Torque Fitness MJ-CORE User manual

MJ-CORE CORE
MJ-CORE CORE
MJ-CORE CABLE TECHNOLOGY CORE

EXPLODED DIAGRAM

PARTS LIST - STEP 1
ITEM PART NUMBER DESCRIPTION QTY
1 DABE03831416NU Cap Head Screw 3/8”x 3 1/4” L 2
2 DABE03843416NU Cap Head Screw 3/8”x 4 3/4”” L 4
3 DB2E03811000U Lock Nut 3/8”x 11t 6
4 DC120010510U 3/8” Flat Washer 8
5 DC322010015U 3/8” Curved Washer 4
6 A05-0212 Alum. Collar w/ Set Screw 2
7 MJ-T Tower Assembly 1
8 P01-5184 Guide Rod 2
9 P02-6927 Spacer Plate (used when without Shroud) 1
10 P04-4404 Top Pulley Bracket 1
11 P06-0034 Weight Stack Cushion 2
12 P10-0862 WEIGHT PLATE, 10 lb 15
13 P11-0210 Selector Pin 1
14 P20-5011 Bottom Tube Assy 1
15 P20-5014 Top Plate w/ Selector Stem Assy 1
Position Bottom Tube Assembly (14) in place prior to installing weight stack.
After weight stack is assembled, raise guide rods and hold in elevated position with bolts used in Bottom Tube Assembly.
Raise Collars (6) to the top of the guide rods and secure in place using Allen wrench.
Clean surface of weight stack and install weight stack labels.

1
4
3
9
10
12
15
2
5
3
6
13
7
14
11
4
8
2
ASSEMBLY - STEP 1
Note: If optional shrouds are
to be assembled, replace item
9 with upper shroud bracket
found in shroud box.

PARTS LIST - STEP 2
ITEM PART NUMBER DESCRIPTION QTY
1 DABE03811416YBU Cap Head Screw 3/8”x 1 1/4” L with blue patch 8
2 DABE03821416YU Cap Head Screw 3/8”x 2 1/4” L with blue patch 2
3 DABE03830016ANU Cap Head Screw 3/8”x 3” L 2
4 DABE03861416NU Cap Head Screw 3/8”x 6 1/4” L 4
5 DB2E03811000U Lock Nut 3/8”x 11t 6
6 DC120010510U 3/8” Flat Washer 10
7 DC322010015U 3/8” Curved Washer 12
8 MJ-T Tower Assembly 1
9 P04-4399 Connect Tube 1
10 P04-4401 Swivel Pulley, Left 1
11 P04-4402 Swivel Pulley, Right 1
12 P07-0434 Seat Pad 1
13 P07-0436 Knee Pad 1
14 P07-0438 Back Pad 1
15 P20-5012 Upright Assy 1
16 DC100035000B C-Clip STW-35 2
