Toshiba RAV-SM560KRT-E User manual

Please read this Installation Manual carefully before installing the Air Conditioner.
• This Manual describes the installation method of the indoor unit.
• For installation of the outdoor unit, follow the Installation Manual attached to
the outdoor unit.
Veuillez lire attentivement ce Manuel d’installation avant d’installer le climatiseur.
• Ce manuel décrit la procédure d’installation de l’unité intérieure.
• Pour installer l’unité extérieure, reportez-vous au Manuel d’installation fourni
avec l’unité extérieure.
Bitte lesen Sie dieses Handbuch sorgfältig, bevor Sie mit der Installation des Klimagerätes beginnen.
• In diesem Handbuch wird die Installation der Raumeinheit beschrieben.
• Um die Außeneinheit zu installieren, folgen Sie den Anweisungen in dem Handbuch, das der Außeneinheit beiliegt.
Prima di installare il condizionatore d’aria, leggere con attenzione questo manuale d’installazione.
• Questo manuale descrive il metodo d’installazione dell’unità interna.
• Per l’installazione dell’unità esterna, fare riferimento al manuale d’installazione fornito insieme all’unità esterna.
Lea atentamente este Manual de instalación antes de proceder a la instalación del aparato de aire acondicionado.
• Este manual describe el método de instalación de la unidad interior.
• Para la instalación de la unidad exterior, consulte el Manual de instalación que acompaña a la unidad exterior.
Leia atentamente o presente Manual de Instalação antes de instalar o Ar Condicionado.
• O presente manual descreve o método de instalar a unidade interior.
• Para a instalação de uma unidade exterior, siga o Manual de Instalação que acompanha a unidade exterior.
Lees deze installatiehandleiding zorgvuldig door voordat u de airconditioner gaat installeren.
• Deze installatiemethode beschrijft de installatiemethode van de binnenunit.
• Zie voor de installatie van de buitenunit, de installatiehandleiding bij de buitenunit.
Ðáñáêáëþ äéáâÜóôå ðñïóå÷ôéêÜ ôï Åã÷åéñßäéï ÅãêáôÜóôáóçò ðñéí áðü ôçí åãêáôÜóôáóç ôïõ Êëéìáôéóôéêïý.
• Ôï ðáñüí Åã÷åéñßäéï ðåñéãñÜ åé ôç ìÝèïäï åãêáôÜóôáóçò ôçò åóùôåñéêÞò ìïíÜäáò.
• Ãéá ôçí åãêáôÜóôáóç ôçò åîùôåñéêÞò ìïíÜäáò, áêïëïõèÞóôå ôï Åã÷åéñßäéï ÅãêáôÜóôáóçò ðïõ óõíïäåýåé ôçí
åîùôåñéêÞ ìïíÜäá.
INSTALLATION MANUAL
MANUEL D’INSTALLATION
INSTALLATIONS-HANDBUCH
MANUALE D’INSTALLAZIONE
MANUAL DE INSTALACIÓN
MANUAL DE INSTALAÇÃO
INSTALLATIEHANDLEIDING
ÅÃ×ÅÉÑÉÄÉÏ ÅÃÊÁÔÁÓÔÁÓÇÓ
AIR CONDITIONER (SPLITTYPE)
CLIMATISEUR (TYPE SPLIT)
KLIMAGERÄT (SPLIT-SYSTEM)
CONDIZIONATORE D'ARIA (TIPO MULTIAMBIENTI)
APARATO DE AIRE ACONDICIONADO (TIPO SPLIT)
AR CONDICIONADO (TIPO SPLIT)
AIRCONDITIONER (GESPLITSTTYPE)
ÊËÉÌÁÔÉÓÔÉÊÏ (ÔÕÐÏÓ SPLIT)
<High-WallType>/<Type mural haut>
<WandmontierterTyp>/<Tipo a condotto nascosto>
<Modelo de pared>/<Tipo Mural>
<Hoog-Wandtype>/<Ôýðïò Õøçëïý Ôïß÷ïõ>
Heat Pump Model/Modèle à thermopompe
Geräte mit Heizung/Modello con pompa di riscaldamento
Modelo con bomba de calor/Modelo de bomba térmica
Model met warmtepomp/ÌïíôÝëï ìå Áíôëßá Èåñìüôçôáò
Indoor Unit/Unité intérieure Outdoor Unit/Unité extérieure
Raumeinheit/Unità interna Außengerät/Unità esterna
Unidad interior/Unidade interior Unidad exterior/Unidade exterior
Binnenunit/ÅóùôåñéêÞ ÌïíÜäá Buitenunit/ÅîùôåñéêÞ ÌïíÜäá
RAV-SM560KRT-E RAV-SM560AT-E
RAV-SM800KRT-E RAV-SM800AT-E

ADOPTION OF NEW REFRIGERANT
This Air Conditioner is a new type which adopts a new refrigerant HFC (R410A) instead of the conventional refriger-
ant R22 in order to prevent destruction of the ozone layer.
UTILISATION DU NOUVEAU REFRIGERANT
Ce climatiseur est d’un type inédit qui utilise le nouveau réfrigérant HFC (R410A) au lieu du réfrigérant traditionnel
R22, afin d’éviter la destruction de la couche d’ozone.
EINFÜHRUNG EINES NEUEN KÜHLMITTELS
Dies ist ein neuartiges Klimagerät.Anstatt des herkömmlichen Kühlmittels R22 verwendet es das neue ozonschicht-
schonende HFC Kühlmittel R410A.
ADOZIONE DI UN NUOVO REFRIGERANTE
Questo condizionatore d'aria è di un tipo nuovo che adotta un nuovo refrigerate HFC (R410A) al posto del
refrigerante convenzionale R22, per prevenire la distruzione dello strato di ozono dell'atmosfera terrestre.
ADOPCIÓN DE NUEVO REFRIGERANTE
Este aparato de aire acondicionado es un modelo reciente que incorpora el nuevo refrigerante HFC (R410A) en
lugar del refrigerante convencional R22 para así evitar daños en la capa de ozono.
ADOPÇÃO DO NOVO REFRIGERANTE
Este ar condicionado é um modelo novo que adopta um novo refrigerante HFC (R410A) em vez do refrigerante
convencional R22 para evitar a destruição da cama de ozono.
ÕÉÏÈÅÔÇÓÇ ÍÅÏÕ ØÕÊÔÉÊÏÕ
Ôï ðáñüí Êëéìáôéóôéêü åßíáé íÝïò ôýðïò ðïõ õéïèåôåß íÝï øõêôéêü HFC (R410 ) óôç èÝóç ôïõ óõìâáôéêïý øõêôéêïý
R22 ðñïêåéìÝíïõ íá âïçèÞóåé óôçí ðñïóôáóßá ôïõ üæïíôïò.
TOEPASSING VAN EEN NIEUW KOELMIDDEL
Deze airconditioner is een nieuwe type dat werkt met een nieuw koelmiddel HFC (R410A) in plaats van met het
conventionele koelmiddel R22, als bijdrage om de aantasting van de ozonlaag te reduceren.

