appropriatelypositionedhardwaretosecurethe
chargerinplace(hardwarenotincluded).
g194202
Figure1
7

2
UnfoldingtheHandle
NoPartsRequired
Procedure
1.Unfoldthehandle(AofFigure2).
2.Pressandholdthelockingbuttonontheuppershaft,alignthelockingbuttonwiththeslottedholeonthe
lowershaft,andslidethe2shaftstogether.Oncetheslottedholeonthelowershaftispastthelocking
button,releasethelockingbutton,andslidethelowershaftintotheuppershaftuntilthetrimmeris
atthedesiredheight(BofFigure2).
Note:Usethelockingbuttononlyforassemblyanddisassembly.Youdonotneedtousethebuttonto
adjustthehandle.
3.Tightenthelowershaftconnectortosecurethehandleatthedesiredheight(CofFigure2).
g195351
Figure2
8

3
InstallingtheAuxiliary
Handle
Partsneededforthisprocedure:
1Auxiliaryhandle
Procedure
1.Lineupthegroovealongthehandlewiththe
grooveontheauxiliaryhandleandslidethe
auxiliaryhandletowardthetrimmerhandle(Aof
Figure3).
2.Snapthehandlesecurelyintoplace(BofFigure
3).
g195362
Figure3
4
InstallingtheGuard
Partsneededforthisprocedure:
1Guard
3Phillipsheadscrew
Procedure
1.Removethe3Phillipsscrewsthataretapedto
theguardandslidetheguardontothetrimmer
base(AofFigure4).
2.Securetheguardontothebaseofthetrimmer
withthe3Phillipsscrews(BofFigure4).
g195743
Figure4
9

5
InstallingtheEdgeGuard
Partsneededforthisprocedure:
1Wireedgeguard
Procedure
Slightlyspreadtheendsofthewireedgeguardapart
andtheninserttheendsintotheholesinthetrimmer
housingasshowninFigure5.
g189882
Figure5
ProductOverview
Specications
Weights
Massofthemachinewithout
thebattery
3.2kg(7.0lb)
Massofthemachinewith
battery88525
4.2kg(9.2lb)
Massofthemachinewith
battery88526
4.8kg(10.5lb)
AppropriateTemperatureRanges
Chargethebatteryat0°C(32°F)to40°C(104°F)*
Useproductsat-15°C(5°F)to60°C(140°F)
Storeproductsat-20°C(-4°F)to60°C(140°F)
UnplugthechargerifBelow-20°C(-4°F)orabove
60°C(140°F)
*Chargingtimewillincreaseifyoudonotchargethe
batterywithinthisrange.
Storethetool,batterypackandbatterychargerinan
enclosedclean,dryarea.
10

Operation
StartingtheTrimmer
1.Makesurethattheventsonthetrimmerare
clearofanydustanddebris.
g194612
Figure6
1.Trimmerventingareas
2.Alignthecavityinthebatterypackwiththe
tongueonthehandlehousing(Figure7).
3.Pushthebatterypackintothehandleuntilthe
batterylocksintothelatch(Figure7).
g189881
Figure7
1.Batterylatch
4.Tostartthetrimmer,pressthelock-outbutton,
thensqueezethevariable-speedtrigger(Figure
8).
g189886
Figure8
1.Lock-outbutton2.Variable-speedtrigger
StoppingtheTrimmer
Tostopthetrimmer,releasethetrigger.
RemovingtheBatteryPack
fromtheTrimmer
Pressthebatterylatchonthemachinetoreleasethe
batterypackandslidethebatterypackoutofthe
machine(Figure9).
g192774
Figure9
1.Batterylatch
11

