TOSVERT VF-AS1
PROFIBUS-DP Option Instruction Manual
PDP002Z
Notice
1. Make sure that this instruction manual is delivered to the end user of
the PROFIBUS option for the VF-AS1.
2. Read this manual before installing or operating the PROFIBUS option
for the VF-AS1. And keep it in a safe place for reference.

E6581279
-1‑
Safety precautions
On the inverter and in its instruction manual, important information is contained for
preventing injuries to users and damages to assets and for proper use of the device. Read
the instruction manual attached to VF-AS1 along with this instruction manual for completely
understanding the safety precautions and adhere to the contents of these manuals.
Explanation of markings
Marking Meaning of marking
Danger Indicates that errors in operation may lead to death or serious injury.
Warning Indicates that errors in operation may lead to injury (*1) to people or that these errors
may cause damage to physical property. (*2)
(*1) Such things as injury, burns or shock that will not require hospitalization or long periods of outpatient
treatment.
(*2) Physical property damage refers to wide-ranging damage to assets and materials.
Meanings of symbols
Marking Meaning of marking
Indicates prohibition (Don't do it).
What is prohibited will be described in or near the symbol in either text or picture form.
Indicates something mandatory (must be done).
What is mandatory will be described inor near the symbol ineither text or picture form.
Indicates danger.
What is dangerous will be described in or near the symbol in either text or picture form.
Indicates warning.
What the warning should be applied to will be described in or near the symbol ineither
text or picture form.
- 1/17 -

E6581279
-2‑
■General Operation
Danger
Disassembly
prohibited
▼Never disassemble, modify or repair.
Doing so could result in electric shock, fire and injury. For repairs, call your sales agency.
Prohibited
▼Do not attach this option to any inverter other than the VF-AS1.
Doing so could result in electric shock or fire.
▼When the inverter is energized, never detach the this option from the VF-AS1.
Doing so could result in electric shock.
▼Don't place or insert any kind of object into the PDP002Z (electrical wire cuttings, rods,
wires).
Doing so could result in electric shock or fire.
▼Do not allow water or any other fluid to come in contact with the PDP002Z.
Doing so could result in electric shock or fire.
Mandatory
▼Turn off the VF-AS1 when installing and wiring the terminal block.
▼If the inverter begins to emit smoke or an unusual odor, or unusual sounds, immediately
turn power off.
If the equipment is continued in operation in such a state, the result may be fire. Call your
local sales agency for repairs.
■Transportation & installation
Danger
Prohibited
▼Do not operate the inverter if it is damaged or any component is missing.
Doing so could result in electric shock or fire. Call your local sales agency for repairs.
▼Do not place any inflammable substances near the VF-AS1 Inverter.
If an accident occurs in which flame is emitted, this could lead to fire.
▼Do not install in any locationwhere the inverter could come into contact withwater or other
fluids.
Doing so could result in electric shock or fire.
▼When installing this option, be careful not to touchthe leads from parts on the reverse side
of its circuit board.
Doing so could result in injury.
Mandatory
▼Operate under the environmental conditions prescribed in the instruction manual.
Operations under any other conditions may result in malfunction.

E6581279
-3‑
■Wiring
Danger
Mandatory
▼Shut off power when installing and wiring this option.
Wait at least 15 minutes and check to make sure that the charge lamp (VF-AS1) is no
longer lit.
▼Electrical construction work must be done by a qualified expert.
Installation or connection of input power by someone who does not have that expert
knowledge may result in fire or electric shock.
■Operations
Danger
Prohibited
▼Do not touch switches when the hands are wet and do not try to clean the inverter with a
damp cloth.
Doing so could result in electric shock.
▼Do not pull on any cable itself.
Doing so could result in damage or malfunction.
■Disposal
Warning
Mandatory
▼For safety's sake, do not dispose of the disused inverter yourself but ask an industrial
waste disposal agent (*).
If the collection, transport and disposal of industrial waste is done by someone who is not
licensed for that job, it is a punishable violationof the law. (Laws in regard to cleaning and
processing of waste materials)
(*) Persons who specialize in the processing of waste and known as “industrial waste
product collectors and transporters” or “industrial waste disposal persons.”
Notes on use
Notes
▼Do not install the inverter where the temperature or the humidity will change rapidly.
▼Keep a distance of 20cm or more between the inverter's power cable and the data
transmission cable.
Or the inverter might malfunction because of noise.
▼Insert a magnetic contactor or similar device betweenthe inverter and the power supply to
ensure that power is turned off if an emergency stop command is entered through the
network.