Accessory parts and Parts to be procured locally .............. 1
1 PRECAUTIONS FOR SAFETY ......................................... 2
2 INSTALLATION PROCEDURE ......................................... 4
3 SELECTION OF INSTALLATION PLACE ........................ 5
4 INSTALLATION OF INDOOR UNIT .................................. 5
5 DRAIN PIPINGWORK ...................................................... 6
6 REFRIGERANT PIPING.................................................... 8
7 EVACUATING .................................................................... 9
8 ELECTRICALWORK ...................................................... 12
9 IMPROVING SYSTEM EFFICIENCY .............................. 14
10 FINAL INSTALLATION CHECKS ................................... 14
11 ENVIRONMENT .............................................................. 16
CONTENTS
SOMMAIRE
INHALT
INDICE
CONTENIDO
ÍNDICE
ÐÅÑÉÅ×ÏÌÅÍÁ
INHOUD
ITALIANOESPAÑOLPORTUGUÊSÅËËÇÍÉÊÁ FRANCAIS
DEUTSCHNEDERLANDS ENGLISH
Pièces accessoires et pièces non fournies........................ 17
1 MESURES DE SECURITE.............................................. 18
2 PROCEDURE D’INSTALLATION.................................... 20
3 SELECTION DU LIEU D’INSTALLATION ...................... 21
4 INSTALLATION DE L’UNITE INTERIEURE .................... 21
5 INSTALLATION DESTUYAUX D’EVACUATION ............. 22
6 TUYAUX DE REFRIGERANT.......................................... 24
7 EVACUATION DE L’AIR .................................................. 25
8 INSTALLATION ELECTRIQUE ....................................... 28
9 AMELIORATION DE L’EFFICACITE DU SYSTEME ...... 30
10 DERNIERESVERIFICATIONS DE L’INSTALLATION .... 30
11 ENVIRONNEMENT ......................................................... 32
Zubehör und bauseits bereitzustellendeTeile ................... 33
1 SICHERHEITSVORKEHRUNGEN .................................. 34
2 INSTALLATIONSABLAUF .............................................. 36
3 AUSWAHL DES AUFSTELLUNGSORTES .................... 37
4 INSTALLATION DER RAUMEINHEIT ............................. 37
5 INSTALLATION DER ABLAUFROHRE .......................... 38
6 KÜHLMITTELLLEITUNGEN ........................................... 40
7 ENTLÜFTEN DER ROHRLEITUNGEN........................... 41
8 ELEKTROINSTALLATION .............................................. 44
9 OPTIMIERUNG DER SYSTEMLEISTUNG..................... 46
10 ÜBERPRÜFUNGEN NACH DER INSTALLATION ......... 46
11 UMWELT ......................................................................... 48
Accessori e parti da acquistare sul posto ......................... 49
1 PRECAUZIONI PER LA SICUREZZA ............................ 50
2 PROCEDURA D’INSTALLAZIONE................................. 52
3 SCELTA DEL POSTO D’INSTALLAZIONE .................... 53
4 INSTALLAZIONE DELL’UNITÀINTERNA...................... 53
5 LAVORO PERTUBAZIONE DI SCARICO ...................... 54
6 TUBAZIONI DEL REFRIGERANTE................................ 56
7 SVUOTAMENTO.............................................................. 57
8 RETE DEI COLLEGAMENTI ELETTRICI....................... 60
9 PER AUMENTARE IL RENDIMENTO DEL SISTEMA ... 62
10 CONTRROLLI DI FINE INSTALLAZIONE ...................... 62
11 AMBIENTE ...................................................................... 64
Componentes accesorios y componentes de obtención local ... 65
1 PRECAUCIONES PARA SU SEGURIDAD ..................... 66
2 PROCEDIMIENTO DE INSTALACIÓN............................ 68
3 SELECCIÓN DEL LUGAR DE INSTALACIÓN............... 69
4 INSTALACIÓN DE LA UNIDAD INTERIOR .................... 69
5 TRABAJOS DE CANALIZACIÓN DE DESAGÜE .......... 70
6 TUBERÍA DE REGRIGERANTE..................................... 72
7 EVACUACIÓN.................................................................. 73
8 TRABAJOS EN EL SISTEMA ELÉCTRICO................... 76
9 MEJORAR LA EFICACIA DEL SISTEMA ...................... 78
10 COMPROBACIONES FINALES...................................... 78
11 MEDIO AMBIENTE ......................................................... 80
Acessórios e peças adquiridas localmente ....................... 81
1 PRECAUÇÕES DE SEGURANÇA ................................. 82
2 PROCEDIMENTO DE INSTALAÇÃO ............................. 84
3 SELECÇÃO DO LOCAL DE INSTALAÇÃO ................... 85
4 INSTALAÇÃO DA UNIDADE INTERIOR ........................ 85
5 INSTALAÇÃO DATUBAGEM DE DRENAGEM ............. 86
6 TUBAGEM DE REFRIGERANTE.................................... 88
7 EVACUAÇÃO .................................................................. 89
8 LIGAÇÕES ELÉCTRICAS .............................................. 92
9 MELHORAR A EFICÁCIA DO SISTEMA ....................... 94
10 VERIFICAÇÕES DE INSTALAÇÃO FINAIS................... 94
11 AMBIENTE ...................................................................... 96
Ðáñåëêüìåíá áíôáëëáêôéêÜ êáé ÅîáñôÞìáôá áðü ôçí ôïðéêÞ áãïñÜ .. 113
1ÐÑÏÖÕËÁÎÅÉÓ ÁÓÖÁËÅÉÁÓ ......................................... 114
2ÄÉÁÄÉÊÁÓÉÁ ÅÃÊÁÔÁÓÔÁÓÇÓ ....................................... 116
3ÅÐÉËÏÃÇ ÔÏÕ ×ÙÑÏÕ ÅÃÊÁÔÁÓÔÁÓÇÓ ..................... 117
4ÅÃÊÁÔÁÓÔÁÓÇ ÔÇÓ ÅÓÙÔÅÑÉÊÇÓ ÌÏÍÁÄÁÓ ........... 117
5ÅÃÊÁÔÁÓÔÁÓÇ ÓÙËÇÍÙÓÅÙÍ ÁÐÏÓÔÑÁÃÃÉÓÇÓ ..... 118
6ÓÙËÇÍÙÓÅÉÓ ØÕÊÔÉÊÏÕ ............................................ 120
7ÅÊÊÅÍÙÓÇ ................................................................... 121
8ÇËÅÊÔÑÏËÏÃÉÊÁ ........................................................ 124
9ÅËÔÉÙÓÇ ÔÇÓ ÁÐÏÄÏÓÇÓ ÔÏÕ ÓÕÓÔÇÌÁÔÏÓ ...... 126
10 ÔÅËÉÊÏÉ ÅËÅÃ×ÏÉ ÅÃÊÁÔÁÓÔÁÓÇÓ ........................... 126
11 ÐÅÑÉ ÁËËÏÍ ............................................................... 128
Accessoires en niet meegeleverde onderdelen ................. 97
1 VOORZORGSMAATREGELENVOOR UWVEILIGHEID 98
2 INSTALLATIEPROCEDURE ......................................... 100
3 KEUZEVAN DE LOCATIEVOOR DE INSTALLATIE ... 101
4 INSTALLATIEVAN DE BINNENUNIT ........................... 101
5 AFVOERLEIDINGEN .................................................... 102
6 KOELMIDDELLEIDINGEN ........................................... 104
7 ONTLUCHTEN .............................................................. 105
8 ELEKTRISCH GEDEELTE ............................................ 108
9 DE EFFICIENCYVAN HET SYSTEEMVERBETEREN . 110
10 LAATSTE CONTROLESVAN DE INSTALLATIE ......... 110
11 MILIEU........................................................................... 112