ChargingtheBatteryPack
Important:Makesuretoreadallsafety
precautions.
Important:Chargethebatterypackonlyin
temperaturesthatarewithintheappropriate
range;refertoSpecications(page10).
Note:Atanytime,pressthebattery-charge-indicator
buttononthebatterypacktodisplaythecurrent
charge(LEDindicators).
1.Plugthepowercordthatmatchesyourpower
outletsintothebatterycharger.
2.Makesurethattheventsonthebatterypackare
clearofanydustanddebris.
3.Lineupthecavityinthebatterypack(Figure10)
withthetongueonthecharger.
g192748
Figure10
1.Batterypackcavity4.Battery-charge-indicator
button
2.Batterypackterminals5.LEDindicators(current
charge)
3.Batterypackventingareas
4.Makesurethattheventsonthebatterycharger
areclearofanydustanddebris.
5.Slidethebatterypackintothechargeruntilitis
fullyseated(Figure11).
g194423
Figure11
1.Chargerventingareas3.Rightindicatorlight
2.Leftindicatorlight
6.Toremovethebatterypack,slidethebattery
backwardoutofthecharger.
7.RefertothefollowingtabletointerprettheLED
indicatorsonthebatterycharger.
LeftLightRightLightIndicates:
OffRedChargerison;nobattery
packinserted
RedRedBatterypackischarging
GreenRedBatterypackischarged
OrangeRedBatterypackistoowarm
RedBlinkingRedReplacethebatterypack
12

AdvancingtheLine
Note:Thetrimmerisequippedwithanauto-feed
head.
1.Withthetrimmerrunning,releasetheswitch
trigger.
2.Waitafewseconds,thenpressthelockout
buttonandsqueezethetrigger.
Note:Thelineextendsapproximately6mm
(1/4inch)witheachstopandstartofthetrimmer
untilthelinereachesthelengthofthegrass
deectorblade.
3.Resumetrimming.
AdvancingtheLine
Manually
Removethebatteryfromthetrimmer,thenpushthe
buttonatthebaseofthespoolretainerwhilepulling
onthetrimmerlinetomanuallyadvancetheline.
g203810
Figure12
1.Button
AdjustingtheHandle
Height
1.Loosenthelowershaftconnector(AofFigure
13).
2.Slidethetelescopingshafttoyourdesired
position(BofFigure13).
Important:Donotslidetheuppershaft
overtheventsonthelowershaftanddonot
removetherubberbumper.
3.Tightenthehandleconnectortosecurethe
handle(CofFigure13).
g189876
Figure13
13

AdjustingtheAuxiliary
Handle
1.Releasetheauxiliary-handlelatch(AofFigure
14).
2.Slidetheauxiliaryhandleupordowntoyour
desiredheight(BofFigure14).
Important:Donotremovetherubber
bumper.
3.Closetheauxiliary-handlelatchtosecurethe
auxiliaryhandleinplace(CofFigure14).
g189875
Figure14
Trimming
g189888
Figure15
Edging
Tousethetrimmerasanedger,refertothefollowing
steps:
1.Presstherotatorbutton,rotatethehead90°,
andmakesurethatitlocksintoplace(Aof
Figure16).
2.Standthetrimmeronthewheelandbegin
edging(BofFigure16).
g189885
Figure16
OperatingTips
•Keepthetrimmertiltedtowardtheareabeingcut;
thisisthebestcuttingarea.
•Thestringtrimmercutswhenyoupassitfromleft
toright.Thispreventsthetrimmerfromthrowing
debrisattheyou.
•Usethetipofthestringtodothecutting;donot
forcethestringheadintouncutgrass.
•Wireandpicketfencescauseextrastringwear,
evenbreakage.Stoneandbrickwalls,curbs,and
woodmaywearstringrapidly.
•Avoidtreesandshrubs.Treebark,woodmoldings,
siding,andfencepostscaneasilybedamaged
bythestrings.
g189887
Figure17
1.Directionofrotation2.Stringpath
14

