Toro 51487 User manual

FormNo.3375-32RevB
12inCordlessTrimmer
ModelNo.51487—SerialNo.313000001andUp
Operator'sManual
Ifyouhavequestionsorproblems,contactusatwww.Toro.comor
calltollfree1-800-237-2654(US)or1-800-248-3258(Canada)before
returningthisproduct.
GeneralSafetyRules
WARNING:Whenusingelectricgardeningappliances,basic
safetyprecautionsshouldalwaysbefollowedtoreducetheriskof
re,electricshock,andpersonalinjury,includingthefollowing:
Readallinstructions.
Theterm“powertool”inallofthewarningsreferstoyour
mains-operated(corded)powertoolorbattery-operated(cordless)
powertool.
1.Workareasafety
A.Keepworkareacleanandwelllit.Clutteredordark
areasinviteaccidents
B.Donotoperatepowertoolsinexplosive
atmospheres,suchasinthepresenceofammable
liquids,gasesordust.Powertoolscreatesparks
whichmayignitethedustorfumes.
C.Keepchildrenandbystandersawaywhileoperating
apowertool.Distractionscancauseyoutolose
control.
2.Electricalsafety
A.Powertoolplugsmustmatchtheoutlet.Never
modifythepluginanyway.Donotuseany
adapterplugswithearthed(grounded)powertools.
Unmodiedplugsandmatchingoutletswillreducerisk
ofelectricshock.
B.Avoidbodycontactwithearthedorgrounded
surfacessuchaspipes,radiators,rangesand
refrigerators.Thereisanincreasedriskofelectric
shockifyourbodyisearthedorgrounded.
C.Donotexposepowertoolstorainorwetconditions.
Waterenteringapowertoolwillincreasetheriskof
electricshock.
D.Donotabusethecord.Neverusethecordfor
carrying,pullingorunpluggingthepowertool.
Keepcordawayfromheat,oil,sharpedgesor
movingparts.Damagedorentangledcordsincrease
theriskofelectricshock.
E.Whenoperatingapowertooloutdoors,usean
extensioncordsuitableforoutdooruse.Useofa
cordsuitableforoutdoorusereducestheriskofelectric
shock.
F.Ifoperatingapowertoolinadamplocationis
unavoidable,usearesidualcurrentdevice(RCD)
protectedsupply.UseofanRCDreducestheriskof
electricshock.
3.Personalsafety
A.Stayalert,watchwhatyouaredoinganduse
commonsensewhenoperatingapowertool.Do
notuseapowertoolwhileyouaretiredorunderthe
inuenceofdrugs,alcoholormedication.Amoment
ofinattentionwhileoperatingpowertoolsmayresult
inseriouspersonalinjury.
B.Usepersonalprotectiveequipment.Alwayswear
eyeprotection.Protectiveequipmentsuchasdust
mask,non-skidsafetyshoes,hardhat,orhearing
protectionusedforappropriateconditionswillreduce
personalinjuries.
C.Preventunintentionalstarting.Ensuretheswitch
isintheoff-positionbeforeconnectingtopower
sourceand/orbatterypack,pickinguporcarrying
thetool.Carryingpowertoolswithyourngeronthe
switchorenergizingpowertoolsthathavetheswitch
oninvitesaccidents.
D.Removeanyadjustingkeyorwrenchbeforeturning
thepowertoolon.Awrenchorakeyleftattachedto
arotatingpartofthepowertoolmayresultinpersonal
injury.
E.Donotoverreach.Keepproperfootingandbalance
atalltimes.Thisenablesbettercontrolofthepower
toolinunexpectedsituations.
F.Dressproperly.Donotwearlooseclothingor
jewelry.Keepyourhair,clothingandglovesaway
frommovingparts.Looseclothes,jewelry,orlonghair
canbecaughtinmovingparts.
G.Ifdevicesareprovidedfortheconnectionofdust
extractionandcollectionfacilities,ensuretheseare
connectedandproperlyused.Useofthesedevices
canreducedust-relatedhazards.
H.Keephandsandfeetawayfromthecuttingarea.
4.Powertooluseandcare
A.Donotforcethepowertool.Usethecorrectpower
toolforyourapplication.Thecorrectpowertoolwill
dothejobbetterandsaferattherateforwhichitwas
designed.
B.Donotusethepowertooliftheswitchdoesnotturn
itonandoff.Anypowertoolthatcannotbecontrolled
withtheswitchisdangerousandmustberepaired.
C.Disconnecttheplugfromthepowersourceand/or
thebatterypackfromthepowertoolbeforemaking
anyadjustments,changingaccessories,orstoring
powertools.Suchpreventivesafetymeasuresreduce
theriskofstartingthepowertoolaccidentally.
©2012—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registeratwww.Toro.com.OriginalInstructions(EN)
PrintedinChina.
AllRightsReserved*3375-32*B