1
Accessory parts and Parts to be procured locally
HAccessory parts
Part name
Installation plate
Installation Manual
Owner’s Manual
Part name
Mounting screw
Ø4mm x 25mm
Pattern paper
Q’ty
1
1
1
Q’ty
8
1
Shape Shape
HParts to be procured locally
Connecting pipe (Liquid side)
(6.35mm (diam.), Nominal (diam.) 1/4” thick 0.8mm)
RAV-SM560KRT-E, RAV-SM560AT-E
(9.52mm (diam.), Nominal (diam.) 3/8” thick 0.8mm)
RAV-SM800KRT-E, RAV-SM800AT-E
Connecting pipe (Gas side)
(12.7mm (diam.), Nominal (diam.) 1/2” thick 0.8mm)
RAV-SM560KRT-E, RAV-SM560AT-E
(15.9mm (diam.), Nominal (diam.) 5/8” thick 1.0mm)
RAV-SM800KRT-E, RAV-SM800AT-E
Power supply cord
2.5mm² (H07RN-F or 245IEC66) or 3.5mm² (AWG-12)
Connecting cable
H07RN-F or 245IEC66 (1.0mm² or more)
Thermal insulation for refrigerant pipe
(10mm or more, thermal insulating foam polyethylene)
Thermal insulation for drain pipe
(10mm or more, foam polyethylene)
Drain pipe (Outer 26mm (diam.))
Tapes
Grounding cable (2.0mm (diam.) or more)
FAN SPEED
TEMP.
FAN
COOL
DRY
HEAT
AUTO
STANDBY
FILTER
PRE-HEAT
DEFROST
LOUVER
MANUAL
CENTRAL
CHECK
AUTO
FIX
LOUVER
<Separate sold parts>
Part name
Wired remote
controller
Q’ty
1
Shape

2
1 PRECAUTIONS FOR SAFETY
•Ensure that all Local, National and International regulations are satisfied.
•Read this “PRECAUTIONS FOR SAFETY”carefully before Installation.
•The precautions described below include the important items regarding safety. Observe them without fail.
•After the installation work, perform a trial operation to check for any problem.
Follow the Owner’s Manual to explain how to use and maintain the unit to the customer.
•Turn off the main power supply switch (or breaker) before the unit maintenance.
•Ask the customer to keep the Installation Manual together with the Owner’s Manual.
CAUTION New Refrigerant Air Conditioner Installation
•THIS AIR CONDITIONER ADOPTS THE NEW HFC REFRIGERANT (R410A) WHICH DOES NOT
DESTROY OZONE LAYER.
The characteristics of R410A refrigerant are ; easy to absorb water, oxidizing membrane or oil, and its pressure
is approx. 1.6 times higher than that of refrigerant R22. Accompanied with the new refrigerant, refrigerating oil
has also been changed. Therefore, during installation work, be sure that water, dust, former refrigerant, or
refrigerating oil does not enter the refrigerating cycle.
To prevent charging an incorrect refrigerant and refrigerating oil, the sizes of connecting sections of charging
port of the main unit and installation tools are charged from those for the conventional refrigerant.
Accordingly the exclusive tools are required for the new refrigerant (R410A).
For connecting pipes, use new and clean piping designed for R410A, and please care so that water or dust does
not enter. Moreover, do not use the existing piping because there are problems with pressure-resistance force
and impurity in it.
CAUTION To Disconnect the Appliance from Main Power Supply.
This appliance must be connected to the main power supply by means of a switch with a contact separation of
at least 3 mm.
The installation fuse (25A D type ) must be used for the power supply line of this conditioner.
WARNING
•Ask an authorized dealer or qualified installation professional to install/maintain the air
conditioner.
Inappropriate installation may result in water leakage, electric shock or fire.
•Turn off the main power supply switch or breaker before attempting any electrical work.
Make sure all power switches are off. Failure to do so may cause electric shock.
•Connect the connecting cable correctly.
If the connecting cable is connected in a wrong way, electric parts may be damaged.
•When moving the air conditioner for the installation into another place, be very careful not
to enter any gaseous matter other than the specified refrigerant into the refrigeration cycle.
If air or any other gas is mixed in the refrigerant, the gas pressure in the refrigeration cycle becomes
abnormally high and it may resultingly causes pipe burst and injuries on persons.
•Do not modify this unit by removing any of the safety guards or by by-passing any of the
safety interlock switches.
•Exposure of unit to water or other moisture before installation may cause a short-circuit of
electrical parts.
Do not store it in a wet basement or expose to rain or water.
ENGLISH