Maintenance
Aftereachuseofthetrimmer,completethefollowing:
1.Removethebatteryfromthetrimmer.
2.Wipethetrimmercleanwithadampcloth.Do
nothosethetrimmerdownorsubmergeitin
water.
CAUTION
Thelinecutoffbladeonthedeectoris
sharpandcancutyou.
Donotuseyourhandstocleanthe
deectorshieldandblade.
3.Wipeorscrapecleanthecuttingheadareaany
timethereisanaccumulationofdebris.
4.Checkandtightenallfasteners.Ifanypartis
damagedorlost,repairorreplaceit.
5.Brushdebrisawayfromairintakeventsand
exhaustonmotorhousingtopreventthemotor
fromoverheating.
ReplacingtheSpool
Useonly2mm(0.080inch)diametermonolament
string.Usetheoriginalmanufacturer’sreplacement
stringforbestperformance(ToroPartNo.88545TE).
Important:Usingalargerdiameterstringcauses
themotortooverheatandfail.
1.Removethebattery.
2.Pushinthetabsonthesideofthespool
retainingcover(Figure17).
g194053
Figure18
1.Eyelet4.Tabs
2.Spool5.Linecutoffblade
3.Spoolretainingcover
3.Pullthespoolretainingcoveruptoremoveit
andremovethespool.
4.Installthenewspoolsothatthestringaligns
withtheeyeletinthestringhead.Threadthe
stringintotheeyelet.
5.Verifythattheendofthestringextends
approximately152mm(6inches)beyondthe
slot.
6.Pullthestringextendingfromthestringheadso
thatthestringreleasesfromtheslotinthespool.
7.Installthespoolretainerbypressingthetabs
intotheslotsandpushingdownuntilthespool
retainerclicksintoplace.
ReplacingtheString
1.Removethebattery.
2.Removethespool;refertoReplacingtheSpool
(page15).
1
2
G015662
g015662
Figure19
1.Spool3.Upperpartofspool
2.Anchorhole
Note:Removeanyoldstringremainingonthe
spool.
3.Thespoolacceptsapproximately3.9m(13ft)of
string.Useonly2mm(0.080inch)diameter
monolamentstring.
Note:Donotuseanyothergaugeortypeof
string,asthiscoulddamagethetrimmer.
4.Insertthestringintotheanchorhole(Figure19).
Windthestringontothespoolinthedirection
shownbythearrowsonthespool.
5.Placethestringintheslotontheupperspool
ange,leavingabout152mm(6inches)
extendedbeyondtheslot.
Note:Donotoverll.Afterwindingthestring,
thereshouldbeatleast6mm(1/4inch)between
15

thewoundstringandtheoutsideedgeofthe
spool.
6.Replacethespoolandthespoolretainer;refer
toReplacingtheSpool(page15).
Storage
Important:Storethetool,batterypack,and
chargeronlyintemperaturesthatarewithinthe
appropriaterange;refertoSpecications(page
10).
Important:Ifyouarestoringthetoolforayearor
longer,removethebatterypackfromthetooland
chargethebatterypackuntil2or3LEDindicators
turnblueonthebattery.Donotstoreafully
chargedorfullydepletedbattery.Whenreadyto
useagain,chargethebatterypackuntiltheleft
indicatorlightturnsgreenonthechargerorall4
LEDindicatorsturnblueonthebattery.
•Disconnecttheproductfromthepowersupply
(i.e.,removetheplugfromthepowersupplyorthe
batterypack)andcheckfordamageafteruse.
•Cleanallforeignmaterialfromtheproduct.
•Whennotinuse,storethetool,batterypack,and
batterychargeroutofthereachofchildren.
•Keepthetool,batterypack,andbatterycharger
awayfromcorrosiveagents,suchasgarden
chemicalsandde-icingsalts.
•Toreducetheriskofseriouspersonalinjury,do
notstorethebatterypackoutsideorinvehicles.
•Storethetool,batterypack,andbatterycharger
inanenclosedclean,dryarea.
PreparingtheBatteryPack
forRecycling
Important:Uponremoval,covertheterminalsof
thebatterypackwithheavy-dutyadhesivetape.
Donotattempttodestroyordisassemblethe
batterypackorremoveanyofitscomponents.
Recycleorproperlydisposeoflithium-ionbattery
packsatabatteryrecyclingfacility.
16

