SERVICE MANUAL
FACSIMILE
GD-1300
Model: GD-1300
Publish Date: July 2008
File No. SME08000400
R080621G0700-TTEC
Ver00_2008-07

Trademarks
•Microsoft
®, Windows®, Windows®98, Windows®Me, Windows®2000, Windows®XP, Windows®
Vista, and Internet Explorer®are registered trademarks or trademarks of Microsoft Corporation in
the U.S.A. and other countries.
• Adobe®, the Adobe®logo, Acrobat®, the Adobe®PDF logo, and ReaderTM are registered trade-
marks or trademarks of Adobe Systems Incorporated in the United States and other countries.
• IBM, PC/AT, and PowerPC are trademarks of International Business Machines Corporation.
• All other trademarks and copyrights are the property of their respective owners.
© 2008 TOSHIBA TEC CORPORATION All rights reserved
Under the copyright laws, this manual cannot be reproduced in any form without prior written permission
of TOSHIBA TEC CORPORATION. No patent liability is assumed, however, with respect to the use of the
information contained herein.

GENERAL PRECAUTIONS REGARDING THE INSTALLATION
AND SERVICE FOR e-STUDIO203S/203SD AND GD-1300
The installation and service should be done by a qualified service
technician.
1. Transportation/Installation
- When transporting/installing the machine, be sure to use the positions as indicated below.
The machine is quite heavy and weighs approximately 17 kg (37 lb.), therefore pay full attention
when handling it.
- Be sure to use a dedicated outlet with AC120V/8A, 220-240V/5A, 230-240V/5A for its power
source.
- The machine must be grounded for safety.
Never ground it to a gas pipe or a water pipe.
- Select a suitable place for installation.
Avoid excessive heat, high humidity, dust, vibration and direct sunlight.
- Also provide proper ventilation as the machine emits a slight amount of ozone.
- The socket-outlet shall be installed near the machine and shall be easily accessible.
2. Service of Machines
- Basically, be sure to turn the main switch off and unplug the power cord during service.
- Be sure not to touch high-temperature sections such as the exposure lamp, the fuser unit and
their periphery.
- Be sure not to touch high-voltage sections such as the chargers and the high-voltage trans-
former.
Especially, the board of these components should not be touched since the electric charge may
remain in the capacitors, etc. on them even after the power is turned OFF.
- Be sure not to touch rotating/operating sections such as gears, belts, pulleys, fan, etc.
- Be careful when removing the covers since there might be the parts with very sharp edges
underneath.
- When servicing the machines with the main switch turned on, be sure not to touch live sections
and rotating/operating sections. Avoid exposure to laser radiation.
- Use suitable measuring instruments and tools.
- Avoid exposure to laser radiation during servicing.
- Avoid direct exposure to the beam.
- Do not insert tools, parts, etc. that are reflective into the path of the laser beam.
- Remove all watches, rings, bracelets, etc. that are reflective.
- Unplug the power cable and clean the area around the prongs of the plug once a year or more.
A fire may occur when dust lies on this area.

3. Main Service Parts for Safety
- The breaker, door switch, fuse, thermostat, thermofuse, thermistor, etc. are particularly important
for safety. Be sure to handle/install them properly. If these parts are shorted circuit and/or made
their functions out, they may burn down, for instance, and may result in fatal accidents. Do not
allow a short circuit to occur. Do not use the parts not recommended by Toshiba TEC Corpora-
tion.
4. Cautionary Labels
- During servicing, be sure to check the rating plate and the cautionary labels such as “Unplug the
power cord during service”, “Hot area”, “Laser warning label” etc. to see if there is any dirt on
their surface and whether they are properly stuck to the machine.
5. Disposition of Consumable Parts, Packing Materials
- Regarding the recovery and disposal of the machine, supplies, consumable parts, packing mate-
rials, follow the relevant local regulations or rules.
6. When parts are disassembled, reassembly is basically the reverse of disassembly unless
otherwise noted in this manual or other related documents. Be careful not to reassemble
small parts such as screws, washers, pins, E-rings, star washers in the wrong places.
7. Basically, the machine should not be operated with any parts removed or disassembled.
8. Precautions Against Static Electricity
- The PC board must be stored in an anti-electrostatic bag and handled carefully using a wrist-
band, because the ICs on it may become damaged due to static electricity.
Caution: Before using the wristband, pull out the power cord plug of the machine and
make sure that there are no uninsulated charged objects in the vicinity.

