Toshiba MMU-AP0072H2UL User manual

1
MMU-AP___2H2ULE15-3C1
6 Indoor unit
4-Way Cassette type
Contents
1. Specifications
2. Dimensions
3. Center of gravity
4. Piping diagram
5. Wiring diagram
6. Electrical current characteristics
7. Sensible capacity table
8. Air throw distance chart
9. Sound data
10. Accessories
11. Reference
MMU-AP0072H2UL
MMU-AP0092H2UL
MMU-AP0122H2UL
MMU-AP0152H2UL
MMU-AP0182H2UL
MMU-AP0212H2UL
MMU-AP0242H2UL
MMU-AP0302H2UL
MMU-AP0362H2UL
MMU-AP0422H2UL
MMU-AP0072H2UL-1
+00E15-3C1_01EN.book Page 1 Thursday, March 24, 2016 11:25 AM

2
MMU-AP___2H2UL E15-3C1
1. Specifications
4-Way Cassette type
Note
* Figures in parentheses are for ceiling panels.
(*1) The actual values in an external operating environment are generally higher than the indicated values due to the contribution from ambient
noise.
Model name MMU-
AP0072H2UL AP0092H2UL AP0122H2UL AP0152H2UL AP0182H2UL AP0212H2UL AP0242H2UL
Cooling Capacity kBtu/h 7.5 9.5 12 15.4 18 21 24
Heating Capacity kBtu/h 8.5 10.5 13.5 17 20 24 27
Electrical
characteristics
Power supply 230 V (208/230 V) 1phase 60 Hz
Power consumption kW 0.021 0.021 0.023 0.026 0.026 0.036 0.036
Appearance
Main unit Zinc hot dipping steel plate Heat-insulating material attached
Ceiling
panel
Model RBC-U31PG(W)-UL
Panel color White (2.5GY9.0/0.5)
Dimension
(Ceiling
panel)*
Unit
Height In 10.1 (1.2)* 10.1 (1.2)* 10.1 (1.2)* 10.1 (1.2)* 10.1 (1.2)* 10.1 (1.2)* 10.1 (1.2)*
Width In 33.1 (37.4)* 33.1 (37.4)* 33.1 (37.4)* 33.1 (37.4)* 33.1 (37.4)* 33.1 (37.4)* 33.1 (37.4)*
Depth In 33.1 (37.4)* 33.1 (37.4)* 33.1 (37.4)* 33.1 (37.4)* 33.1 (37.4)* 33.1 (37.4)* 33.1 (37.4)*
Packing
Height In 11.3 (3.9)* 11.3 (3.9)* 11.3 (3.9)* 11.3 (3.9)* 11.3 (3.9)* 11.3 (3.9)* 11.3 (3.9)*
Width In 36.0 (39.8)* 36.0 (39.8)* 36.0 (39.8)* 36.0 (39.8)* 36.0 (39.8)* 36.0 (39.8)* 36.0 (39.8)*
Depth In 37.2 (39.8)* 37.2 (39.8)* 37.2 (39.8)* 37.2 (39.8)* 37.2 (39.8)* 37.2 (39.8)* 37.2 (39.8)*
Total weight
(Ceiling
panel)*
Unit lbs 42 (10)* 42 (10)* 46 (10)* 46 (10)* 46 (10)* 48 (10)* 48 (10)*
Packed unit lbs 51 (15.5)* 51 (15.5)* 55 (15.5)* 55 (15.5)* 55 (15.5)* 57 (15.5)* 57 (15.5)*
Heat exchanger Finned tube
Fan unit
Fan Turbo fan
Standard air flow (High/Mid/Low) cfm 470/430/400 550/490/460 550/480/440 550/480/440 670/540/490 550/480/440
Motor W 60 60 60 60 60 60 60
Air filter Standard filter (Long life filter)
Connecting
pipe
Gas side In 3/8" 3/8" 3/8" 1/2" 1/2" 5/8" 5/8"
Liquid side In 1/4" 1/4" 1/4" 1/4" 1/4" 3/8" 3/8"
Drain port (Nominal dia.) In VP25 (Polyvinyl chloride tube: External Dia.1-1/4 Internal Dia.1)
Sound pressure level (High/Mid/Low) (*1) dB(A) 32.5/30.5/29
34/31.5/29.5 35/33/31 35/33/31 38/33/31 38/33/31
Option parts
Spacer for height adjustment TCB-SP1602UUL
Air-discharge direction kit TCB-BC1602UUL
Fresh-air chamber TCB-GFC1602UUL
Fresh Air inlet box TCB-GB1602UUL
Auxiliary fresh air flange TCB-FF101URUL
+00E15-3C1_01EN.book Page 2 Thursday, March 24, 2016 11:25 AM