Troubleshooting
Performonlythestepsdescribedintheseinstructions.Allfurtherinspection,maintenance,andrepairwork
mustbeperformedbyanauthorizedservicecenterorasimilarlyqualiedspecialistifyoucannotsolvethe
problemyourself.
ProblemPossibleCauseCorrectiveAction
1.Thebatteryisnotfullyinstalledinthe
tool.
1.Removeandthenreplacethebattery
intothetool,makingsurethatitisfully
installedandlatched.
2.Thebatterypackisnotcharged.2.Removethebatterypackfromthetool
andchargeit.
3.Thebatterypackisdamaged.3.Replacethebatterypack.
Thetooldoesnotstart.
4.Thereisanotherelectricalproblem
withthetool.
4.ContactanAuthorizedServiceDealer.
1.Thebatterypackchargecapacityis
toolow.
1.Removethebatterypackfromthetool
andfullychargethebatterypack.
Thetooldoesnotreachfullpower.
2.Theairventsareblocked.2.Cleantheairvents.
1.Thereisdebrisonthedrumareaon
thetrimmer.
1.Cleananydebrisoffofthedrumarea.
Thetoolisproducingexcessivevibration
ornoise.
2.Thespoolisnotproperlywound.2.Advancethelineusingthetrigger
switchand/orremovethelineonthe
spoolandwindthespoolagain.
Thebatterypackloseschargequickly.1.Thebatterypackisoverorunderthe
appropriatetemperaturerange.
1.Movethebatterypacktoaplace
whereitisdryandthetemperatureis
between0°C(32°F)and40°C(104°F).
1.Thebatterychargerisoverorunder
theappropriatetemperaturerange.
1.Unplugthebatterychargerandmove
ittoaplacewhereitisdryandthe
temperatureisbetween0°C(32°F)
and40°C(104°F).
Thebatterychargerisnotworking.
2.Theoutletthatthebatterychargeris
pluggedintodoesnothavepower.
2.Contactyourlicensedelectricianto
repairtheoutlet.
Thebatterypackshowsonly3LED
indicatorsafteronlyafewsecondsof
usingafullychargedbattery.
1.Thisisanormaloccurrence.1.Stopthetoolandpress
battery-charge-indicatorbuttonor
theremovethebatteryfromthetoolto
displaytheactualbatterycharge.
All4LEDindicatorsareblinkingon
thebatterypackafteryoupressthe
battery-charge-indicatorbuttononthe
batterypackandthecurrentcharge
displays(whenthebatterypackisnotin
use).
1.Thebatterypackisoverorunderthe
appropriatetemperaturerange.
1.Movethebatterypacktoaplace
whereitisdryandthetemperatureis
between0°C(32°F)and40°C(104°F).
All4LEDindicatorsareblinkingonthe
batterypackafterreleasingthetrigger
(whenthebatterypackisinuse).
1.Thebatterypackisoverorunderthe
appropriatetemperaturerange.
1.Movethebatterypacktoaplace
whereitisdryandthetemperatureis
between0°C(32°F)and40°C(104°F).
2LEDindicatorsareblinkingon
thebatterypackafteryoupressthe
battery-charge-indicatorbuttononthe
batterypackandthecurrentcharge
displays(whenthebatterypackisnotin
use).
1.Thereisadifferenceinvoltage
betweencellsinthebatterypack.
1.Placethebatteryonthechargeruntil
itisfullycharged.
2LEDindicatorsareblinkingonthe
batterypackafterreleasingthetrigger
(whenthebatterypackisinuse).
1.Thereisadifferenceinvoltage
betweencellsinthebatterypack.
1.Placethebatteryonthechargeruntil
itisfullycharged.
17

ProblemPossibleCauseCorrectiveAction
1LEDindicatorisblinkingonthebattery
pack.
1.Thebatterypackislowvoltage.1.Placethebatterypackonthecharger.
Itisdifculttoremovethebatterypack
fromthetool.
1.Thebatterypack/toolisneworthere
iscorrosioninthebatteryterminals
and/ortheterminalsonthetool.
1.Cleantheterminalsonthebatterypack
andthetool.Thenapplydielectric
greasetothebatteryterminals;donot
useanyothertypeoflubricantasitcan
damagetheterminals.
18