GD-1300 PRODUCT OUTLINE 1 - 1
[1] PRODUCT OUTLINE
This unit provides the FAX function when installed to the following
machines:
Machines to install this unit :
• e-STUDIO203S
• e-STUDIO203SD
[2] SPECIFICATIONS
Large item Middle item Small item Sub item Specifications
Communicatio
n system Electronic transmission
system
Electronic
transmission time Less than 3 sec (Super G3 mode, 33600bps) Less than 7 sec (G3 ECM mode, 14400bps)
Compression/
Extraction system MH, MR, MMR, JBIG
MODEM speed 33600bps - 2400bps (Automatic fall-back)
Mutual
communication Super G3/G3
Used line Public switched telephone network (PSTN), Private
branch exchange (PBX)
R-key operation when
setting PBX Yes (Germany only)
PBX setting Yes (Germany, Sweden, Spain, Italy, Switzerland,
Finland, Denmark, Norway)
Used line number 1 line
Connection form For 1 line of telephone;
• FAX machine
• External telephone
ECM Yes
Transmission
functions Transmission operation Items which can be selected and
registered by user
when transmitting
• Specifying the destination number
• Resolution
• Density
• Transmission start time
• Polling receive
• Cover addition setting
• Send document scan system
Auto send
function Auto send function to a predetermined telephone number
Application send
function Chain dial Max. 50 digits
Rapid key dial Registration key One-touch key
Number of items Max. 18 items
Number of digits of
destination number Max. 40 digits
Destination
registration name Max. 20 characters
Retrieval characters 0 - 3 characters
Communication start
speed Max. speed: 33600bps/ High speed: 14400bps/ Middle speed: 9600bps/ Low speed: 4800bps
International
communication mode NO/ Mode 1/ Mode 2/ Mode 3
Transmission method One-touch dial key

GD-1300 SPECIFICATIONS 2 - 1
Large item Middle item Small item Sub item Specifications
Transmission
functions Application send function Speed dial Number of items 100 items (Reduction number 00 - 99)
Number of digit of
destination number 40 digits
Destinationregistration
name 20 characters
Retrieval characters 0 - 3 characters
Communication start
speed Max. speed: 33600bps/ High speed: 14400bps/ Meddle speed: 9600bps/ Low speed: 4800bps
International
communication mode NO/ Mode 1/ Mode 2/ Mode 3
Transmission method Speed dial key + (00 - 99) + Start key
Group dial Registration key One-touch dial key
Numberofgroupswhich
can be registered
18 items (One-touch dial + Group dial)
Destinationregistration
name 20 characters
Number of stations
which can be
registered in one group
Max. 100 stations in one group (Max. total items
which can be registered: 150 items)
Numbers which can be
registered Destination numbers registered in one-touch dial and speed dial, 10-key dial
Retrieval characters 0 - 3 characters
Transmission method Group dial key
Address book send Retrieval target • Speed dial
• One-touch dial
• Group dial
Retrieval key SEARCH key
Retrieval character 0 - 3 characters
Send functions Document scan
function Document size Max. document width Inch series: 8.5" AB series: 210mm
Max. document length 500mm ∗(Only from RADF, with user support)
∗RADF: Single surface scan
Send document size AB series: A4
Inch series: Letter (8.5" x 11")/Legal (8.5" x 14")
(Default: Letter (8.5" x 11"))
Document size
specification Yes
Half-tone reproduction Half-tone 256 gradations
Resolution selection Manual 5 steps
Standard/Fine/Super Fine/Fine + Half-tone/Super
Fine + Half-tone (Default: Standard)
Scan density select
function Density select Light/Medium/Dark
Scan resolution select
function Selectable image quality mode Scan density
Resolution select Standard: 8dot x 3.85 line/mm
Fine: 8dot x 7.7 line/mm
Super Fine: 8dot x 15.4 line/mm
Half-tone: Scan in 256 gradations
Document table scan
(OC send) function Book document scan/send function from the document table (OC). In one send job, the send
document size is fixed.

GD-1300 SPECIFICATIONS 2 - 2
Send functions Send document
information adding
function
Sender registration/
send function Sender telephone number 20 digits
Sender registration
name 36 characters
Send header function Header display content Sender number registered in sender registration/
Sender name/ Send date and time/ page
Page counter function Adding position Top right (The right edge)
Adding form P. XXX (Max. 999)
Cover adding function Display items • Date and time
• Destination name (Max. 20 characters)
• Destination number (Max. 40 digits)
• Sender name (Max. 20 characters)
• Sender number (Max. 20 digits)
• Send quantity (3 digits)
• Send message (When send message adding
function is used)
Send message adding
function Fixed message NO MESSAGE/CONFIDENTIAL/PLS. DISTRIBUTE/ URGENT/PLS. CALL BACK/IMPORTANT
Index function Yes (Max. 10 kinds in printable area)
Basic send
functions Direct send function Yes
Memory send function Send form
Number of items of
send reservation
• Send reservation
• Time specifying send
• Group send
• Serial broadcast
Max. 52 items (excluding redial)
Group send and broadcast are treated as one item.
Operation when
memory full • Document scan stop • Memory full display →Job continuation check
• Job continuation: Scanned document data are sent.
• Job stop: Scanned document data are deleted.
• In either case, document is held in RADF and not
discharged.
Quick online send
function Valid when memory mode is ON. Scan of send document data and send are performed together.
Auto resend function When busy tone
detected Redial is performed according to the setting of "Number/interval of redial when busy."
When no response
(CED/ FSK signal are
not detected)
Redial is performed according to the setting of
"Number/ interval of resend in communication error."
Communication error
Long document send
function Supports up to 500mm. When this length is exceeded, "PAPER JAM" occurs.
Application send
function Manual send function This function allows to switch to FAX manually when off-hook with document set.
Time specifying send
function Available communication Memory send, Polling, serial broadcast, serial send request
Number of set items Max. 5 items
Set range 00:00 - 23:59 (Unit: 1 min)
Day of week 8 kinds (From Monday to Sunday, and no
specification)
Group send function A message is sent sequentially to two or more
destinations registered in group dial. (Max. 52
destinations can be registered in one group.)
Serial broadcast
function Broadcast send destination Max. 100 items
Duplex send function Valid only in duplex support models.
Direct send and scan from OC cannot be made.
Send document size A4/ Letter/ Legal size
Large item Middle item Small item Sub item Specifications