D.Storeidlepowertoolsoutofthereachofchildren
anddonotallowpersonsunfamiliarwiththepower
toolortheseinstructionstooperatethepowertool.
Powertoolsaredangerousinthehandsofuntrained
users.
E.Storeidleappliancesindoors.Whennotinuse,
appliancesshouldbestoredindoorsinadryandhigh
orlocked-upplace,outofthereachofchildren.
F.Maintainpowertools.Checkformisalignmentor
bindingofmovingparts,breakageofpartsand
anyotherconditionthatmayaffectthepowertools
operation.Ifdamaged,havethepowertoolrepaired
beforeuse.Manyaccidentsarecausedbypoorly
maintainedpowertools.
G.Keepcuttingtoolssharpandclean.Properly
maintainedcuttingtoolswithsharpcuttingedgesare
lesslikelytobindandareeasiertocontrol.
H.Usethepowertool,accessoriesandtoolbitsetc.,
inaccordancewiththeseinstructionsandinthe
mannerintendedfortheparticulartypeofpower
tool,takingintoaccounttheworkingconditions
andtheworktobeperformed.Useofthepowertool
foroperationsdifferentfromthoseintendedcouldresult
inahazardoussituation.
I.Keepguardsinplaceandinworkingorder.
5.Service
Haveyourpowertoolservicedbyaqualiedrepair
personusingonlyidenticalreplacementparts.Thiswill
ensurethatthesafetyofthepowertoolismaintained.
6.BatterySafety
A.Donotchargeapplianceinrain,orinwetlocations.
B.Donotusebattery-operatedapplianceintherain.
C.Useonlythefollowingtypeandsizebattery:Toro
batterymodel88504or88506andbatterycharger
88503.
D.Removeordisconnectthebatterybeforeservicing,
cleaning,orremovingmaterialfromthegardening
appliance.
E.Donotdisposeofthebatteryinare.Thecellmay
explode.Checkwithlocalcodesforpossiblespecial
disposalinstructions.
F.Donotopenormutilatethebattery.Releasedelectrolyte
iscorrosiveandmaycausedamagetotheeyesorskin.
Itmaybetoxicifswallowed.
G.Exercisecareinhandlingbatteriesinordernottoshort
thebatterywithconductingmaterialssuchasrings,
bracelets,andkeys.Thebatteryorconductormay
overheatandcauseburns.
H.Chargingtimewillbeincreasedifthebatteryischarged
whenthetemperatureisnotbetween41to104degrees
F(5to40degreesC).
SAVETHESEINSTRUCTIONS
2

SafetyandInstructionalDecals
Safetydecalsandinstructionsareeasilyvisibletotheoperatorandarelocatednearanyareaofpotentialdanger.
Replaceanydecalthatisdamagedorlost.
SymbolNameDesignation/Explanation
DCDirectcurrentTypeofcurrent
VVoltsVoltage
121–7615
121–7614
125–3227
1.Warning—readtheOperator’sManual;donotoperatein
wetconditions;weareyeprotection.
125–3291
121–7602
125–3226
3

