Digital Input / Output Relay Interface Installation Manual
Contents
1 Precautions for safety. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
2 Introduction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
3 Before installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
4 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
5 Connection of power cables / earth wires / communication cables . . . . . . . . . . . . . 5
6 Setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
7 Test run. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 9
• Thank you very much for purchasing this TOSHIBA / Carrier Digital Input / Output Relay Interface.
• Please read this manual carefully beforehand for proper installation of the relay interface.
1-EN
+00DE93229101-1_01EN.book Page 1 Friday, October 4, 2013 2:40 PM

Toshiba
–2–
EN
Digital Input / Output Relay Interface Installation Manual
1Precautions for safety
• Read these “Precautions for Safety” carefully before installation.
• The precautions described below include important items regarding safety. Observe them without fail.
Understand the following details (indications and symbols) before reading the body text, and follow the
instructions.
• After the installation work has been completed, perform a test run to check for any problems. Explain how to use
and maintain the unit to the customer.
• Ask customer to keep this Manual at accessible place for future reference.
Indication Meaning of Indication
Text set off in this manner indicates that failure to adhere to the directions in the warning could result in
serious bodily harm (*1) or loss of life if the product is handled improperly.
Text set off in this manner indicates that failure to adhere to the directions in the caution could result in
serious bodily injury (*2) or damage (*3) to property if the product is handled improperly.
*1: Serious bodily harm indicates loss of eyesight, injury, burns, electric shock, bone fracture, poisoning, and other
injuries which leave aftereffect and require hospitalization or long-term treatment as an outpatient.
*2: Bodily injury indicates injury, burns, electric shock, and other injuries which do not require hospitalization or long-
term treatment as an outpatient.
*3: Damage to property indicates damage extending to buildings, household effects, domestic livestock, and pets.
Symbols Meaning of Symbols
“ " Indicates prohibited items.
The actual contents of the prohibition are indicated by a picture or text placed inside or next to the graphic
symbol.
“ " Indicates compulsory (mandatory) items.
The actual contents of the obligation indicated by a picture or text placed inside or next to the graphic
symbol.
•Ask an authorized dealer or qualified installation professional to install or reinstall this unit.
Inappropriate installation may result in electric shock or fire.
•Electrical work must be performed by a qualified electrician in accordance with this installation
manual.
The work must satisfy all local, national and international regulations.
Inappropriate work may result in electric shock or fire.
•Be sure to turn off all main power supply switches before starting any electrical work.
Failure to do so may result in electric shock.
•Do not modify the unit.
A fire or an electric shock may occur.
•Do not install this unit where flammable gas may leak.
If gas leaks and accumulates around the unit, it may cause a fire.
•Perform wiring correctly in accordance with specified the current capacity.
Failure to do so may result in short-circuiting, overheating or fire.
•Use predefined cable and connect them certainly. Keep the connecting terminal free from
external force.
It may cause an exothermic or a fire.
WARNING
CAUTION
WARNING
CAUTION
2-EN
+00DE93229101-1_01EN.book Page 2 Friday, October 4, 2013 2:40 PM

Toshiba
–3–
Digital Input / Output Relay Interface Installation Manual
2Introduction
Applications / functions / specifications
Applications
• The Digital Input / Output Relay Interface is used to control air conditioners by interlocking them with electric lock
signals, and to transmit air conditioner failures to other devices.
Functions
• The Digital Input / Output Relay Interface connects non-voltage contact signals, transmits their input status to
the Smart BMS Manager, and outputs signals from the contacts (open collector) according to the command from
the Smart BMS Manager.
Specifications
External view
Unit: inch (mm)
Power supply 120 VAC, 60 Hz
Power consumption 5 W
Operating temperature / humidity 32 to 104 °F (0 to 40 °C), 10 to 90% RH (no condensation)
Storage temperature -4 to 140 °F (-20 to +60 °C)
Chassis material Galvanized sheet metal 0.8 t
Dimensions 2.59” (H) x 7.59” (W) x 9.68” (D) inch (66 (H) x 193 (W) x 246 (D) mm)
Mass 2.98 lb (1.35 kg)
Digital input
Input type Photo-coupler insulation
Input points 8 points
Input registance 3 k ohm
Input "ON" current 3.6 mA
Digital output
Output type Open collector
Output points 4 points
Output current Max. 35 mA (per point)
Output voltage Less than DC 24 V
External power supply for Digital Output DC 12 V, 90 mA
7.59" (193)
9.68" (246)
9.68" (246)
2.5"
(63.6)
2.59" (66)
3.03" (77)3.03" (77)
7.6" (193.4)
8.62" (219)
9.21" (234)
7.59" (193)
4.72" (120)
1.34"
(34)
6-Ø7/32”
(6-Ø5.5)
mounting holes
3-EN
+00DE93229101-1_01EN.book Page 3 Friday, October 4, 2013 2:40 PM

