Tosot GWH09AFCXB-A3DNA2B/I User manual

User Manual
SPLIT AIR CONDITIONER
Before installing and using your TOSOT Air Conditioner,
please read this user manual in its entirety.
MO DEL NUMBERS
Indoor Unit Outdoor Unit
GWH09AFCXB-A3DNA2B/I GWH09QCXB-A3DND4B/O
GWH09AFCXB-D3DNA2B/I GWH09QCXB-A3DND4B/O
GWH12AFCXB-A3DNA2C/I GWH12QCXB-A3DND4C/O
GWH12AFCXB-D3DNA2C/I GWH12QCXB-D3DND4C/O
GWH18AFDXE-D3DNA2B/I GWH18QDXE-D3DNB2A/O

Welcome to the TOSOT Direct Family!
We’re extremely happy to welcome you as a new member of our family! Please
read the tips below before using your product for the first time.
1. The split-type air conditioner is a heavy object, which needs two or more people
to lift and install. Failure to do so could result in injury or other accidents.
2. Allow the unit tosit upright for at least 3-4 hours before powering on. Shipping
carriers may set the unit on its side, which causes the refrigerant to pool in
certain areas. Standing the unit upright for 3-4 hours allows the refrigerant to
move freely within the coils.
3. Some parts with sharp edges may cause injury, so gloves are highly
recommended for unpacking and installing.
4. Run the unit continuously for 24 hours after installation. This allows the unit to
work out any “kinks”that may have resulted during shipping from our factory to
your doorstep.
5. If you have any problems with your product, please send us an email before
submitting a return request, as there might be a simple solution for your issue.
Tips for First-Time Use

Table ofContents
------------------------------------------------
--------------------------------------------------------------
------------------------------------------------------------
------------------------------------------------------------
--------------------------------------
------------------------------------
-------------------------------------------
-------------------------------------------------------
-------------------------------------------------------
---------------------------------------
----------------------------------
----------------------------------------
----------------------------------------
-----------------------------------------------------
--------------------------------------------------
----------------------------------------------------
----------------------------------------------------
--------------------------------------------
Safety Precautions
Warning
Caution
Electrical Safety Warning
Part List
Required Tools
Parts Description
Remote Control
FunctionIcons Description
Combination Buttons
App Control
Care andMaintenance
Precautions
Cleaningthe Indoor Unit
Cleaningthe Reusable Filter
Offseason Maintenance
Preseason Maintenance
Troubleshooting
01
01
02
03
05
06
07
08
09
13
15
----------------------------------------
Replacing the Batteries16
17
17
17
17
19
19
20
------------------------------------------------
--------------------------------------
Malfunction Codes
Quick Guide for Installation
22
23

--------------------------------------
------------------------
-----------------------
--------------------------
---------------------------
------------------------------------------
------------------------------
---------------------------------------
-------------------------------------------
---------------------------------------
-------------
-------------------------------------------
------------------
-----------------------
--------------------------------------------
-----------------------------------------------
------------------------------------------------------
-----------------------------------------
--------------------------------------------
--------------------------------------------------
------------------------------------------
--------------------------------------------------------------
-----------------------------------
Indoor Unit Installation
Select an Installation Site
Attach the Mounting Plate to the Wall
Connect the Wiring of the Indoor Unit
Connecting the Refrigerant Pipings
Drillingthe piping hole on the wall
Mountthe Indoor Unit
Extend the pipe by unwinding it
Outdoor Unit Installation
Select aInstallation Site
Install the DrainJoint
Secure the Outdoor Unit
Connect the Refrigerant Pipe to Outdoor Unit
Note OnPipe Length
Refrigerant Piping Connection Instructions
Connect the Signal and Power Cables
Air Evacuation
Gas LeakChecks
Electrical Safety Checks
Test Run
Warranty & Customer Support
Warranty Information
Customer Support
28
28
29
29
31
34
35
36
37
37
38
38
39
40
40
43
45
46
46
47
48
48
48

