Toshiba IK-WB02A - PoE Network Camera User manual

NETWORK CAMERA
Safety Precautions
IK-WB02A
For information on the latest products and peripheral
devices, refer to the following Web page.
■ http://www.netcam.toshiba.com
●The above URL is subject to change without prior notice.
If the URL changes, refer to the Toshiba website
(http://www.cctv.toshiba.com).
●The Operations Manual for this product is included on the
supplied mini CD-ROM.
●These Safety Precautions appy to firmware version R 1.01
and later.
Model
*A lens is not supplied with the
network camera.
WB02-03
IK-WB02A Precautions E new 2004.11.24, 15:271

2
FCC(US) Information
Product Name : NETWORK CAMERA
Model Number(s) : IK-WB02A
FCC Notice “Declaration of Conformity Information”
This device complies with part 15 of the FCC Rules.
Operation is subject to the following two conditions :
(1) This device may not cause harmful interference, and
(2) this device must accept any interference received,
including interference that may cause undesired
operation.
Toshiba America Information System, Inc.
Security & Network Video Products
9740 Irvine Boulevard,
Irvine, California 92618-1697
[phone]
This equipment has been tested and found to comply with
the limits for a Class B digital device, pursuant to part 15
of the FCC Rules. These limits are designed to provide
reasonable protection against harmful interference in a
residential installation. This equipment generates, uses
and can radiate radio frequency energy and, if not
installed and used in accordance with the instructions,
may cause harmful interference to radio communications.
However, there is no guarantee that interference will not
Tested To Comply
With FCC Standards
FOR HOME OR OFFICE USE
IK-WB02A Precautions E new 2004.11.24, 15:272

3
occur in a particular installation. If this equipment does
cause harmful interference to radio or television reception,
which can be determined by turning the equipment off
and on, the user is encouraged to try to correct the
interference by one or more of the following measures:
- Reorient or relocate the receiving antenna.
- Increase the separation between the equipment and
receiver.
- Connect the equipment into an outlet on a circuit
different from that to which the receiver is connected.
- Consult the dealer or an experienced radio/TV
technician for help.
Warning : Changes or modifications made to this
equipment, not expressly approved by
Toshiba or parties authorized by Toshiba
could void the user's authority to operate the
equipment.
Canadian Information
Industry Canada
This Class B digital apparatus complies with Canadian
ICES-003.
Cet appareil numérique de la classe B est conforme à
la norme NMB-003 du Canada.
IK-WB02A Precautions E new 2004.11.24, 15:273

4
Thank you for purchasing the IK-WB02A Network
Camera.
Before you start using the camera, read these Safety
Precautions carefully to ensure correct usage. Once
you have finished reading these Safety Precautions,
keep it in a convenient place for future reference.
The design, specifications, software, and manual
contents are subject to change without prior notice.
Some pictures and illustrations contained herein may
slightly differ from the actual images.
Terms and Trademarks
●The term “OS” is used in the Operations Manual to
indicate operating systems compatible with this
product.
- Windows 2000: Microsoft
®
Windows
®
2000 operating system
- Windows XP: Microsoft
®
Windows
®
XP operating system
●The formal name of Windows®is Microsoft®
Windows®Operating System.
●Microsoft®and Windows®are trademarks or
registered trademarks of Microsoft®Corporation in
the United States and other countries.
●Adobe is a registered trademark and Acrobat
Reader is a trademark of Adobe Systems
Incorporated.
●Other product names appearing in these Safety
Precautions or the Operations Manual may be
trademarks or registered trademarks of their
respective holders.
Introduction
IK-WB02A Precautions E new 2004.11.24, 15:274

5
Accessories
Confirm that all of the following accessories have been
supplied with the network camera.
Mini CD-ROM (x1)
*Includes the Operations
Manual and the software
Camera Finder.
Safety Precautions and Quick
Start Guide (this document) (x1)
* The Quick Guide is at the back
of the Safety Precautions.
WARRANTY (x1)
IK-WB02
IRIS connector (x1)
EMI core
About the POWER
SELECT Switch
(x1)
(x3)
For details on how to use the
EMI core, refer to “How to use
EMI core” on the mini CD-ROM.
IK-WB02A Precautions E new 2004.11.24, 15:275

