Toshiba BMS-IFWH5UL User manual

ENERGY MONITORING RELAY INTERFACE
Installation Manual
Model name:
BMS-IFWH5UL

–1–
Energy Monitoring Relay Interface Installation Manual
Contents
1 Precautions for safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3 Before installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5 Connection of power cables / earth wires / communication cables . . . . . . . . . . . . . 5
6 Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
7 Test run. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
• Thank you very much for purchasing this TOSHIBA / Carrier Energy Monitoring Relay Interface.
• Please read this manual carefully beforehand for proper installation of the relay interface.
1-EN

–2–
EN
Energy Monitoring Relay Interface Installation Manual
1Precautions for safety
• Read these “Precautions for Safety” carefully before installation.
• The precautions described below include important items regarding safety. Observe them without fail.
Understand the following details (indications and symbols) before reading the body text, and follow the
instructions.
• After the installation work has been completed, perform a test run to check for any problems. Explain how to use
and maintain the unit to the customer.
• Ask customer to keep this Manual at accessible place for future reference.
Indication Meaning of Indication
Text set off in this manner indicates that failure to adhere to the directions in the warning could result in
serious bodily harm (*1) or loss of life if the product is handled improperly.
Text set off in this manner indicates that failure to adhere to the directions in the caution could result in
serious bodily injury (*2) or damage (*3) to property if the product is handled improperly.
*1: Serious bodily harm indicates loss of eyesight, injury, burns, electric shock, bone fracture, poisoning, and other
injuries which leave aftereffect and require hospitalization or long-term treatment as an outpatient.
*2: Bodily injury indicates injury, burns, electric shock, and other injuries which do not require hospitalization or long-
term treatment as an outpatient.
*3: Damage to property indicates damage extending to buildings, household effects, domestic livestock, and pets.
Symbols Meaning of Symbols
“ " Indicates prohibited items.
The actual contents of the prohibition are indicated by a picture or text placed inside or next to the graphic
symbol.
“ " Indicates compulsory (mandatory) items.
The actual contents of the obligation indicated by a picture or text placed inside or next to the graphic
symbol.
•Ask an authorized dealer or qualified installation professional to install or reinstall this unit.
Inappropriate installation may result in electric shock or fire.
•Electrical work must be performed by a qualified electrician in accordance with this installation
manual.
The work must satisfy all local, national and international regulations.
Inappropriate work may result in electric shock or fire.
•Be sure to turn off all main power supply switches before starting any electrical work.
Failure to do so may result in electric shock.
•Do not modify the unit.
A fire or an electric shock may occur.
•Do not install this unit where flammable gas may leak.
If gas leaks and accumulates around the unit, it may cause a fire.
•Perform wiring correctly in accordance with specified the current capacity.
Failure to do so may result in short-circuiting, overheating or fire.
•Use predefined cable and connect them certainly. Keep the connecting terminal free from
external force.
It may cause an exothermic or a fire.
WARNING
CAUTION
WARNING
CAUTION
2-EN

–3–
Energy Monitoring Relay Interface Installation Manual
2Introduction
Applications / functions / specifications
Applications
• The Energy Monitoring Relay Interface is used to measure and distribute the power of the air conditioner.
Functions
• The interface calculates output power pulses with connected power meters, and then sends the calculation result
to the Smart BMS Manager.
Specifications
External view
Unit: inch (mm)
Power supply 120 VAC, 60 Hz
Power consumption 3 W
Operating temperature / humidity 32 to 104 °F (0 to 40 °C), 10 to 90% RH (no condensation)
Storage temperature -4 to 140 °F (-20 to +60 °C)
Chassis material Galvanized sheet metal 0.8 t
Dimensions 2.59” (H) x 7.59” (W) x 9.68” (D) inch (66 (H) x 193 (W) x 246 (D) mm)
Mass 2.98 lb (1.35 kg)
Power meter input
Input type Photo-coupler insulation
Input points 8 points
Input registance 3 k ohm
Input "ON" current 3.6 mA
Input pulse condition 50 msec or more
7.59" (193)
3.03" (77)
9.68" (246)
9.68" (246)
2.5"
(63.6)
2.59" (66)
3.03" (77)
7.6" (193.4)
8.62" (219)
9.21" (234)
7.59" (193)
4.72" (120)
1.34"
(34)
6-Ø7/32”
(6-Ø5.5)
mounting holes
3-EN