GD-1300 SPECIFICATIONS 2 - 3
Incoming
functions
system
Incomingdetection
function Call signal detection function Call bell is distinguished from net call signals to judge incoming.
Remoteselectfunction
by CNG detection Receive is started when CNG signal is detected in standby with external telephone used.
Application
incoming function Distinctive Ringing function (North America) Conforms to the call distinguishing function provided
by the local telephone company.
(Europe)
Only distinction of TEL/FAX (When FAX distinction of
ON/OFF) (Default: OFF)
Call bell pattern OFF/STANDARD/Pattern 1 - 5 (North America)
Incoming reject
function Incoming is rejected when remaining memory capacity is less than 7%.
Call sound volume
adjustment function Volume select OFF/LOW/MIDDLE/HIGH
Alarm sound volume
adjustment function Volume select OFF/LOW/MIDDLE/HIGH
Key sound volume
setting Follows setting on the main unit.
Junk FAX protection
function Junk stations are registered to be rejected.
Number of
registrations Max. 10 items
Receive
functions
system
Receive function Receive standby mode • Auto (AUTO)
• Manual (MAN.)
• Answering machine (A.M.)
Basic receive
function Auto receive function The line is switched to FAX by detection of call signal. (receive standby mode)
Number of calls AUTO: 0 - 9 times (Default: 2 times)
Tel/FAX auto select No
Incoming reject
conditions • During Simulation by serviceman • Insufficient memory capacity
• During menu
• During memory status display
Manual receive
function Receive is manually started.
Number of calls 0 - 9 times (Default: 0 times)
Memory receive
function Receive data are accumulated in memory, and outputted when output conditions are satisfied.
Substitution receive
function Countermeasure against print inhibit state. • No recording paper
• Recording paper jam
• During copy/print job
• During printing by printer
• Cover open
• Paper empty, size error
Forcible memory
receive function No
Overtake output
function No
Receivedocument
output function Autoreduction/divided receive function Auto reduction function When the reference line number is in the specified range.
Divided receive
function When the reference line number exceeds the specified range.
Polling receive
function(Send request
function)
The remote machine must be provided with polling
function. Communication is allowed with an other
company machine.
Sequential send
request (Polling)
communication
Polling is made to two or more specified destinations.
Number of items of destination registration: Max. 100
items
Remote send Scanned document data in memory are sent
automatically by send request from the remote
machine.
Protection function • Check by sender number
• Check by allow number
Large item Middle item Small item Sub item Specifications

GD-1300 SPECIFICATIONS 2 - 4
Receive
functions
system
Print system Recording paper Recordable size A4/8.5" x 11"/8.5" x 14"
Recording paper
setting AUTO/TRAY 1/TRAY 2 (When the option installed) (In AUTO, TRAY1 has priority.) (Default: AUTO)
(North America)
Paper feed Paper feed by tray (Excluding multi manual feed)
Recording paper size
detection The recording paper length is detected. If the size differs, a paper size error occurs.
Recording paper
empty detection Detected by a paper pickup error.
Duplex receive Available only in the duplex function support models.
Transfer function Receive data are transferred to the registered station.
Number of registered
transfer destination 1 item
Registered telephone
number 40 digits
Local transfer Countermeasures against an error
• Paper jam
• No toner cartridge
•Notoner
• During toner supply
• Toner empty
• No recording paper
Telephone
functions
system
Main unit
telephone function On-hook dial function Yes
Manual redial function Max. memory digit 50 digits
Display digits End 20 digits
Pause function Yes (Fixed to 2sec)
Pulse/Tone select
function Yes (Set by soft switch)
Externaltelephone
connection
function
Select function by
DTMF Select number (1 digit) + [**] (0 - 9)
Record table
system Report list Report output function Report select • TIMER LIST • ACTIVITY REPORT
• TELEPHONE# LIST
•GROUPLIST
• PASSCODE LIST
• JUNK FAX# LIST
• USER PROGRAM LIST
Recording table auto
print function Number of items Auto print for every 50 items of send/receive total.
Communication report
list Report select • Send report list • Receive report list
• Serial broadcast send report list
• Image memory addition
Print status select • ALWAYS PRINTS
• ERROR ONLY
• NEVER PRINTS
Large item Middle item Small item Sub item Specifications