6
Introduction… ............................................................... 4
Table of Contents .......................................................... 6
IMPORTANT SAFEGUARDS ......................................... 7
NOTES ON USE AND INSTALLATION ........................ 11
Precautions for Use ..................................................... 12
Camera Installation Guide .......................................... 15
Table of Contents
For details on settings, operations, etc, refer to the
Operations Manual (PDF file) included on the mini
CD-ROM.
Acrobat Reader is required to view the PDF file. If you
do not have Acrobat Reader, download it from the Web
site of Adobe Systems Incorporated.
IK-WB02A Precautions E new 2004.11.24, 15:276

7
IMPORTANT SAFEGUARDS
1. Read Instructions
All the safety and operating instructions should be read
before the product is operated.
2. Retain Instructions
The safety instructions and instruction manual should be
retained for future reference.
3. Heed Warnings
All warnings on the product and in the instruction manual
should be adhered to.
4. Follow Instructions
All operating and use instructions should be followed.
5. Cleaning
Disconnect this video product from the power supply
before cleaning.
6. Attachments
Do not use attachments not recommended by the video
product manufacturer as they may cause hazards.
7. Water and Moisture
Do not use this video product near water-for example, near
a bath tub, wash bowl, kitchen sink, or laundry tub, in a
wet basement, or near a swimming pool and the like.
8. Accessories
Do not place this video product on an unstable cart, stand,
tripod, bracket or table. The video product may fall,
causing serious injury to a child or adult, and serious
damage to the product. Use only with stand, tripod,
bracket, or table recommended by the manufacturer, or
sold with the video product. Any mounting of the product
should follow the manufacturer's instructions, and should
use a mounting accessory recommended by the
manufacturer.
IK-WB02A Precautions E new 2004.11.24, 15:277

8
IMPORTANT SAFEGUARDS (Cont.)
9. Ventilation
This video product should never be placed near or over a
radiator or heat register. This video product should not be
placed in a built-in installation such as a bookcase or rack
unless proper ventilation is provided or the manufacturer's
instructions have been adhered to.
10. Power Sources
This video product should be operated only from the type
of power source indicated on the marking label. If you are
not sure of the type of power supply to your location,
consult your product dealer.
11. Power-Cord Protection
Power-Supply cords should be routed so that they are not
likely to be walked on or pinched by items placed upon or
against them, paying particular attention to cords at plugs,
screws and the point where they exit from the product.
12. Lightning
For added protection for this video product during a
lightning storm, or when it is left unattended and unused
for long periods of time, unplug it from the wall outlet and
disconnect the power supply and cable system. This will
prevent damage to the video product due to lightning and
power-line surges.
13. Overloading
Do not overload power supply and extension cords as
this can result in a risk of fire or electric shock.
14. Object and Liquid Entry
Never push objects of any kind into this video product
through openings as they may touch dangerous voltage
points or short-out parts that could result in a fire or
electrical shock. Never spill liquid of any kind on the video
product.
IK-WB02A Precautions E new 2004.11.24, 15:278

9
15. Servicing
Do not attempt to service this video product yourself as
opening or removing covers may expose you to dangerous
voltage or other hazards. Refer all servicing to qualified
service personnel.
16. Damage Requiring service
Disconnect this video product from the power supply and
refer servicing to qualified service personnel under the
following conditions.
a. When the power-supply cord or plug is damaged.
b. If liquid has been spilled, or objects have fallen into the
video product.
c. If the video product has been exposed to rain or water.
d. If the video product does not operate normally by
following the operating instructions in the instruction
manual. Adjust only those controls that are covered by
the instruction manual as an improper adjustment of
other controls may result in damage and will often
require extensive work by a qualified technician to
restore the video product to its normal operation.
e. If the video product has been dropped or the cabinet
has been damaged.
f. When the video product exhibits a distinct change in
performance-this indicates a need for service.
17. Replacement Parts
When replacement parts are required, be sure the service
technician has used replacement parts specified by the
manufacturer with the same characteristics as the original
part. Unauthorized substitutions may result in fire, electric
shock or other hazards.
18. Safety Check
Upon completion of any service or repairs to this video
product, ask the service technician to perform safety
checks to determine that the video product is in proper
operating condition.
IK-WB02A Precautions E new 2004.11.24, 15:279