3
MMU-AP___2H2ULE15-3C1
Note
* Figures in parentheses are for ceiling panels.
(*1) The actual values in an external operating environment are generally higher than the indicated values due to the contribution from ambient
noise.
Model name MMU- AP0302H2UL AP0362H2UL AP0422H2UL AP0072H2UL-1
Cooling Capacity kBtu/h 30 36 42 7.5
Heating Capacity kBtu/h 34 40 47.5 8.5
Electrical
characteristics
Power supply 230 V (208/230 V) 1phase 60 Hz
Power consumption kW 0.043 0.088 0.112 0.023
Appearance
Main unit Zinc hot dipping steel plate Heat-insulating material attached
Ceiling
panel
Model RBC-U31PG(W)-UL
Panel color White (2.5GY9.0/0.5)
Dimension
(Ceiling panel)*
Unit
Height In 10.1 (1.2)* 12.6 (1.2)* 12.6 (1.2)* 10.1 (1.2)*
Width In 33.1 (37.4)* 33.1 (37.4)* 33.1 (37.4)* 33.1 (37.4)*
Depth In 33.1 (37.4)* 33.1 (37.4)* 33.1 (37.4)* 33.1 (37.4)*
Packing
Height In 11.3 (3.9)* 13.8 (3.9)* 13.8 (3.9)* 11.3 (3.9)*
Width In 36.0 (39.8)* 36.0 (39.8)* 36.0 (39.8)* 36.0 (39.8)*
Depth In 37.2 (39.8)* 37.2 (39.8)* 37.2 (39.8)* 37.2 (39.8)*
Total weight
(Ceiling panel)*
Unit lbs 48 (10)* 59 (10)* 59 (10)* 46 (10)*
Packed unit lbs 57 (15.5)* 69 (15.5)* 69 (15.5)* 55 (15.5)*
Heat exchanger Finned tube
Fan unit
Fan Turbo fan
Standard air flow (High/Mid/Low) cfm 730/630/510 1160/840/630 1250/840/670
550/490/460
Motor W 60 150 150 60
Air filter Standard filter (Long life filter)
Connecting
pipe
Gas side In 5/8" 5/8" 5/8" 3/8"
Liquid side In 3/8" 3/8" 3/8" 1/4"
Drain port (Nominal dia.) In VP25 (Polyvinyl chloride tube: External Dia.1-1/4 Internal Dia.1)
Sound pressure level (High/Mid/Low) (*1) dB(A) 41/36.5/34 46/40.5/36.5 48.5/40.5/37.5
34/31.5/29.5
Option parts
Spacer for height adjustment TCB-SP1602UUL –
Air-discharge direction kit TCB-BC1602UUL –
Fresh-air chamber TCB-GFC1602UUL –
Fresh Air inlet box TCB-GB1602UUL –
Auxiliary fresh air flange TCB-FF101URUL –
+00E15-3C1_01EN.book Page 3 Thursday, March 24, 2016 11:25 AM