GD-1300 SPECIFICATIONS 2 - 5
Memory
functions
system
Memory outline Memory capacity Standard memory 2MB
Option No
Document quantity to
be stored A4 standard documents 120 pages
Data storage area/
backup when service
interruption (Recorded
data, receive data)
Image data Flash memory (Data are retained when the power is
turned off or when the battery is exhausted.)
Data other than image SRAM (Data are retained when the power is turned
off, but deleted when the battery is exhausted with the
power OFF.)
Treatment when
memory full Quick online Memory full on the first page Send cancel without call-out
Memory full on the
second or later page The line is shut-off after sending the last page of scanned data.
Memory send Memory full on the first
page Send cancel
Memory full on the
second or later page Send/Cancel is selected depending on the select menu display.
Send: The line is shut off after sending the scanned
data.
Cancel: Cancel even scanned data.
Memory status
check function Yes (The remaining memory capacity (%) is displayed on the LCD.)
Memory content
check function Not-sent job is displayed on the LCD. (Cancel is possible.)
Document jam Error LED, LCD message are displayed.
Service
functions
system
Simulation
function Send/receive of specified signals, commands, and image data are performed without a remote machine.
Counter function Communication
counter • Number of send pages • Number of receive pages
• Number of output pages
• Send time
• Receive time
Others Environmental
functions Auto clear Conforms to the main unit setting. When the operation is left for 1 min or more, the display returns
to the main menu.
Auto shut -off Conforms to the main unit setting.
Date and time
setting function (North America) Month/ Day/ Year/ Day of week/ O'clock/ minute
(Europe)
Day/ Month/ Year/ Day of week/ O'clock/ minute
Image priority
function STANDARD/FINE/SUPER FINE
BEEP LENGTH
(Communication
end sound length)
setting
3SEC/1SEC/NO BEEP
Auto summer time
setting (North America) Second Sunday of March AM2:00 →3:00,
First Sunday of November AM2:00 →1:00
(Default: OFF)
(Europe)
Last Sunday of March AM1:00 →2:00,
Last Sunday of October AM1:00 →0:00
(Default: ON)
Multi language
function Conforms to the main unit setting.
Large item Middle item Small item Sub item Specifications

GD-1300 INSTALLATION PROCEDURE 3 - 1
[3] INSTALLATION PROCEDURE
<Before installation>
For improvement of workability, some description in this manual as
well as components and accessories may change without prior
notice. In this case, refer to the service manual.
Turn off the main switch of the copier and then remove the power
plug of the copier from the outlet.
1. Parts included
Remove all pieces of fixing tape and fixing materials from the
finisher.
2. Installation procedure
(1) Detach the RADF or OC.
Detach the RADF or OC from the copier and softly place it on top
of the original table as shown below.
(2) Remove the rear cabinet.
1) Unscrew the screw and remove the rear cabinet shielding
plate. (Save the screw.)
2) Unscrew three screws and remove the rear cabinet. (Save the
screws.)
(3) Attach the speaker unit.
Attach the speaker unit using a supplied screw as shown below.
(4) Attach the FAX modem PWB.
1) When RADF is installed, unscrew the screw holding the RADF
ground terminal. (Save the screw.)
2) Insert two supplied screws and tighten them loosely as shown
below.
3) Attach the sponge around the bent portion of the FFC cable as
shown in the figure.
Cable: 1
Sponge: 1
FAX Modem PWB: 1
Key sheet: 1
FAX keyboard: 1 Ground angle: 1
Speaker unit: 1
Gasket: 2
Core: 1
Line cable: 1
Operation Manual: 1
Screws (M3x6): 5
For North America
Screws (M3x6): 6
For other than North America
North America
FCC label: 1
1
2
2 2
3
1

GD-1300 INSTALLATION PROCEDURE 3 - 2
4) Align the top frame portion of the FAX modem PWB with the
screw hole at the back of the speaker unit.
5) Place the holes of the bottom portion of the FAX modem PWB
onto the loosely tightened screws.
Slide the PWB to left to secure as shown below.
6) When RADF is installed, secure the RADF ground terminal
and the FAX modem PWB onto the copier using the screw
removed earlier in (4)-1).
• When OC is installed, secure the FAX modem PWB onto
the copier using a supplied screw.
7) Secure the FAX modem PWB onto the copier using a supplied
screw.
8) Tighten two loosely tightened screws completely.
9) Secure the ground angle using a supplied screw.
(5) Connect the cable, and the speaker connector
Connect the copier and the FAX modem PWB with the cable.
Fix the snap band to the FAX PWB.
NOTE: Connect the speaker connector to the FAX modem PWB.
(6) Work the rear cabinet, and attach the gasket.
1) Cut and remove the cut-out portion from the rear cabinet using
a tool such as nippers. (Be careful with the tool’s direction so
that the cut surface is flat.)
2) Attach two Gasket as shown.
(7) Reattach the rear cabinet.
1) Reattach the rear cabinet and secure it using three screws.
2) Reattach the rear cabinet shielding plate and secure it using
one screw removed earlier.
Reattach the RADF detached in Step (1).
(8) Peel off the dummy key sheet.
Open the RADF or OC.
Peel the edge of the dummy key sheet using a tool such as a
retractable knife, and then peel off the entire key sheet.
Ground angle
64
7
8
9
5 5
8
Speaker
connector
Cable
Gasket Gasket
Putting
standard
Putting
standard
1
2
Cut-out portion