10
IMPORTANT SAFEGUARDS (Cont.)
The CAUTION label, shown on the above part, is attached
on the bottom of camera.
The lightning flash with arrowhead symbol,
within an equilateral triangle, is intended to alert
the user to the presence of uninsulated
"dangerous voltage" within the product's
enclosure that may be of sufficient magnitude
to constitute a risk of electric shock to persons.
The exclamation point within an equilateral
triangle is intended to alert the user to the
presence of important operating and
maintenance (servicing) instructions in the
literature accompanying the appliance.
WARNING:
TO REDUCE THE RISK OF FIRE OR
ELECTRIC SHOCK, DO NOT
EXPOSE THIS APPLIANCE TO RAIN
OR MOISTURE.
CAUTION
CONNECT 24V AC UL LISTED
CLASS 2 POWER SUPPLY.
FIELD INSTALLATION MARKING:
WORDED : “THIS INSTALLATION SHOULD BE MADE BY A QUALIFIED SERVICE
PERSON AND SHOULD CONFORM TO ALL LOCAL CODES.”
Note: The camera is designed for indoor use.
IK-WB02A Precautions E new 2004.11.24, 15:2710

11
NOTES ON USE AND INSTALLATION
• Do not aim the camera at the sun
Do not aim the camera at the sun or point it at sun even if
you are not shooting.
• Do not shoot intense light
Intense light such as a spotlight may cause a bloom or
smear. A vertical stripe may appear on the screen.
However, this not a malfunction.
• Treat the camera with care
Do not drop the camera or subject it to strong shock or
vibration. Otherwise, the camera may malfunction.
• Never touch internal parts
Do not touch the internal parts of the camera other than
the parts specified. Otherwise, the camera may
malfunction.
• Do not splash water on the camera
Install the camera where the camera can be kept dry. If the
camera gets wet, turn off the power and contact your dealer.
• Install the camera
Where no video noise appears
If cables are wired near electric lighting wires or a TV set,
noise may appear in images. In this event, relocate cables
or reinstall equipment.
• Check the ambient temperature and humidity
Avoid using the camera where the temperature is hotter
or colder than specified. Otherwise, the quality of images
may deteriorate or internal parts may be affected. Special
care is required to use the camera at high temperature
and humidity.
• Should you notice any trouble
If any trouble occurs while you are using the camera, turn
off the power and contact your dealer. Continued use in
this state might cause fire or electric shock. For details on
repair, consult the place of purchase, or please contact
the technical support number.
IK-WB02A Precautions E new 2004.11.24, 15:2711

12
Precautions for Use
About the SD Memory Card
●There is a limit to the number of rewrites that is
possible with the SD memory card. Replacing of
the SD memory card when performing periodic
maintenance of the camera is recommended.
●The camera supports the following SD memory
cards. Do not use memory cards with other
specifications.
SD memory card: 64MB, 128MB, 256MB and
512MB SD memory cards (3.3
V) supported.
Physical interface: Part 1. Physical Layer
Specification; Version 1.01
●Images may not be recorded or read correctly if an
unsupported SD memory card is used with the
camera.
●Carefully read the
User's guide , precautions on use,
and any other information supplied with a
purchased memory card.
●An SD memory card can be used for the loop
recording of images. The life-span (number of
rewrites possible) of an SD memory card is greatly
affected by the capacity of the SD memory card.
The use of a 128MB, 256MB or 512MB large-
capacity SD memory card is recommended for loop
recording.
●To achieve maximum performance of the camera,
the use of a Toshiba SD memory card is
recommended. If a card of another company is
used, the recording intervals may lengthen and the
erasure time during overwriting may increase. As a
IK-WB02A Precautions E new 2004.11.24, 15:2712