3
•After unpacking the unit, examine it carefully if there are possible damage.
•Do not install in a place that might increase the vibration of the unit.
•To avoid personal injury (with sharp edges), be careful when handling parts.
•Perform installation work properly according to the Installation Manual.
Inappropriate installation may result in water leakage, electric shock or fire.
•When the air conditioner is installed in a small room, provide appropriate measures to
ensure that the concentration of refrigerant leakage occur in the room does not exceed the
critical level.
•Install the air conditioner securely in a location where the base can sustain the weight
adequately.
•Perform the specified installation work to guard against an earthquake.
If the air conditioner is not installed appropriately, accidents may occur due to the falling unit.
•If refrigerant gas has leaked during the installation work, ventilate the room immediately.
If the leaked refrigerant gas comes in contact with fire, noxious gas may generate.
•After the installation work, confirm that refrigerant gas does not leak.
If refrigerant gas leaks into the room and flows near a fire source, such as a cooking range, noxious gas might
generate.
•Electrical work must be performed by a qualified electrician in accordance with the
Installation Manual. Make sure the air conditioner uses an exclusive power supply.
An insufficient power supply capacity or inappropriate installation may cause fire.
•Use the specified cables for wiring connect the terminals securely fix. To prevent external
forces applied to the terminals from affecting the terminals.
•Be sure to provide grounding.
Do not connect ground wires to gas pipes, water pipes, lightning rods or ground wires for telephone cables.
•Conform to the regulations of the local electric company when wiring the power supply.
Inappropriate grounding may cause electric shock.
•Do not install the air conditioner in a location subject to a risk of exposure to a combustible
gas.
If a combustible gas leaks, and stays around the unit, a fire may occur.
1 PRECAUTIONS FOR SAFETY

4
2 INSTALLATION PROCEDURE
Installation Diagram of Indoor Unit
Air filter
Min. 6 mm thick heat resisting polyethylene foam
Bottom
Right
Rear left
Rear
Left
Cut the piping hole
sloped slightly
Wall
For rear left and side pipe exit
Do not allow the drain hose to sag.
Make sure to run the drain hose
sloped downward.
The auxiliary piping can be connected
the left, rear left, rear, right or bottom.
Insulate the refrigerant pipes
separately with insulation, not together.
Insert the cushion between the
indoor unit and wall, and lift indoor
unit to make work easier.
Hook
1 Installation
plate
Hook
170mm
or more
65mm or more
170mm
or more
Pipe
insulation
Mounting the Installation Plate
For installation of the indoor unit,
use the paper template included.
When the installation plate is directly mounted on the wall
1. Securely fix the installation plate to the wall by screwing it through the upper and lower fixing holes.
2. To mount the installation plate on a concrete wall with anchor bolts, utilize the anchor bolt holes as illustrated in
the above figure.
3. Attach the installation plate horizontally to the wall.
CAUTION
When installing the installation plate with mounting screw, do not use the anchor bolt hole.
Otherwise the unit may fall down and result in personal injury and property damage.
Ø5mm hole
Clip anchor
(local parts)
Mounting screw
Ø4 x 25mm
Anchor bolt
Projection
15mm or less
Indoor unit
Weight
Installation
plate
Pipe holeMounting screw
Mounting screw
Pipe hole Thread
Hook
Hook
Hook
0
80100
100mm
100mm
180
Indoor unit
55 65
170
120

5
3 SELECTION OF INSTALLATION PLACE
WARNING
•Install the air conditioner where there is sufficient strength to withstand the weight of the unit.
If the strength is not sufficient, the unit may fall down resulting in injury.
CAUTION
Upon approval of the customer, install the air conditioner in a place that satisfies the
following conditions.
•Place where the unit can be installed horizontally.
•Place where a sufficient servicing space can be ensured for safe maintenance and check.
•Place where drained water will not cause any problem.
Avoid installing in the following places.
•Place exposed to air with high salt content (seaside area), or place exposed to large quantities of sulfide gas
(hot spring). (Should the unit be used in these places, special protective measures are needed.)
•Place exposed to oil, vapor, oil smoke or corrosive gas.
•Place where organic solvent is used nearby.
•Place close to a machine generating high frequency.
•Place where the discharged air blows directly into the window of the neighboring house. (For outdoor unit)
•Place where noise of the outdoor unit is easy to transmit.
(When installing the air conditioner on the boundary with the neighbor, pay due attention to the level of noise.)
•Place with poor ventilation.
•Where the ceiling height is more than 3m.
•Where the floor/wall/ceiling structure is unable to support the weight of the unit.
4 INSTALLATION OF INDOOR UNIT
WARNING
•Install the air conditioner certainly at a place to sufficiently withstand the weight.
If the strength is insufficient, the unit may fall down resulting in human injury.
•Perform a specified installation work to guard against an earthquake.
An incomplete installation can cause accidents by the units falling and dropping.
Locate the unit so as to provide uniform circulation of chilled air.
Avoid locating the unit as shown in the bad-marked figures below :
If a good location is not possible, use a fan to circulate the air evenly throughout the room.
Good location
Evenly hot or cooled Bad location Shaded area well hot or cooled Bad location Shaded area well hot or cooled