Toshiba
–4–
EN
Digital Input / Output Relay Interface Installation Manual
3Before installation
Check the following package contents.
Use the following wiring materials to connect the signal lines and power lines. (locally procured)
4Installation
Digital Input / Output Relay Interface installation method and
orientation
There are five installation methods for this relay interface as shown below, surface mount and wall mounts. Use
the attached screws.
REQUIREMENT
Do not install the unit in any of the following places.
• Humid or wet place
• Dusty place
• Place exposed to direct sunlight
• Place where there is a TV set or radio within one meter
• Place exposed to rain (outdoors, under eaves, etc.)
Installation space and maintenance space
A side space for connecting through cable inlets and an upper space for maintenance
must be reserved before installation.
The other sides can be adjacent to surrounding objects.
No. Item Quantity Remarks
1 Digital Input / Output Relay Interface 1
2 Installation Manual 1
3 Screw 4 5/32” x 0.47” (M4 x 12 mm) tapping screws
4 Pin terminal 2
5Cableclamp 1
No. Line Description
1ForRS-485
Type 2-core shielded wires
Wire size AWG16 (1.25 mm2), 1600 ft (500 m) max. (total length)
Length
2 For digital Input / Output connection
Type
2-core wire, AWG22 (0.3 mm2), 320 ft (100 m) max.Wire size
Length
3Forpower Type UL, CSA approved power supply wire
AWG18 (0.75 mm2), 160 ft (50 m) max.
Wire size
No good
3.94”(100)
7.87”
(200)
4-EN
+00DE93229101-1_01EN.book Page 4 Friday, October 4, 2013 2:40 PM

Toshiba
–5–
Digital Input / Output Relay Interface Installation Manual
5Connection of power cables / earth wires /
communication cables
CAUTION
• The RS-485 communication cable has polarity. Connect A to A, and B to B. If connected with incorrect polarity, the
unit will not work.
Power cables / earth wires / communication cables
Connect power cables, earth wires, and communication cables to the specified terminals on the terminal block.
REQUIREMENT
Disconnect the appliance from the main power supply.
This appliance must be connected to the main power supply by a circuit breaker or switch with a contact separation
of at least 3 mm.
Fasten the screws to the terminal with torque of 0.5 Nm.
LN
BASG
RS-485
DI1 DI6DI2 DI4
DI3 DI7 DI8DI5
1234
LED1
LED2
LED3
LED4
LED5
SW1SW2SW3
SW4SW6
SW7
12V
GND
DO1
DO2
DO3
DO4
LED6
LED7
LED8
LED9
1.38"
(35) 1.38"
(35)
1.38"
(35) 0.24" (6)
0.39" (10)
2.17"
(55) 0.39" (10)
+-+-+-+-+-+-+-+-
0.24" (6)
Power supply
120 VAC, 60 Hz
Length of stripped
power cable
Length of stripped
communication cable
Digital input
contacts
Smart BMS
Manager
Digital
output
load
Length of stripped digital
Input / Output connector wire
Insert the wire by pushing
the lever with a
screwdriver. Check that the
wire is inserted securely.
When inserting two RS-485
communication cables into a single
terminal for connection to another
interface, crimp them using the
attached pin terminal.
Secure each cable with a
cable clamp.
Connect the earth
wire to the earth
terminal on the
chassis.
To connect 2 cables, change the
preset cable clamp to the
provided one and fix the cables
with the cable clamp as shown in
the figure.
Remove the grommet from the power
supply wire hole. Attach the conduit
pipe to the plate with a lock nut.
Use 1/2 inch conduit pipe.
Lock nut
Conduit pipe
Power supply wire
hole (Ø7/8” (22.2))
5-EN
+00DE93229101-1_01EN.book Page 5 Friday, October 4, 2013 2:40 PM