SafetyPrecautions
01
Your safety and the safety of others are very important to us. Please read the
following safety precautions before use and installation.A digital version can be
obtained from customer support.
Warning
Failed to do the following instructions might cause the possibility of death or
serious injury.
1. Do notconnect the power before finishing installation.
2. Do notspray or wash the air conditioner with water to avoid electric shock or
malfunction.
3. Do notinsert fingers or objects into the air inlet or air outlet. It may cause
personal injury or damage.
4. Do notblock the air outlet or air inlet. It may cause malfunction.
5. Installation must be performed according to installation instructions and in
accordance with the requirement of NEC and CEC by authorized personnel only.
Improper installation may cause water leakage, electrical shock, fire, or may
void the warranty.
6. Service or maintenance must be performed by authorized and qualified
professionals. Otherwise, it may cause serious damage or personal injury or death.
7. Make sure the power supply is cut off before proceeding with any work related
to electricity or general maintenance.
8. If the refrigerant leaks or requires discharge during installation, maintenance,
or disassembly, it should be handled by certified professionals or otherwise in
compliance with local laws and regulations.
9. The air conditioner must be properly grounded. The grounding resistance should
comply with national electric safety regulations. Incorrect grounding may cause
electric shock.
10. This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities or lack of experience and
knowledge, unless they have been given supervision or instruction concerning
use of the appliance by a person responsible for their safety.

02
Caution
1. Please follow the instructions for installation and use of this product in this user
manual.
2. The indoor unit should be installed close tothe wall.
3. The appliance must be positioned so that the plug is accessible. The plug should
be able to reach a properly-grounded wall outlet after finishing installation.
Extension cords, power strips, or similar devices should not be used with this
product.
4. The yellow-green wire in the air conditioner is grounding wire, which cannot be
used for other purposes.
5. The temperature of the refrigerant circuit will be hot. Please keep wires and
cables away from the copper refrigerant tube.
6. Do not spill water on the remote controller, otherwise the remote controller may
be broken.
7. Do not use a hair dryer to dry the filter after washing to avoid deformation or fire
hazard.
8. Do not step or put heavy objects on the top panel of the outdoor unit. It may
cause damage or personal injury.
9. If any of the below issues occur, please turn off the air conditioner and disconnect
power immediately. Contact the dealer or qualified professionals for service.
a. Power cord is overheating or damaged.
b. There are abnormal sounds during operation.
c. Circuit breakers trips frequently.
d. Air conditioner gives off a burning smell.
e. Indoor unit is leaking.
11. This appliance can be used by children ages 8 and above and persons with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, if they have been given supervision or instruction concerning use
of the appliance in a safe way and understand the hazards involved. Children
shall not play with the appliance. Cleaning and user maintenance shall not be
made by children without supervision.
12. After removing the filter, do not touch the metal fins in order to avoid injury.

03
Electrical Safety Warning
1. Do not share the same electrical socket with other appliances as this may create
afire hazard.
2. Do notcover the power cord with a rug or carpeting.
3. Do notrest hot or heavy objects on the appliance and power cord.
4. Never plug or unplug the appliance with wet hands.
5. Never unplug the appliance by pulling on the power cord.
6. According tothe local safety regulations, use a qualified power supply circuit and
circuit breaker and make sure the power supply matches with the requirement of
the air conditioner. Unstable power supply may result in electric shock, fire hazard
or malfunction.
7. All wires of indoor unit and outdoor unit should be in accordance with national
wiring regulations.
8. If the power cord is damaged, it must be replaced by the manufacturer or an
authorized technical service center.
9. Make sure the power supply is cut off when cleaning the air conditioner.
Otherwise, it may cause electric shock.
(1) this device may not cause harmful interference, and (2) this device must accept
any interference received, including interference that may cause undesired operation.
NOTE: This equipment has been tested and found to comply with the limits for a
Class B digital device, pursuant to part 15 of the FCC Rules. These limits are
designed to provide reasonable protection against harmful interference in a
residential installation. This equipment generates, uses, and can radiate radio
FCC WARNING
WARNING: Changes or modifications to this unit not expressly approved by the
party responsible for compliance could void the user’s authority to operate the
equipment.
FCC STATEMENT
This device complies with Part 15 of the FCC Rules. Operation is subject to the
following two conditions :