GD-1300 INSTALLATION PROCEDURE 3 - 3
(9) Remove the dummy keyboard.
Unscrew the screw, and remove the dummy keyboard with a tool
like a pillar as shown below. (Save the screw.)
(10) Attach the FAX keyboard.
1) Remove the tape which is fixing the harness to the operation
panel.
2) Connect the copier cable to the FAX keyboard. Note that the
cable should be folded as shown below and placed under the
keyboard.
3) Place the FAX keyboard and secure it using the screw
removed earlier.
4) Affix the key sheet to the FAX keyboard.
(11) Paste the label on the rear cabinet of the copier.
Paste the FCC label on the position shown in the illustration.
Insert the power plug of the copier to the outlet and turn on
the main switch of the copier. Then, carry out the following
procedure.
(12) Set the destination.
1) Execute SIM 66-01.
2) Set the following values to SW80-1 – 8 of the FAX soft switch.
U.S.A. (10110101)
Canada (00100000)
U.K. (10110100)
Germany (00000100)
France (00111101)
Sweden (10100101)
Spain (10100000)
Italy (01011001)
Switzerland (10100110)
Finland (00111100)
Denmark (00110001)
Norway (10000010)
Netherlands (01111011)
Luxembourg (01101001)
Belgium (00001111)
3) Only for U.K., France, Netherlands, Belgium, Luxembourg, set
the FAX soft SW67-1 to 0.
(13) Connect the FAX modem PWB line cable.
Wrap the line cable twice around the supplied core, and connect it
to the FAX modem PWB as shown.
In order to manifest the compliance with FCC Part 68 and ICES-03.
it is required to provide the machine with the FCC Registration
Number (USA), Ringer Equivalence (USA) and Ringer Equivalence
(Canada).
After installing the FAX expansion kit in the machine, please put the
registration label, packed with the kit, on the prescribed location.
2
3
4Putting standard
FCC label
Putting
standard
FCC label

GD-1300 SIMULATION 4 - 1
[4] SIMULATION
1. Entering the simulation mode
To enter the serviceman simulation mode, press the keys as follows:
[#] key →[∗] key →[Clear] key →[∗] key
To cancel the simulation mode, press the [Clear All] key.
2. Key rule
3. List of simulations
[Numeric] key: Entry of MAIN CODE/SUB CODE
Selection of an item
Setup of an adjustment value in case of simulations for adjustment
[ ] [ ] key: Selection of MAIN CODE/SUB CODE
Selection of an item
[ENTER]/[OK]/[START] key: Settlement
<In case of simulations for print>
[ENTER]/[OK] key: Settlement (Without print)
[START] key: Settlement/Print
[Clear] key: (Interrupting operation check) Returns to the upper hierarchy.
In case of simulation of operation check, terminates the operations.
[Clear All] key: Exits from the simulation mode.
For a simulation of adjustment, the display returns to the initial display (00-00).
Main
code Sub code Contents
22 11 FAX-related counter display
24 10 FAX counter clear
46 12 Density adjustment in the FAX mode (Collective
adjustment)
13 FAX mode density adjustment (Normal text)
14 FAX mode density adjustment (Fine text)
15 FAX mode density adjustment (Super fine)
39 FAX mode sharpness adjustment
66 01 FAX soft SW setting
02 FAX soft SW initializing (excluding the adjustment
values)
03 FAX PWB memory check
04 Signal send mode (Max. value)
05 Signal send mode (Soft SW set value)
07 Image memory content print
Main
code Sub code Contents
66 10 Image memory content clear
11 300bps signal send (Max. value)
12 300bps signal send (Soft SW set value)
13 Dial test
17 DTMF signal send (Max. value)
18 DTMF signal send (Soft SW set value)
21 FAX information print
24 FAST SRAM clear
30 TEL/LIU status change check
33 Signal detection check
34 Communication time measurement
37 Speaker sound volume setting
38 Time setting/check