4
MMU-AP___2H2UL E15-3C1
2. Dimensions
MMU-AP0072H2UL, AP0092H2UL, AP0122H2UL, AP0072H2UL-1
37.4"(950) Panel external dimension
30.7"(780) Hanging bolt pitch
12.7"(323)
45
Hanging bolt 3/8"(M10)
(To be procured locally)
10.1"(256)
5.2"(132)
1.2"
(30)
0.5"
(12)
Indoor unit
Ceiling panel
Ceiling
bottom
surface
Ceiling bottom
surface
Ceiling panel
(Sold separately)
Ceiling
bottom
surface
7.4"(187)
6.1"(155)
1.1"
(28.5)
2.4"
(61)
1.3"
(32) 2.2"
(57)
Z view
2.5"
(64)
37.4"(950) Panel external dimension
Z16.4"(416.5)
Drain-up standing-up size
11.8"(300)
or less
Stand-up
33.5"(850) or less
Indoor unit Ceiling bottom
surface
Stand-up
26.0"(661)
or less
Drain pipe
connecting port
7.4"(189)
Ceiling
bottom
surface
Electric
parts box
33.1"(840) Unit external dimension
10.6"(269)
16.1"(408)
Ceiling bottom
surface 4.4"
(112)
6.8"(172)
1.7"
(42)
2.3"
(58)
9.5"(241.5)
1.6"
(40)
9.9"(251)
11.1"(281)
12.0"(306)
4.2"
(106.5)
2.8"
(72)
Hole for remote
controller wires
Conduit hole(Knockout)
Ceiling bottom surface
Hole for power
supply cable
Refrigerant pipe
connecting port
(Liquid) Ø 1/4"(6.4)
Refrigerant pipe
connecting port
(Gas) Ø 3/8"(9.5)
Knockout for simple OA
For 3.9"(100)
27.2±0.8"(690) Hanging bolt pitch
33.1"(840) Unit external dimension
Unit: in (mm)
33.9" to 35.8"(860 to 910) Ceiling open dimension
39.4"(1000)
or more
33.9" to 35.8"(860 to 910) Ceiling open dimension
Space required for installation
0.6"(15)
or more
39.4"(1000)
or more
0.6"(15)
or more
39.4"(1000)
or more
7.9"(200)
7.9"(200)
( 17.7"(450))
( 17.7"(450))
Check port
Check port
When a fresh-air inlet box is
installed, make check port
at the side of the fresh-air
inlet box.
+00E15-3C1_01EN.book Page 4 Thursday, March 24, 2016 11:25 AM

5
MMU-AP___2H2ULE15-3C1
MMU-AP0152H2UL, AP0182H2UL, AP0212H2UL, AP0242H2UL, AP0302H2UL
37.4"(950) Panel external dimension
30.7"(780) Hanging bolt pitch
12.7"(323)
45
Hanging bolt 3/8"(M10)
(To be procured locally)
10.1"(256)
5.2"(132)
1.2"
(30)
0.5"
(12)
Indoor unit
Ceiling panel
Ceiling
bottom
surface
Ceiling bottom
surface
Ceiling panel
(Sold separately)
Ceiling
bottom
surface
7.4"(187)
6.1"(155)
1.1"
(28.5)
2.4"
(61)
1.3"
(32) 2.2"
(57)
Z view
2.5"
(64)
37.4"(950) Panel external dimension
Z16.4"(416.5)
Drain pipe
connecting port
7.4"(189)
Ceiling
bottom
surface
Electric
parts box
33.1"(840) Unit external dimension
10.6"(269)
16.1"(408)
Ceiling bottom
surface 4.4"
(112)
6.8"(172)
1.7"
(42)
2.3"
(58)
9.5"(241.5)
1.6"
(40)
9.9"(251)
11.1"(281)
12.0"(306)
4.2"
(106.5)
2.8"
(72)
Hole for remote
controller wires
Conduit hole(Knockout)
Ceiling bottom surface
Hole for power
supply cable
Refrigerant pipe
connecting port
(Liquid) A
Refrigerant pipe
connecting port
(Gas) B
Knockout for simple OA
For 3.9"(100)
27.2±0.8"(690) Hanging bolt pitch
33.1"(840) Unit external dimension
39.4"(1000)
or more
Space required for installation
0.6"(15)
or more
39.4"(1000)
or more
0.6"(15)
or more
39.4"(1000)
or more
7.9"(200)
7.9"(200)
( 17.7"(450))
( 17.7"(450))
Check port
Check port
When a fresh-air inlet box is
installed, make check port
at the side of the fresh-air
inlet box.
Drain-up standing-up size
11.8"(300)
or less
Stand-up
33.5"(850) or less
Indoor unit Ceiling bottom
surface
Stand-up
26.0"(661)
or less
33.9" to 35.8"(860 to 910) Ceiling open dimension
33.9" to 35.8"(860 to 910) Ceiling open dimension
Unit:in (mm)
Model MMU- A B
AP015, 018 Type 1/4" (6.4) 1/2" (12.7)
AP021, 024, 030 Type 3/8" (9.5) 5/8" (15.9)
+00E15-3C1_01EN.book Page 5 Thursday, March 24, 2016 11:25 AM