04
frequency energy and, if not installed and used in accordance with the instructions,
may cause harmful interference to radio communications. However, there is no
guarantee that interference will not occur in a particular installation. If this equipment
does cause harmful interference to radio or television reception, which can be
determined by turning the equipment off and on, the user is encouraged to try to
correct the interference by one or more of the following measures:
IC STATEMENT
This device complies with Industry Canada licence exempt RSS standard(s).
Operation is subject to the following two conditions: (1) this device may not cause
interference, and (2) this device must accept any interference, including interference
that may cause undesired operation of the device.
Cet appareil est conforme aux limites d’exposition au rayonnement RF stipulées par
la FCC et l’IC pour une utilisation dans un environnement non contrôlé. Les antennes
utilisées pour cet émetteur doivent être installées et doivent fonctionner à au moins
20 cm de distance des utilisateurs et ne doivent pas être placées près d’autres
antennes ou émetteurs ou fonctionner avec ceux-ci. Les installateurs doivent s’assurer
qu’une distance de 20 cm sépare l’appareil (à l’exception du combiné) des utilisateurs.
This equipment complies with FCC’s and IC’s RF radiation exposure limits set forth
for an uncontrolled environment. The antenna(s) used for this transmitter must be
installed and operated to provide a separation distance of at least 20 cm from all
persons and must not be collocated or operating in conjunction with any other
antenna or transmitter. Installers must ensure that a 20cm separation distance will
be maintained between the device (excluding its handset) and users.
Le présent appareil est conforme aux CNR d'Industrie Canada applicables aux
appareils radio exempts de licence. L'exploitation est autorisée aux deux conditions
suivantes : (1) l'appareil ne doit pas produire de brouillage, et (2) l'utilisateur de
l'appareil doit accepter tout brouillage radioélectrique subi, même si le brouillage est
susceptible d'en compromettre le fonctionnement.
●Reorient or relocate the receiving antenna.
●Increase the separation between the equipment and receiver.
●Consult the dealer or an experienced radio/TV technician for help.
● Connect the equipment to an outlet on a circuit different from that to which the
receiver is connected.

05
Parts List
Mounting plate
Drywall anchor
Remote control holder
AAA battery
Air filter
Wall cuff
Drain joint
Mounting plate fixing
screw
PARTLOOKS LIKE QUANTITY
1
1
1
1
1
Fixing screw for remote
controller holder2
2
5
5
Remote control 1
MODE FAN
SWING TURBO
SLEEP TEMP
WiFi
LIGHT
CLOCK
TIMER
ON
TIMER
OFF

06
Required Tools
Pipe bundle (5 meters)
Sealing gum
Tape
Drain hose (2 meters)
PARTLOOKS LIKE QUANTITY
2
1
2
1
Electrical cable
(5 meters)1
Signal cable
(6 meters)1
1. Bubble Level
2. Electric Drill with drill bit for pilot holes
3. Wire stripper/crimp tool
4. Screwdriver
5. Standard wrench
6. Open-end torque wrench
7. Drill with 2.2/2.8 inch hole saw
8. Vacuum pump

07
Parts Description
Indoor Unit
Display
1
2
3
4
5
6
Air Inlet
Front Panel
Reusable Filter
Air Outlet
Horizontal Louver
Aux Button
1 2 3
5
4
6
Indoor Unit
1
1
2
3
Air Inlet
Wire Connection
Air Outlet
Temp Indicator
Power Indicator
Note:This is a universal introduction for a variety of models. Display
content may be different from the actual. Please refer tothe actual unit
2
3

08
Remote Control
Temperature Setting
Sleep Mode
Freeze Guard Function
X-FAN Function
WiFi Function
Light
Set Temp.
Outdoor Ambient
Temp.
Indoor Ambient
Temp.
Clock
Time Setting
Timer On/Off
Up & Down Swing
Turbo Mode
Send Signal
Auto Mode
Cool Mode
Child Lock
Operation Mode
Dry Mode
Fan Mode
Heat Mode
I Feel
Fan Speed Setting
Temp.
Display Type
MODE FAN
SWING TURBO
SLEEP TEMP
WiFi
LIGHT
CLOCK
TIMER
ON
TIMER
OFF
Function icons:
Note:
●This is a universal remote control for a variety of different models. If your model
does not have a function listed on the remote control, when you press the
corresponding button on the remote controller, the unit will keep the original
setting and there will be no changes in the operation of your unit.
●Outdoor Ambient Temp. is not available for this model.

09
Function Icons Description
Press this button toturn on the unit. Press this button again toturn off the unit.
Press this button tocycle through the following modes:
Note:After starting up the heat mode, the indoor unit will delay 1~5 minutes
before it starts blowing air. The actual delay time will depend on the current
indoor temperature.
MODE
●Once the unit is powered on the air conditioner will give out a sound and the
power indicator will light up. After that you can operate the air conditioner
by using remote control.
●When pressing a button on the remote control, the signal iconon the remote
control will blink once and the air conditioner will emit asingle beep sound, which
means the signal has been sent tothe air conditioner. The remote control will
display the active function icons.
●While powered off the set temperature and clock icons will be displayed. If the
timer or light functions are set, the corresponding icons will be also displayed on
the remote control.
AUTO COOL DRY FAN HEAT
Auto mode: The air conditioner will adjust the fan speed automatically to maintain
the set temperature. The set temperature can't be adjusted. Press "FAN" button
can adjust fan speed.
Cool mode: The air conditioner will operate under standard cooling mode. The set
temperature and fan speed can be adjusted.
Dry mode: The air conditioner will run on low speed for dehumidification. The fan
speed cannot be adjusted.
Fan mode:The air conditioner will not produce cool or warm air, only blow air from
the current room temperature. The fan speed can be adjusted.
Heat mode: The air conditioner operates under heat mode instead of cooling. The
set temperature and fan speed can be adjusted.