E6581279
-4‑
Introduction
Thank you for purchasing a “VF-AS1 PROFIBUS Option (PDP002Z),” for TOSVERT VF-AS1
inverter. Installing this option in the VF-AS1 and using it together, data communication can be
made with a host computer or other device via PROFIBUS DP (DP-V0). Please read the entire
manual carefully before attempting to control your inverter via PROFIBUS connection.
Besides this instruction manual, the “PDP002Z Function Manual” is required to develop the
software of communication with VF-AS1. In such a case, please get in touch with our branch
offices or sales offices. (“PDP002Z Function Manual”: E6581343).
This manual is also aimed at the operator using "VF-AS1 PROFIBUS option", so please use it
for future maintenance and inspection.
■Explanation of model number of PROFIBUS option
PDP 002 Z −0
Revision No.
Cable length (cable between inverter and unit), Z: No cable
PROFIBUS model number
PROFIBUS
■Check of accessories
PROFIBUS option is shipped together with the following items in the package. Contact your
sales agency if any of these is missing.
• VF-AS1 PROFIBUS option ....... 1 board
(PDP002Z)
• Instruction manual for the VF-AS1 PROFIBUS option (this manual) ....... 1 copy
Japanese: ..... E6581278
English:......... E6581279
• LED name label ....... 1 pcs.
Manual

E6581279
-5‑
Contents
1. OVERVIEW .................................................................................................................................. 6
2. EXTERIOR FEATURES.................................................................................................................7
2.1. PROFIBUS connector............................................................................................................8
2.2. Status indicator..................................................................................................................... 8
3. INSTALLING THE PDP002Z...........................................................................................................9
4. CONNECTING TO THE NETWORK.............................................................................................. 10
4.1. Installation method .............................................................................................................. 10
4.2. Setting a stationaddress..................................................................................................... 11
5. COMMUNICATIONS-RELATED PARAMETERS OF THE VF-AS1................................................... 13
5.1. f851: Communication Loss Action Setting (Network breaks).............................................. 14
5.2. f852: Preset speed operationselection............................................................................ 14
5.3. f830: PPO TYPE Setting................................................................................................ 15
6. PROFIBUS LOCAL/REMOTE OPERATION.................................................................................. 16
7. SPECIFICATIONS....................................................................................................................... 17
8. WARRANTY................................................................................................................................ 17

E6581279
-6‑
1.Overview
The PDP002Z option allows the VF-AS1 inverter to be connected as a slave (DP-V0) into a
PROFIBUS network. Up to 126 stations* can be connected to the network (* including a
master. If no repeater is provided, up to 32 stations can be connected to each segment).
Master
(PLC, etc.)
VF-AS1 VF-AS1
VF-AS1
PROFIBUS
Maximum connectable units: 126
(In a case like the one above, PLC is
included in the count.)
PDP002Z PDP002Z
PDP002Z
Repeater

E6581279
-7‑
2.Exterior features
The external view of this option and the name of each part are shown below.
Danger
Prohibited
▼Do not change the switch setting when the power is on.
It could lead to electric shocks, or the option might breaks down or get
damaged.
PROFIBUS connector
(Refer to Section 2.1)
Status indicator
(Refer to Section 2.2)
Address switch
（Refer to Section 4.2）
Panel mounting tabs
(Refer to Section 3)

E6581279
-8‑
2.1. PROFIBUS connector
Used to connect PROFIBUS network cables. The connector is a D-Sub connector with 9 pin
female and the connector pin allocation described below follows the PROFIBUS standard.
The PDP002Z has no termination resistor. Therefore, termination resistors need to be
connected to the station on each side of the PROFIBUS network or the master, as shown in
the figure below. (The PROFIBUS connector with termination resistor are recommended.)
2.2. Status indicator
The PDP002Z has two LEDs, ST (status) and DX (data exchange) to indicate the
statuses of PROFIBUS-DP and the PDP002Z itself.
ST (Status): Red LED
LED Meanings
Off No diagnostics present
Flashes Waiting for parameterisation or configuration
Lights DP status error
* For example, a station address is not set correctly.
DX (Data exchange): Green LED.
Indicates the status of the PROFIBUS network.
It lights when the PDP002Z is on-line and data exchange is possible.
Pin number Symbol Signal type
1 NC Reserved
2 NC Reserved
3 RxD/TxD-P Send/receive data (+)
4 CNTR-P Control signal
5 DGND 0V (Insulated from the inside)
6 VP +5V power
7 NC Reserved
8 RxD/TxD-N Send/receive data (-)
9 NC Reserved
390 ohm*
VP(6 pin)
220 ohm*
RxD/TxD-P(3 pin)
390 ohm*
RxD/TxD-N(8 pin)
DGND(5 pin) * 1/4W or more is recommended.
15 4 3 2
9 8 7 6