6
5 DRAIN PIPING WORK
Piping and Drain Hose Installation
In case of right-side exit
•Cut out the knockout portion by the slits with a knife
or pair of wire cutters as necessary.
In case of downward pipe exit
•Cut out the knockout portion by the slits with a knife
or pair of wire cutters as necessary.
Piping via left-hand connection
When piping the refrigerant pipe and drain pipe at the left side or at the rear left side, follow the procedure below.
(An incomplete piping may cause lifting-out of the main unit form the wall surface.)
1. Using a cutter, etc., cut off the portion of the connecting pipe, which is applied with heat-insulator.
(In this time, be sure not to damage the pipe.)
Slit
(Body right)
Slit
(Body right)
2. After connection of the pipes, apply heat insulation to the naked
pipes with the shield pipes (Accessory) (Length: 360mm). In the
case of piping at the rear left side, cut off the shield pipe
(Accessory) by 250mm.
Connect the pipes so that pipe at gas side (Ø15.88 side) is set at
the upper side. (See the figure at the right.)
NOTE :
Using vinyl tape, seal surely the heat-insulated portions of the main
unit and the connecting pipes.
In order to prevent the water leak, set the slit portion of the shield
pipe upward and apply sealing.
Wind firmly the shield pipe and the naked pipe with the vinyl tape so
that a clearance will not generate.
(Do not use the other heat-insulation material than the shield pipe
(Accessory) for heat-insulation of the naked pipes.)
•Bend the connecting pipe so that it is laid within 43mm above
the wall surface. If the connecting pipe is laid exceeding
43mm above the wall surface, the indoor unit could be
unstable when set on the wall. When bending the connecting
pipes, always use a suitable bending tool to avoid damaging
the pipes.
Bend the connection pipe within a radius of 30mm.
To connect the pipe after installation of unit (figure)
NOTE :
If the pipe is bent incorrectly, the indoor unit could be unstable on the wall.
After passing the connecting pipe through the pipe hole, connect the connecting pipe to the auxiliary pipes and
insulate as necessary.
465mm
365mm Liquid side
Gas side
Outward form
of indoor unit
(To the front of the flare)
R 30mm
43mm
Use the handle of a screwdriver, etc.
80˚
250mm
360mm
45˚
(61.4mm)
Piping to left side
Cut off the heat-insulated portion at a position 250mm
from the flare nut end of the pipe (Ø9.52) at the liquid side.
(The cut portion is not used.)
Piping to rear left side
Liquid side (Ø9.52)
Cut off the heat-insulated portion at a position 360mm
from the flare nut end of the pipe (Ø9.52) at the liquid side.
(The cut portion is not used.)
Shield pipe
(Accessory)
Seal surely the connecting
part with vinyl tape.
Heat-insulation material
for pipes of the main unit Using vinyl tape, wind firmly the shield pipe and the naked pipe in this part so that a clearance will not generate.
Shield pipe (Accessory)
Connecting pipe
[Insertion of the shield pipe (Accessory)]
Heat-insulation material
for connecting pipe

7
CAUTION
•Bind the auxiliary pipes (two) and connecting cable with tape tightly. In case of left-side pipe exit and rear-left
exit, bind the auxiliary pipes (two) only with facing tape.
Gas side
(Be sure to set the gas side at upper side.)
Liquid side
Drain pipe
(Be sure to set the drain pipe at rear side.)
•Carefully arrange pipes so that any pipe does not stick out of the rear plate of the indoor unit.
•Carefully connect the auxiliary pipes and connecting pipes to each other and cut off the insulating tape wound
on the connecting pipe to avoid double-taping at the joint, then seal the joint with vinyl tape, etc.
•In order to reduce the possibility of condensed water being produced within the indoor unit, make sure to
insulate both the connecting pipes.
(Use a suitable form of insulation material specifically design designed for refrigeration pipe work.)
•When bending a pipe, ensure care is taken to prevent pipe damage.
Drainage
1. Run the drain hose sloped downwards.
50 mm
or more
Do not rise the drain hose. Do not form the drain hose
into the waved shape.
Do not put the
drain hose end
into water.
Do not put the drain
hose end into the
drainage ditch.
2. It is not possible to add water to the drain pan to
confirm correct drainage. To do this, the unit must be
operated in the COOL mode.
3. When connecting extension drain hose, insulate the
connecting part of extension drain hose with pipe
insulation.
Pipe insulation
Extension drain hose
Inside the room
Drain hose
CAUTION
Arrange the drain pipe to allow proper drainage from the unit. Incorrect drainage can result in condensation
problems.
This structure of this air conditioner is designed
condensed water, which may form on the back of the
indoor unit, into the drain pan.
Therefore, do not store the power cables and other parts
within the drain guide.
Space for
pipes
Wall
Drain
guide
5 DRAIN PIPING WORK

8
B
6 REFRIGERANT PIPING
Refrigerant Piping
1. If the outdoor units are to be mounted on a wall, make sure that the platform supporting is sufficiently strong.
The platform should be designed and manufactured to maintain its strength over a long period of time, and
sufficient consideration should be given to ensuring that the outdoor unit will not fall.
2. Use copper pipe with 0.8 mm or more thickness.
3. Flare nut and flare works are also different from those of the conventional refrigerant.
Take out the flare nut attached to the main unit of the air conditioner, and use it.
CAUTION
IMPORTANT 4 POINTS FOR PIPING WORK
1. Take away dust and moisture from the inside of the connecting pipes.
2. Tight connection (between pipes and unit)
3. Evacuate the air in the connecting pipes using VACUUM PUMP.
4. Check the gas leakage. (Connected points)
Permissible Piping Length and Head
Imperial (Wing nut type)
•Flaring dia meter size : A (Unit : mm) *In the case of flaring for R410A with the conventional
flare tool, pull out it approx. 0.5 mm more than that for
R22 to adjust to the specified flare size.
The copper pipe gauge is useful
for adjusting projection margin size.
+0
- 0.4
A
Flaring
Insert a flare nut into the pipe, and flare the pipe.
As the flaring sizes of R410A differ from those of refrigerant R22, the flare
tools newly manufactured for R410A are recommended.
However, the conventional tools can be used by adjusting projection margin
of the copper pipe.
•Projection margin in flaring : B (Unit : mm)
Rigid (Clutch type)
Outer diam. of
copper pipe
6.35
9.52
12.7
R410A tool used
R410A R22
0 to 0.5 (Same as left)
0 to 0.5 (Same as left)
0 to 0.5 (Same as left)
Conventional tool used
R410A R22
1.0 to 1.5 0.5 to 1.0
1.0 to 1.5 0.5 to 1.0
1.0 to 1.5 0.5 to 1.0
Outer diam. of copper pipe
6.35
9.52
12.7
R410A R22
1.5 to 2.0 1.0 to 1.5
1.5 to 2.0 1.0 to 1.5
2.0 to 2.5 1.5 to 2.0
Outer diam. of copper pipe
6.35
9.52
12.7
A
R410A R22
9.1 9.0
13.2 13.0
16.6 16.2
The maximum piping length from the outdoor to indoor unit
30 m (Without charge 20m) 50 m (Without charge 20m)
(RAV-SM560AT-E) (RAV-SM800AT-E)
The maximum height difference outdoor/indoor unit
Outdoor unit is above Outdoor unit is below
30m 15m