121–7606
4

Setup
LooseParts
Usethechartbelowtoverifythatallpartshavebeenshipped.
ProcedureDescriptionQty.Use
Screw2
1Wall-mountingbracket1Mountthewall-mountingbracket.
2Nopartsrequired–
Auxiliaryhandle1
Latch1
3Brace1
Installtheauxiliaryhandle.
Guard1
4Phillipsheadscrew1
Mounttheguardtothebaseofthe
trimmer.
5Wireedgeguard1Installtheedgeguard
6Nopartsrequired–Adjustthetrimmerheightandbase
orientation
1
MountingtheWall-Mounting
Bracket
Partsneededforthisprocedure:
2Screw
1Wall-mountingbracket
Procedure
Note:Thebracketshouldbemountedindoorsandoutofthe
reachofchildren.
1.Placethebracketagainstthewallandmarkthe2hole
locations.
2.Drillthepilotholes.
A.Ifmountingthebracketonwallboard,plaster,or
cement,drill2holesforthewallanchors(notsupplied)
atthemarkedlocations.
B.Ifmountingthebracketonwood,drill2holesslightly
smallerthanthediameterofthescrewthreadsatthe
markedlocations.
3.Installthescrews(Figure1).
A.Ifmountingthebracketonwallboard,plaster,or
cement,insertthe2wallanchors(notsupplied)intothe
holesthenthreadthescrewsintothewallanchors.
B.Ifinstallingthebracketonwood,drivethe2screwsinto
thewall.
G018599
1
Figure1
5

2
AssemblingtheTrimmer
NoPartsRequired
Procedure
1.Removethetapeandthetubefromthelowerpole(Figure2).
Figure2
1.Tube3.Lowerpole
2.Tape
2.Slidetheupperpoleintothelowerpole,liningupthetabs
intheupperpolewiththereceivingtabsinthelowerpole,
andsecureitbytighteningthescrew.
Note:Thereisanaudibleclickwhentheupperpoleand
lowerpoleareintheproperposition.
Figure3
1.Upperpole3.Receivingtabs
2.Screw
3.Cutthezip-tieandremoveitfromthetriggerhandle
(Figure4).
Figure4
1.Zip-tie
6

3
InstallingtheAuxiliaryHandle
Partsneededforthisprocedure:
1Auxiliaryhandle
1Latch
1Brace
Procedure
1.Positiontheauxiliaryhandleontheshaftofthetrimmerwith
thesmoothsurfacefacingtheoperator(Figure5).
G017277
Figure5
1.Auxiliaryhandle3.Brace
2.Latch
2.Slidethebraceintotheauxiliaryhandlesothatthebrace
restsinthegroovealongtheshaft(Figure5).
3.Slidethelatchfromtheleftthroughthehandleandbrace
asshownandtightenthelatchscrewwithaPhillipshead
screwdriver(Figure5).
4
InstallingtheGuard
Partsneededforthisprocedure:
1Guard
1Phillipsheadscrew
Procedure
1.RemovethePhillipsheadscrewinstalledinthetrimmer
base(Figure6).
2.SlidetheguardontothetrimmerbaseasshowninFigure6.
G017622
Figure6
1.Phillipsheadscrew2.Guard
3.SecuretheguardusingaPhillipsheadscrew.
7

5
InstallingtheEdgeGuard
Partsneededforthisprocedure:
1Wireedgeguard
Procedure
Inserttheendsofthewireedgeguardintotheholesinthetrimmer
housing,asshowninFigure7.
G017621
1
Figure7
1.Wireedgeguard
6
AdjustingtheHandleHeight
andBaseOrientation
NoPartsRequired
Procedure
•Toadjusthandleheight,iptheauxiliaryhandlelatch,slideit
upordowntothedesiredheight,thensecureitinplaceby
closingthelatch(Figure8).
Figure8
1.Auxiliaryhandle2.Auxiliaryhandlelatch
•Toadjusttheorientationofthebase,pressdownonthe
rotatorbuttonlocatedatthebaseoftheshaft,thenmovethe
basetofacethedesireddirection(Figure9).
1
G015683
Figure9
1.Rotatorbutton
8

Operation
Important:Thebatterypackisnotfullychargedwhenit
ispurchased.Beforeusingthetrimmerforthersttime,
placethebatterypackinthechargerandchargeuntilthe
LEDindicatorsturngreen.Makesuretoreadallsafety
precautions.Withregularuse,itwillneedshortercharging
time.Ifstoringforaprolongedperiodoftime,removethe
battery.Whenreadytouseagain,chargethebatterypack
untiltheLEDindicatorsturngreen.
StartingtheTrimmer
1.Alignthetongueofthebatterypackwiththecavityinthe
handlehousing(Figure10).
g017453
1
2
3
Figure10
1.Triggerhandle3.Latch
2.Tongue
2.Graspthetriggerhandle(Figure10).
3.Pushthebatterypackintothehandleuntilthelatchlocks
intoplace.
4.Tostartthetrimmer,slidethelockswitchbacktotheOn
position,thensqueezethetrigger(Figure11).
g017454
1
2
Figure11
1.Lockswitch2.Trigger
StoppingtheTrimmer
Tostopthetrimmer,releasethetrigger.
9