EuropeanPrivacyNotice
TheInformationT oroCollects
ToroWarrantyCompany(T oro)respectsyourprivacy.Inordertoprocessyourwarrantyclaimandcontactyouintheeventofaproductrecall,weaskyou
tosharecertainpersonalinformationwithus,eitherdirectlyorthroughyourlocalTorocompanyordealer.
TheT orowarrantysystemishostedonserverslocatedwithintheUnitedStateswhereprivacylawmaynotprovidethesameprotectionasapplies
inyourcountry.
BYSHARINGYOURPERSONALINFORMATIONWITHUS,YOUARECONSENTINGTOTHEPROCESSINGOFYOURPERSONALINFORMATION
ASDESCRIBEDINTHISPRIVACYNOTICE.
TheWayT oroUsesInformation
Toromayuseyourpersonalinformationtoprocesswarrantyclaims,tocontactyouintheeventofaproductrecallandforanyotherpurposewhichwetell
youabout.T oromayshareyourinformationwithT oro'safliates,dealersorotherbusinesspartnersinconnectionwithanyoftheseactivities.Wewillnot
sellyourpersonalinformationtoanyothercompany.Wereservetherighttodisclosepersonalinformationinordertocomplywithapplicablelawsand
withrequestsbytheappropriateauthorities,tooperateoursystemsproperlyorforourownprotectionorthatofotherusers.
RetentionofyourPersonalInformation
Wewillkeepyourpersonalinformationaslongasweneeditforthepurposesforwhichitwasoriginallycollectedorforotherlegitimatepurposes
(suchasregulatorycompliance),orasrequiredbyapplicablelaw.
Toro'sCommitmenttoSecurityofYourPersonalInformation
Wetakereasonableprecautionsinordertoprotectthesecurityofyourpersonalinformation.Wealsotakestepstomaintaintheaccuracyandcurrent
statusofpersonalinformation.
AccessandCorrectionofyourPersonalInformation
Ifyouwouldliketorevieworcorrectyourpersonalinformation,pleasecontactusbyemailat[email protected].
AustralianConsumerLaw
AustraliancustomerswillnddetailsrelatingtotheAustralianConsumerLaweitherinsidetheboxoratyourlocalT oroDealer.
374-0282RevC