GD-1300 SIMULATION 4 - 2
4. Descriptions of various simulations
Main
code Sub code Contents Details of function/operation
22 11 FAX-related counter
display [Function] The FAX-related counter is displayed.
[Operation]
24 10 FAX counter clear [Function]
When [ENTER]/[OK]/[START] key is pressed, the FAX count value is set to 0 and "000,000" is dis-
played on the LCD.
[Operation]
46 12 Density adjustment in
the FAX mode
(Collective
adjustment)
[Function]
When [START] key is pressed, scan is executed with the entered exposure adjustment value and the
data stored on the FAX side is rewritten into the entered value.
All data of the exposure adjustment values are rewritten into the same value.
For the density adjustment table data, refer to SIM46-13 (density adjustment (Normal text) in the FAX
mode).
[Operation]
1) Initial display
∗[Clear] key: Returns to the main-sub code
input display.
2) Select 1
("xxx,xxx" is the current value.)
∗[Clear] key: Returns to "1) Initial display".
2) Select 2
("xxxxx: xxx. xx" is the current value.)
∗[Clear] key: Returns to "1) Initial display".
SELECT COUNTER
1:PAGE 2:TIME
SEND PAGE:xxx,xxx
RECV PAGE:xxx,xxx
TX TIME:xxxxx:xx.xx
RX TIME:xxxxx:xx.xx
1) Initial display
24-10 FAX CLR.
CLEARED 000,000
1) Initial display
("XX" is the exposure adjustment value of nor-
mal text stored on the FAX side.)
2) Enter a 2-digit value as the exposure adjust-
ment value with [Numeric] key.
("YY" is the entered exposure adjustment
value.)
3) Press [START] key.
Scan is started (self print), and the LED o
f
[START] key is turned off.
4) Print is started (self print).
After completion of printing, returns to “2)” dis
-
play.
ADJUST EXP. AUTO
XX
ADJUST EXP. AUTO
YY
ADJUST EXP. AUTO
SCAN YY
ADJUST EXP. AUTO
PRINT YY

GD-1300 SIMULATION 4 - 3
46 13 FAX mode density
adjustment (Normal
text)
[Function]
Scan is started with the exposure adjustment value entered with [START] key, and the stored data of
the selected mode on the FAX side is rewritten into the input value.
[Operation]
14 FAX mode density
adjustment (Fine text) [Function] When [START] key is pressed, scan is started with the entered exposure adjustment value and the
data of the selected mode on the FAX side is changed to the entered value.
For the density adjustment value table data, refer to SIM46-13 (FAX mode density adjustment (Nor-
mal text).)
[Operation]
15 FAX mode density
adjustment (Super
fine)
[Function]
When [START] key is pressed, scan is started with the entered exposure adjustment value and the
data of the selected mode on the FAX side is changed to the entered value.
For the density adjustment value table data, refer to SIM46-13 (FAX mode density adjustment (Nor-
mal text).)
[Operation]
Main
code Sub code Contents Details of function/operation
Density adjustment value data table
When initializing each data: 50
Mode Photo Exposure adjustment value
STD (Normal text) off
Fine (Fine text) on
off
Sfine (Super fine) on
off
1) Initial display
("XX" is the corresponding exposure adjustment
value of normal text mode stored on the FAX
side.)
2) Enter a 2-digit value as the exposure adjust-
ment value with [Numeric] key.
("YY" is the entered exposure adjustment
value.)
3) Press [START] key.
Scan is started (self print), and the LED o
f
[START] key is turned off.
4) Print is started (self print).
After completion of printing, returns to “2)”
display.
ADJUST EXP. STD
XX
ADJUST EXP. STD
YY
ADJUST EXP. STD
SCAN YY
ADJUST EXP. STD
PRINT YY
1) Initial display
("XX" is the corresponding exposure adjustment
value of the fine text mode stored on the FAX
side.)
2) Enter a 2-digit value as the exposure adjust-
ment value with [Numeric] key.
("YY" is the entered exposure adjustment
value.)
3) Press [START] key.
Scan start (self print)
4) Print start (self print)
After completion of printing, returns to “2)”
display.
ADJUST EXP. FINE
XX
ADJUST EXP. FINE
YY
ADJUST EXP. FINE
SCAN YY
ADJUST EXP. AUTO
PRINT YY
1) Initial display
("XX" is the corresponding exposure adjustment
value of the super fine mode stored on the FAX
side.)
2) Enter a 2-digit value as the exposure adjust-
ment value with [Numeric] key.
("YY" is the entered exposure adjustment
value.)
3) Press [START] key.
Scan start (self print)
4) Print start (self print)
After completion of printing, returns to “2)”
display.
ADJUST EXP. S-FINE
XX
ADJUST EXP. S-FINE
YY
ADJUST EXP. S-FINE
SCAN YY
ADJUST EXP. S-FINE
PRINT YY