ChargingtheBatteryPack
Important:Forbestresults,yourbatterytoolshouldbe
chargedinalocationwherethetemperatureismorethan
41degreesF(5degreesC)butlessthan104degreesF(40
degreesC).Toreducetheriskofseriouspersonalinjury,
donotstoreoutsideorinvehicles.Chargingtimewillbe
increasedifnotchargedwithinthisrange.
1.Turnthebatteryupsidedownandlineupthebatteryterminal
withtheslotinthecharger(Figure12andFigure13).
G017407
1
2
Figure12
1.LEDindicators2.Insertbatteryhere
G016223
1
2
3
Figure13
1.LEDindicators(levelof
charge)
3.Batteryterminal
2.Releasebutton
2.Slidethebatteryintothechargeruntilitclicksintoplace.
3.Toremovethebattery,pressdownonthereleasebutton
andslidethebatterybackwardsoutofthecharger.
4.RefertothetablebelowtointerprettheLEDindicatorson
thebatterycharger.
LEDCOLOR
LeftRightIndicates:
RedRedBatteryischarging
RedGreenFullycharged
RedOrangeBatteryistoo
warm:Remove
forapproximately
30minutes
RedGreenNobatterypresent
Red(blinking)Red(blinking)Defectivebattery
AdvancingtheLine
Thetrimmerisequippedwithanauto-feedhead.Thelinewill
advance6mm(1/4inch)eachtimeyoustopandstartthe
trimmer.Whenthelinereachesthebladeinthedeector,itwill
becutoffatthatlength.
1.Withthetrimmerrunning,releasetheswitchtrigger.
2.Waittwoseconds,thenpresstheswitchtrigger.
3.Resumetrimming.
AdvancingtheLineManually
Disconnectthestringtrimmerfromthepowersupply,thenpush
theredbuttonatthebaseofthespoolretainerwhilepullingonthe
trimmerlinetomanuallyadvancetheline.
Figure14
1.Button
10

Trimming
G016254
Figure15
Edging
Tousethetrimmerasedger,presstherotatorbuttonandrotate
theheadasshowninFigure16.
1
2
G015660
Figure16
1.Rotatorbutton2.Edgerguide
UsingthePowerSaverFeature
Engagingthepowersaverfeaturewillextendtheruntimeofthe
batterybyshorteningthelengthofthetrimmerlineanddecreasing
theloadonthemotor.
Ifyouareexperiencingreducedbatteryruntime,itisrecommended
thatyouengagethepowersaverfeature.
Pushdownandrotatethepowersaverknob(Figure17)180
degrees(1/2turn)toshortenthelengthofthetrimmerline.This
reducesthepowerconsumptionofthetrimmerandextendsthe
runtimeofthebattery.
Toresumeoperationintheregularmode,pushdownandrotate
thepowersaverknob180degrees(1/2turn).
g017455
1
Figure17
1.Powersaverknob
OperatingTips
•Keepthetrimmertiltedtowardtheareabeingcut;thisisthe
bestcuttingarea.
•Thestringtrimmercutswhenpassingtheunitfromleftto
right.Thiswillavoidthrowingdebrisattheoperator.
•Usethetipofthestringtodothecutting;donotforcestring
headintouncutgrass.
•Wireandpicketfencescauseextrastringwear,even
breakage.Stoneandbrickwalls,curbs,andwoodmaywear
stringrapidly.
•Avoidtreesandshrubs.Treebark,woodmoldings,siding,
andfencepostscaneasilybedamagedbythestrings.
11