9
Tightening connection
Align the centers of the connecting pipes and tighten
the flare nut as far as possible with your fingers. Then
tighten the nut with a spanner and torque wrench as
shown in the figure.
CAUTION
•Do not apply excess torque. Otherwise, the nut
may crack depending on the conditions.
(Unit : N•m)
•Tightening torque of flare pipe connections
Pressure of R410A becomes higher than that of R22.
(Approx. 1.6 times) Therefore, using a torque
wrench, tighten firmly the flare pipe connecting
sections which connect the indoor and outdoor units
up to the specified tightening torque.
Incorrect connections may cause not only a gas
leakage, but also a trouble of the refrigeration cycle
or compressor damage.
Half union Flare nut
Externally
threaded side Internally
threaded side
Use a wrench to secure. Use a torque wrench to tighten.
Flare at
indoor unit side
Flare at
outdoor unit side
Outer diam. of copper pipe
6.35 mm (diam.)
9.52 mm (diam.)
12.7 mm (diam.)
15.9 mm (diam.)
Tightening torque
14 to 18 (1.4 to 1.8 kgf•m)
33 to 42 (3.3 to 4.2 kgf•m)
50 to 62 (5.0 to 6.2 kgf•m)
63 to 77 (6.3 to 7.7 kgf•m)
7 EVACUATING
AIR PURGE
Evacuate the air in the connecting pipes and in the
indoor unit using vacuum pump.
Do not use the refrigerant in the outdoor unit.
For details, see the manual of vacuum pump.
Use a vacuum pump
Be sure to use a vacuum pump with counter-flow
prevention function so that inside oil of the pump does
not flow backward into pipes of the air conditioner
when the pump stops.
1. Connect the charge hose from the manifold valve to
the service port of the gas side packed valve.
2. Connect the charge hose to the port of vacuum
pump.
3. Open fully the low pressure side handle of the
gauge manifold valve.
4. Operate the vacuum pump to start for evacuating.
Perform evacuating for about 35 minutes if the
piping length is total 30 meters for model SM560
and 50 meters for model SM800.
(assuming a pump capacity of 27 liters per minute.)
Then confirm that the compound pressure gauge
reading is –101 kPa ( –76 cmHg).
5. Close the low pressure side valve handle of gauge
manifold.
6. Open fully the valve stem of the packed valves
(both sides of Gas and Liquid).
7. Remove the charging hose from the service port.
8. Securely tighten the caps on the packed valves.
6 REFRIGERANT PIPING

10
<For RAV-SM800AT-E model>
•As shown in the figure, be sure to use a double
spanner to loosen or tighten the flare nut of the valve
at gas side. If using a single spanner, the nut cannot
be tightened with necessary tightening torque.
On the contrary, use a single spanner to loosen or
tighten the flare nut of the valve at liquid side.
SM800 type valve at gas side
Cover
Cap
Piping valve
Tightened
Flare nut
Loosened
Cover
Do not put the spanner or
torque wrench, etc. on
the cover.
The valve may be broken.
<For RAV-SM560AT-E model>
<For RAV-SM800AT-E model>
Hexagonal wrench is required.
Gas side (12.7 mm (diam.))
Gas side (9.52 mm (diam.))
Liquid side (6.35 mm (diam.))
Service port
50 to 62 N•m (5.0 to 6.2 kgf•m)
33 to 42 N•m (3.3 to 4.2 kgf•m)
14 to 18 N•m (1.4 to 1.8 kgf•m)
14 to 18 N•m (1.4 to 1.8 kgf•m)
Packed valve handling precautions
•Open the valve stem all the way out ; do not try to
open it beyond the stopper.
•Securely tighten the valve stem cap in torque as
follows:
Compound pressure gauge
Service port (Valve core (Setting pin))
Packed valve (Gas side)
Pressure gauge
Manifold valve
Handle Hi
(Keep fully closed)
Charge hose
(For R410A only)
Vacuum pump adapter
for counter-flow prevention
(For R410A only)
Handle Lo
Charge hose
(For R410A only)
–101kPa
(–76cmHg)
Vacuum
pump
Valve rod
Valve unit Flare nut
Stopper
Charge port
Charge cap
Service port
(Valve core (Setting pin))
Compound pressure gauge
Packed valve at gas side
Pressure gauge
Manifold valve
Handle Hi
(Keep fully closed)
Charge hose
(For R410A only)
Vacuum pump adapter
for counter-flow prevention
(For R410A only)
Handle Lo
Charge hose
(For R410A only)
–101kPa
(–76cmHg)
Vacuum
pump