13
result, the number of delivered frames of live video
may decrease.
●Do not use a memory card containing the data
recorded by another device with the camera as this
may result in the camera not functioning correctly.
●Do not modify, overwrite the data, or change the
folder name of an SD memory card. It may result in
the camera not functioning correctly.
●Data recorded with the camera do not comply with
the image file format Exif and the DCF standard. If
the SD memory card is to be removed to play
images, use a personal computer to play the
images. Other devices may not be capable of
displaying the images.
About the AC Adapter
●An AC adapter is not supplied with this model. If
you want to use an AC adapter, you will need to
provide an adapter with DC12V output or AC24V
output that is capable of supplying at least 10 W.
About the PoE Power Supply Device
●A PoE power supply device is required for supplying
power to the camera via the LAN cable.
IK-WB02A Precautions E new 2004.11.24, 15:2713

14
About the software
This product contains a piece of software (hereafter the
Software) licensed to TOSHIBA CORPORATION
(hereafter TOSHIBA) by TOPCO CORPORATION.
(hereafter TOPCO).
The copyright and other intellectual property rights of
the software are held by TOPCO or the licensor.
The software is protected by the Copyright Law,
Universal Copyright Convention, and other intellectual
property laws and agreements. The permission of
TOPCO or the licensor must therefore be obtained
before the software can be reproduced.
Note, however, that the software is partly covered under
the GNU General Public License Version 2 (hereafter
GPL2). You can obtain a copy of GPL2 at http://
www.fsf.org/copyleft/gpl.html. TOPCO will provide the
GPL-covered source code of the software in
accordance with the terms of GPL2. Contact TOPCO if
you need it for more information.
Precautions for Use (Cont.)
IK-WB02A Precautions E new 2004.11.24, 15:2714

15
1/4"-20UNC
112 15
Wall
9.5mm
4
6
80
The Installation Guide is for reference only.
Mounting bracket is not included.
EIM-0010325 4/26/2000
Camera Installation Guide
Installation Example
IK-WB02A Precautions E new 2004.11.24, 15:2715

TOSHIBA AMERICA INFORMATION SYSTEMS. INC
Security & Network Video Products
9740 Irvine Boulevard,
Irvine California 92618-1697
Phone Number: [phone]
IK-WB02A Precautions E new 2004.11.24, 15:2716

For information on the latest products and peripheral devices, refer to
the following Web page.
■http://www.netcam.toshiba.com
The above URL is subject to change without prior notice. If the URL
changes, refer to the Toshiba website
(http://www.cctv.toshiba.com).
This User’s Guide applies to the firmware version R1.01 and later.
NETWORK CAMERA
Model: IK-WB02A
Operation Manual
To get started, read the separate “Safety Precautions” carefully.
*A lens is not supplied with the network camera.
WB02-02
IK-WB11/01_01Cover_E 2004.10.21, 15:001