E6581279
-9‑
3.Installing the PDP002Z
Install the PROFIBUS option to VF-AS1 as follows:
* When this option is used together with the IO card option, attach this option to the front
panel side.
(1) Turn off input power of VF-AS1 and wait for at least 15 minutes and then check that the
CHARGE lamp on VF-AS1 is no longer lit.
(2) Securing the option to the inverter
a) Insert a flat-blade screwdriver in each of the two holes at the upper part of the front
panel, release the panel mounting tab by pushing the screwdriver down, and remove
the front panel cover.
b) Install the option in the inverter by fitting the tabs on the lower side of the option into
the slots at the lower part of the inverter front panel.
c) Make sure the option is securely attached to the inverter. Then, check whether the
plastic bosses on the inverter case have fitted in the holes at the upper and lower
parts of the option.
d) Insert the tabs at the lower part of the front cover into the slots at the lower part of
the inverter to attach the front cover to the inverter.
e) Stuck the enclosed "LEDname label" onthe optionLED display part of a front cover.
a)
b)
c)
d)
e)
ST
DX
MNS
MNS
MNS
LED name label

E6581279
-10‑
4.Connecting to the network
4.1. Installation method
(1) Using the DIP switch on the PROFIBUS option, set a station address (Refer to Section
4.2).
(2) Connect a PROFIBUS connector to the PDP002Z. (Refer to Section 2.1.)
* If the PDP002Z is located at an end of the bus, connect a terminal resistor to it. (When
using a connector with termination resistor, set it ON.)
(3) Once all the parameters are set, the power must be cycled to the VF-AS1 for these
changes to take effect. (Refer to Section 5.)

E6581279
-11‑
4.2. Setting a station address
The DIP switch onthe circuit board of the option is used to set a station address. EachDIP
switch is ON when it is flipped to the lower position. By default, it is factory-configured to 2.
The station address must be unique and not match any other device on the network.
SW
ID 1 2 3 4 5 6 7 8 SW ID 1 2 3 4 5 6 7 8
0OFF OFF OFF OFF OFF OFF OFF OFF 32 OFF OFF ON OFF OFF OFF OFF OFF
1OFF OFF OFF OFF OFF OFF OFF ON 33 OFF OFF ON OFF OFF OFF OFF ON
2OFF OFF OFF OFF OFF OFF ON OFF 34 OFF OFF ON OFF OFF OFF ON OFF
3OFF OFF OFF OFF OFF OFF ON ON 35 OFF OFF ON OFF OFF OFF ON ON
4OFF OFF OFF OFF OFF ON OFF OFF 36 OFF OFF ON OFF OFF ON OFF OFF
5OFF OFF OFF OFF OFF ON OFF ON 37 OFF OFF ON OFF OFF ON OFF ON
6OFF OFF OFF OFF OFF ON ON OFF 38 OFF OFF ON OFF OFF ON ON OFF
7OFF OFF OFF OFF OFF ON ON ON 39 OFF OFF ON OFF OFF ON ON ON
8OFF OFF OFF OFF ON OFF OFF OFF 40 OFF OFF ON OFF ON OFF OFF OFF
9OFF OFF OFF OFF ON OFF OFF ON 41 OFF OFF ON OFF ON OFF OFF ON
10 OFF OFF OFF OFF ON OFF ON OFF 42 OFF OFF ON OFF ON OFF ON OFF
11 OFF OFF OFF OFF ON OFF ON ON 43 OFF OFF ON OFF ON OFF ON ON
12 OFF OFF OFF OFF ON ON OFF OFF 44 OFF OFF ON OFF ON ON OFF OFF
13 OFF OFF OFF OFF ON ON OFF ON 45 OFF OFF ON OFF ON ON OFF ON
14 OFF OFF OFF OFF ON ON ON OFF 46 OFF OFF ON OFF ON ON ON OFF
15 OFF OFF OFF OFF ON ON ON ON 47 OFF OFF ON OFF ON ON ON ON
16 OFF OFF OFF ON OFF OFF OFF OFF 48 OFF OFF ON ON OFF OFF OFF OFF
17 OFF OFF OFF ON OFF OFF OFF ON 49 OFF OFF ON ON OFF OFF OFF ON
18 OFF OFF OFF ON OFF OFF ON OFF 50 OFF OFF ON ON OFF OFF ON OFF
19 OFF OFF OFF ON OFF OFF ON ON 51 OFF OFF ON ON OFF OFF ON ON
20 OFF OFF OFF ON OFF ON OFF OFF 52 OFF OFF ON ON OFF ON OFF OFF
21 OFF OFF OFF ON OFF ON OFF ON 53 OFF OFF ON ON OFF ON OFF ON
22 OFF OFF OFF ON OFF ON ON OFF 54 OFF OFF ON ON OFF ON ON OFF
23 OFF OFF OFF ON OFF ON ON ON 55 OFF OFF ON ON OFF ON ON ON
24 OFF OFF OFF ON ON OFF OFF OFF 56 OFF OFF ON ON ON OFF OFF OFF
25 OFF OFF OFF ON ON OFF OFF ON 57 OFF OFF ON ON ON OFF OFF ON
26 OFF OFF OFF ON ON OFF ON OFF 58 OFF OFF ON ON ON OFF ON OFF
27 OFF OFF OFF ON ON OFF ON ON 59 OFF OFF ON ON ON OFF ON ON
28 OFF OFF OFF ON ON ON OFF OFF 60 OFF OFF ON ON ON ON OFF OFF
29 OFF OFF OFF ON ON ON OFF ON 61 OFF OFF ON ON ON ON OFF ON
30 OFF OFF OFF ON ON ON ON OFF 62 OFF OFF ON ON ON ON ON OFF
31 OFF OFF OFF ON ON ON ON ON 63 OFF OFF ON ON ON ON ON ON