6
MMU-AP___2H2UL E15-3C1
MMU-AP0362H2UL, AP0422H2UL
9.5"(241.5)
33.1"(840) Unit external dimension
37.4"(950) Panel external dimension
30.7"(780) Hanging bolt pitch
5.2"(132)
12.6"(319)
0.5"
(12)
Z view
1.2"
(30)
7.4"(187)
6.1"(155)
1.1"
(28.5)
2.4"
(61)
1.3"
(32) 2.2"
(57)
2.5"
(64)
16.4"(416.5)
37.4"(950) Panel external dimension
Z
10.6"(269)
12.7"(323)
7.4"(189)
2.8"
(72) 4.2"
(106.5)
33.1"(840) Unit external dimension
16.1"(408)
4.4"
(112)
6.8"(172)
1.7"
(42)
Ceiling bottom
surface
Ceiling
bottom
surface
Indoor unit
Ceiling
bottom
surface
Ceiling panel
Ceiling bottom
surface
Ceiling panel
(Sold separately)
Hanging bolt 3/8"(M10)
(To be procured locally)
Electric
parts box
Ceiling bottom surface
Ceiling
bottom
surface
Drain pipe
connecting port
2.3"
(58)
1.6"
(40)
9.9"(251)
11.1"(281)
12.0"(306)
Hole for remote
controller wires
Conduit hole(Knockout)
Hole for power
supply cable
45
Refrigerant pipe
connecting port
(Liquid) 3/8"(9.5)
Refrigerant pipe
connecting port
(Gas) 5/8"(15.9)
27.2±0.8"(690) Hanging bolt pitch
Knockout for simple OA
For 3.9"(100)
39.4"(1000)
or more
Space required for installation
0.6"(15)
or more
39.4"(1000)
or more 39.4"(1000) or more
0.6"(15)
or more
33.9" to 35.8"(860 to 910) Ceiling open dimension
33.9" to 35.8"(860 to 910) Ceiling open dimension
7.9"(200)
( 17.7"(450))
7.9"(200)
( 17.7"(450))
Check port
When a fresh-air inlet box is
installed, make check port
at the side of the fresh-air
inlet box.
Check port
Drain-up standing-up size
11.8"(300)
or less
Stand-up
26.0"(661)
or less
Stand-up
33.5"(850) or less
Indoor unit Ceiling bottom
surface
Unit:in (mm)
+00E15-3C1_01EN.book Page 6 Thursday, March 24, 2016 11:25 AM

7
MMU-AP___2H2ULE15-3C1
3. Center of gravity
Model name X (In) Y (In) Z (In)
Total weight
Main unit
(lbs)
Ceiling panel
(lbs)
MMU-AP0072H2UL
18.5
17.9 6.05
42
10
MMU-AP0092H2UL
MMU-AP0122H2UL
46MMU-AP0152H2UL
MMU-AP0182H2UL
MMU-AP0212H2UL
48MMU-AP0242H2UL
MMU-AP0302H2UL
MMU-AP0362H2UL 17.7 7.25 59
MMU-AP0422H2UL
MMU-AP0072H2UL-1 17.9 6.05 46
+00E15-3C1_01EN.book Page 7 Thursday, March 24, 2016 11:25 AM

8
MMU-AP___2H2UL E15-3C1
4. Piping diagram
Air heat exchanger
at indoor side
Sensor
(TC2)
㹋
Fan
Fan Motor
Sensor
(TCJ)
Sensor
(TC1)
Strainer
Pulse
Motor
Valve
Liquid side Gas side
Capillary Tube
Sensor
(TA)
+00E15-3C1_01EN.book Page 8 Thursday, March 24, 2016 11:25 AM