Figure18
1.Directionofrotation3.Stringpath
2.Idealcuttingrange
Maintenance
Aftereachuseofthetrimmer,completethefollowing:
1.Removethebatteryfromthetrimmer.
2.Wipethetrimmercleanwithadampcloth.Donothosethe
trimmerdownorsubmergeitinwater.
CAUTION
Thelinecut-offbladeonthedeectorissharpand
cancutyou.Donotuseyourhandstocleanthe
deectorshieldandblade.
3.Wipeorscrapecleanthecuttingheadareaanytimethereis
anaccumulationofdebris.
4.Checkandtightenallfasteners.Ifanypartisdamagedor
lost,repairorreplaceit.
5.Brushdebrisawayfromairintakeventsonthebackofthe
shafttopreventthemotorfromoverheating.
ReplacingtheSpool
Useonly.065inch(1.6mm)diametermonolamentstring.Use
originalmanufacturer’sreplacementstringforbestperformance
(Toropartnumber88532).
1.Removethebattery.
2.Pushinthetabsonthesideofthespoolretainer(Figure19).
1
2
3
4
G015663
Figure19
1.Spoolretainer3.Slots
2.Spool4.Tabs
3.Pullthespoolretaineruptoremoveitandremovethespool.
4.Toinstallthenewspool,makesurethestringiscapturedin
oneoftheretainingslotsonthenewspool.Makesurethe
endofthestringextendsapproximately6inches(152mm).
5.Installthenewspoolsothatthestringalignswiththeeyelet
inthestringhead.Threadthestringintotheeyelet.
6.Pullthestringextendingfromthestringheadsothestring
releasesfromtheslotinthespool.
7.Reinstallthespoolretainerbydepressingtabsintoslotsand
pushingdownuntilspoolretainerclicksintoplace.
ReplacingtheString
1.Removethebattery.
2.Removethespool.SeeReplacingtheSpool(Figure19).
1
2
G015662
Figure20
1.Slotinupperspoolange2.Hole
12

Note:Removeanyoldstringremainingonthespool.
3.Thespoolwillacceptupto15feet(4.5m)ofstring.Use
only.065inch(1.6mm)diametermonolamentstring.
Note:Donotuseanyothergaugeortypeofstring,asthis
coulddamagethetrimmer.
4.Insertthestringintotheanchorholeintheupperpartof
thespool(Figure20).Windthestringontothespoolinthe
directionshownbythearrowsonthespool.
5.Placethestringintheslotontheupperspoolange,leaving
about6inches(152mm)extendedbeyondtheslot.
Note:Donotoverll.Afterwindingthestring,thereshould
beatleast1/4inch(6mm)betweenthewoundstringand
theoutsideedgeofthespool.
6.Replacethespoolandthespoolretainer.RefertoSpool
Replacementearlierinthismanual.
BatteryPackPreparationFor
Recycling
WARNING
Uponremoval,coverthebatterypack'sterminalswith
heavy-dutyadhesivetape.Donotattempttodestroy
ordisassemblethebatterypackorremoveanyofits
components.Lithium-ionbatteriesmustberecycledor
disposedofproperlyatthenearestbatteryrecycling
facility.
Service
Shouldthisitemneedservice,taketheproducttoyourAuthorized
ToroServiceDealer.YourToroDealerisspeciallytrainedtorepair
ToroproductsandwillensurethatyourTorostays“All”Toro.
Storage
•Cleanallforeignmaterialfromtheproduct.
•Storeitinawell-ventilatedplacethatisinaccessibleto
children.
•Keepawayfromcorrosiveagentssuchasgardenchemicals
andde-icingsalts.
Troubleshooting
Usingthebatterywhenitishotcanreducetheoperatingtime.
Thebatterywillautomaticallystopworkingwhenitisoverheated
topreventdamagetoit.Removethebatteryfromthechargerand
allowittocoolbeforeplacingitbackintothetrimmer.
Usingthebatterywhenthereismoistureontheleadscancause
thetrimmertomalfunction.Allowthebatterytodryorwipeitdry
beforeplacingitbackintothetrimmer.
Usingthetrimmertocutthickgrassintemperaturesabove90
Fahrenheit(32Celsius)mayreducetheruntime.Engagethe
powersavingfeaturetohelpincreasetheoperatingtime.Referto
UsingthePowerSaverFeature(page11).
13