–4–
EN
Energy Monitoring Relay Interface Installation Manual
3Before installation
Check the following package contents.
Use the following wiring materials to connect the signal lines and power lines. (Procured on site)
4Installation
Energy Monitoring Relay Interface installation method and
orientation
There are five installation methods for this relay interface as shown below: surface mount and wall mounts.
Use the attached screws.
REQUIREMENT
Do not install the unit in any of the following places.
• Humid or wet place
• Dusty place
• Place exposed to direct sunlight
• Place where there is a TV set or radio within one meter
• Place exposed to rain (outdoors, under eaves, etc.)
Installation space and maintenance space
A side space for connecting through cable inlets and an upper space for maintenance
must be reserved before installation.
The other sides can be adjacent to surrounding objects.
No. Item Quantity Remarks
1 Energy Monitoring Relay Interface 1
2 Installation Manual 1
3 Screw 4 5/32” x 0.47” (M4 x 12 mm) tapping screws
4 Pin terminal 2
5 Cable clamp 1
No. Line Description
1 For RS-485
Type 2-core shield wires
Wire size AWG16 (1.25 mm2), 1600 ft (500 m) max. (total length)
Length
2 For connection to power meter
Type
2-core wire, AWG22 (0.3 mm2), 320 ft (100 m) max.Wire size
Length
3Forpower Type UL, CSA approved power supply wire
AWG18 (0.75 mm2), 160 ft (50 m) max.
Wire size
No good
3.94”(100)
7.87”
(200)
4-EN

–5–
Energy Monitoring Relay Interface Installation Manual
5Connection of power cables / earth wires /
communication cables
CAUTION
• The RS-485 communication cable has polarity. Connect A to A, and B to B. If connected with incorrect polarity, the
unit will not work.
Power cables / earth wires / communication cables
Connect power cables, earth wires, and communication cables to the specified terminals on the terminal block.
REQUIREMENT
Disconnect the appliance from the main power supply.
This appliance must be connected to the main power supply by a circuit breaker or switch with a contact separation
of at least 3 mm.
Fasten the screws to the terminal with torque of 0.5 Nm.
LN
BASG RS-485
DI1 DI6DI2 DI4
DI3 DI7 DI8DI5
1234
LED1
LED2
LED3
LED4
LED5
SW1SW2SW3
SW4SW6
SW7
+ - + - + - + - + - + - + - + -
1.38"
(35) 1.38" (35)
1.38"
(35) 0.24" (6)
0.24" (6)
0.39" (10)
2.17"
(55) 0.39" (10)
Power
supply
120 VAC,
60 Hz
Length of stripped
power cable
Length of stripped
communication cable
Power meter
Smart BMS Manager
Length of stripped
power meter wire
Insert the wire by pushing
the lever with a
screwdriver.
Check that the wire is
inserted securely.
When inserting two RS-485
communication cables into a single
terminal for connection to another
interface, crimp them using the
attached pin terminal.
Secure each cable with a
cable clamp.
Connect the
earth wire to the
earth terminal on
the chassis.
To connect 2 cables, change the
preset cable clamp to the
provided one and fix the cables
with the cable clamp as shown in
the figure.
Remove the grommet from the power
supply wire hole. Attach the conduit
pipe to the plate with a lock nut.
Use 1/2 inch conduit pipe.
Lock nut
Conduit pipe
Power supply wire hole
(Ø7/8” (22.2))
5-EN

–6–
EN
Energy Monitoring Relay Interface Installation Manual
Wiring connection
The following describes a connection example of Energy Monitoring Relay Interface.
Shield earthing
• The RS-485 communication cable must be earthed on Smart BMS Manager. It does not have to be earthed on
Energy Monitoring Relay Interface.
The shielded wire must be crimped with closed end connector. The shielded wire end must be insulated and left
open.
Connection of power meters
• Use a power meter with a pulse generator.
Connect the non-voltage contact output of the power meter to the Energy Monitoring Relay Interface.
An external input circuit is shown below.
Input signal is electrically isolated by photo-coupler.
(1) Example of contact input connection
(2) Example of contact input connection
CAUTION
• Output sink current has polarity.
When they are connected to inappropriate input terminal, the unit may not operate properly.
+
-
12 V
Input
terminal
Contact
DI-1 to DI-8
Power meter
(with pulse generator)
Energy Monitoring Relay Interface
+
-
12 V
Input
terminal
Current
sink
DI-1 to DI-8
Power meter
(with pulse generator)
Energy Monitoring Relay Interface
6-EN