GD-1300 SIMULATION 4 - 4
46 39 FAX mode sharpness
adjustment [Function] When [START] key is pressed, scan is started with the entered sharpness adjustment value, and the
data of the selected mode stored on the FAX side is changed to the entered value.
[Operation]
66 01 FAX soft SW setting [Function]
Use to check the FAX soft SW setting.
Every time when the key is pressed, the bit on the first line is switched 0 and 1.
[Operation]
02 FAX soft SW
initializing (excluding
the adjustment values)
[Function]
Use to initializing FAX soft SW.
[Operation]
Main
code Sub code Contents Details of function/operation
Sharpness adjustment value data table
When initializing each data: 1
Mode Sharpness adjustment value
1: STD
2: FINE
3: S-FINE
4: FINE/PHOTO
5: S-FINE/PHOTO
1) Initial display
2) [ ] [ ] key or after 2sec
Every time when [ ] key is pressed, the
second line is changed in the sequence of
No. 1 →2 →3 →4 →5 →1.
When [ ] key is pressed, the sequence is
reversed.
3) Select the arrow key 1-5, and the LED of
[START] key is lighted.
("ZZZZ" is the mode selected among STD,
FINE, S-FINE, FINE/PHOTO, and S-FINE/
PHOTO.)
("X" is the corresponding sharpness adjustment
value of the selected mode stored on the FAX
side.)
∗[Clear] key: Returns to “2)” display.
4) Enter a one-digit value (0-2) as the sharp
-
ness adjustment value with [Numeric] key.
("Y" is the entered sharpness adjustment value.
)
∗[Clear] key: Returns to “2)” display.
5) Press [START] key.
Scan start (self print)
6) Print start (self print)
After completion of printing, returns to “4)”
display.
SHARPNESS SETTING
PRESS ←,→
SHARPNESS SET (1-5)
1:STD
SHARPNESS SETTING
ZZZZ(0-2) X
SHARPNESS SETTING
ZZZZ(0-2) Y
SHARPNESS SETTING
SCAN Y
SHARPNESS SETTING
PRINT Y
1) Initial display
∗[Clear] key: Returns to the main-sub code
input display.
2) Enter a 3-digit value of soft SW No. (To
enter the fourth digit, shift to the left.), and
the press [ENTER]/[OK] key.
"xxxxxxxx" is the set content.
∗Select 2: Returns to the soft SW No. entry dis-
play.
3) Select 1
4) Change with 1-8 of [Numeric] key and the
press [ENTER]/[OK] key.
"xxxxxxxx" is the set content.
∗Select 2: Returns to the soft SW No. entry dis
-
play.
5) Select 1
After 2sec, returns to "1) Initial display".
ENTER FAX SOFT SW. #
(3 DIGITS) SW.___
No.### xxxxxxxx
CHANGE? 1:YES 2:NO
No.### xxxxxxxx
USE # KEY 12345678
No.### xxxxxxxx
STORED? 1:YES 2:NO
STORED
1) Initial display
After 2sec, main code and sub code input display.
INITIALIZED

GD-1300 SIMULATION 4 - 5
66 03 FAX PWB memory
check [Function] Use to check the FAX PWB memory.
[Operation]
04 Signal send mode
(Max. value) [Function] Use to set the signal send mode (Max. value).
Facsimile simulation design specifications.
[Operation]
Main
code Sub code Contents Details of function/operation
1) Initial display
2) [ ] [ ] key or after 2sec
Every time when [ ] key is pressed, the second line is changed in the sequence of No. 1 →2 →
3 →1.
When [ ] key is pressed, the sequence is reversed.
∗[Clear] key: Returns to the main-sub code input display.
3) [ENTER]/[OK] key
4) After completion of check
• When the result is OK
• In case of sum check error
• In case of address bus check
error
• In case of data check error
• In case of data bus check
error
• In case of erase check error
∗[Clear] key: Returns to "1) Initial display".
SELECT CHECK MEMORY
PRESS ←, →
SELECT MEMORY (1-3)
1:DRAM
SELECT MEMORY (1-3)
2:SRAM
SELECT MEMORY (1-3)
3:FLASH
CHECKING MEMORY
MEMORY CHECK RESULT
OK
MEMORY CHECK RESULT
XXXXXXXX SUM NG
MEMORY CHECK RESULT
XXXXXXXX A-BUS NG
MEMORY CHECK RESULT
XXXXXXXX DATA NG
MEMORY CHECK RESULT
XXXXXXXX D-BUS NG
MEMORY CHECK RESULT
XXXXXXXX ERASE NG
1 NO SIGNAL 13 7200bps(V34) 25 2400bps(V27ter)
2 33600bps(V34) 14 4800bps(V34) 26 300bps(FLAG)
3 31200bps(V34) 15 2400bps(V34) 27 2100Hz(CED)
4 28800bps(V34) 16 14400bps(V33) 28 1100Hz(CNG)
5 26400bps(V34) 17 12000bps(V33) 29 300bps(V21)
6 24000bps(V34) 18 14400bps(V17) 30 2100Hz(ANSam)
7 21600bps(V34) 19 12000bps(V17) 31 DUMMY RING
8 19200bps(V34) 20 9600bps(V17) 32 NO VOICE ANSWER
9 16800bps(V34) 21 7200bps(V17) 33 NO RING BACK TONE
10 14400bps(V34) 22 9600bps(V29) 34 LINE OFF HOOK
11 12000bps(V34) 23 7200bps(V29) 35 LINE ON HOOK
12 9600bps(V34) 24 4800bps(V27ter)
1) Initial display
2) 2-digit (1-35) with [Numeric] key / [ ] [ ] key / 2sec after
Pressing [ ] key or [ ] key reverses the sequence.
∗[Clear] key: Returns to the main-sub code input display.
3) [ENTER]/[OK] key
Send after setting
∗[Clear] key: Returns to "1) Initial display".
SELECT OUTPUT SIGNAL
(2 DIGITS) No.___
No. (1-35)
1:NO SIGNAL
..... No. (1-35)
35:LINE ON HOOK
OUTPUTING SIGNAL MAX
PRESS CLEAR TO STOP