Toshiba
–6–
EN
Digital Input / Output Relay Interface Installation Manual
Wiring connection
The following describes a connection example of Digital Input / Output Relay Interface.
CAUTION
If an inductive load (relay coil) or a bulb is connected, a surge voltage or rush current will be generated. Take adequate
measures against surge voltage or rush current.
Shield earthing
• The RS-485 communication cable must be earthed on Smart BMS Manager. It does not have to be earthed on
Digital Input / Output Relay Interface. The shielded wire must be crimped with closed end connector. The
shielded wire end must be insulated and left open.
Connection of external digital inputs
• Input circuit examples are shown below (electrically isolated using a photo-coupler).
CAUTION
• Output sink current has polarity.
When they are connected to inappropriate input terminal, the unit may not operate properly.
Connection of external digital outputs
• Output circuit examples are shown below (open collector output electrically isolated using a photocoupler).
(1) Example of contact input connection (2) Example of contact input connection
(1) Example of load connection (2) Example of load connection
12 V
+
-
Input terminal
Contact
DI-1 to DI-8
12 V
+
-
Input terminal
Current sink
DI-1 to DI-8
12 V
GND
Output terminal
DO1 to DO4 Load
Power
supply
12 V
+12 V
Output terminal
DO1 to DO4
6-EN
+00DE93229101-1_01EN.book Page 6 Friday, October 4, 2013 2:40 PM

Toshiba
–7–
Digital Input / Output Relay Interface Installation Manual
Connection diagram
LN
SW1
SW7
SG A B
DI1
DI2
DI3
DI4
DI5
DI6
DI7
DI8
4
SW1
SW7
SG A B
DI1
DI2
DI3
DI4
DI5
DI6
DI7
DI8
1
12 VGND
DO1
DO2
DO3
DO4
GND
DO1
DO2
DO3
12 V
LN
DO4
Input contact 1
Input contact 2
Input contact 3
Input contact 4
Input contact 5
Input contact 6
Input contact 7
Input contact 8
Load 1
Load 2
Load 3
Load 4
Power supply
Power supply
The RS-485 communication cable must
be earthed on Smart BMS Manager. It
does not have to be earthed on Digital
Input / Output Relay Interface.
Set the Digital Input / Output Relay
Interface address with SW1. Assign 1 to 8
to each address to avoid duplication. You
can set the Digital Input / Output Relay
Interface address independently from the
Energy Monitoring Relay Interface
address.
CAUTION: The SW1 setting is read when
the power is turned on. Push the reset
switch (SW6) after changing the address.
Set the RS-485 terminator resistor on an
Energy Monitoring Relay Interface.
Set SW7 as "120 ohm" on a Digital Input /
Output Relay Interface with address
SW1=1, when the Digital Input / Output
Relay Interface is used in a system without
Energy Monitoring Relay Interface. Set
SW7 as "Open" on the other interfaces.
The RS-485 signal
wire has polarity A
and B. Be careful
when connecting
the wire.
Input contact 1
Input contact 2
Input contact 3
Input contact 4
Input contact 5
Input contact 6
Input contact 7
Input contact 8
Load 1
Load 2
Load 3
Load 4
Smart BMS
Manager
7-EN
+00DE93229101-1_01EN.book Page 7 Friday, October 4, 2013 2:40 PM