E6581279
-12‑
SW
ID 1 2 3 4 5 6 7 8 SW ID 1 2 3 4 5 6 7 8
64 OFF ON OFF OFF OFF OFF OFF OFF 96 OFF ON ON OFF OFF OFF OFF OFF
65 OFF ON OFF OFF OFF OFF OFF ON 97 OFF ON ON OFF OFF OFF OFF ON
66 OFF ON OFF OFF OFF OFF ON OFF 98 OFF ON ON OFF OFF OFF ON OFF
67 OFF ON OFF OFF OFF OFF ON ON 99 OFF ON ON OFF OFF OFF ON ON
68 OFF ON OFF OFF OFF ON OFF OFF 100 OFF ON ON OFF OFF ON OFF OFF
69 OFF ON OFF OFF OFF ON OFF ON 101 OFF ON ON OFF OFF ON OFF ON
70 OFF ON OFF OFF OFF ON ON OFF 102 OFF ON ON OFF OFF ON ON OFF
71 OFF ON OFF OFF OFF ON ON ON 103 OFF ON ON OFF OFF ON ON ON
72 OFF ON OFF OFF ON OFF OFF OFF 104 OFF ON ON OFF ON OFF OFF OFF
73 OFF ON OFF OFF ON OFF OFF ON 105 OFF ON ON OFF ON OFF OFF ON
74 OFF ON OFF OFF ON OFF ON OFF 106 OFF ON ON OFF ON OFF ON OFF
75 OFF ON OFF OFF ON OFF ON ON 107 OFF ON ON OFF ON OFF ON ON
76 OFF ON OFF OFF ON ON OFF OFF 108 OFF ON ON OFF ON ON OFF OFF
77 OFF ON OFF OFF ON ON OFF ON 109 OFF ON ON OFF ON ON OFF ON
78 OFF ON OFF OFF ON ON ON OFF 110 OFF ON ON OFF ON ON ON OFF
79 OFF ON OFF OFF ON ON ON ON 111 OFF ON ON OFF ON ON ON ON
80 OFF ON OFF ON OFF OFF OFF OFF 112 OFF ON ON ON OFF OFF OFF OFF
81 OFF ON OFF ON OFF OFF OFF ON 113 OFF ON ON ON OFF OFF OFF ON
82 OFF ON OFF ON OFF OFF ON OFF 114 OFF ON ON ON OFF OFF ON OFF
83 OFF ON OFF ON OFF OFF ON ON 115 OFF ON ON ON OFF OFF ON ON
84 OFF ON OFF ON OFF ON OFF OFF 116 OFF ON ON ON OFF ON OFF OFF
85 OFF ON OFF ON OFF ON OFF ON 117 OFF ON ON ON OFF ON OFF ON
86 OFF ON OFF ON OFF ON ON OFF 118 OFF ON ON ON OFF ON ON OFF
87 OFF ON OFF ON OFF ON ON ON 119 OFF ON ON ON OFF ON ON ON
88 OFF ON OFF ON ON OFF OFF OFF 120 OFF ON ON ON ON OFF OFF OFF
89 OFF ON OFF ON ON OFF OFF ON 121 OFF ON ON ON ON OFF OFF ON
90 OFF ON OFF ON ON OFF ON OFF 122 OFF ON ON ON ON OFF ON OFF
91 OFF ON OFF ON ON OFF ON ON 123 OFF ON ON ON ON OFF ON ON
92 OFF ON OFF ON ON ON OFF OFF 124 OFF ON ON ON ON ON OFF OFF
93 OFF ON OFF ON ON ON OFF ON 125 OFF ON ON ON ON ON OFF ON
94 OFF ON OFF ON ON ON ON OFF 126 OFF ON ON ON ON ON ON OFF
95 OFF ON OFF ON ON ON ON ON