10
Press this button tocycle through the Auto fan mode and 3 fan speeds (Low,
Medium, High)
FAN
SWING
TURBO
Auto
Note:
●Under AUTO fan mode, the air conditioner will select the proper fan speed
automatically.
●X-FAN Function：Hold the fan speed button for 2 seconds in COOL or DRY
mode. The icon will be displayed. Under this mode the indoor fan will
continue operating for a few minutes after powering off in order to dry the
indoor unit. X-FAN is not available in AUTO, FAN or HEAT modes. This
function will help to dry the moisture on the evaporator to prevent mold.
To shut the X-FAN off after powering the unit off, hold the fan speed button
for 2 seconds.
Press this button tocycle through the following air flow directions:
no display
(horizontal louvers
stops at current position)
When selecting , the horizontal louvers will automatically swing up & down
across the maximum range. .
When selecting " ", the unit will blow air at afixed position.
The horizontal louvers will not move.
When selecting " ", the unit will blow air across a set range.
The louvers will automatically swing up & down across this range.
To manually set afixed air direction, press and hold the " button for 2 seconds
until it reaches your desired angle, then release the button. The louvers will not
move from this position.
Under cool or heat modes, press this button to enter quick cool or quick heat
mode. The icon will display on the remote control. Press the button again
to exit the turbo function and the icon will disappear.

11
SLEEP
●Pressing the ▲ or ▼ button will increase/decrease the set temperature by
1°F. Holding the button for 2 seconds will cause the temperature to change
rapidly. Release the button once your desired temperature is reached.
●After pressing the Timer or Clock button, press the ▲ or ▼ button to adjust
the time.
●Under cool or heat mode,press this button to enter the sleep operation
mode. The icon will display on remote control. Press the button again to
exit sleep mode. Sleep mode is only available in cooling or heating modes,
as explained in detail below.
●During sleep, the set temperature of the air conditioner may no longer be
suitable tothe human body’s optimal sleeping needs. By activating the
sleep function with the remote control, the air conditioner will automatically
adjust the set temperature to meet the optimal sleeping needs of the human
body.
Sleep Mode Under Cooling Mode
1. If the temp is set to 61-74°F (16-23°C), the temp will increase 2°F per hour
for 3 hours. Four (4) hours later the temp will decrease by 2°F and remain
at this temp.
2. If the temp is set to 75-81°F (24-27°C), the temp will increase 2°F per hour
for 2 hours. Five (5) hours later the temp will decrease by 2°F and remain
at this temp.
3. If the temp is set to 82-84°F (28-29°C), the temp will increase 2°F per hour
for 1 hour. Six (6) hours later the temp will decrease by 2°F and remain at
this temp.
4. If the temp is set to 85°F (30°C), the temp will not increase. Seven (7) hours
later the temp will decrease by 2°F and remain at this temp.
Sleep Mode Under Heating Mode
1. If the temp is set to 61°F (16°C), it will run at this temp with no change.
2. If the temp is set to 62-68°F (17-20°C), the temp will decrease 2°F per hour
for 1 hour and remain at this temp.
3. If the temp is set to 69-81°F (21-27°C), the temp will decrease 2°F per hour
for 2 hours and remain at this temp.
4. If the temp is set to 82-86°F (28-30°C), the temp will decrease 2°F per hour
for 3 hours and remain at this temp.

12
TEMP
LIGHT
CLOCK
TIMER
ON
TIMER
OFF
Press this button, you can see indoor set temperature, indoor ambient
temperature or outdoor ambient temperature on the indoor unit's display.
The setting on remote control will cycle through as below:
no display
When selecting " " or no display with the remote control, the temperature
indicator on the indoor unit displays the set temperature.
When selecting " " with the remote control, the temperature indicator on
the indoor unit displays the indoor ambient temperature.
When selecting " " with the remote control, the temperature indicator on
the indoor unit displays the outdoor ambient temperature. ●Not available for
this model.
Note:(This function might vary across different models)
When selecting the display of indoor or outdoor ambient temperature,
the temperature indicator displays the corresponding temperature then
automatically turns to display the set temperature after a few seconds.
Press this button toturn off the display light on the indoor unit. The icon
on the remote control will disappear. Press the button again toturn on the
display light.
Press this button toset the clock time. The icon on the remote control will
blink. Press the "▲" or "▼" button within 5 seconds to set clock time. Each
press of the "▲" or "▼" button will increase or decrease 1 minute. Holding
the "▲" or "▼" button will change time rapidly. Release this button after
reaching your required time. Press the "CLOCK" button again to confirm the
time and the icon will stop blinking.
TIMER ON/OFF:
When the unit is not running, press this button to schedule when the unit
will power on by using the "▲" or "▼" button to adjust the length of time
before powering on.When the unit is running, press this button to schedule
when the unit will power off. The timer setting will increase or decrease by

