Toshiba 4200FA XT1 Guide

T42X3F150XAMXN
One-Line Drawing
4200FA XT1UPS, 15kVA Capacity
Single Input Transformer Model,
208/120V Output
UPS Cabinet
AC Output
208/120V
3Ph/4W,
50/60Hz,
15kVA,
0.8 PF
Static Switch Bypass
Battery Cabinet(s) or Rack(s) with DC Breaker
AC Input
208-600V
3Ph/3W
50/60Hz
Maintenance Bypass
Converter
DC Chopper/
Charger
SYNC
Customer
supplied
wiring
Customer Utility Supply
Customer
supplied
wiring
TOSHIBA
INTERNATIONAL CORPORATION
Houston Texas, USA
THIS MATERIAL IS THE EXCLUSIVE PROPERTY OF
TOSHIBA INTERNATIONAL CORPORATION AND SHALL NOT
BE REPRODUCED, USED, OR DISCLOSED TO OTHERS
UNLESS PRIOR WRITTEN AUTHORIZATION IS OBTAINED.
TITLE
DRAWING NO. REV.
NOTES
A B C D E F G H I J
1
2
3
4
5
6
7
8
9
10
1
2
3
4
5
6
7
8
9
10
1.2
Inverter
Isolation
Transformer
D
Y
Make-Before-Break
High
Freq.
Filter
High
Freq.
Filter
3) An output transformer is not equipped in models with 208/120V output.
2) A Maximum of 2 transformers can be equipped within the standard UPS cabinet.
Contactor
MCCB Contactor
1) This drawing is for illustration purposes only and is subject to change without notice. TIC
is not responsible for any errors or omissions.
EO
Drawn by
DATE 03/25/04
JIS
Approved by
DATE 03/25/04
ST
72B