11
Additional refrigerant
1. The amount of refrigerant put into the outdoor unit
at the factory is sufficient to fill up to 20m of
refrigerant piping work.
2. If the length of the refrigerant piping work is 20m or
less, addition of refrigerant at the installation site is
unnecessary.
3. If the length of the piping work exceeds 20m, extra
refrigerant must be added. Refer to the outdoor
installation manual for details of the extra amounts.
4. Overcharge or undercharge of refrigerant in the
outdoor unit may cause malfunction of the
compressor.
Add Only R410A Refrigerant to These Units
Heat insulation
1. Provide heat insulation on the refrigerant piping on
both the liquid side and gas side separately, and
ensure that all joints in the insulation are compleatly
sealed (without gap).
2. Since the temperature of the piping on the gas side
increases during heating operations, the heat
insulating material used must be able to withstand
temperatures of more than 120°C.
3. Use the pipe insulation supplied in the accessory
pack to insulate the piping connecting section on
the indoor unit side.
Closed completely
Handle
Opened fully
Valve unit
Valve unit
Charge port
Charge port
Handle
Pull out the handle and
using cutting pliers, etc.
turn it counterclockwise
by 90˚. (Open fully)
Flare nut
Flare nut
Push in handle.
Handle position
*1. Use the vacuum pump, vacuum pump adapters,
and gauge manifold referring to the manuals
attached to each tool before using them. For the
vacuum pump, check oil is filled up to the specified
line of the oil gauge.
*2. While the air is purged, check again that the
connecting port of charge hose, which has a
projection to push the valve core, is firmly con-
nected to the charge port.
Valve handling precautions
•Open the valve stem or the handle until it strikes
the stopper. It is unnecessary to apply further
force.
•Securely tighten the cap with a torque wrench.
•Cap tightening torque
Ø6.4
Valve Ø9.5
size Ø12.7
Ø15.9
Charge port
14 to 18N•m (1.4 to 1.8kgf•m)
33 to 42N•m (3.3 to 4.2kgf•m)
33 to 42N•m (3.3 to 4.2kgf•m)
20 to 25N•m (2.0 to 2.5kgf•m)
14 to 18N•m (1.4 to 1.8kgf•m)
7 EVACUATING

12
8 ELECTRICAL WORK
For the air conditioner that has no power cord.
NOTE:
For selection and connection method of the power
supply cords, refer to the details in the Installation
Manual of the outdoor unit.
CAUTIONS
•If incorrect/incomplete wiring is carried out, it
may cause an electrical fire or smoke.
•Prepare the power supply for exclusive use with
the air conditioner.
•Be sure to use the cord clamps specified
positions with attached to the product.
•Do not damage or scratch the conductive core
and inner insulator of power and inter-connecting
cables when peeling them.
•Be sure to comply with local cords on running
the wire from outdoor unit to indoor unit (size of
wire and wiring method etc.)
•Use the power cord and Inter-connecting cable
with specified thickness, specified type, and
protective devices specified.
How to wire
1. Connect the connecting cable to the terminal as
identified with their respective matched numbers on
the terminal block of indoor and outdoor unit.
H07 RN-F or 245 IEC 66 (1.5 mm2or more)
2. Insulate the unsheathed redundant cords
(conductors) with electrical insulation tape.
Process them so that they do not touch any
electrical or metal parts.
3. For inter-unit wiring, do not use a cut wire jointed to
another on the way.
Wiring between units
1. Connect the wires between the units correctly.
Errors made in the connections can result in the
unit malfunctioning.
2. Connect the control wires between the outdoor unit
and indoor unit as shown in the figure below :
Wiring connections
Connecting
cable
Earth line
10
50
10
70
123
123
21
Air inter
grille Front panel
Cord clamp
Terminal cover
Screw
Screw
Earth line
Connecting
cable

13
Installation of Remote Controllers
Precautions
1. Low-voltage circuit provision is used for remote
controller communication, and as such, the remote
controller cable is subject to the low-power circuit
provision of internal wiring regulations and therefore
it cannot be brought into direct contact with a high-
voltage AC power line, or housed in the same
conduit tube as a power line.
Flush wall mounting
•Feed the 3-core cable (obtained locally) though the
back of the remote controller and then connect to the
ABC terminals.
•Attach the remote controller to the wall using two
suitable mounting screws (obtained locally).
Wall surface mounting
•Attach the remote controller to the wall using two
suitable mounting screws (obtained locally).
•Connect the 3-core cable (obtained locally) to the
ABC terminals.
•Make a U-shaped cut-out in the center of the top
edge of the decorative cover and pass the 3-core
cable though the cut-out.
Remote Controller Cabling
Cabling diagram
•For details of cabling/installation of the remote
controller, refer to the Installation Manual packaged
in the remote controller.
Terminal block
for remote controller
cabling of indoor unit
A
B
C
A
B
C
Remote controller cable
(Local procure)
Remote
controller unit
or sensor part
3-core cable,
obtained locally
Mounting screws (x 2)
obtained locally
3-core cable,
obtained locally
Mounting screws (x 2)
obtained locally
8 ELECTRICAL WORK

14
9 IMPROVING SYSTEM EFFICIENCY
Air flow direction adjustment
1. To improve the effects of cooling and heating, use the outlet louver appropriately for cooling and heating
operations. When in cooling operation the most efficient louver position will be horizontal and when in heating
operation the optimum louver position is downwards.
Increasing heating effect
1. One method increase the warming effect is to fit an additional means of re-circulating the warmed air from the
upper part of the room :
2. However if the warming effect of the air conditioner is not good owing to the installation position or the structure of
the room, then reset the room temperature regulator as follows to raise the temperature of the room. Adjust
position 1 and 2 on DIP switch SW03 located on the indoor P.C. board, according to the table below :
Options
Test operation
To switch the TEST RUN (COOL) mode, push TEMPORARY button for 10
seconds. (The beeper will make a short beep.)
10 FINAL INSTALLATION CHECKS
Precautions
1. Ensure that the electrical cable used for
power supply and control of the system is
unable to come into contact with either
service valves or piping work which are not
insulated.
Electrical wiring
1. When installation is complete, check that all
power supply and interconnecting wiring has
been appropriately protected.
Refrigerant piping
1. When refrigerant and drain piping have been
completed. Ensure that all pipework is fully
insulated and apply finishing tape to seal the
insulation.
Check and Test Operation
•Pressure of R410A is approx. 1.6 times of that of R22.
If installation work is incompletely finished, a gas leakage
may occur at the cases such as pressure rise during
operation.
Therefore, be sure to test the piping connections for leakage.
•Check the flare nut connections, valve stem cap
connections and service port cap fittings
for gas leak with a leak detector or soap water.
Dip switch SW03
position 1 & 2
Temperature increased
Position 1 : ON Position 1 : OFF Position 1 : OFF
Position 2 : OFF Position 2 : ON Position 2 : OFF
Factory pre-set +2°C+4°C
TEMPORARY button
Valve
cover
Cord clamp
Piping cover
Indoor/outdoor
connecting cables
Power cable
Flare nut
connections
(Indoor unit)