2
Installation/Set up Viewing • Listening
and Operation
Recording Setting up Others
Table of Contents
●Table of Contents .................................................................................................... 2
●Important Safety Instructions .................................................................................. 4
●Names and Features of Parts ................................................................................. 5
Installation/Set up
●Installing a Lens/Connecting to a Video Monitor .................................................... 8
● Installing a Lens .................................................................................................. 8
● Connecting to a Video Monitor ............................................................................ 8
●Line-Lock control .................................................................................................... 9
●Adjusting a Lens ................................................................................................... 10
● Adjusting the Back Focus .................................................................................. 10
● Adjusting the Iris ................................................................................................ 10
• Auto Iris Lens ................................................................................................. 10
• Fixed iris lens ................................................................................................. 11
● Back Light Compensation ................................................................................. 11
● Auto White Balance (AWB) ................................................................................ 11
●Setting Up the Network Camera Environment ...................................................... 12
● Requirements for Network Camera Monitoring System .................................... 12
●Connecting the Camera and Personal Computer by Network .............................. 13
• About the IP Address ..................................................................................... 13
● Structure of Connection ..................................................................................... 14
● Connecting ........................................................................................................ 15
●Using the Camera Search Application “Camera Finder” ...................................... 16
●Changing Administrator Login ID and Password .................................................. 18
●Setting up Access Restriction ............................................................................... 20
●Configuring the Network Manually ....................................................................... 22
Viewing ● Listening and Operation
●Viewing and Listening .......................................................................................... 26
● Viewing Images ................................................................................................. 26
• Audio Listening ............................................................................................... 26
• Camera Window Screen ................................................................................ 27
• Menu that is displayed when right-clicking on the image ............................... 27
● Adjusting Images on the Camera ...................................................................... 28
● Adding Images .................................................................................................. 30
●Using Playback Function ...................................................................................... 31
●Playing Alarm Images .......................................................................................... 32
●Playing Recorded Normal Images ........................................................................ 33
●Viewing Logs ........................................................................................................ 34
●Speaking .............................................................................................................. 35
Recording
●About Recording Images ...................................................................................... 38
●Recording Images on an SD Memory Card ......................................................... 39
● Recording Settings ............................................................................................ 39
●Recording Images on FTP Server ........................................................................ 41
● Record Settings ................................................................................................. 41
• Periodic FTP by Schedule .............................................................................. 44
• FTP by External Alarm/Motion Detection ....................................................... 46
IK-WB02-02-06 2004.10.21, 01:492

3
Installation/Set up
Viewing • Listening
and Operation Recording Setting up Others
• FTP by EXT Control (Recording Data by EXT Control) ................................. 48
• Image Accumulation to SD Memory Card ...................................................... 49
● File Transfer Order ............................................................................................. 50
• Periodic FTP by Schedule .............................................................................. 50
●Recording Images on a Personal Computer ........................................................ 51
● Image Recording Feature .................................................................................. 51
● Recording Current Image Data as Still Image ................................................... 53
Setting up
●How to Set up ....................................................................................................... 56
● General Configuration ....................................................................................... 56
●System Settings ................................................................................................... 57
• Restoring the default settings ......................................................................... 58
• Rebooting the network camera ...................................................................... 58
• Updating the Firmware ................................................................................... 59
• Click “Firmware update” ................................................................................. 59
• Importing the Settings Saved on a Personal Computer ................................. 59
●User Settings ........................................................................................................ 60
●Admin Settings ..................................................................................................... 62
●Alarm Settings ...................................................................................................... 64
●Network Settings .................................................................................................. 66
●Mail Settings ......................................................................................................... 68
●FTP Client Settings .............................................................................................. 70
●FTP Server Settings ............................................................................................. 71
●DDNS Settings ..................................................................................................... 72
●Recording Settings ............................................................................................... 73
●Audio Settings ...................................................................................................... 74
●Updating the Firmware ......................................................................................... 75
●Saving the Settings on a Personal Computer ....................................................... 77
● Importing the Settings Saved on a Personal Computer .................................... 78
Others
●Alarm Terminals .................................................................................................... 80
●Index (Glossary) ................................................................................................... 82
●Display of Logs ..................................................................................................... 86
●Before Calling Service Personnel... ...................................................................... 88
●Specifications ....................................................................................................... 95
●Appearance Diagram ............................................................................................ 96
IK-WB02-02-06 2004.10.21, 01:493

4
Installation/Set up Viewing • Listening
and Operation
Recording Setting up Others
Important Safety Instructions
Be sure to read “IMPORTANT SAFEGUARDS” in the
separate “Safety Precautions.”
IK-WB02-02-06 2004.10.21, 01:494