9
MMU-AP___2H2ULE15-3C1
5. Wiring diagram
MMU-AP0072H2UL, AP0092H2UL, AP0122H2UL, AP0152H2UL, AP0182H2UL, AP0212H2UL,
AP0242H2UL, AP0302H2UL, AP0362H2UL, AP0422H2UL, AP0072H2UL-1
䎃 䏌䏑䏇䏌䏆䏄䏗䏈䏖䎃 䏗䏋䏈䎃 䏗䏈䏕䏐䏌䏑䏄䏏䎃 䏅䏏䏒䏆䏎䎑
䎃 䎃 䎃 䎃 䎯䏈䏗䏗䏈䏕䎃 䏄䏗䎃 䏌䏑䏖䏌䏇䏈䎃 䏌䏑䏇䏌䏆䏄䏗䏈䏖䎃 䏗䏋䏈䎃 䏗䏈䏕䏐䏌䏑䏄䏏䎃 䏑䏘䏐䏅䏈䏕䎑
䎤䎃 䏇䏒䏗䏗䏈䏇䎃 䏏䏌䏑䏈䎃 䏄䏑䏇䎃 䏅䏕䏒䏎䏈䏑䎃 䏏䏌䏑䏈䎃 䏌䏑䏇䏌䏆䏄䏗䏈䎃 䏗䏋䏈
䎃 䎃 䎃 䎃 䏚䏌䏕䏌䏑䏊䎃 䏄䏗䎃 䏖䏌䏗䏈䎑
䎃 䏌䏑䏇䏌䏆䏄䏗䏈䏖䎃 䏗䏋䏈䎃 䏆䏒䏑䏗䏕䏒䏏䎃 䎳䎑䎦䎑䏅䏒䏄䏕䏇䎑
䎵䎨䎧䎝䎵䎨䎧
䎺䎫䎬䎝䎺䎫䎬䎷䎨 䎼䎨䎯䎝䎼䎨䎯䎯䎲䎺
䎥䎯䎸䎝䎥䎯䎸䎨 䎥䎯䎮䎝䎥䎯䎤䎦䎮 䎪䎵䎼䎝䎪䎵䎤䎼 䎳䎱䎮䎝䎳䎬䎱䎮
䎲䎵䎱䎝䎲䎵䎤䎱䎪䎨
䎪䎵䎱䎝䎪䎵䎨䎨䎱 䎥䎵䎺䎝䎥䎵䎲䎺䎱
䎦䎲䎯䎲䎵
䎬䎧䎨䎱䎷䎬䎩䎬䎦䎤䎷䎬䎲䎱
+00E15-3C1_01EN.book Page 9 Thursday, March 24, 2016 11:25 AM

10
MMU-AP___2H2UL E15-3C1
6. Electrical current characteristics
MCA: Minimum Circuit Amps FLA: Full Load Amps
MOCP: Maximum Overcurrent Protection (Amps)
Type Model Nominal Voltage
(V-Ph-Hz)
Voltage Range
(V)
Power
consumption FLA MCA MOCP
Min Max kW A A A
4-Way
Cassette
type
MMU-AP0072H2UL 208/230-1-60 187 253 0.021 0.6 0.8 15
MMU-AP0092H2UL 208/230-1-60 187 253 0.021 0.6 0.8 15
MMU-AP0122H2UL 208/230-1-60 187 253 0.023 0.6 0.8 15
MMU-AP0152H2UL 208/230-1-60 187 253 0.026 0.6 0.8 15
MMU-AP0182H2UL 208/230-1-60 187 253 0.026 0.6 0.8 15
MMU-AP0212H2UL 208/230-1-60 187 253 0.036 0.8 1.0 15
MMU-AP0242H2UL 208/230-1-60 187 253 0.036 0.8 1.0 15
MMU-AP0302H2UL 208/230-1-60 187 253 0.043 0.8 1.0 15
MMU-AP0362H2UL 208/230-1-60 187 253 0.088 1.0 1.3 15
MMU-AP0422H2UL 208/230-1-60 187 253 0.112 1.0 1.3 15
MMU-AP0072H2UL-1 208/230-1-60 187 253 0.023 0.6 0.8 15
+00E15-3C1_01EN.book Page 10 Thursday, March 24, 2016 11:25 AM
