Toshiba RAV-SM562UT-E User manual

R410A
FILE NO. A05-018
Revised: Jul/25/2005
PRINTED IN JAPAN, Jan.,2006 ToMo
SERVICE MANUAL/IN EGRA ION
SPLI YPE
INDOOR UNIT
<DIGITAL INVERTER>
RAV-SM562UT-E RAV-SM562BT-E RAV-SM562CT-E
RAV-SM802UT-E RAV-SM802BT-E RAV-SM802CT-E
RAV-SM1102UT-E RAV-SM1102BT-E RAV-SM1102CT-E
RAV-SM1402UT-E RAV-SM1402BT-E RAV-SM1402CT-E
<SUPER DIGITAL INVERTER>
RAV-SP1102UT-E
• Service Manual for RAV-SM✻✻✻KRT and RAV-SM✻✻✻XT contact the Sales company or Dealer.
OUTDOOR UNIT
<DIGITAL INVERTER>
RAV-SM562AT-E RAV-SM802AT-E RAV-SM1102AT-E RAV-SM1402AT-E
<SUPER DIGITAL INVERTER>
RAV-SP562AT-E RAV-SP802AT-E RAV-SP1102AT-E RAV-SP1402AT-E
Heronhill - for all your Toshiba requirements
Tel: [phone]
www.heronhill.co.uk
Fax: [phone]

– 160 –
Location Part Description
No. No.
214 43049776 Socket, Ø9.52
215 43047688 Nut, Flare, 1/2 IN, Ø12.7
216 43149352 Nut, Flare, 5/8 IN, Ø15.88
217 43149353 Socket, 1/2 IN, Ø12.7
218 43149354 Socket, 5/8 IN, Ø15.88
219 43049697 Bonnet, Ø6.35
220 43047609 Bonnet, Ø9.52
221 43147195 Bonnet, 1/2 IN, Ø12.7
222 43194029 Bonnet, Ø15.88
223 43019904 Holder, Sensor, SUS
224 43170245 Hose, Drain
225 43139137 Rubber, Cushion
226 43097212 Nut
227 4314Q009 Distributor Ass’y
228 4314Q010 Distributor Ass’y
Location Part Description
No. No.
201 43121736 Pump, Drain, ADP-1409,
220-240V
202 43120215 Fan, Ass’yTurbo, TJ461
203 4314J265 Refrigeration Cycle Ass’y
204 4314J266 Refrigeration Cycle Ass’y
205 4318T681 Owner’s Manual
206 43172187 Pan Ass’y, Drain,
PS-F+ABS, Sheet
207 43151290 Switch, Float, FS-0218-102
208 43121738 Motor, Fan, SWF-230-60-1R
209 43170244 Hose, Drain, 25A
210 43079249 Band, Hose
211 43047685 Nut, Flare, 1/4 IN, Ø6.35
212 43047686 Nut, Flare, 3/8 IN, Ø9.52
213 43149351 Socket, Ø6.35
208
225
202
226
215,216,217,
218,221,222
211,212,213,
214,219,220
227,228
206
201
207
223
209
203,204
210
224
ON / OFF
FAN
TEMP.
SWING/FIXTIME
MODE
VENT
UNITSET CL
FILTER
RESET
TEST
TIMER SET
CODE No.
UNIT No.
TEST SETTING
DATA SET
R.C. No.
H
15. EXPLODED VIEWS AND PARTS LIST
15-1. Indoor Unit
15-1-1. 4-Way Air Discharge CassetteType
RAV-SM562UT-E, RAV-SM802UT-E
Heronhill - for all your Toshiba requirements
Tel: [phone]
www.heronhill.co.uk
Fax: [phone]

–161 –
Location Part Description
No. No.
401 43160565 Terminal Block, 3P, 20A
402 43050425 Sensor, TC (F6)
403 43050426 Sensor, TA
404 43160568 Terminal Block, 2P,
1A, AC30V
405 4316V280 P.C.Board Ass’y, MMC-1402
AB
405
403
404
402
401
Heronhill - for all your Toshiba requirements
Tel: [phone]
www.heronhill.co.uk
Fax: [phone]

–166 –
304 311
306
312
305
307
303
301
313
309
302 308
310
Location Part Description
No. No.
301 43409164 Panel, PS-HI100
302 43480010 Air Filter, ABS
303 43407120 Outlet, Air Form, PS-F
304 4302C063 Motor, Louver, MP24Z
305 43409173 Louver, ABS
306 43422001 Joint, Kit
307 43422002 Joint, Kit
Location Part Description
No. No.
308 43407116 Grille, Catch, ABS
309 43409168 Grille, Air, Inlet
310 43409182 Cover, Panel Ass’y,
PS-HI100
311 43407123 Fix, Motor, ABS
312 43160573 Lead, Motor
313 43182002 Washer, SPCC
RBC-U21PG (W) - E2