Notes:
14

Notes:
15

TheToroPromise-ElectricProducts
ATwo-YearFullWarrantyforResidentialUsefortheUnitedStatesandCanada
TheToroCompanyanditsafliate,ToroWarrantyCompany,pursuanttoanagreementbetweenthem,jointlywarrantthisproductfortwoyearsagainst
defectsinmaterialorworkmanshipwhenusedfornormalresidentialpurposes.*
IfyouthinkyourToroProductcontainsadefectinmaterialsorworkmanship,ifyouhavequestionsorproblems,andbeforereturningthisproductcall
tollfree:
Trimmers:Blowers:Snowthrowers:
1-800-237-2654(US)
1-800-248-3258(Canada)1-888-367-6631(US) 1-888-430-1687(Canada)
1-800-574-3312(Mexico)
1-800-808-2963(US)
1-800-808-3072(Canada)
Toreceiveareplacementorrepair,atouroption,returnthecompleteunittotheseller.UnitedStatesandCanadacustomersmayreturntheirproduct,
withproofofpurchase,toanyAuthorizedServiceDealer.UnitedStatescustomersmayalsoreturntheirproduct,withproofofpurchase,postage
prepaid,totheToroServiceCenter,5500SEDelaware,Ankeny,IA50021.
Thiswarrantycoversproductdefectsonly.NeitherTheToroCompanynorToroWarrantyCompanyisliableforindirect,incidental,or
consequentialdamagesinconnectionwiththeuseoftheToroProductscoveredbythiswarranty,includinganycostorexpenseofproviding
substituteequipmentorserviceduringreasonableperiodsofmalfunctionornon-usependingcompletionofrepairsunderthiswarranty.
Somestatesdonotallowexclusionsofincidentalorconsequentialdamages,sotheaboveexclusionsmaynotapplytoyou.Thiswarranty
givesyouspeciclegalrights,andyoumayalsohaveotherrightswhichvaryfromstatetostate.
CountriesOtherthantheUnitedStatesandCanada
CustomerswhohavepurchasedToroproductsexportedfromtheUnitedStatesorCanadashouldcontacttheirToroDistributor(Dealer)toobtain
guaranteepoliciesforyourcountry,province,orstate.IfforanyreasonyouaredissatisedwithyourDistributor’sserviceorhavedifcultyobtaining
guaranteeinformation,contacttheToroimporter.Ifallotherremediesfail,youmaycontactusatT oroWarrantyCompany.
AustralianConsumerLaw
AustraliancustomerswillnddetailsrelatingtotheAustralianConsumerLaweitherinsidetheboxoratyourlocalToroDealer.
*Residentialusemeansuseoftheproductonthesamelotasyourhome.PartNumber374-0262Rev.D
374-0262RevD