15
Useful Functions (SM800AT-E only) Self-Diagnosis by LED Indication
In addition to the code checking by remote controller of the indoor unit, troubles of the outdoor unit can be diagnosed by LED
indications on the cycle control P.C. board of the outdoor unit. Utilize them for various checks.
For the check by remote controller of the indoor unit, refer to the Installation Manual of the indoor unit.
Before a check, confirm each bit of the DIP switch is set to OFF position.
LED indication and code checking
Installation/ServicingTools Changes in the product and components
In the case of an air conditioner using R410A, in order to prevent any other refrigerant from being charged accidentally, service
port diameter of the outdoor unit control valve (3 way valve) has been changed. (1/2 UNF 20 threads per inch)
•In order to increase the pressure resisting strength of the refrigerant piping flare processing diameter and size of opposite
side of flare nuts has been changed. (for copper pipes with nominal dimensions 1/2 and 5/8)
New tools for R410A
D800 ¡: Red
D801 ¡: Yellow
D802 ¡: Yellow
D803 ¡: Yellow
¥: Rapid flash
l: Go off
¡: Go on
•Incidentally, the “refrigerant cylinder”comes with the refrigerant designation (R410A) and protector coating in the U,S.’s ARI
specified rose color (ARI color code: PMS 507).
•Also, the “charge port and packing for refrigerant cylinder”require 1/2 UNF 20 threads per inch corresponding to the charge
hose’s port size.
10 FINAL INSTALLATION CHECKS
LED indication Cycle control P.C. board LED indication
D800 D801 D802 D803
¡lll
ll¡l
¡¡ll
l¡l¡
l¡ll
¡¡¡l
¡ll¡
l¡¡l
¡¡l¡
ll¡¡
¥lll
l¥ll
¥¥ll
ll¥l
¥l¥l
Cause
Heat exchanger sensor (TE) error
Suction sensor (TS) error
Discharge sensor (TD) error
High-pressure protection error
Outdoor temperature sensor (TO) error
DC outside fan error
Communication error between IPDU (Abnormal stop)
Discharge temp. error
EEPROM error
Communication error between IPDU (No abnormal stop)
G-Tr short-circuit protection
Detect circuit error
Current sensor error
Comp. lock error
Comp. break down
New tools for R410A
Gauge manifold
Charge hose
Electronic balance
for refrigerant charging
Torque wrench
(nominal diam. 1/2, 5/8)
Flare tool
(clutch type)
Gauge for projection adjustment
Vacuum pump adapter
Gas leakage detector
Applicable to R22 model
××
××
×
××
××
×
¡
××
××
×
¡
——
¡
××
××
×
Changes
As pressure is high, it is impossible to measure by means of conventional
gauge. In order to prevent any other refrigerant from being charged, each
port diameter is changed.
In order to increase pressure resisting strength, hose materials and port
size are changed (to 1/2 UNF 20 threads per inch).
When purchasing a charge hose, be sure to check the port size.
As pressure is high and gasification speed is fast, it is difficult to read the
indicated value by means of charging cylinder, as air bubbles occur.
The size of opposite sides of flare nuts have been increased. Incidentally,
a common wrench is used for nominal diameters 1/4 and 3/8.
By increasing the clamp bar’s receiving hole, strength of spring in the tool
has been improved.
Used when flare is made with using conventional flare tool.
Connected to the conventional vacuum pump. It is necessary to use an
adapter to prevent vacuum pump oil from flowing back to the charge hose.
The charge hose connecting part has two ports-one for conventional
refrigerant (7/16 UNF 20 threads per inch) and one for R410A.
If the vacuum pump oil (mineral) mixes with R410A a sludge may occur
and damage the equipment.
Exclusive for HFC refrigerant.

16
11 ENVIRONMENT
Environmental Issues
Product maintenance
1. To minimize the chances of environmental damage and to ensure the efficient operation of the unit, it is
recommended to have the air conditioner periodically checked and serviced by a qualified engineer.
Product disposal
1. Please dispose of the air conditioner unit in an environmentally responsible manner.
Recycling is the preferred disposal method.
2. When disposing of an air conditioner system, contact either the manufacture, your local environmental control
authority or a local waste disposal company for advice.
3. Ensure all packing material is either recycled or disposed of in accordance with local regulations.
4. The refrigerant gas within the unit should only be removed by an authorized company.
WARNING
Discharge of refrigerant to atmosphere is illegal and may lead to prosecution.

17
Plaque d’installation Vis de fixation
Ø 4 mm x 25 mm
Manuel d’installation Gabarit en papier
Manuel du
propriétaire
Télécommande avec fil
1
1
1
1
8
1
Nom de la pièce Quantité Forme
Nom de la pièce Quantité Forme
Nom de la pièce Quantité Forme
FAN SPEED
TEMP.
FAN
COOL
DRY
HEAT
AUTO
STANDBY
FILTER
PRE-HEAT
DEFROST
LOUVER
MANUAL
CENTRAL
CHECK
AUTO
FIX
LOUVER
Pièces accessoires et pièces non fournies
HPièces accessoires
<Pièces vendues séparément>
HPièces non fournies
Tuyau de raccordement (côtéliquide)
((diam.) 6.35 mm, (diam.) nominal 1/4", épaisseur 0.8 mm)
RAV-SM560KRT-E, RAV-SM560AT-E
((diam.) 9.52 mm, (diam.) nominal 3/8", épaisseur 0.8 mm)
RAV-SM800KRT-E, RAV-SM800AT-E
Tuyau de raccordement (côtégaz)
((diam.) 12.7 mm, (diam.) nominal 1/2", épaisseur 0.8 mm)
RAV-SM560KRT-E, RAV-SM560AT-E
((diam.) 15.9 mm, (diam.) nominal 5/8", épaisseur 1.0 mm)
RAV-SM800KRT-E, RAV-SM800AT-E
Cordon d’alimentation
2.5 mm²(H07RN-F ou 245IEC66) ou 3.5 mm²(AWG-12)
Câble de raccordement
H07RN-F ou 245IEC66 (1.0 mm²ou plus)
Isolation thermique du tuyau de réfrigérant
(10 mm ou plus, polyéthylène expanséthermo-isolant)
Isolation thermique du tuyau d’évacuation
(10 mm ou plus, polyéthylène expansé)
Tuyau d’évacuation ((diam.) ext. 26 mm)
Rubans
Câble de terre ((diam.) 2.0 mm ou plus)