GD-1300 SIMULATION 4 - 6
66 05 Signal send mode
(Soft SW set value) [Function] Use to set the signal send mode (Soft SW set value).
Facsimile simulation design specifications.
[Operation]
07 Image memory
content print [Function] Use to print the image memory content.
[Operation]
10 Image memory
content clear [Function] Use to clear the image memory content.
[Operation]
Main
code Sub code Contents Details of function/operation
1 NO SIGNAL 13 7200bps(V34) 25 2400bps(V27ter)
2 33600bps(V34) 14 4800bps(V34) 26 300bps(FLAG)
3 31200bps(V34) 15 2400bps(V34) 27 2100Hz(CED)
4 28800bps(V34) 16 14400bps(V33) 28 1100Hz(CNG)
5 26400bps(V34) 17 12000bps(V33) 29 300bps(V21)
6 24000bps(V34) 18 14400bps(V17) 30 2100Hz(ANSam)
7 21600bps(V34) 19 12000bps(V17) 31 DUMMY RING
8 19200bps(V34) 20 9600bps(V17) 32 NO VOICE ANSWER
9 16800bps(V34) 21 7200bps(V17) 33 NO RING BACK TONE
10 14400bps(V34) 22 9600bps(V29) 34 LINE OFF HOOK
11 12000bps(V34) 23 7200bps(V29) 35 LINE ON HOOK
12 9600bps(V34) 24 4800bps(V27ter)
1) Initial display
2) 2-digit (1-35) with [Numeric] key / [ ] [ ] key / 2sec after
Pressing [ ] key or [ ] key reverses the sequence.
∗[Clear] key: Returns to the main-sub code input display.
3) [ENTER]/[OK] key: Send after setting
∗[Clear] key: Returns to "1) Initial display".
SELECT OUTPUT SIGNAL
(2 DIGITS) No.___
No. (1-35)
1:NO SIGNAL
..... No. (1-35)
35:LINE ON HOOK
OUTPUTING SIGNAL SSW
PRESS CLEAR TO STOP
• When print is allowed
After completion of printing,
main code and sub code input
display.
• When there is no print data
After 2 sec, FAX control is
terminated.
• When print is inhibited
After 2 sec, main code and sub
code input display.
PRINT STORED NO DATA CAN NOT PRINT
• When there are some print data
After completion of memory clear, the buzzer
sounds.
Remains unchanged until the power is turned
off.
• When there are no print data
After completion of memory clear
After 2sec, main code and sub code input dis-
play.
CLEAR IMAGE MEMORY
CLEARED
PLEASE POWER OFF
CLEAR IMAGE MEMORY
CLEARED

GD-1300 SIMULATION 4 - 7
66 11 300bps signal send
(Max. value) [Function] Use to set the 300bps signal send (Max. value).
1: NO SIGNAL
2: 11111
3: 11110
4: 00000
5: 010101
6: 00001
[Operation]
12 300bps signal send
(Soft SW set value) [Function] Use to set the 300bps signal send (Soft SW set value).
1: NO SIGNAL
2: 11111
3: 11110
4: 00000
5: 010101
6: 00001
[Operation]
Main
code Sub code Contents Details of function/operation
1) Initial display
2) [ ] [ ] key or after 2sec
Every time when [ ] key is pressed, the second line is changed in the sequence of No. 1 →2
→3 →4 →5 →6 →1.
When [ ] key is pressed, the sequence is reversed.
∗[Clear] key: Returns to the main-sub code input display.
3) [ENTER]/[OK] key
∗[Clear] key: Returns to "1) Initial display".
SELECT SIGNAL
PRESS ←, →
SELECT SIGNAL (1-6)
1:NO SIGNAL
..... SELECT SIGNAL (1-6)
6:00001
OUTPUTING SIGNAL MAX
PRESS CLEAR TO STOP
1) Initial display
2) [ ] [ ] key or after 2sec
Every time when [ ] key is pressed, the second line is changed in the sequence of No. 1 →2
→3 →4 →5 →6 →1.
When [ ] key is pressed, the sequence is reversed.
∗[Clear] key: Returns to the main-sub code input display.
3) [ENTER]/[OK] key
∗[Clear] key: Returns to "1) Initial display".
SELECT SIGNAL
PRESS ←, →
SELECT SIGNAL (1-6)
1:NO SIGNAL
..... SELECT SIGNAL (1-6)
6:00001
OUTPUTING SIGNAL SSW
PRESS CLEAR TO STOP