E6581279
-13‑
5.Communications-related parameters of the VF-AS1
On the network, the VF-AS1 (including the PDP002Z) serves as a slave device. Using the
parameters listed below, set the slave device on the network and its mode of operation.
The GSD files used to configure the PDP002Z can be downloaded from the Toshiba
Schneider Inverter web site.
http://www.inverter.co.jp/product/inv/vfas1/pdp/
Parameter Function Adjustment range Default setting
f830*Communication option
setting 1
(PPO TYPE)
0: None
1: PPO TYPE 1
2: PPO TYPE 2
3: PPO TYPE 3
4: PPO TYPE 4
0
f851
Inverter operation
at
the
communications
loss action
(Networkwirebreaks)
0: Stop and break of connection
1: None
2: Deceleration stop
3: Coast stop
4: Emergency stop
5: Preset speed operation command
(Operating at the preset speed operation frequency
set with f852)
0
f852 Preset speed
operation selection 0: None 1 to 15: Preset speed 0
f853 Monitoring of
communication device
station address
Displays the station address assigned with the
DIP switch.
0 to 125
1
f854** Monitoring of
communications
device’s baud rate
Displays the network communication speed set
with the DIP switch.
0: 12 Mbit/s
1: 6 Mbit/s
2: 3 Mbit/s
3: 1.5 Mbit/s
4: 500 kbit/s
5: 187.5 kbit/s
6: 93.75 kbit/s
7: 45.45 kbit/s
8: 19.2 kbit/s
9: 9.6 kbit/s
255: Disabled
0
* When the parameters are changed, the power must be cycled to the VF-AS1 for the
changes to take effect.
** The baud rate of the PDP002Z is automatically set by configuration a baud rate for the
master.

E6581279
-14‑
5.1. f851: Communication Loss Action Setting (Network breaks)
This parameter sets up the VF-AS1 response to a loss of communications with the
PROFIBUS network.
0: Stop and break of connection
The inverter decelerates the motor to a stop and gives the alarm.
Commands entered through the network are canceled, and the commands set with
parameters cmod and fmod become effective.
When communications are restored, the alarm is turned off.
1: None
The inverter remains inthe state where it was whenthe problem arose, and it gives the 
alarm.
2: Deceleration stop
The inverter decelerates the motor to a stop and gives the alarm. Commands entered
through the network are not canceled.
3: Coast stop
The inverter issues a command for a frequency of 0Hz and gives the alarm. Commands
entered through the network are not canceled.
4: Emergency stop
The error message err8 is displayed. Commands entered through the network are
not canceled.
When communications are restored, the inverter is not restored to working order and the
error message err8 does not disappear until the inverter is reset.
5: Preset speed operation command
Refer to Section 5.2
5.2. f852: Preset speed operation selection
If the communication loss action (parameter f851) is set to 5 (preset speed command),
the VF-AS1 will run at a preset speed as set up by this parameter in the case of a
communication loss (withalarm). Commands entered throughthe networkarenot canceled.
For example,
If the inverter is set as described below,
f851 = 5 (preset speed operation command)
f852 = 8 (preset speed operation frequency 8)
f287 (preset speed operation frequency 8) = 10 (10Hz)
Operation is carried out as follows.
Network Operation of the VF-AS1
Normal conditions........... Operates according to commands entered through the network.
↓ ↓
communications loss ...... Operates at 10Hz.
↓ ↓
Restoration.................... Operates according to commands entered through the network.