FormNo.3375-32RevB
Desbrozadorainalámbricade30cm(12pulgadas)
Nºdemodelo51487—Nºdeserie313000001ysuperiores
Manualdeloperador
Siustedtienealgunapreguntaoalgúnproblema,contáctenosen
www.Toro.comollamealteléfonogratuito1-800-237-2654(EE.UU.)o
1-800-248-3258(Canadá)antesdedevolveresteproducto.
Normasgeneralesde
seguridad
ADVERTENCIA:Cuandoseutilizanaparatosdejardinería
eléctricos,esnecesarioobservarunasnormasbásicasde
seguridad,incluyendolassiguientes,andereducirelriesgode
incendio,descargaeléctricaylesionespersonales:
Leatodaslasinstrucciones.
Eltérmino"herramientaeléctrica"queapareceenlasadvertencias
sereeresiempreaunaherramientaaccionadaporelsuministro
eléctricodelared(concable)ounaherramientaeléctrica
accionadaporbatería(sincable).
1.Seguridaddelazonadetrabajo
A.Mantengalazonadetrabajolimpiaybieniluminada.
Laszonasdesordenadasuoscurassonunainvitación
alaccidente
B.Noutiliceherramientaseléctricasenatmósferas
explosivas,comoporejemploenpresencia
delíquidosinamables,gasesopolvo.Las
herramientaseléctricascreanchispasquepueden
inamarelpolvoolosvapores.
C.Mantengaalejadosaniñosyotraspersonas
mientrasutilizaunaherramientaeléctrica.Las
distraccionespuedenhacerquepierdaelcontrol.
2.Seguridadeléctrica
A.Laclavijadelaherramientaeléctricadebeserdel
tipocorrectoparaelenchufe.Nuncamodiqueel
enchufeenmodoalguno.Noutiliceadaptadoresde
enchufeconherramientaseléctricascontomade
tierra.Elusodeclavijassinmodicaryenchufescon
tomadetierrareduciráelriesgodedescargaeléctrica.
B.Evitetocarsuperciesconectadasatierra,tales
comotuberías,radiadores,cocinasyrefrigeradores.
Hayunmayorriesgodedescargaeléctricasisucuerpo
hacetierra.
C.Noexpongalasherramientaseléctricasalalluvia
oacondicioneshúmedas.Sientraaguaenuna
herramientaeléctrica,elriesgodedescargaeléctrica
aumenta.
D.Nomaltrateelcable.Noutiliceelcablenuncapara
transportar,arrastrarodesenchufarlaherramienta
eléctrica.Mantengaelcablealejadodelcalor,del
aceite,debordescortantesydepiezasmóviles.
Loscablesdañadosoenredadosaumentanelriesgo
dedescargaeléctrica.
E.Siutilizaunaherramientaeléctricaenelexterior,
utiliceuncablealargadoradecuadoparaelusoen
exteriores.Elusodeuncableapropiadoparaeluso
enexterioresreduceelriesgodedescargaeléctrica.
F.Sinoesposibleevitarelusodeunaherramienta
eléctricaenunlugarhúmedo,utiliceunsuministro
eléctricoprotegidoporundispositivodecorriente
residual(RCD).ElusodeunRCDreduceelriesgode
descargaeléctrica.
3.Seguridadpersonal
A.Manténgasealerta,estéatentoaloqueestá
haciendoyutiliceelsentidocomúnmientrasutiliza
unaherramientaeléctrica.Noutiliceunherramienta
eléctricasiestácansadoobajolainuenciade
drogas,alcoholomedicamentos.Unabrevefalta
deatenciónmientrasutilizaunaherramientaeléctrica
puedeprovocarlesionespersonalesgraves.
B.UtiliceequiposdeprotecciónpersonalLleve
protecciónocularsiempre.Elusodeequiposde
protecciónpersonalcomomascarillas,calzadode
seguridadantideslizante,cascoyprotecciónauditiva,
encondicionesapropiadas,reduciráelriesgode
lesionespersonales.
C.Eviteelencendidoaccidental.Asegúresedequeel
interruptorestáenlaposicióndeapagadoantes
deconectarlaherramientaalatomadecorriente
y/oalabatería,yantesdelevantarotransportarla
herramienta.Transportarlasherramientaseléctricas
coneldedosobreelinterruptoroenchufarherramientas
eléctricasconelinterruptorenlaposicióndeencendido
esunainvitaciónalaccidente.
D.Retirecualquierllavedeajusteantesdeencender
laherramientaeléctrica.Unallaveolvidadaenun
componentegiratoriodeunaherramientaeléctrica
puededarlugaralesionespersonales.
E.Nointentealcanzarzonasdemasiadoalejadas.Pise
rmeymantengaelequilibrioentodomomento.
Estopermiteunmayorcontroldelaherramientaen
situacionesimprevistas.
F.Utilicelaropaadecuada.Nolleveropasojoyas
sueltas.Mantengaelpelo,laropaylosguantes
alejadosdelaspiezasmóviles.Laropasuelta,las
joyasyelpelolargopuedenquedaratrapadosen
piezasmóviles.
G.Siexistendispositivosparalaconexióndesistemas
derecogidayextraccióndepolvo,asegúresede
conectarlosyusarloscorrectamente.Elusode
estosdispositivospuedereducirlosriesgosasociados
conelpolvo.
©2012—TheToro®Company
8111LyndaleAvenueSouth
Bloomington,MN55420
Registresuproductoenwww.Toro.com.Traduccióndeloriginal(ES)
ImpresoenChina.
Reservadostodoslosderechos*3375-32*B