13
1 minute with each press of the "▲" or "▼" button. Holding the "▲" or "▼"
button for 2 seconds will change the time rapidly. Release the button once
it reaches your set time. . Press the button again to confirm the timer and
the "ON"/"OFF" indicator on the remote control will stop blinking.
Note: " " button takes no effect on the timer setting. If you don’ t
need the timer, press the TIMER ON/OFF button tocancel and the
timer indicator light will shut off.
Combination Buttons
●Energy-Saving Mode
Under cool mode, press and hold the TEMP and CLOCK buttons simultaneously
to activate or turn off the energy-saving function. When the energy-saving function
is activated, "SE" will be displayed on the remote control and the air conditioner
will adjust the set temperature automatically tosave on energy costs.
Under Energy-saving Mode the fan speed and temperature settings can’t be
adjusted and the TURBO mode is not available. Sleep mode and Energy-Saving
Mode can’t operate at the same time.
●Freeze Guard Heating Function
Under heat mode, press and hold the TEMP and CLOCK buttons simultaneously
to activate or turn off the freeze guard function. When this function is activated,
and "46°F/8°C" will be shown on remote control, and the air conditioner keeps
the room temperature above 46°F/8°C.
WiFi:
Press this button to turn on the WiFi function. An icon will be shown on the
remote control. Press the button again to turn off this function.
WiFi
With the remote powered off, press the MODE and WiFi buttons
simultaneously to reset WiFi to factory settings.

Under the Freeze Guard Heating Function, fan speed and temperature settings
can’t be adjusted and the "TURBO" mode is not available. The sleep mode and
the Freeze Guard Heating Function can’t operate at the same time.
This function is typically used when away for vacation or holiday and is intended
to save energy and protect pipes or plants from freezing when the building is
unoccupied.
14
●Child lock
Press ▲ and ▼ simultaneously toturn the child lock function on or off. While in
this mode the remote control will display a LOCK symbol and will not send any
signal tothe air conditioner.
●Change Between °F and °C
With the unit powered off, press the MODE and ▼ buttons simultaneously to switch
between Fahrenheit and Celsius displays.
●I FEEL
Press the ▲ and MODE buttons simultaneously to activate I FEEL mode. The
icon will be displayed on the remote control. Inthis mode your unit will use a
sensor located in the remote control to determine the temperature setting of your
air conditioner.
Please put the remote control near the user when using this function. Do not put
the remote control near any place with too high or too low temperature in order to
avoid inaccurate temperature readings. When I FEEL is turned on, the remote
control should be put within 20 ft of the indoor unit so the unit can receive the
signal from the remote control.

15
App Control
2. Open the "GREE+" App after installation. You can create a new account or log in
with an existing account.
Supported Equipment
Installation and Setup
iOS 7.0 & above version
Android 4.4 & above version
must work with operating
frequency: 2.4GHz
Smart Phone System Wireless Routers
1. Scan the QR code or search for "GREE+" in the App Store or Google Play Store.
3. Add a device by tapping the “+” button as shown in the picture. The app will
automatically start searching for devices. Press the “WiFi” button on the remote
control to turn on the WiFi function.
*Please make sure the "wifi" indicator is light on in the remote control.

Replacing the Batteries
●Press the back side of the remote control battery cover and slide out following
the engraved arrow.
●Replace with two new AAA(1.5V) batteries of the same make and model. Make
sure the polarities (+ & -) are aligned correctly.
●Reinstall the battery cover box.
Signal SenderBattery
Reinstall
Remove
Cover of Battery Box
16
4. Tap the available device icon and select your Wi-Fi network. Enter your WiFi
password, then tap the “Next” button.
5. Once the device is added successfully, you will return back to the “My home”
page. Select your appliance to start app control.
If you have problems,
please refer to "Help" in the app or contact our support team.
AC