E6581279
-15‑
5.3. f830: PPO TYPE Setting
The PPO type of PDP002Z is set up by this parameter.
The PROFIBUS-DP protocol uses so-called PPOs (Parameter/Process Data Objects) in
cyclic communication. The figures below show the PPO types and configurations that the
PDP002Z supports.
PKW PZD
PKE IND PWE PZD1 STW
ZSW
PZD2
HSW
HIW PZD3 PZD4 PZD5 PZD6
PPO TYPE 1: Octet-String 12
PPO TYPE 2: Octet-String 20
PPO TYPE 3: Octet-String 4
PPO TYPE 4: Octet-String 12
PKW：Parameter ID/value
PZD：Process Data, cyclically transferred
PKE：Parameter ID (1st and 2nd octet)
IND：Sub-index (3rd octet), 4th octet is reserved
PWE：Parameter value (5th until 8th octet)
STW：Control word
HSW：Main setpoint
ZSW：Status word
HIW：Main actual value

E6581279
-16‑
6.PROFIBUS Local/Remote Operation
The example below shows how to configure the VF-AS1 for local / remote operation.
<Terminal function>
F terminal........... RUN command
R terminal........... PROFIBUS/Local (Terminal in this example) switching
RR/S4 terminal.... Operation frequency command
<Wiring>
VF-AS1
F
R
CC
PP
RR/S4
Variable resistor for adjustment
10k ohm
PROFIBUS/Local
Switch
Operation command
SINK
SW1
SOURCE
CCA
<Parameter setting>
cmod (command mode selection) = 0 (terminal board)
fmod (frequency setting mode selection 1) = 2 (RR/S4)
f112 (input terminal selection 2 (R)) = 48 (PROFIBUS/Local control)
<Operation>
R-CC terminal open:
VF-AS1 is controlled as slave device of PROFIBUS.
R-CC terminal closed:
F-CC terminal short to RUN
F-CC terminal open to STOP
Output frequency is set up by the RR/S4 signal input.

E6581279
-17‑
7.Specifications
Item Specifications
Model number PDP002Z
Technical data
PROFIBUS DP-V0
PPO TYPE: 1 to 4 by No.3.072 Profile for Variable Speed Drives
Connector: D-Sub 9 pin female
Station address setting: DIP switch
Baud rate: 9.6 kbps up to 12Mbps
Use environments Indoors, an altitude of 3,000m or less, where the product will not be exposed to direct sunlight, corrosive or explosive gases, vapor, coarse particulates including dust, and
where there is no grinding fluid or grinding oil nearby
Ambient
temperature -10 to +60°C
Storage
temperature -25 to +65°C
Relative humidity 20 to 93% (no condensation and absence of vapor)
Vibration 5.9m/s2{0.6G} or less (10 - 55Hz)
8.Warranty
Any part of the inverter that proves defective will be repaired free of charge under the following
conditions:
1. If the product breaks down within one year after delivery, although it is installed and handled
properly, and if the breakdown is undoubtedly attributable to a defect in designing or
manufacturing by Toshiba Schneider Inverter Corporation, the product shall be repaired free
of charge.
2. This warranty applies only to the inverter main unit.
3. For the following kinds of failure or damage, the repair cost shall be borne by the customer
even within the warranty period.
1) Failure or damage caused by improper or incorrect use or handling, or unauthorized
repair or modification of the inverter
2) Failure or damage caused by the inverter falling or an accident during transportation after
the purchase
3) Failure or damage caused by fire, salty water or wind, corrosive gas, earthquake, storm or
flood, lightning, abnormal voltage supply, or other natural disasters
4) Damage sustained as a result of the fact that the product was used for any application
other than that designated for the PROFIBUS option (circuit board) for the VF-AS1.
4. If terms and conditions of warranty are otherwise specified, priority is given to them.
- 17E -