Toshiba
–8–
EN
Digital Input / Output Relay Interface Installation Manual
6Setting
The following settings are necessary to use Digital Input / Output Relay Interfaces.
• SW1 Address set switch
When two or more Digital Input / Output Relay Interfaces are used, set a different address for each unit
to avoid address duplication.
Assign addresses in ascending order.
CAUTION
•When the SW1 setting has been changed, push the reset switch SW6. The new address setting is read.
•Address of Digital Input / Output Relay Interface can be set independently from Energy Monitoring Relay
Interface.
• SW2 Operation mode set switch
• SW3 Test switch
• SW4 Test switch
These switches are not used during normal operation. Set zero (0) or “all
OFF”.
• SW6 Reset switch
When performing an address setting with SW1, push this reset switch after the address setting to read
the set value.
• SW7 RS-485 terminator resistor select switch
Terminator resistor of RS-485 must be set on Energy Monitoring Relay Interface.
When Digital Input / Output Relay Interface is used without Energy Monitoring Relay Interface, set it
[120 ohm] on Digital Input / Output Relay Interface with address SW1=1 and, set it [Open] on the other
Interfaces.
LN
BASG RS-485
DI1 DI6DI2 DI4DI3 DI7 DI8DI5
1234
LED1
LED2
LED3
LED4
LED5
SW1SW2SW3
SW4SW6
SW7
12 V
GND
DO1
DO2
DO3
DO4
LED6
LED7
LED8
LED9
+ - + - + - + - + - + - + - + -
SW1 Address set switch
1-8 Address
0, 9-F Not used
SW2 Operating mode set switch (0 usually)
SW3 Test switch (all OFF usually)
SW4 Test switch
SW6 Reset switch
SW7
RS-485 terminator resistor select switch
120 ohm Open
LED1 Power indicator
LED2 RS-485 communication status indicator
LED3 Not used
LED4 Test indicator
LED5 Test indicator
LED6 -LED9 Digital output indicator
ON ON
8-EN
+00DE93229101-1_01EN.book Page 8 Friday, October 4, 2013 2:40 PM

Toshiba
–9–
Digital Input / Output Relay Interface Installation Manual
7Test run
Before starting test run
Turn on the power of the Digital Input / Output Relay Interface after all cable connections and settings are
completed. Turn on power of the air conditioning control system.
Test run
Confirming external input connection
• In the test mode, when the external inputs connected to the input terminals DI-1 to DI-8 are ON, the respective
LEDs will goes on so you can confirm the connection.
▼Confirming procedure:
1Set the operation mode switch SW2 to “3”, and push the reset switch SW6 to enter the test mode.
2Unless SW4 is pushed, the respective input status of DI-1 to DI-4 is indicated by LED2 to LED5.
3When SW4 is pushed, the respective input status of DI-5 to DI-8 is indicated by LED2 to LED5.
(*) To return to the normal operation, reset SW2 to “zero (0)” and push SW6.
Checking external output connection
• In the test mode, you can set output terminals DO1 to DO4 to ON or OFF with the test switch. Their output status
is indicated by each LED.
▼Checking procedure:
1Set the operation mode switch SW2 to “3” in the same way as the external input check, and then
push the reset switch SW6 to enter the test mode.
2When the bit of the test switch SW3 is set to ON, the external output turns ON; when set to OFF,
the external output turns OFF. Bits 1 to 4 of SW3 correspond to output terminals DO1 to DO4.
The respective output status of output terminals DO1 to DO4 is indicated by LED6 to LED9.
The LEDs light with the output ON, and goes off with the output OFF.
(*)To return to normal operation, reset SW2 to “zero (0)” and push SW6.
LED2 LED3 LED4 LED5
SW4 OFF Displays DI-1 input
status.
Displays DI-2 input
status.
Displays DI-3 input
status.
Displays DI-4 input
status.
SW4 ON Displays DI-5 input
status.
Displays DI-6 input
status.
Displays DI-7 input
status.
Displays DI-8 input
status.
Input ON: LED lights
Input OFF: LED turns off
LED6 LED7 LED8 LED9
Displays DO1 output status. Displays DO2 output status. Displays DO3 output status. Displays DO4 output status.
Output ON: LED lights
Output OFF: LED turns off
9-EN
+00DE93229101-1_01EN.book Page 9 Friday, October 4, 2013 2:40 PM

Toshiba
–10–
EN
Digital Input / Output Relay Interface Installation Manual
Checking the RS-485 communication status
Use LED2 for checking the RS-485 communication status.
When RS-485 communication with Smart BMS Manager is normal, LED2 will blink.
LED Normal operation Abnormal operation
LED1 Power indicator ON OFF
LED2 RS-485 communication status indicator Blinking OFF
LED3 Not used OFF —
LED4 Test indicator OFF —
LED5 Test indicator OFF —
10-EN
+00DE93229101-1_01EN.book Page 10 Friday, October 4, 2013 2:40 PM

DE93229101-1
Toshiba
+00DE93229101-1_01EN.book Page 13 Friday, October 4, 2013 2:40 PM