TheToroWarrantyResidentialProducts
and
TheToroGTSStartingGuarantee
ConditionsandProductsCovered
TheT oroCompanyanditsafliate,T oroWarrantyCompany,pursuantto
anagreementbetweenthem,jointlypromisetorepairtheT oroProduct
listedbelowifdefectiveinmaterialsorworkmanshiporiftheToroGTS
(GuaranteedtoStart)enginewillnotstartontherstorsecondpull,
providedtheroutinemaintenancerequiredintheOperator'sManualhave
beenperformed.
Thefollowingtimeperiodsapplyfromtheoriginaldateofpurchase:
ProductsWarrantyPeriod
WalkPowerMowers
•CastDeck5yearsResidentialUse2
90DaysCommercialUse
—Engine5yearsGTSGuarantee,Residential
Use3
—Battery2years
•SteelDeck2yearsResidentialUse2
30DaysCommercialUse
—Engine2yearsGTSGuarantee,Residential
Use3
TimeMasterMowers3yearsResidentialUse2
90DaysCommercialUse
•Engine3yearsGTSGuarantee,Residential
Use3
•Battery2years
ElectricHandHeldProducts
•UltraProducts2yearsResidentialUse2
•PowerPlexProducts3yearsResidentialUse2
—Battery2years
ElectricWalkPowerMowersNoWarrantyforCommercialUse
AllRide-OnUnitsBelow
•EngineSeeenginemanufacturer'swarranty4
•Battery2yearsResidentialUse2
•Attachments2yearsResidentialUse2
DHLawn&GardenTractors2yearsResidentialUse2
30DaysCommercialUse
TimeCutter3yearsResidentialUse2
30DaysCommercialUse
•Engine3yearsResidentialUse2
2yearsor300hoursCommercial
Use5
TimeCutterHD3yearsor300hours5
•Engine3yearsor300hoursCommercial
Use5
1OriginalPurchasermeansthepersonwhooriginallypurchasedtheToroProduct.
2Residentialusemeansuseoftheproductonthesamelotasyourhome.Useatmorethanone
locationisconsideredcommercialuseandthecommercialusewarrantywouldapply.
3TheToroGTSStartingGuaranteedoesnotapplywhentheproductisusedcommercially.
4SomeenginesusedonToroProductsarewarrantedbytheenginemanufacturer.
5Whicheveroccursrst.
Warrantymaybedeniedifthehourmeterisdisconnected,altered,or
showssignsofbeingtamperedwith.
OwnerResponsibilities
YoumustmaintainyourT oroProductbyfollowingthemaintenance
proceduresdescribedintheOperator'sManual.Suchroutinemaintenance,
whetherperformedbyadealerorbyyou,isatyourexpense.
InstructionsforObtainingWarrantyService
IfyouthinkthatyourT oroProductcontainsadefectinmaterialsor
workmanship,followthisprocedure:
1.Contactyoursellertoarrangeserviceoftheproduct.Ifforany
reasonitisimpossibleforyoutocontactyourseller,youmay
contactanyT oroAuthorizedDistributortoarrangeservice.Visit
http://www.toro.com/en-us/locator/pages/default.aspxtolocateaT oro
distributorinyourarea.
2.Bringtheproductandyourproofofpurchase(salesreceipt)tothe
servicingoutlet.Ifforanyreasonyouaredissatisedwiththeservicing
outlet’sanalysisorwiththeassistanceprovided,contactusat:
ToroWarrantyCompany
ToroCustomerCareDepartment,RLCDivision
8111LyndaleAvenueSouth
Bloomington,MN55420-1196
001–952–948–4707
ItemsandConditionsNotCovered
Thereisnootherexpresswarrantyexceptforspecialemissionsystem
coverageandenginewarrantycoverageonsomeproducts.Thisexpress
warrantydoesnotcoverthefollowing:
•Costofregularmaintenanceserviceorparts,suchaslters,fuel,
lubricants,oilchanges,sparkplugs,airlters,bladesharpening
orwornblades,cable/linkageadjustments,orbrakeandclutch
adjustments
•Componentsfailingduetonormalwear
•Anyproductorpartwhichhasbeenaltered,misused,neglected,
requiresreplacement,orrepairduetoaccidentsorlackofproper
maintenance
•Pickupanddeliverycharges
•RepairsorattemptedrepairsbyanyoneotherthananAuthorizedToro
ServiceDealer
•Repairsnecessaryduetofailuretofollowrecommendedfuel
procedure(consultOperator'sManualformoredetails)
–Removingcontaminantsfromthefuelsystemisnotcovered
–Useofoldfuel(morethanonemonthold)orfuelwhichcontains
morethan10%ethanolormorethat15%MTBE
–Failuretodrainthefuelsystempriortoanyperiodofnon-use
overonemonth
•Repairsoradjustmentstocorrectstartingdifcultiesduetothe
following:
–Failuretofollowpropermaintenanceproceduresorrecommended
fuelprocedure
–Rotarymowerbladestrikinganobject
•Specialoperationalconditionswherestartingmayrequiremorethan
twopulls:
–Firsttimestartsafterextendedperiodofnon-useoverthree
monthsorseasonalstorage
–Cooltemperaturestartssuchasthosefoundinearlyspringand
lateautumn
–Improperstartingprocedures-ifyouarehavingdifcultystarting
yourunit,pleasechecktheOperator'sManualtoensurethat
youareusingthecorrectstartingprocedures.Thiscansavean
unnecessaryvisittoanAuthorizedToroServiceDealer.
GeneralConditions
Thepurchaseriscoveredbythenationallawsofeachcountry.Therights
towhichthepurchaserisentitledwiththesupportoftheselawsarenot
restrictedbythiswarranty.
374-0268RevL