–7–
Energy Monitoring Relay Interface Installation Manual
Connection diagram
LN
SW1
SW7
SG A B
DI1
DI2
DI3
DI4
DI5
DI6
DI7
DI8
4
SW1
SW7
SG A B
DI1
DI2
DI3
DI4
DI5
DI6
DI7
DI8
1
LN
Power meter 1
Power meter 2
Power meter 3
Power meter 4
Power meter 5
Power meter 6
Power meter 7
Power meter 8
Power supply
Power supply
The RS-485 communication
cable must be earthed on Smart
BMS Manager. It does not have
to be earthed on Energy
Monitoring Relay Interface.
Set the Energy
Monitoring Relay
Interface address
with SW1. Assign 1
to 8 to each address
to avoid duplication.
You can set the
Energy Monitoring
Relay Interface
address
independently from
the Digital Input /
Output Relay
Interface address.
CAUTION: The
SW1 setting is read
when the power is
turned on. Push the
reset switch (SW6)
after changing the
address.
Set SW7 as “120 ohm”
on a Energy Monitoring
Relay Interface with
address SW1=1, and
“Open” on the other
interfaces.
The RS-485
communication
cable has polarity
A and B. Be careful
when connecting
the wire.
Power meter 1
Power meter 2
Power meter 3
Power meter 4
Power meter 5
Power meter 6
Power meter 7
Power meter 8
Connect the shield
wire of the two
wires
The RS-485
communication
cable has polarity A
and B. Be careful
when connecting
the wire.
Smart BMS
Manager
7-EN

–8–
EN
Energy Monitoring Relay Interface Installation Manual
6Setting
The following settings are necessary to use Energy Monitoring Relay Interfaces.
• SW1 Address set switch
When two or more Energy Monitoring Relay Interfaces are used, set a different address for each unit to
avoid address duplication.
Assign addresses in an ascending order.
CAUTION
•When the SW1 setting has been changed, push reset switch SW6. The new address setting is read.
•You can set the Energy Monitoring Relay Interface address independently from the Digital Input / Output
Relay Interface address.
• SW2 Operation mode set switch These switches are not used during normal operation.
Set zero (0) or “all OFF”.
• SW3 Test switch
• SW4 Test switch
• SW6 Reset switch
When performing an address setting with SW1, push this reset switch after the address setting to read
the set value.
• SW7 RS-485 terminator resistor select switch
• Set SW7 as “120 ohm” on a Energy Monitoring Relay Interface with address SW1=1, and “Open” on
the other interfaces.
• When a Digital Input / Output Relay Interface is used with these interfaces in the same system,
terminator resistor setting on the Digital Input / Output Relay Interface is not necessary.
SW1 Address set switch
1-8 Address
0, 9-F Not used
SW2 Operating mode set switch (0 usually)
SW3 Test switch (all OFF usually)
SW4 Test switch
SW6 Reset switch
SW7
RS-485 terminator resistor select switch
120 ohm Open
LED1 Power indicator
LED2 RS-485 communication status indicator
LED3 Not used
LED4 Test indicator
LED5 Test indicator
ON
ON
LN
BASG RS-485
DI1 DI6DI2 DI4
DI3 DI7 DI8DI5
1234
LED1
LED2
LED3
LED4
LED5
SW1SW2SW3
SW4SW6
SW7
+ - + - + - + - + - + - + - + -
8-EN

Toshiba
–9–
Energy Monitoring Relay Interface Installation Manual
7Test run
Before starting test run
Turn on the power of the Energy Monitoring Relay Interface after all wire connections and settings are completed.
Turn on power of the air conditioning control system.
Test run
Confirming external input connection
• In the test mode, when the external inputs connected to the input terminals DI-1 to DI-8 are ON, the respective
LEDs will goes on so you can confirm the connection.
▼Confirming procedure:
Set the operation mode switch SW2 to “3”, and push the reset switch SW6 to enter the test mode.
Unless SW4 is pushed, the respective input status of DI-1 to DI-4 is indicated by LED2 to LED5.
When SW4 is pushed, the respective input status of DI-5 to DI-8 is indicated by LED2 to LED5.
(*) To return to the normal operation, reset SW2 to “zero (0)” and push SW6.
Checking the RS-485 communication status
Use LED2 for checking the RS-485 communication status.
When RS-485 communication with Smart BMS Manager is normal, LED2 will blink.
LED2 LED3 LED4 LED5
SW4 OFF Displays DI-1 input status. Displays DI-2 input status. Displays DI-3 input status. Displays DI-4 input status.
SW4 ON Displays DI-5 input status. Displays DI-6 input status. Displays DI-7 input status. Displays DI-8 input status.
Input ON: LED lights
Input OFF: LED turns off
LED Normal operation Abnormal operation
LED1 Power indicator ON OFF
LED2 RS-485 communication status indicator Blinking OFF
LED3 Not used OFF —
LED4 Test indicator OFF —
LED5 Test indicator OFF —
9-EN

–10–
EN
Energy Monitoring Relay Interface Installation Manual
10-EN
MEMO
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................
...................................................................................................

DE93329101-1