H.Mantengalasmanosylospiesalejadosdelazona
decorte.
4.Usoycuidadodelasherramientaseléctricas
A.Nofuercelaherramientaeléctrica.Utilicela
herramientaeléctricaadecuadaparaeltrabajoa
realizar.Laherramientaeléctricacorrectarealizaráel
trabajomejoryconmayorseguridadalavelocidad
paralaquefuediseñada.
B.Noutilicelaherramientaeléctricasielinterruptor
nolaenciendeyapaga.Cualquierherramienta
eléctricaquenopuedasercontroladaconelinterruptor
espeligrosaydebeserreparada.
C.Desconectelaclavijadelenchufey/odesconecte
labateríadelaherramientaeléctricaantesde
realizarcualquierajuste,cambiardeaccesorio
oalmacenarlaherramienta.Estasmedidasde
seguridadpreventivasreducenelriesgodeunarranque
accidentaldelaherramientaeléctrica.
D.Sinolaestáusando,guardelaherramientaeléctrica
fueradelalcancedelosniños,ynopermita
quelautilicenpersonasnofamiliarizadasconla
herramientaeléctricaoconestasinstruccionesde
usodelaherramientaeléctrica.Lasherramientas
eléctricassonpeligrosasenmanosdeusuarios
inexpertos.
E.Guardebajotecholosaparatosquenoseestán
utilizando.Cuandonoseestánutilizando,losaparatos
debenguardarseenunlugarseco,enaltoobajollave,
yfueradelalcancedelosniños.
F.Mantenimientodelasherramientaseléctricas.
Compruebequelaspiezasmóvilesestán
correctamentealineadasyquesemueven
librementesinagarrotarse,quenohaypiezasrotas,
yquenohayotrascircunstanciasquepodrían
afectaralusodelaherramientaeléctrica.Si
existendaños,hagarepararlaherramientaeléctrica
antesdeusarla.Muchosaccidentessedebena
unmantenimientodecientedelasherramientas
eléctricas.
G.Mantengalasherramientasdecortealadasy
limpias.Unaherramientadecortebienmantenidacon
losbienaladosesmásfácildecontrolaryhaymenos
probabilidadesdequeseagarrote.
H.Utilicelaherramienta,losaccesorios,lasbrocas,
etc.,segúnloindicadoenestasinstruccionesyde
lamaneraprevistaparacadatipodeherramienta
eléctrica,teniendoencuentalascondicionesde
trabajoyeltrabajoarealizar.Elusodelaherramienta
eléctricaparaoperacionesdiferentesdelasprevistas
podríadarlugaraunasituacióndepeligro.
I.Mantengalosprotectorescolocadosyenbuen
estadodefuncionamiento.
5.Mantenimiento
Elmantenimientodesuherramientaeléctricadebeser
realizadoporuntécnicodereparacionesdebidamente
cualicado,utilizandoúnicamentepiezasderepuesto
idénticas.Sólodeestamanerasegarantizael
mantenimientodelaseguridaddelaherramientaeléctrica.
6.Seguridaddelasbaterías
A.Nocargueelaparatobajolalluviaoenlugares
húmedos.
B.Noutiliceaparatosalimentadosporbateríabajola
lluvia.
C.Utiliceúnicamentebateríasdelsiguientetipoytamaño:
bateríaToromodelo88504o88506ycargadorde
bateríamodelo88503.
D.Retireodesconectelabateríaantesderealizar
tareasdemantenimientoolimpieza,yantesderetirar
materialesdelaparatodejardinería.
E.Notirelabateríausadaalfuego.Lasceldaspueden
explosionar.Compruebesilanormativalocalcontiene
algunainstrucciónespecialsobrelaeliminacióndelas
baterías.
F.Noabranimutilelabatería.Elelectrolitoliberadoes
corrosivoypuedecausardañosenlosojosolapiel.
Puedesertóxicosiesingerido.
G.Almanejarlasbaterías,tengacuidadodenohacer
cortacircuitoconmaterialesconductores,talescomo
anillos,pulserasollaves.Labateríaoelconductor
puedenrecalentarseycausarquemaduras.
H.Eltiempodecargadelabateríaserámayorsila
temperaturanoestáenelintervalode5a40°C(41a
104°F)durantelacarga.
GUARDEESTASINSTRUCCIONES
2

Pegatinasdeseguridadeinstrucciones
Laspegatinaseinstruccionesdeseguridadestánalavistadeloperadoryestánubicadascercadecualquierzona
depeligropotencial.Sustituyacualquierpegatinaqueestédañadaoquefalte.
SímboloNombreDesignación/explicación
CCCorrientecontinuaTipodecorriente
VVoltiosVoltaje(Tensión)
121–7615
121–7614
125–3227
1.Advertencia–leaelManualdeloperador;noutilicela
máquinaencondicioneshúmedas;lleveprotecciónocular.
125–3291
121–7602
125–3226
3

121–7606
4
